System 5000 U s e r s M a n u a l Revision 1 ISECUREtrac Corporation iiSECUREtrac 2250 User’s Manual Rev 1.0 Confidential Page 1 7/3/2007 Introduction This manual covers the installation and removal of the iSECUREtrac Corp System 5000 personal tracking system. Equipment List · System 5000 PTU (Personal Tracking Unit) · iSECUREtrac System 5000 Intellicuff (see user manual for bracelet transmitter or installation) · iSECUREtrac System 5000 Charging Base · Floor based power module with AC power cord Installation Tools · None System Status Indicators · An LCD with indicator icons is provided on the PTU. The icon in the lower right hand corner will display a battery when on battery power and a lighting bolt when in the charging base and the base is plugged into the power line. · The charging base has a red LED that can be seen when looking through a transparent window in the cradle area of the changing base. When the led can be seen the base is being powered. Connecting a Offender at the Agent's location · The agent enters configuration information into the server software. · The offender comes to the agent’s office. · The agent forces the unit to call. · The agent confirms configuration has been uploaded to the unit. · Wireless bracelet transmitter is attached to the ankle of the offender. · Agent waits for Installation message signal display on the PTU LCD · The agent gives the offender the PTU and Charging Station. · The offender takes the PTU and Charging Station home. · The offender connects the Charging Station to AC receptacles. · The offender places the PTU in the Charging Station when at home · The offender carries PTU with them when not at home ISECUREtrac Corporation iiSECUREtrac 2250 User’s Manual Rev 1.0 Confidential Page 2 7/3/2007 Removal of an Offender at Agent's Location · The agent enters removal information into the server software. · PTU will deactivate on next call. · The agent notifies offender of removal. · The offender removes the Charging Station power. · The offender comes the agent’s office bringing the PTU and Charging Station. · Wireless transmitter is removed from the ankle of the offender. Location of the Charging base at offenders location · The unit should be set on a level a table at least 30 inches off the floor · The table should not be close to a source of water or a location where it will be easily knocked to the floor. · The unit should be several feet away from electrical kitchen appliances and televisions sets. · The best location is the center of the dwelling, to provide the same distance between the bracelet receiver and when its transmitter is at the extreme areas of the dwelling, i.e. the center of the inclusion zone. Wearing the PTU · Do Not wear the unit such that it is closer than 1 ft to the head of the Offender · Do Not submerge in water. · Do Not drop. · When in a car place the unit should be out of direct summertime sun light. FCC Requirements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution to the user Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment ISECUREtrac Corporation iiSECUREtrac 2250 User’s Manual Rev 1.0 Confidential Page 3 7/3/2007 Service Requirements In the event of equipment malfunction, all repairs should be performed by our Company or an authorized agent. It is the responsibility of users requiring service to report the need for service to our Company or to one of our authorized agents, Service can be obtained at iSECUREtrac Corp. 5078 S 111 th Street Omaha, NE 68137

This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TEST REPORT Report Number: 3125064LEX-001 Project Number: 3125064 Evaluation of Model Number: System 5000 Base FCC ID: OAM5000BASE FCC Part 15 Subpart B & FCC Part 15 Subpart C For iSECUREtrac Corporation Test Performed by: Test Authorized by: Intertek 731 Enterprise Drive Lexington, KY 40510 iSECUREtrac Corporation 5022 South 114th Street Omaha, NE 68137 Prepared By:_______________________________Date:____6/21/2007________ Jason Centers, Senior Project Engineer Approved By:______________________________Date:____6/21/2007_________ Bryan C. Taylor, Team Leader Intertek 731 Enterprise Drive, Lexington, KY 40510 Telephone: 859-226-1000 Fax: 859-226-1040 Web: www.etlsemko.com 731 Enterprise Drive, Lexington KY 40510 Evaluation For:iSECUREtrac Corporation FCC ID: OAM5000BASE Model No: System 5000 Base Report Number: 3125064LEX-001 Page 2 of 21 FCC Part 15 Evaluation TABLE OF CONTENTS 1 JOB DESCRIPTION .......................................................................................................................... 3 1.1 COMPANY INFORMATION............................................................................................................ 3 1.2 TEST SAMPLE INFORMATION....................................................................................................... 3 1.3 SYSTEM SUPPORT EQUIPMENT.................................................................................................... 3 1.4 CABLES USED DURING TESTING................................................................................................. 4 1.5 SYSTEM BLOCK DIAGRAM(S) ...................................................................................................... 4 1.6 MODE(S) OF OPERATION / ENGINEERING JUDGMENTS................................................................ 4 2 EXECUTIVE SUMMARY................................................................................................................. 5 2.1 MODIFICATIONS REQUIRED FOR COMPLIANCE............................................................................ 5 3 TEST FACILITY................................................................................................................................ 6 3.1 TEST EQUIPMENT......................................................................................................................... 6 4 FIELD STRENGTH OF FUNDAMENAL & SPURIOUS RADIATION, EMISSION BANDWIDTH ............................................................................................................................................. 7 4.1 TEST PROCEDURE........................................................................................................................ 7 4.2 TEST RESULTS............................................................................................................................. 8 5 RADIATED RECEIVER EMISSIONS .......................................................................................... 15 5.1 TEST PROCEDURE...................................................................................................................... 15 5.2 TEST RESULTS........................................................................................................................... 16 6 CONDUCTED VOLTAGE EMISSIONS....................................................................................... 18 6.1 TEST METHOD: .......................................................................................................................... 18 6.2 TEST RESULTS: .......................................................................................................................... 19 731 Enterprise Drive, Lexington KY 40510 Evaluation For:iSECUREtrac Corporation FCC ID: OAM5000BASE Model No: System 5000 Base Report Number: 3125064LEX-001 Page 3 of 21 FCC Part 15 Evaluation 1 JOB DESCRIPTION 1.1 Company Information Company Information Manufacturer: iSECUREtrac Corporation Address: 5022 South 114th Street Omaha, NE 68137 Contact Name: Jef Higgason Telephone Number: (402) 537-5663 Email Address: [email protected] 1.2 Test Sample Information The iSECUREtrac Corporation System 5000 Base is a charging and communications base that connects to the System 5000 PTU unit that is used by law enforcement to locate and track offenders. Test sample Model Number: System 5000 Base Serial Number: Not Labeled FCC ID: OAM5000BASE Device Category: Mobile RF Exposure Category: General Population/Uncontrolled Environment Transmission: AM Modulation Frequency Range (MHz) 439.21 MHz & 451.4 MHz Antenna Type: Wire Antenna Antenna Location: Internal Power Supply Manufacture: Sunny Computer Technology Co., LTD Model – SYS1089-1005-T3 Input: 100-240VAC, 1A Output: 5VDC, 2.0A 1.3 System Support Equipment No support equipment was necessary for the evaluation. 731 Enterprise Drive, Lexington KY 40510 Evaluation For:iSECUREtrac Corporation FCC ID: OAM5000BASE Model No: System 5000 Base Report Number: 3125064LEX-001 Page 4 of 21 FCC Part 15 Evaluation 1.4 Cables Used During Testing Cables Connection Description Length …
