OEW-AGBB-M1CDMA Cellular BaseStation

ADC Telecommunications Inc.
CDMA Cellular BaseStation - FCC ID OEW-AGBB-M1 - ADC Telecommunications Inc.
Click to zoom

Application Details

Equipment Class
PCB - PCS Licensed Transmitter
Date of Grant
Dec 30, 2004
Application Purpose
Original Equipment
Date of Application
Dec 30, 2004
Equipment Note
CDMA Cellular BaseStation
Frequency Range
1930.00000000 - 1990.00000000
Company
ADC Telecommunications Inc.
Country
United States

Documents & Files

Select a file to view

Cover Letter(s)

↗
↗

External Photos

↗
↗

ID Label/Location Info

↗

Internal Photos

↗
↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

1 Mike Kuo From: Claire Hoque Sent: December212004Tuesday 2:17 PM To: Mike Kuo Cc: Thu Chan; Nancy Omron; Chuck Cowden Subject: answer: interWAVE Communications, Inc., FCC ID: OEW-AGBB-M1, Assessment NO.: AN04T4355, Notice#1 FCC ID LABEL(revised).pdf RF Transmit Power Configuratio... Hi Mike, Here are the answers. Question #1: Please delete Part 15 statement on the proposed FCC ID label which is not applicable to this Part 24 base station. <answer>FCC ID label has been revised, pls see the attachment. Question #2: Based upon theory of operation, there are three type of configuration: Indoor Pico Cell BS, outdoor Pico Cell BS and Micro Cell BS. Depends on the configuration, the rated output power for each channel can be 50mW, 1 W or 100W. The measured average output power is 1.77W which does not match with typical configuration. Please confirm the type of configuration for this device and what is the rated output power . <Interwave>Output power of the CDMA products is based upon average power. The output power will vary depending upon configuration and number of traffic channels/users at any given time. The maximum RF output power per antenna port is 25W on the microcell product line. For the indoor pico product, it is 50 mW. The outdoor pico is not currently being produced. The 100W figure came from some eary systems that had much larger RF power amplifiers. Attached is an application note we supply our customers. It explains how transmit power works in CDMA systems, and how to configure it. It also gives typical power levels to expect with various number of active channels, and also examples with Interwave microcell and picocell hardware. Thanks, Claire

ID Label/Location Info

PROPOSED FCC ID LABEL AND LOCATION INTERWAVE COMMUNICATIONS FCC ID: OEW-AGBB-M1 FCC ID LABEL LOCATION

Test Report

FCC CFR47 PART 24 SUBPART E CERTIFICATION TEST REPORT FOR EUT: CDMA CELLULAR BASESTATION MODEL NUMBER: WAVE2000BS PLUS FCC ID: OEW-AGBB-M1 REPORT NUMBER: 04U3009-1 ISSUE DATE: NOVEMBER 15, 2000 Prepared for INTERWAVE COMMUNICATIONS 2495 LEGHORN STREET MOUNTAINT VIEW, CA 94043 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 2 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 3 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.4. SOFTWARE AND FIRMWARE .................................................................................................... 6 5.5. WORST-CASE CONFIGURATION AND MODE......................................................................... 6 5.6. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. LIMITS AND RESULTS ................................................................................................................. 10 7.1. OCCUPIED BANDWIDTH ........................................................................................................ 10 7.2. MODULATION CHARACTERISTICS........................................................................................ 14 7.1. RF POWER OUTPUT.................................................................................................................14 7.3. FREQUENCY STABILITY .......................................................................................................... 16 7.4. SPURIOUS EMISSION AT ANTENNA TERMINAL................................................................... 18 7.5. FIELD STRENGTH OF SPURIOUS RADIATION..................................................................... 24 7.6. RADIATED EMISSIONS BELOW 1 GHz ................................................................................... 26 7.7. POWERLINE CONDUCTED EMISSIONS (DIGITAL) ............................................................. 31 8. SETUP PHOTOS .............................................................................................................................. 35 REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 4 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: INTERWAVE COMMUNICATIONS 2495 LEGHORN STREET MOUNTAINT VIEW, CA 94043, USA EUT DESCRIPTION: CDMA CELLULAR BASESTATION MODEM NAME: Wave2000 BS Plus DATE TESTED: NOVEMBER 09 TO 11, 2004 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 24 SUBPART E NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: THU CHAN VIEN TRAN EMC SUPERVISOR EMC TECHNICIAN COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 5 of 40 COMPLIANCE CERTIFICA…

Text truncated - open the document above for the full version.

Test Setup Photos

REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 35 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 36 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED RF MEASUREMENT SETUP RADIATED FRONT PHOTO REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 37 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED BACK PHOTO REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 38 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP LINE CONDUCTED FRONT PHOTO REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 39 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. LINE CONDUCTED BACK PHOTO REPORT NO: 04U3009-1 DATE: NOVEMBER 15, 2004 EUT: CDMA CELLULAR BASESTATION FCC ID: OEW-AGBB-M1 Page 40 of 40 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. END OF REPORT TEMPERATURE CHAMBER PHOTO

Contact Information

Applicant

Mark Miska(Director of Technology)
[email protected]952 403 8340Fax: 952 403 8858

Test Firm

Compliance Certification Services IncSteve Cheng
[email protected]408-463-0885Fax: 408-463-0888

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
124E1.93 GHz - 1.99 GHz1.78 W1M39F9W2.5000000000 ppm
Confidentiality
Long Term
Grant Notes
Output power is conducted at antenna terminals. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of ��1.1307(b)(3).
