B/T GPS RECEIVER (BGP-2000) OPERATING GUIDE J Communications Co., Ltd. Acknowledging Special Precautions and the FCC Industry Canada Notice Cautions Modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance Information This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received. Including interference that may cause undesired operation. Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio Frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Getting Started 1. Introduction This GPS Receiver is the mobile GPS receiver integrated with Bluetooth technology. The BGP-2000 offers flexible and various location awareness application for both consumer and corporate usages. 2. General Features Your BGP-2000 is an excellent navigation and positioning aid tool when using with mobile terminal devices of Bluetooth enabled, which the host with GPS application software installed. The general features are z Best mobile GPS receiver for consumer and corporate z GPS receiver with Bluetooth transceiver built-in z Provides fully interoperability with Bluetooth integrated mobile devices z Ultra-low power consumption z Long operation time ( 8 hours) z LED lights indicate GPS status, Bluetooth connection and battery condition z Embedded high sensitivity GPS active antenna and Bluetooth antenna z Compatible with all GPS map running on various hardware platforms z Navigating freely without wire connection to host mobile devices. 3. Prepare to use you BGP-2000 Receiver To help you begin to use your BGP-2000 receiver, read this user guide in the first step. This user guide explains the detail how BGP-2000 operates, functions, and common features of the BGP-2000. Before you begin using your BGP-2000, you must complete the application software installation tasks on your host device like PDA mobile phone, MMS mobile phone, handheld PC, and portable PC hardware. For information about the hardware operation and application software installation, please refer to the documentation that accompanies each product. 4. GPS signal reception The BGP-2000 offers high position accuracy and fast Time-To-First-Fix (TTFF), which rely on environment circumstances where receiver located as well as initial states of the receiver. During attempting to a position fix, the receiver needs to lock on to at least 3 satellites and, uses the signal can be received as well as the data of latest position stored in the receiver’s digital memory in order to compute the location of the device. Environmental factors that influence the position accuracy and TTFF including such as Tall buildings, Narrow street and passageway, Protection film on glass, Heavy foliage, Large cliffs, and other obstructions where the satellite signals may blocked, and, poor satellites geometry situation. Initial state of the receiver, means latest status in memory of the receiver, may mainly determine the time of TTFF. Position can be quickly fixed within only 10 seconds from a hot-start state and needs 45 seconds typically from a cold- start state. Or, might need at least 3 to 5 minutes from a completely restart-state, for example, flying a distance over 500 kilometers from initial origin. BGP-2000 uses the satellite signals to calculate an exact geodetic location through triangulation method, contained in 10 meters CEP accurateness devoid of Selective Availability (SA), which is good enough for general location awareness purposes. The position data is then converted within the receiver to latitude and longitude coordinates, which is usually provided in the geodetic datum on which GPS is based (WGS84). Position offsets of hundreds of meters or much more can result from using the wrong datum. In addition to datum used, there are number of positioning errors can occur, limiting accuracy. The major errors including satellites orbiting error, poor satellites geometry, multi-path signals, atmospheric delay and receiver clock timing. 5. Caution and Warning BGP-2000 contains a rechargeable Ni-MH battery which supplies the power for the of GPS and Bluetooth operation. Care and caution must take into account are : z Only use the charger supplies with the BGP-2000. Use other charger can damage the BGP-2000 and even dangerous at the risk of explosion. z Do not expose BGP-2000 to high temperatures higher than 85C such in car under direct sunshine. Expose BGP-2000 to high temperatures environment can not only shorten the life of electronic devices and melt or drape certain plastics, but also can damage the battery and even dangerous at the risk of explosion. z Do not try to open or break the receiver. There is no service accessory part inside the receiver. Open the receiver will void the warranty. Designation 1. Power Switch 2. LED Indicators - Battery Status LED (Blue) - GPS status …
Text truncated - open the document above for the full version.
124-4, Ojeon-Dong, Ulwang-City, Kyungki-Do, KOREA 437- 070 Nov 12, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : J Communications Co., Ltd. FCC ID : OAJBGP2000 15.19 statement request Gentlemen: Because The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual. Sincerely,
124-4, Ojeon-Dong, Ulwang-City, Kyungki-Do, KOREA 437-070 Nov 12, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: OAJBGP2000. including signing of all documents relating to these matters. Any and all acts carried out by DIGITAL EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from J Communications Co., Ltd. Sincerely,
124-4, Ojeon-Dong, Ulwang-City, Kyungki-Do, KOREA 437-070 Nov 12, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : J Communications Co., Ltd. FCC ID : OAJBGP2000 Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, J Communications Co., Ltd. hereby requests confidentiality of the Block diagram, Schematics, Parts list, and Operational description of the attached test report. These documents contain detailed system and equipment description and related information about the product which J Communications Co., Ltd. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, J Communications Co., Ltd. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely,
FCC ID: OAJBGP2000 Copyright □ 2004, DIGITAL EMC Co., Ltd. View 1 FCC ID: OAJBGP2000 Copyright □ 2004, DIGITAL EMC Co., Ltd. View 2 FCC ID: OAJBGP2000 Copyright □ 2004, DIGITAL EMC Co., Ltd. View 3
FCC ID: OAJBGP2000 Copyright Ⓒ 2004, DIGITAL EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase (SEE NEXT PAGE) FCC ID: OAJBGP2000 Copyright Ⓒ 2004, DIGITAL EMC Co., Ltd. Label Description
FCC ID: OAJBGP2000 Copyright Ⓒ 2004, DIGITAL EMC Co., Ltd. View 1 FCC ID: OAJBGP2000 Copyright Ⓒ 2004, DIGITAL EMC Co., Ltd. View 2 FCC ID: OAJBGP2000 Copyright Ⓒ 2004, DIGITAL EMC Co., Ltd. View 3
Bluetooth™ Module Application Note ABM-200 Class2 Bluetooth Module Production Information Data Sheet ID : ABM-200-2XXX Dec.2002 Module Features -Bluetooth™ V1.1 Compliant -Transmit Power +4dBm(Class2) -2.7V to 3.6V Operation -Full Bluetooth data rate over UART and USB -Four low power modes : Park, Sniff, Hold and Deep Sleep -Support for up to seven slaves General Description ABM-200-2XXX is a Class 2 surface mountable Bluetooth™ Module for Mobile Phone, PDA, Notebook PC, Desktop PC, applications. It provides fully compliant Bluetooth system for data and voice communications. Physical interface to host (UART, USB) can support full Bluetooth data rate 723.2k/57.6kbps. A-Law, u-Law,13bit or 16bit linear PCM, 8k sample/sec synchronous bidirectional audio interface is also available. BlueCore2-EXT SPI UART USB PCM PIO 4M or 8M Flash Memory Regulator X-Tal 16MHz I N T E R F A C E TX_RX (A) TX_RX (B) BPF Balun VDD VDD-1.8V Loop Filter ANTENNA Application Laptop and Desktop PCs Mobile Phones Cordless Headsets Personal Digital Assistants (PDAs) Digital Camera & Printer Domestic and Industrial Applications Specification -Operating Conditions Support Voltage................. 2.7V ~3.6V Temperature Range............ -20~+70°C -Power Consumption ACL Data (UART/115.2kbps) ....... 18mA Voice Only (HV3 Packet) ............ 28mA -Radio Characteristics Receiver Sensitivity ... -84dBm Transmitter Power ..... +2.0dBm(Typical) Features -Size(18.0 X 14.0 X 2.0mm) -Class2 Support(+4dBm) -Surface Mountable -Single 3.3V Power Supply -Support PCM interface for SCO Copyright © 2002, AirLogic Co., Ltd. All specification are preliminary and AirLogic reserves the right to change these without notice. http://www.airlogic.co.kr Bluetooth™ Module Application Note Electrical Characteristics Absolute Maximum Ratings Parameter Min Max Unit Storage Temperature -40 +85 °C Supply Voltage 2.7 3.6 DCV Other Pin Voltage V ss -0.4 V DD +0.4 DCV Recommended Operating Conditions Parameter Min Max Unit Temperature -20 +70 °C Supply Voltage for UART 3.0 3.6 DCV Supply Voltage USB 3.1 3.6 DCV Power Consumption Mode AveragePeak Unit SCO connection HV3(1s interval sniff mode)(Slave) 28 mA SCO connection HV3(1s interval sniff mode)(Master) 28 mA SCO connection HV1(Slave) 62 mA SCO connection HV1(Master) 62 mA ACL Data transfer, 115.2kbps UART (Master) 18 mA ACL Data transfer, 720kbps USB (Slave) 62 mA ACL Data transfer, 720kbps USB (Master) 62 mA Deep Sleep Mode, Initial 1.5 mA ACL connection, Sniff Mode 40ms interval, 57.6kbps UART 4 mA ACL connection, Sniff Mode 1.28s interval, 38.4kbps UART 0.8 mA Park Mode 0.6 mA RF Specification Transmitter Performance Parameter Condition Min Typ Max Unit Output Power Normal/extreme test -6 2 4 dBm Power Density Normal/extreme test - - 20 dBm Power Control Normal/extreme test 2dB ≤ Step size ≤ 8dB Frequency Range Normal/extreme test 2402 - 2480 MHz 20dB Bandwidth Normal/extreme test - 850 1000 KHz ±2MHz - - -20 dBm ±3MHz - - -40 dBm Adjacent channel power ±4MHz - - -40 dBm ∆F1avg 140 - 175 KHz ∆F2max 115 - - KHz Modulation Characteristics ∆F2avg / ∆F1avg - - 80 % Initial Carrier Frequency Tolerance -75 - 75 KHz One slot packet(DH1) -25 - 25 KHz Three slot packet(DH3)-40 - 40 KHz Carrier Frequency Drift five slot packet(DH5) -40 - 40 KHz Transceiver Performance Parameter Condition MinTyp Max Unit 30MHz-1GHz - - -36 dBm 1GHz-12.75GHz - - -30 dBm 1.8GHz-5.3GHz - - -47 dBm Out-of-Band Spurious Emissions 5.1GHz-5.3GHz - - -47 dBm Copyright © 2002, AirLogic Co., Ltd. All specification are preliminary and AirLogic reserves the right to change these without notice. http://www.airlogic.co.kr Bluetooth™ Module Application Note Receiver Performance Parameter Condition Min Typ Max Unit Sensitivity level Single slot packets -70 -80 - dBm Sensitivity level Multi slot packets -70 - - dBm C/I co-channel - 9 11 dB C/I1MHz (Adjacent channel selectivity) - -2 0 dB C/I2MHz (2nd Adjacent channel selectivity) - -34 -30 dB C/I performance C/I ≥3MHz (3rd Adjacent channel selectivity) - -43 -40 dB 30MHz-2000MHz -10 - - dBm 2000MHz-2400MHz -27 - - dBm 2500MHz-3000MHz -27 - - dBm Blocking performance 3000MHz-12.75MHz -10 - - dBm Intermodulation Performance n=5 -39 - - dBm Maximun Input Level -20 -5 - dBm Pin Description Pin No. Pin Name Description 1 PIO(6) Programmable I/O terminal or CLK_REQ 2 PIO(1) TX Enable 3 PIO(0) RX Enable 4 AIO(0) Programmable I/O terminal 5 PIO(7) Programmable I/O terminal 6 AIO(1) Programmable I/O terminal 7 RESET_IN Module Reset INPUT 8 GND Common Ground 9 UART_RX UART Data in 10 UART_TX UART Data out 11 UART_RTS UART ready to send 12 UART_CTS UART clear to send 13 SPI_CLK Serial Peripheral Interface clock 14 SPI_MISO Serial Peripheral Interface data output 15 VCC +3.3V Power Supply 16 PCM_SYNC Synchronous data strobe 17 PCM_IN Synchronous 8Kss -1 data input 18 PCM_OUT Synchronous 8Kss -1 data output 19 PCM_CLK Synchronous data clock 20 USB DP USB Data plus 21 USB DN USB Data minus 22 SPI_MOSI Serial Peripheral Interface data input 23 GND Common Ground 24 SPI_CSB Chip select for Synchronous Serial Interface active low 25 PIO(5) Programmable I/O terminal or USB_DETACH 26 PIO(2) Programmable I/O terminal or USB_PULL_UP 27 PIO(3) Programmable I/O terminal or USB_WAKE_UP 28 PIO(4) Programmable I/O terminal or USB_ON 29 GND Common Ground 30 RF-IN_OUT Connect to Antenna Copyright © 2002, AirLogic Co., Ltd. All specification are preliminary and AirLogic reserves the right to change these without notice. http://www.airlogic.co.kr Bluetooth™ Module Application Note Copyright © 2002, AirLogic Co., Ltd. All specification are preliminary and AirLogic reserves the right to change these without notice. http://www.airlogic.co.kr Ordering information Dimensions Unit : mm 2 Class2 Flash Memory Size 4 4 Mbit 8 8 Mbit Interface UA UART US USB BC BCSP ABM2002XXX Top View 1 30 15 16 ......................... ......................... 14.0 2.0 0.6 18.0 0.4 0.4 1.0 1.0 0.7 0.8 2.0 2.0 1.3 . . . . . . . . . . . . . . . .…
Text truncated - open the document above for the full version.
BT GPS SERIES (4-06-01-20) MODEL CODE 4060102 SCHEMATIC BGP-2000.SCH(Rev:1.0) CORRECT DATE 2004-10-11 승인원 NAME & DESCRIPTION VENDOR CODE TYPE 01 BGP-2000(BLUETOOTH GPS ) 10 BATTERY CONNECTOR 2P 0 S 1 J4 2052-0002-1 RES. CHIP 0 Ω ±5% 1/16W 0603 RC21 1/16 000 JT S 1 R47 3052-1022-1 RES. CHIP 1 KΩ ±5% 1/16W 0603 RC21 1/16 102 JT S 5 R14 , 16 , 28 , 31 , 39 4052-1032-1 RES. CHIP 10 KΩ ±5% 1/16W 0603 RC21 1/16 103 JT S 5 R6 , 11 , 15 , 37 , 46 5052-1042-1 RES. CHIP 100 KΩ ±5% 1/16W 0603 RC21 1/16 104 JT S 2 R12 , 25 6052-1822-1 RES. CHIP 1.8 KΩ ±5% 1/16W 0603 RC21 1/16 182 JT S 1 R43 7052-2202-1 RES. CHIP 22 Ω ±5% 1/16W 0603 RC21 1/16 220 JT S 1 R32 8052-2212-1 RES. CHIP 220 Ω ±5% 1/16W 0603 CR 1/16 221 JT S 5 R19 , 21 , 23 , 29 , 42 9052-2222-1 RES. CHIP 2.2 KΩ ±5% 1/16W 0603 RC21 1/16 222 JT S 1 R7 10052-2232-1 RES. CHIP 22 KΩ ±5% 1/16W 0603 RC21 1/16 223 JT S 1 R38 11052-2422-1 RES. CHIP 2.4 KΩ ±5% 1/16W 0603 RC21 1/16 242 JT S 1 R44 12052-2722-1 RES. CHIP 2.7 KΩ ±5% 1/16W 0603 RC21 1/16 272 JT S 1 R8 13052-3312-1 RES. CHIP 330 Ω ±5% 1/16W 0603 CR 1/16 331 JT S 1 R18 14052-4712-1 RES. CHIP 470 Ω ±5% 1/16W 0603 RC21 1/16 471 JT S 2 R24 , 27 15052-4722-1 RES. CHIP 4.7 KΩ ±5% 1/16W 0603 RC21 1/16 472 JT S 2 R33 , 35 16052-4732-1 RES. CHIP 47 KΩ ±5% 1/16W 0603 RC21 1/16 473 JT S 3 R17 , 34 , 36 17118-0202-1 CAP. TANTAL 2.2uF/6.3V +-10% SIZE:A TCSS0J225KAAR S 1 C35 18118-1003-1 CAP.TANTAL CHIP 10uF/10V SIZE:A TA-010TCMS100 M-AL S 2 C33 , 36 19118-2201-1 CAP.TANTAL CHIP 22uF/4V +-20% SIZE:A TA-004TCM220M -AL S 2 C26 , 32 20151-1012-1 CAP.CERAMIC CHIP 100 pF ±5% 0402 0402 CG 101J 9BB-- S 57 C1,2,3,4,5,6,7,8,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,27,28,29,34,37,42,43,44,45,46,49,51,52,53,54,55,56,57,58,59,61,62,63,64,65,66,67,68,69,71,72,73,74,75 21152-1045-1 CAP.CERAMIC CHIP 0.1 uF ±80%0603 0603 2F 104Z 8BB-- S 4 C9 , 31 , 47 , 48 22241-0010-1 IC OP AMP. DUAL(CMOS) VSOP-08 NJU7016R-TE2 S 1 U6 23246-0002-1 IC MMIC SWITCH 1.8㎓ BGA427 S 1 U1 24264-0331-2 IC VOLT. REGULATOR 3.3V SOP-8 UTC LM2954-3.3V(SOP- 8) S 1 U3 25266-0007-1 IC VOLT. DETECTOR 2.0V LOW ACTIVE S80820CLNB-B6F-T 2S 1 U2 26268-0001-1 High Current Li-ion Batt Charger System, 4*4 16LEAD TYPE SC803IMLTR S 1 U4 27313-0011-1 GPS MODULE 12CH, 16Mbit SIRF2-LP(JCOM) JGR-SRM-LPF S 1 GPS 28313-1002-1 BLUETOOTH MODULE(AIRLOGIC) ABM-200 S 1 BT GPS 29319-0020-1 BRT PNP B:4K7,47K SOT-323 MK:PF KRA306 S 3 Q1 , 2 , 8 30319-1018-1 BRT NPN B:47K,47K SOT-323 MK:ND KRC404 S 5 Q3 , 4 , 5 , 6 , 7 31342-0008-1 DIODE SWITCHING USC MK:UF KDS160 S 7 D9 , 11 , 12 , 13 , 14 , 15 , 17 BT GPS SERIES (4-06-01-20) MODEL CODE 4060102 SCHEMATIC BGP-2000.SCH(Rev:1.0) CORRECT DATE 2004-10-11 승인원 NAME & DESCRIPTION VENDOR CODE TYPE 01 BGP-2000(BLUETOOTH GPS ) 32344-0006-1 DIODE SCHOTTKY IF 200mA USC MK:UL KDR357 S 1 D1 33344-0012-1 DIDOE BARRIER SCHOTTKY 200mA IuA 10V MA2SD24 S 1 D8 34344-0015-1 DIODE SCHOTTKY VF:0.50V, 1A MK:B140 B140 S 1 D16 35352-0001-1 LED CHIP DUAL HT-155SD/YG-DT S 1 D3 36355-0101-1 LED GREEN SM1316 S 1 D2 37356-0502-1 LED CHIP 1.6x0.8x0.5mm BLUE SSC-HB103 S 1 D4 38415-1575-1 FILTER SAW 1575.42MHz NSVS658 S 1 SF1 39452-1013-7 INDUCTOR CHIP CERAMIC 100nH ± 5% 1608 1608GC2T-R10J S 8 L1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 40484-1562-1 GPS ANTENNA 1575.42MHz 35x35x3Tmm B35-3450753-JCOM1 I 1 ANT1 41489-4032-1 ANTENNA SMT CHIP 2400MHz 50Ω 11x5x1.2mm W41-BF-19 S 1 ANT2 42520-0015-1 SWITCH SLIDE SMD TYPE 1C-2P 7x3x1.5 SSSS811101 S 1 SW1 43540-0003-1 CONNECTOR MCX-4R-PCB I 1 J2 44549-0006-1 SMD DC POWER SOCKET(1.65mm) TDC-003 S 1 J1 45549-1011-1 JACK 4P 2.6¢ 8.3 X 13.95 X 4.7 EPJ-02511KS S 1 J3 46577-3001-1 BATTERY BACK-UP MS-NI 3.1V 5.5mAh MS621F-FL11E I 1 BAT1 47577-3602-1 BATTERY PACK LI-POLYMER 3.7V 1080mAh 503759 A 1 BATT 48596-0803-A BGP-2000PCB FRA/양면/1.0T BGP-2003 A 1 PCB 49702-0095-A SHIELD CAN Sn도금 (JMK-425) SPTE, 13.5X7.0X5.5 T0.3 I 1 SHD1 50소모품 GPS ENGINE LABEL 무지 32.5X32.5XT0.15(R1.0) GPS ENGINE LABEL 무지 A 1 LABEL BT GPS SERIES (4-06-01-20) MODEL CODE 4060102SCHEMATIC BGP-2000.SCH(Rev:1.0)CORRECT DATE 2004-10-11 승인원 NAME & DESCRIPTION VENDOR CODE MAKER VENDOR TYPE 01 BGP-2000 ( BLUETOOTH GPS ) 1 010-0272-1 RES. CARBON FILM 2.7 ohm +-5% 1/8W RD1/8WT52J 2.7 Ω 델타코퍼레이션 델타코퍼레이션 I 2 010-1022-1 RES. CARBON FILM 1K ohm +-5% 1/8W RD1/8WT52J 1K Ω 델타코퍼레이션 델타코퍼레이션 I 3 010-3312-1 RES. CARBON FILM 330 ohm +-5% 1/8W RD1/8WT52J 330 Ω 델타코퍼레이션 델타코퍼레이션 I 4 010-3322-1 RES. CARBON FILM 3.3K ohm +-5% 1/8W RD1/8WT52J 3.3KΩ 델타코퍼레이션 델타코퍼레이션 I 5 010-4722-1 RES. CARBON FILM 4.7K ohm +-5% 1/8W RD1/8WT52J 4.7KΩ 델타코퍼레이션 델타코퍼레이션 I 6 013-3902-1 RES. CARBON FILM 39 ohm +-5% 1.0W 39 Ω /1W 델타코퍼레이션 델타코퍼레이션 I 7 051-1022-1 RES. CHIP 1 KΩ ± 5% 1/16W 0402 CR 1/16 102 JT PHILIPS 월드칩 S 8 051-1032-1 RES. CHIP 10 KΩ ± 5% 1/16W 0402 CR 1/16 103 JT PHILIPS 월드칩 S 9 051-2202-1 RES. CHIP 22 Ω ± 5% 1/16W 0402 CR 1/16 220 JT PHILIPS 월드칩 S 10 051-2212-1 RES. CHIP 220 Ω ± 5% 1/16W 0402 CR 1/16 221 JT PHILIPS 월드칩 S 11 051-2232-1 RES. CHIP 22 KΩ ± 5% 1/16W 0402 CR 1/16 223 JT PHILIPS 월드칩 S 12 051-4712-1 RES. CHIP 470 Ω ± 5% 1/16W 0402 CR 1/16 471 JT PHILIPS 월드칩 S 13 051-4722-1 RES. CHIP 4.7 KΩ ± 5% 1/16W 0402 CR 1/16 472 JT PHILIPS 월드칩 S 14 051-4732-1 RES. CHIP 47 KΩ ± 5% 1/16W 0402 CR 1/16 473 JT PHILIPS 월드칩 S 15 051-5612-1 RES. CHIP 560 Ω ± 5% 1/16W 0402 CR 1/16 561 JT PHILIPS 월드칩 S 16 052-1002-1 RES. CHIP 10 Ω ± 5% 1/16W 0603 CR 1/16 100 JT PHILIPS 월드칩 S 17 052-1012-1 RES. CHIP 100 Ω ± 5% 1/16W 0603 RC21 1/16 101 JT PHILIPS 월드칩 S 18 052-1022-1 RES. CHIP 1 KΩ ± 5% 1/16W 0603 RC21 1/16 102 JT PHILIPS 월드칩 S 5 R14 , 16 , 28 , 31 , 39 19 052-1032-1 RES. CHIP 10 KΩ ± 5% 1/16W 0603 RC21 1/16 103 JT PHILIPS 월드칩 S 5 R6 , 11 , 15 , 37 , 46 20 052-1822-1 RES. CHIP 1.8 KΩ ± 5% 1/16W 0603 RC21 1/16 182 JT PHILIPS 월드칩 S 1 R43 21 052-2202-1 RES. CHIP 22 Ω ± 5% 1/16W 0603 RC21 1/16 220 JT PHILIPS 월드칩 S 1 R32 22 052-2212-1 RES. CHIP 220 Ω ± 5% 1/16W 0603 CR 1/16 221 JT PHILIPS 월드칩 S 5 R19 , 21 , 23 , 29 , 42 23 052-2222-1 RES. CHIP 2.2 KΩ ± 5% 1/16W 0603 RC21 1/16 222 JT PHILIPS 월드칩 S 1 R7 24 052-2232-1 RES. CHIP 22…
Text truncated - open the document above for the full version.
AA BB CC DD 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 Title SizeNo.Rev. FileDateTimeof ABM-200-2XX A4REV 1.0 D:\...\\ABM-200-2XX.sch2003/03/0101:5711 note1 note2 note3 note4 note5 R4 180k 2 1 4 3 XT1 16MHz R3 4.7k RX_IN E1 AUX_DAC D2 TX/RX_A G1 TX/RX_B F1 TUNE J1 VSS_VCO1 H2 VSS_VCO2 J2 VSS C7 VSS_ANA2 L3 VSS_RADIO F2 VSS_RADIO G2 VSS_RADIO E2 VSS_CORE A9 VSS_PADS A11 VSS_PIO A2 VSS_MEM C11 A_18 K11 A_17 K10 A_16 K9 A_15 J11 A_14 J10 A_13 J9 A_12 J8 A_11 H11 A_10 H10 A_9 H9 A_8 G11 A_7 G10 A_6 G9 A_5 F11 A_4 F10 A_3 F9 A_2 E11 A_1 E9 A_0 D9 D_15 K4 D_14 J4 D_13 L5 D_12 K5 D_11 J5 D_10 L6 D_9 K6 D_8 J6 D_7 L7 D_6 K7 D_5 J7 D_4 L8 D_3 L11 D_2 L10 D_1 L9 D_0 K8 AIO_2 J3 RST F3 AIO_1 L4 AIO_0 K3 UART_RTS B7 UART_CTS B6 UART_TX C8 UART_RX C9 USB_DN A6 USB_DP A7 SPI_MISO B4 SPI_MOSI A5 SPI_CLK B5 SPI_CSB A4 PCM_OUT B9 PCM_IN B10 PCM_CLK B8 PCM_SYNC B11 PIO_0 C1 PIO_1 C2 PIO_2 B3 PIO_3 B2 PIO_4 B1 PIO_5 A3 PIO_6 C3 PIO_7 E3 PIO_8 D3 PIO_9 C4 PIO_10 C5 PIO_11 C6 XTAL_OUT L2 VSS_ANA1 K2 XTAL_IN L1 VDD_MEM D11 VDD_CORE A8 VDD_PADS A10 VDD_PIO A1 VDD_VCO H1 VDD_ANA K1 VDD_RADIO D1 VDD_RADIO H3 CSB C10 REB D10 WEB E10 TEST_EN G3 U1 BC212015A +1V8 +1V8 L5 3.9nH +1V8 C2 15pF C1 47pF L6 6.8nH R1 2.2 +1V8 +1V8 +3V15-RADIO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 CN1 CN15 +3V15-RADIO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 CN2 CN15 +3V15-RADIO A0 E1 A1 D1 A2 C1 A3 A1 A4 B1 A5 D2 A6 C2 A7 A2 A8 B5 A9 A5 A10 C5 A11 D5 A12 B6 A13 A6 A14 C6 A15 D6 A16 E6 A17 B2 A19 D4 WE A4 CE F1 OE G1 NC B4 NC F6 DQ0 E2 DQ1 H2 DQ2 E3 DQ3 H3 DQ4 H4 DQ5 E4 DQ6 H5 DQ7 E5 DQ8 F2 DQ9 G2 DQ10 F3 DQ11 G3 DQ12 F4 DQ13 G5 DQ14 F5 DQ15 G6 NC A3 VSS1 H1 VSS2 H6 VCC G4 NC B3 NC C4 NC D3 A18 C3 U3 SST39VF400A-70-BK C19 NF C15 2.2uF/10V C12 47pF 123 456 T1 BL-2012 C9 2pF C8 2pF L2 2.7nH L1 2.7nH C13 NF C14 220pF(COG) C18 10nF +3V15-RADIO C11 10nF C4 3.3pF C5 10pF C16 10nF C7 10nF C6 47pF +3V15-RADIO IN 1 OUT 3 GND 2 GND 4 U2 MDR741F VIN 1 GND 2 EN 3 BYP 4 OUT 5 U4 XC6204B182MR C3 2.2uF/10V UART-TX UART-RX UART-CTS UART-RTS PCM-OUT PCM-IN PCM-CLK PCM-SYNC PIO(7) PIO(6) PIO(5) PIO(4) PIO(3) PIO(2) PIO(1) PIO(0) SPI-CSB SPI-CLK SPI-MOSI SPI-MISO USB_DP USB_DN RESET-IN AIO_0 AIO_1 PIO(8) PIO(9) PIO(10) PIO(11) FEEDING FEEDING PIO(4) PIO(3) PIO(2) PIO(5) SPI-CSB SPI-MOSI USB_DN USB_DP PCM-CLK PCM-OUT PCM-IN PCM-SYNC PIO(6) PIO(1) PIO(0) AIO_0 PIO(7) AIO_1 RESET-IN UART-RX UART-TX UART-RTS UART-CTS SPI-CLK SPI-MISO A00A01A02A03A04A05A06A07A08A09A10A11A12A13A14A15A16A17A18D00D01D02D03D04D05D06D07D08D09D10D11D12D13D14D15 A00 A01 A02 A03 A04 A05 A06 A07 A08 A09 A10 A11 A12 A13 A14 A15 A16 A17 D00 D01 D02 D03 D04 D05 D06 D07 D08 D09 D10 D11 D12 D13 D14 D15 A18 CSBWEBOEB CSB WEB OEB AirLogic Bluetooth Module (ABM-200-2XX) Ver 1.0 (MLCC) (MLCC) 2003/02/28
124-4, Ojeon-Dong, Ulwang-City, Kyungki-Do, KOREA 437-070 Nov 12, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 RE : RF exposure information FCC ID : OAJBGP2000 Bluetooth GPS Receiver To whom it may concern: The product stated above, comply with the FCC limits for Human exposure to RF emissions. This device is categorically excluded from routine environmental because it operate at very low power level. The equipment is deemed to comply with the SAR or MPE limits without testing due to this very low power level (EIRP < 2.5 mW) Sincerely,
DEMC#DR50110411L FCC ID: RRRXBM-100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 1 of 40 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE J Communications Co., Ltd. 124-4, Ojeon-Dong, Ulwang-City, Kyungki-Do, KOREA 437-070 Dates of Tests: October 26 ~ November 01,2004 Test Report S/N: DR50110411L Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification : FHSS Sequence Spread Spectrum (FHSS) Device name : Bluetooth GPS Receiver Manufacturer I : J Communications Co., Ltd. Manufacturer II : AIRLOGIC Co., Ltd. (Bluetooth Module) Model No. : BGP-2000 Bluetooth Module Model No. : ABM-200 Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2001 Frequency Range : 2402 ~ 2480 MHz Max. Output power : 1.67mW Conducted Data of issue : November 02, 2004 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. OAJBGP2000 J Communications Co., Ltd. DEMC#DR50110411L FCC ID: RRRXBM-100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 2 of 40 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.6 BAND - EDGE (at 20 dB blow) ---------------------------------------------------------------- 3.2.7 OUT OF BAND EMISSION - RADIATED -------------------------------------------------- 3.2.8 AC CONDUCTED EMISSIONS -------------------------------------------------------------- 3.3 RECEIVER REQUIREMENTS --------------------------------------------------------------------- 3.3.1 AC CONDUCTED EMISSIONS -------------------------------------------------------------- 3.3.2 OUT OF BAND EMISSION - RADIATED -------------------------------------------------- ANNEX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 11 14 18 21 28 29 33 33 37 38 DEMC#DR50110411L FCC ID: RRRXBM-100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 3 of 40 1. General information’s This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer November 02, 2004 Won -Jong LEE Data Name Signature Report Reviewed By: manager November 02, 2004 Dong -Min JUNG Data Name Signature Ordering party: Company name : J Communications Co., Ltd. Address : 124-4, Ojeon-Dong, Ulwang-City, , KOREA Zip code : 437-070 City/town : Kyungki-Do Country : Korea Date of order : October 26, 2004 DEMC#DR50110411L FCC ID: RRRXBM-100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 4 of 40 2. Information’s about test item OAJBGP2000 2.1 Equipment information Equipment model name BGP-2000 Model name of Bluetooth Module ABM-200 Type of equipment Bluetooth GPS Receiver Frequency band 2402 ~ 2480 MHz Type of Modulation GFSK Channel Spacing 1.0 MHz Type of antenna Chip Antenna Power - Rechargeable Lithium-Ion-Polymer Battery: Normal 3.7 Vdc - AC/DC Adaptor: UL305-0510 Input: 100 – 240VAC, 50/60Hz, 0.3A Output: 5VDC, 1A 2.2 Tested frequency Frequency TX RX Low frequency 2402MHz 2402MHz Middle frequency 2441MHz 2441MHz High frequency 2480MHz 2480MHz 2.3 Tested environment Temperature : 15 ~ 35 ( o C) Relative humidity content : 20 ~ 75 % Air pressure : 86 ~ 103 kPa Details of power supply : 3.7 Vdc (powered by power supply for RF measurement) 120Vac / 60Hz(for Emission) 2.4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer AC/DC Adaptor UL305-0510 N/A UNIFIVE Notebook computer PP02X 8K493A01 DELL 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing -> none DEMC#DR50110411L FCC ID: RRRXBM-100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 5 of 40 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) I. Transmit mode(Tx) Carrier Frequency Separation > 25 kHz C Number of Hopping Frequencies > 75 hops C 20 dB Bandwidth < 1 MHz C 15.247(a) Dwell Time 0.4 seconds within a 30 second period per any frequency C 15.247(b) Transmitter Output Power < 1Watt C Band-edge (or Occupied BW for IC) 2400 < f < 2483.5 MHz C 15.247(c) Out of Band Emissions…
