OGUVER1920Flex Badge

Midmark RTLS Solutions, Inc.
Flex Badge - FCC ID OGUVER1920 - Midmark RTLS Solutions, Inc.
Click to zoom

Application Details

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Date of Grant
Feb 27, 2007
Application Purpose
Original Equipment
Date of Application
Feb 27, 2007
Equipment Note
Flex Badge
Frequency Range
433.90000000 - 433.90000000
Company
Midmark RTLS Solutions, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Versus Information System User Guide V ERSUS TECHNOLOGY, INC. 2600 MILLER CREEK ROAD T RAVERSE CITY, MI 49684 (231) 946-5868 www.versustech.com i Copyright 1991 – 2006 Versus Technology, Inc., all rights reserved. This document contains user’s information on technology that is proprietary to Versus Technology, Inc. Permitted transmittal, receipt, or possession of this document does not express license or imply any rights to use, sell, design, or manufacture this information. No reproduction, publication or disclosure of this information, in whole or in part, shall be made without prior written authorization from an officer of Versus Technology, Inc. WARNING! This product is not designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury, death, or severe property damage. This product or its systems are covered by one or more of the following U.S. Patents: 4,906,853; 5,017,794; 5,027,314; 5,119,104; 5,276,496; 5,548,637; 5,572,195; 5,355,222; 5,387,993; 6,104,295; 6,154,139; 6,838,992. Note: Versus Information Systems (VIS™) VIS uses patented infrared and radio frequency technology to deliver precise location-specific information. VIS is marketed directly to medical facilities and through a network of authorized distributors. Because Versus Technology, Inc. is constantly improving its products, specifications within all Versus manuals are subject to change without notice. Revision date: September 2006 Proprietary Information – Do Not Distribute FCC STATEMENT: Components complying with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void your FCC authorization to use these products. Contents 1. Introduction ...........................................................................................................................3 1.1 Purpose of This Guide ..................................................................................................3 1.2 Computer Requirements ...............................................................................................3 1.2.1 Server Computer Requirements ......................................................................4 1.2.2 Computer Workstation Requirements Including Relay Controlled Devices ....4 1.3 Terms and Definitions ...................................................................................................5 1.4 Versus Hardware Parts List ..........................................................................................6 2. System Description ..............................................................................................................7 2.1 Infrared (IR) Tracking ....................................................................................................7 2.2 Radio Frequency (RF) Signals......................................................................................7 2.3 System Hardware Components ....................................................................................8 2.3.1 Badges .............................................................................................................8 2.3.2 Sensors ..........................................................................................................11 2.3.3 Collectors .......................................................................................................12 2.3.4 Ethernet Concentrators ..................................................................................12 2.3.5 Optional Hardware .........................................................................................12 Versus Technology, Inc. 3 1. Introduction 1.1 Purpose of This Guide This document is intended to provide information about the components of a Versus Information Systems (VIS TM ) system. Read this entire document before proceeding with the installation. A general understanding of wiring and telephone installation techniques is assumed. 1.2 Computer Requirements The VIS software runs in the Microsoft Windows 2000 or XP environments and requires a computer system with reasonable capacity and speed. Versus Technology, Inc. 4 1.2.1 Server Computer Requirements The minimum computer requirement for the server computer running the Data Server, Badge Server, and Configuration Utilities are as follows: Operating System Windows 2000 or XP, Pro or Server version recommended Processor Current shipping model or better Memory 512 MB RAM or more, depending on operating system Hard drive 40 GB or equivalent 2 nd Hard Drive 40 GB hard drive for purpose of redundancy Floppy Disk Drive 3.5 1.44 MB CD-ROM 48X CD-ROM or better, CD-RW optional Sound Card Standard sound card or better (optional) Speakers Standard Speakers (optional) Network Card Standard Ethernet Card Modem 56K Data/Fax Modem (optional) Tape Backup 10/20GB, SCSI, Travan-5 or Equivalent (recommended) UPS UPS recommended These are minimums only; additional resources may be needed depending on the size of the system. 1.2.2 Computer Workstation Requirements Including Relay Controlled Devices As part of the Versus System, relay-controlled devices (such as corridor lights) can be connected to relay boards, which are then connected to a computer that contains a relay control board. The computer that contains the relay control board will also have the Relay Control software installed for configuring the relays. The computer requires a PCI slot for the PCI-DIO96H relay controller card. One PCI-DIO96H relay controller card can have two CIO-ERB48 relay boards connected to it. One workstation can have up to five PCI-DIO96H relay controller cards in…

Text truncated - open the document above for the full version.

Cover Letter(s)

FCC ID: OGUVER1920 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Versus Technology, Inc.), hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Robert Wiser Versus Technology, Inc.

Cover Letter(s)

Page 1 of 2 CSF-20-07 Rev 1.1 February 28, 2007 Versus Technology, Inc. 2600 Miller Creek Road Traverse City, MI 49684 Attention: Robert Wiser We have reviewed the application for certification authorization which was submitted to Elite. Upon review of your application it was determined that additional information is required to complete the application for certification authorization. The additional information required is listed below: Administrative Review 1. Exhibit C: Internal photographs are blurry. Please submit clearer internal photographs. Technical Review 2. Exhibit E: Test measurement report states that a double ridged waveguide antenna was used for the measurements above 1GHz. The equipment list does not list a double ridged waveguide antenna. The application for certification authorization cannot continue until all information requested above is returned to Elite. The status of your application for certification authorization has been placed on hold for a period of 30 days or until the items listed above have been addressed. During this time Elite will be happy to answer any questions or assist in any way possible for a successful grant of certification authorization. At the conclusion of the allotted 30 day period, Elite reserves the right to dismiss your application for certification authorization if no reply to this inquiry is received. Sincerely, Dan Crowder Certification Department Supervisor ELITE ELECTRONIC ENGINEERING

Test Report

AHD 92723 Mich. Hwy-152 Sister Lakes, MI 49047 A copy of this Report will be on file with AHD to: July, 2011 Page 1 of 21 EMC Test Report #0600902F2 Issued 02/28/07 REGARDING THE FCC 15.231E TESTING OF C HANGES TO THE PCB LAYOUT OF 433.9MH Z TRANSMITTER, MODEL VER-1920 Category: Low Power Transmitter Judgment: FCC Part 15 – compliant Prepared for: Mr. Bob Wiser VERSUS Technology 2600 Miller Creek Rd. Traverse City, MI 49684 Test Date(s): April 18,19, 2006 Report prepared by: Report reviewed by: __________________________ Gordon Helm, NCE Jim Teune, NCE Data recorded by: __ Gordon Helm, NCE Test Engineer, AHD Test report #0600902F2 FCC B for VER1 920 Tested April 18,19, 2006 AHD, 92723 Mich. Hwy152, Sister Lakes, MI 49047, (269) 424-7014 Page 2 of 21 Table of Contents STATEMENTS CONCERNING THIS REPORT.............................................................................3 SUMMARY OF RESULTS.......................................................................................................5 C HANGES MADE...........................................................................................................5 EUT DESCRIPTION.............................................................................................................6 EUT PICTURES............................................................................................................6 E QUIPMENT TESTED: ..........................................................................................................8 S UPPORT EQUIPMENT & CABLING.................................................................................8 SETUP PICTURES.........................................................................................................8 MEASUREMENT REPORT...................................................................................................12 S TANDARDS APPLIED TO TEST....................................................................................12 EQUIPMENT CONFIGURATION......................................................................................12 TEST METHODOLOGY / JUSTIFICATION.........................................................................12 VARIANCE FROM TEST PROCEDURE......................................................................13 T EST DATA................................................................................................................13 R ADIATED FIELD STRENGTH MEASUREMENTS: [15.231(B), 15.205] .......................14 OCCUPIED BANDWIDTH [15.231(C)] ......................................................................15 MEASUREMENT FACILITIES & EQUIPMENT...........................................................................16 TEST SITE.................................................................................................................16 M EASUREMENT EQUIPMENT USED...............................................................................16 ENVIRONMENT...........................................................................................................16 APPENDIX A..................................................................................................................16 G ENERAL MEASUREMENT PROCEDURES......................................................................16 RADIATED...........................................................................................................16 FORMULAS AND SAMPLE CALCULATIONS: .................................................18 C ABLE LOSS..............................................................................................................19 ANTENNA FACTORS....................................................................................................19 AHD ENDORSEMENTS................................................................................................20 Test report #0600902F2 FCC B for VER1 920 Tested April 18,19, 2006 AHD, 92723 Mich. Hwy152, Sister Lakes, MI 49047, (269) 424-7014 Page 3 of 21 STATEMENTS CONCERNING THIS REPORT NVLAP Accreditation: NVLAP Lab Code 200129-0 The scope of AHD accreditation is the conducted emissions, radiated emissions test methods of: IEC/CISPR 22: Limits and methods measurement of radio disturbance characteristics of information technology equipment. FCC Method – 47 CFT Part 15 – Digital Devices. AS/NZS 3548: Electromagnetic Interference – Limits and Methods of Measurement of Information Technology Equipment. IEC61000-4-2 and Amend.1: ElectroStatic Discharge Immunity IEC61000-4-5: Surge Immunity Test Data: This test report contains data included in the scope of NVLAP accreditation. Subcontracted Testing: This report does not contain data produced under subcontract. Test Traceability: The calibration of all measuring and test equipment and the measured data using this equipment are traceable to the National Institute for Standards and Technology (NIST). Limitations on results: The test results contained in this report relate only to the Item(s) tested. Any electrical or mechanical modification made to the test item subsequent to the test date shall invalidate the data presented in this report. Any electrical or mechanical modification made to the test item subsequent to this test date shall require an evaluation to verify continued compliance. Limitations on copying: This report shall not be reproduced, except in full, without the written approval of AHD. Limitations of the report: This report shall not be used to claim product endorsement by NVLAP, FCC, or any agency of the US Government. Statement of Test Results Uncertainty: Following the guidelines of NAMAS publication NIS81 and NIST Technical Note 1297, the Measurement Uncertainty at a 95% confidence level is determined to be: ± 1.4 dB Retention of Records: 1) For equipment verified to comply with FCC regulations, the manufacturer is obliged to retain this report with the product records for two years following the manufacture of the equipment that was teste…

Text truncated - open the document above for the full version.

Test Setup Photos

Test report #0600902F2 FCC B for VER1 920 Tested April 18,19, 2006 AHD, 92723 Mich. Hwy152, Sister Lakes, MI 49047, (269) 424-7014 Page 9 of 21 Radiated Setup – Flat orientation Test report #0600902F2 FCC B for VER1 920 Tested April 18,19, 2006 AHD, 92723 Mich. Hwy152, Sister Lakes, MI 49047, (269) 424-7014 Page 10 of 21 Radiated Setup – End orientation Test report #0600902F2 FCC B for VER1 920 Tested April 18,19, 2006 AHD, 92723 Mich. Hwy152, Sister Lakes, MI 49047, (269) 424-7014 Page 11 of 21 Radiated Setup – Side orientation

Contact Information

Applicant

Tracy Matula(Product Engineering and Quality Manager)
[email protected]8779837787Fax: 231-946-6775

Technical Contact

Versus Technology, Inc.Robert L Wiser
[email protected]231-946-5868

2600 Miller Creek Road · Michigan · United States

Non-Technical Contact

Versus Technology, Inc.Henry J Tenarvitz
[email protected]231-946-5868

Test Firm

AHD EMC LaboratoryGordon Helm
[email protected]269-313-2433Fax: 269-429-9016

Technical Specifications

#Rule PartsFrequency RangePower Output
115.231(e)433.9 MHz - 433.9 MHz-
