O9DALActilink USB Bridge

© FitSense Technology 2006/2007 The ActiLink Personal TM Step 1 : Logon to www.actihealth.com. Step 2 : Download the ActiLink Software: Go to the tab marked downloads and click Download ActiLink Software. This will automatically begin the download process. At the end of the process you will have the icon in your system tray. Step 3 : Plug the ActiLink TM into an available USB port. ActiLink Software The installation of the ActiLink software will put an ActiHealth icon in your notification bar (system tray). This is typically located on the bottom right hand corner of your Windows Task Bar. See picture below: With this icon you can click on and it will open your web browser and automatically take you to www.actihealth.com. (If you have previously logged in an used the remember me check box, this will take you right to your dashboard!) You can also right click on to get to a list of maintenance options. When the icon is yellow, this indicates there is no Internet connection. When the icon is white with red, this indicates there is no ActiLink TM plugged in to your USB. Disclaimer The ActiLink TM is not a medical device. This device is provided for feedback on exercise and routine activity only. FitSense recommends that you consult a physician before beginning any exercise program or performing strenuous activity. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. Regulatory Information FCC ID: O9DAP This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Patents The ActiLink TM is covered in whole or in part by patents pending. Specs USB 1.0/2.0 Battery: N/A Dimensions: .2.35 x .675” or .3” Weight: 8 grams Water Resistant: N/A Operating Temperature:14F to 104F Storage Temperature: -4 to 122F Transmission Distance: Up to 30 ft Radio Frequency: 2.428Ghz Compliance: FCC Limited Warranty The ActiLink TM is warranted against defects in material and workmanship for one year after purchase. Defective products will be repaired or replaced. The warranty does not cover normal wear, damage, loss or commercial use. The warranty is void if the unit is disassembled by anyone other than a FitSense Authorized Technician. For any warranty claims please contact your plan administrator. THE FORGOING IS YOUR SOLE REMEDY UNDER THIS LIMITED WARRANTY. IN NO EVENT WILL FITSENSE TECHNOLOGY INC. BE LIABLE FOR ANY INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF ABILITY TO USE THE PRODUCT EVEN IF FITSENSE HAS BEEN ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. This warranty gives you specific legal rights and you man also have other rights which vary from state to state.

REV CHANGED BY DATE DESCRIPTION - 12/15/2005 m T B S H E E T μ J C D ±0.1 m m 2 P LACE D ECIMAL ± 1 .0 DI MENSIONSI N[ ]AREINC HE S a s sp e cifica ll y a u t horizedb yFitSense , I nc. 214-00013-01 DATE SCAL E: 1 Ne it h e rthisd o cume n t no r t h ei nfo r ma t i o n 1 ADHESIVE-BACKED WHITE POLYESTER LABEL t h er e in is tob e r e p r oduce d , d ist r ib u t e d , use d O F 1 : 1 D S N ' D P A PERS I ZE DR A WIN G N U MBE R M A T ' L DR A W N C H K ' D REV o r di s clo se d e it h e rin wh o le o ri np a r t , e xce p t ACTILINK LABEL E X CE P T A S NOT E D, A LLDI MSAREMM p r o p ri e t a r y i nfo r ma t i on o f FitS e nse , I n c. F ax:508.357.7 9 90 JCD D R A W N DSN'D A DATE C HK 'D SURFACEFINI S H : 3 . 2 A SMEY14.5M- 19 94AP P LI E S 0PLACEDECIM A L ANGU L ARTOL'S 1PL A CED EC IM A L ±0. 25 m m ±1.0 m m Thisd o cument co nta in s co nfiden t ia l or 2 1B o stonR o ad POB o x 7 30 S outhboro u g h , MA 01 7 72 Phon e :50 8 .3 0 3 . 8811 07 5 MIL TOTAL THICKNESS 02 JCD 12/20/2005 ADDED S/N 03 JCD 1/19/2006 LONGER LABEL FOR LENGTHENED CASE 04 JCD 1/31/2006 ADDED P/N. CHANGED S/N SCHEME. REARRANGED. 05 JCD 3/13/2006 REMOVED BOX AROUND S/N 06 JCD 5/24/2006 REPLACED “ACTIHEALTH.COM” WITH “FITSENSE” AND AH ACTIVATED LOGO. 07 JCD 9/3/2006 CHANGED FROM B-SIZED TO A-SIZED DRAWING. ALL PRINTING: BLACK SERIALIZATION OF LABELS IS REQUIRED: A TEXT FILE WILL BE PROVIDED WITH BATCH OF 14-DIGIT NUMBERS TO BE PRINTED.

Certification and Signatures We certify that this report is a true report of the results obtained from the tests of the equipment stated and relates only to the equipment tested. We further certify that the measurements shown in this report were made in accordance with the procedures indicated and vouch for the qualifications of all Retlif Testing Laboratories personnel taking them. Scott Wentworth Branch Manager NVLAP Approved Signatory Todd Hannemann Laboratory Supervisor Non-Warranty Provision The testing services have been performed, findings obtained, and reports prepared in accordance with generally accepted testing laboratory principles and practices. This warranty is in lieu of all other warranties, either express or implied. Non-Endorsement This test report contains only findings and results arrived at after employing the specific test procedures and standards listed herein. It is not intended to constitute a recommendation, endorsement, or certification of the product or material tested. This report must not be used by the client to claim product endorsement by NVLAP, NIST or any agency of the U.S. Government. Test Report No. R-4927N-1 FCC ID:09DAL Test Report No. R-4927N-1 FCC ID:09DAL APPLICANT FITSENSE TECHNOLOGY 21 Boston Road Southborough, MA 01772 MANUFACTURER SAME TEST SPECIFICATION: FCC Rules and Regulations Part 15, Subpart C, Para. 15.249 TEST PROCEDURE: ANSI C63.4:2003 TEST SAMPLE DESCRIPTION BRANDNAME: Fitsense MODEL: ActiLink TYPE: Personal USB 2.4GHz Wireless Transceiver POWER REQUIREMENTS: 5vdc via host PC USB Port FREQUENCY BAND OF OPERATION: 2400 to 2483.5MHz FREQUENCY OF OPERATION : 2429.0MHz FCC ID: 09DAL APPLICABLE RULE SECTION: Part 15, Subpart C, Section 15.249 TESTS PERFORMED 15.249 (a) Fundamental & Harmonic Emissions 15.249 (d) Out of Band/Bandedge Emissions 15.249 (e) Peak Field Strength 15.207 Conducted Emissions Test Report No. R-4927N-1 FCC ID:09DAL MEASUREMENT PROCEDURES 15.249 (a/d) Field Strength of Fundamental, Harmonic and Out of Band/Band Edge Emissions The field strength of the fundamental, harmonic and out of band/bandedge emissions were measured. The EUT was plugged into the USB port of the host PC which was placed on a 80cm high wooden test stand located 3 meters from the test antenna on an FCC listed open area test site. Emissions from the EUT were maximized by rotating the turntable and adjusting the antenna polarization. The maximized field strength of each observed emission was measured, recorded and compared to the specified limits of 15.249 (a), (d)/15.209 as appropriate. Peak field strength of emissions were measured, recorded and verified to meet the specified limit (limit corresponds to 20dB above the maximum permitted average limit). When necessary the marker/delta method was used to verify bandedge compliance. 15.207 (a) AC Line Conducted Emissions The test sample was plugged into the USB port of the Host PC which was placed on a 0.8m high wooden test stand above the floor of the test area (ground plane). The rear of the EUT was aligned flush with the rear of the test stand. The test stand was situated such that the EUT was located 0.4m from all other grounded surfaces. The power cord of the host PC was connected to an artificial mains network (LISN). The spectrum analyzer was connected to the RF port of the LISN and peak/quasipeak and average measurements were taken in the frequency range of 150kHz to 30MHz on each the hot and neutral leads. Test Results: The measured AC line conducted emissions met the limit specified in 15.207 (a). Test Report No. R-4927N-1 FCC ID:09DAL RADIATED EMISSIONS EQUIPMENT LIST ENTypeManufacturerDescriptionModel No.Cal DateDue 3116Pre-AmplifierMiteq0.1 GHz - 18 GHzAFS42-358/27/20078/27/2008 3117Power SupplyB&K Precision0-30 Vdc, 3.0 A16301/23/20071/23/2008 3430Horn AntennaMCS Corporation18 GHz - 26.5 GHzK-50391/23/20071/23/2008 4029BTest Site AttenuationRetlif3 / 10 MetersRNH6/20/20076/20/2008 4984AHigh Gain HornMicrolab/FXR1.0 - 1.7 GHzL638A1/24/20071/24/2008 4984BHigh Gain HornMicrolab/FXR1.7 - 2.6 GHzR638A1/24/20071/24/2008 4984CHigh Gain HornMicrolab/FXR2.6 - 3.95 GHzS638A1/24/20071/24/2008 4984DHigh Gain HornMicrolab/FXR3.95 - 5.85 GHzH638A1/24/20071/24/2008 4984EHigh Gain HornMicrolab/FXR5.8 - 8.2 GHzC638A1/24/20071/24/2008 4984FHigh Gain HornMicrolab/FXR8.2 - 12.4 GHzX638A1/24/20071/24/2008 4984GHigh Gain HornMicrolab/FXR12.4 GHz - 18 GHzY638A1/24/20071/24/2008 5053BiconilogEMCO26 MHz - 3 GHz3142C10/4/200710/4/2008 5072PreamplifierMiteq18 GHz-40 GHzJS4-18004000-301/10/20071/10/2008 R425Spectrum AnalyzerAgilent100 Hz - 26.5GHzE7405A;A11/3/200612/11/2007 ENType CONDUCTED EMISSIONS EQUIPMENT LIST ManufacturerDescriptionModel No.Cal DateDue 4039LISNFiltronN/AFSR-707A8/28/20078/28/2008 503010 DB Atten. (50 ohm)NardaDC - 12.4 GHz757C-105/9/20075/9/2008 7032LISNRohde & SchwarzN/AESH 3-Z510/19/200710/19/2008 R425Spectrum AnalyzerAgilent100 Hz - 26.5GHzE7405A;A11/3/200612/11/2007 Test Report No. R-4927N-1 FCC ID:09DAL RADIATED EMISSIONS SETUP PHOTOGRAPHS Test Report No. R-4927N-1 FCC ID:09DAL CONDUCTED EMISSIONS SETUP PHOTO Job No: Serial No: Date: TransmitTestAntennaMeterCorrectionDuty CycleCorrected Converted FrequencyFrequencyPositionReadingFactorCorrectionReadingReading MHzMHz Polarization dBuVdBdBdBuV/muV/m 2429.002429.00H74.08-14.500.0059.58952.80 4858.00H53.38-10.440.0042.94140.28 7287.00V39.30-9.40-29.9031.26 9716.00------ 12145.00------ 14574.00------ 17003.00------ 19432.00------ 21861.00------ 24290.00------ The ActiLink Personal USB TransceiverTest Sample: TABULAR DATA SHEET Test Method: Customer: Fundamental Field Strength & Harmonics Fitsense TechnologyR-4927N-1 Limit Operating Mode: Technician: ActiLinkHHFP-00256-06143Model No: FCC Part 15 Paragraph: 15.249 (a) Notes: Continuously Transmitting M.Seamans11/26/2007 Average Readings to Average Limits Test Specification: Data Sheet 1 of 1 At the harmonic frequencies where no meter reading is recorded, there was no harmonic observed above the…

Text truncated - open the document above for the full version.

Test Report No. R-4927N-1 FCC ID:09DAL RADIATED EMISSIONS SETUP PHOTOGRAPHS Test Report No. R-4927N-1 FCC ID:09DAL CONDUCTED EMISSIONS SETUP PHOTO
