OE5S884S884 Inductive Reader

Mount the backplate using countersunk headed screws adjacent to the opening edge of the door and at a convenient height (recommended height is 5' (1.5m) to top of unit). If fixing hole ’A’ is used then the breakout must be removed and the screw must not protrude. Feed the required cables through the backplate: ·The cable from the controller. ·A cable from a External Reader (Optional). ·General Purpose Input / Output cable (Optional) If wall tamper function is to be used then breakout ‘B’ must be removed and an appropriate wall screw fitted through the hole to actuate the tamper lever. 2 1 Mount the Backplate Reader Connections The S884 is a and keypad. The reader can be set to use Wiegand or The S884 reader will read smartMAX encoded MIFARE cards and card serial numbers from most ISO 14443A smart cards which have a 4-byte UID (User Identification). The reader may be configured to read other card types by presenting a programming card to the reader during start up. contactless smart-card reader, with Graphic LCD 20mA current loop communications. The securing screws ‘C’ are integral to the backplate and are unscrewed via the small holes in the enclosure so that the screw heads locate in the counterbored holes on the inside of the enclosure. You should find that the backplate has holes for connection to most standard electrical backboxes. C A B Installation and User Instructions for S884 Readers 0V RX+ RX- TX+ TX- 12V Controller 0V TX+ TX- RX+ RX- +V Reader TB1 20mA current loop 0V Green Data 0 Red Data 1 12V Controller 0V GRN 0 +V Use Belden 9537 Cable Wiegand RED 1 Reader TB1 Connect shield at controller end only. Connect shield at controller end only. Twisted pairs (use Belden 9503 Cables) Note: Use LK2 to select the communications mode (See Step 3). Set LK2 (COMMS) across the center and WE pin for Wiegand communications, or across the center and CL pin for 20mA current loop communications. Set LK3 (USER Keypad audio feedback) to 1 for sound on, or 0 for sound off. Set LK4 (EXT RDR) across the center and WE pin for Wiegand communications, or across the center and MAG pin for Magstripe Reader communications. 3 Reader Links 4 External Reader Connections (Optional) 0V 0/CK 1/DA +V Reader TB1 Magstripe 0V 0/CK 1/DA +V Reader TB1 Wiegand Wiegand Reader Magstripe Reader IN 1 IN 2 C SPKR Reader TB2 I/O Connections 5 General Purpose Inputs & Outputs (Optional) COM NC NO SPKR Presentthe cardface-ontothereaderuntilyouhear a"bleep". Cardscanbepresentedinrapidsuccession; there is no need, for example, to wait for "UNLOCKED" to disappear before presenting another. If the reader has been enabled for user-code mode at the controller, you can gain access by pressing the O key, entering your card number, then pressing the P key. A Setup menu can be displayed by pressing the O and P keys simultaneously while power is applied. You can use the menu to change the contrast and language used for the LCD (default English). Use the four function keys to navigate around the menu. 9600-0537. Installation and User Instructions for S884 Readers, Issue x1.0 19th April 2010. G4S Technology, 2010. FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any unauthorized modification to this device may void the authority of the user to operate it. All trademarks acknowledged. © LED Status Indicator GREEN – The lock is released and you may open the door. RED – You do not have access rights to gain entry, or the reader did not read your card properly (in this case, present it again). YELLOW – Enter your PIN. If you make a mistake, the message INVALID PIN is momentarily displayed, followed by ENTER PIN, to prompt you to try again. Specifications Input voltage: 9-14Vdc. Input current: 200mA @ nom. 12Vdc. Operating temperature: 14 to 131°F (-10 to 55°C) Operating humidity: 15 to 90%, non-condensing. Maximum read range: 4" (100mm). Approvals: EN50133, EN302291, EN301489 6 Using the Reader Note: Use LK4 to select the External Reader type (See Step 3). The reader is connected to the controller using the 20mA current loop scheme shown in section 2 and, in addition, the external reader is connected as shown below. 0V Clock Data 12V 0V 0s 1s 12V

Front Overview Rear Overview

Serial Label Position 112 mm 145 mm

Front Overview PCB Component Side

Total number of pages: 37 TRaC Wireless Test Report:TTR-000222WUS1 Applicant:G4S Technology Limited Apparatus:S884 Specification(s):CFR47 Part 15 July 2008 Purpose of Test: Certification FCCID: OE5S844 Authorised by: : Radio Product Manager Issue Date:28 th April 2010 Authorised Copy Number: PDF Radio Test Report: TTR-000222WUS1 2 Contents Section 1:Introduction3 1.1General3 1.2Tests Requested By4 1.3Manufacturer4 1.4Apparatus Assessed4 1.5Test Result Summary5 1.6Notes Relating To The Assessment6 1.7Deviations from Test Standards6 Section 2:Measurement Uncertainty7 2.1Application of Measurement Uncertainty7 2.2Measurement Uncertainty Values8 Section 3:Modifications10 3.1Modifications Performed During Assessment10 Appendix A:Formal Emission Test Results11 A1Transmitter Intentional Emission Radiated12 A2Radiated Electric Field Emissions13 A3Power Line Conducted Emissions15 A5Frequency Stability17 Appendix B:Supporting Graphical Data18 Appendix C: Additional Test and Sample Details24 Appendix D:Additional Information30 Appendix E:Calculation of the duty cycle correction factor31 Appendix F:Photographs and Figures32 Radio Test Report: TTR-000222WUS1 3 Section 1:Introduction 1.1General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samplessubmitted to the Laboratory. Test performed by:TRaC Telecoms & Radio[ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone:+44 (0) 1482 801801 Fax:+44 (0) 1482 801806 TRaC Telecoms & Radio[X] Moss View Nipe Lane Up Holland West Lancashire, WN8 9PY United Kingdom Telephone:+44 (0) 1695 556666 Fax:+44 (0) 1695 577077 Email:[email protected] Web site:http://www.tracglobal.com Tests performed by:D Winstanley Report author:D Winstanley This report must not be reproduced except in full without prior written permission from TRaC Telecoms & Radio. Radio Test Report: TTR-000222WUS1 4 1.2Tests Requested By This testing in this report was requested by : G4S Technology Limited Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ 1.3Manufacturer As Above 1.4Apparatus Assessed The following apparatus was assessed between19/03/2010and 23/03/2010 S884 The above equipment is a 13.56MHzCard Reader Radio Test Report: TTR-000222WUS1 5 1.5Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test TypeRegulation Measurement standard Result Spurious Emissions Radiated <1000MHz Title 47 of the CFR: Part 15 Subpart (c) 15.209 ANSI C63.10Pass Spurious Emissions Radiated >1000MHz Title 47 of the CFR: Part 15 Subpart (c) 15.209 ANSI C63.10N/A AC Power conducted emissions Title 47 of the CFR: Part 15 Subpart (c) 15.207 ANSI C63.10Pass Intentional Emission Frequency Title 47 of the CFR: Part 15 Subpart (c) 15.225 ANSI C63.10Pass Intentional Emission Field Strength Title 47 of the CFR: Part 15 Subpart (c) 15.225 ANSI C63.10Pass Intentional Emission Band Occupancy Title 47 of the CFR: Part 15 Subpart (c) 15.225 ANSI C63.10Pass Intentional Emission ERP (mW) Title 47 of the CFR: Part 15 Subpart (c) ANSI C63.10N/A Unintentional Radiated Spurious Emissions Title 47 of the CFR: Part 15 Subpart (b) 15.109 ANSI C63.10Pass Antenna Arrangements Integral: Title 47 of the CFR: Part 15 Subpart (c) 15.203 -Pass Antenna Arrangements External Connector Title 47 of the CFR: Part15 Subpart (c) 15.204 -N/A Restricted Bands Title 47 of the CFR: Part 15 Subpart (c) 15.205 -- Maximum Frequency of Search Title 47 of the CFR: Part 15 Subpart (c) 15.33 -- Extrapolation Factor Title 47 of the CFR: Part 15 Subpart (c) 15.31(f) -- Abbreviations used in the above table:- CFR: Code of Federal RegulationsANSI: American National Standards Institution REFE: Radiated Electric Field EmissionsPLCE: Power Line Conducted Emissions Radio Test Report: TTR-000222WUS1 6 1.6Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performedexcept where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature: 17 to 23 C Humidity : 45 to 75 % Barometric Pressure: 86 to 106 kPa All dates used in this report are in the format dd/mm/yy. This assessment has been performed in accordance with the requirements ofISO/IEC 17025. 1.7Deviations from Test Standards There were no deviations from the standards tested to. Radio Test Report: TTR-000222WUS1 7 Section 2:Measurement Uncertainty 2.1Application of Measurement Uncertainty The following table contains the measurement uncertainties for measurements The following procedure is used when determining the result of a measurement : (i)If specification limits are not exceeded by the measured result, extended by the positive comp…

Text truncated - open the document above for the full version.

H-Field Test Setup Close Up Powerline Test Setup Powerline Close Up
