DWG NO.Rev. 0Page 1 of 4 SPECIFICATIONS FOR COMPACT Bi DIRECTIONAL AMPLIFIER (CBDA) WITH AGC& MGC MODEL:MW-CBDA-ESMR-10W80-A DWG NO.Rev. 0Page 2 of 4 BDA OVERVIEW: The Compact Bi-Directional Amplifier (CBDA) assembly provides an exceptional repeater/booster performances to extend the coverage area of radio communications in buildings and RF shielded environments. Features such as high linearity power amplifiers are contributing for the overall improved system linearity performances. The unit is based on a duplexed path configuration, having sharp out of band attenuation for improved isolation between the receiving and transmitting paths. BLOCK DIAGRAM DESCRIPTION: The CBDA Downlink path receives the RF signals from base station amplifies them and transmits them to the subscriber. The BDA Uplink path receives the RF signals from the subscriber amplifies them and transmits them to the base station. Two duplexers frequency separate the signals to the proper amplifying path and isolate the two signals. For each path two amplifiers do the path signal amplification; a low noise amplifier (LNA) and a high power amplifier. The low noise amplifier has a 30 dB step attenuator at its output. The step attenuator is used to set the BDA repeater gain. The power amplifiers in the BDA have an AGC option switch. When switched on, the AGC circuit limits the amplifier output power. The AGC amplifier has a Power LED lamp that illuminates when the output power has reached the preset power limit. Duplexer Downlink Duplexer Uplink LNA Attenuator Power Monitor PA AGC LNA Attenuator Power Monitor PA AGC BDA RF BLOCK DIAGRAM TO BASE TO MOBILE DWG NO.Rev. 0Page 3 of 4 ELECTRICAL SPECIFICATIONS: Frequency Range (MHz) Down Link (Base to Mobile): 851 - 866 Up Link (Mobile to Base) : 806 - 821 Passband Gain @Min attenuation 80 dB nominal Passband Ripple +/- 1.5 dB max Manual Attenuation Range 0 to 30 dB in 2 dB steps Isolation between up and down link90 dB typical Noise Figure 6.0 dB max Amplifier Power Output @1 dB Compression Down Link: 10 Watts minimum Up Link : 1 Watt minimum 3rd Order output Intercept pointDown Link: +50 dBm typical Up Link : +45 dBm typical Impedance level 50 ohms V.S.W.R In/Out 1.5 : 1 max AGC Attenuation Range25 dB typical AGC Factory Power Preset @ Uplink @Downlink +24 dBm nom. +30 dBm nom. Power Supply: 110/220V AC, 50-60 Hz * same specifications for both paths unless specified. MECHANICAL SPECIFICATIONS: Size mm(Inch): 265(10.4) x 250(9.8) x140(5.5) RF Connectors: N-type Female Weight: 9 kg. Approx. ENVIROMENTAL CONDITIONS: Operating temperature: - 30 ° C to + 50 ° C Storage temperature : - 50 ° C to + 90 ° C DWG NO.Rev. 0Page 4 of 4 MECHANICAL OUTLINE

CBDAESMR10W-PART LIST Part No. Description Quantity ZWS-100PF-15 POWER SUPPLY 1 300HA65000 PRE AMP. 2 300DA48000 1W AMP. +AGC, 15V 1 GRF2022-AGC 10W AMP. 800-1000MHz 10W 1 CD836/15SK-D2/3 DIPLEXER 2 SM86-11SMA-16SMA-50CM CABLE ASSEMBLY W01 1 SM86-11SMA(x2)-26CM CABLE ASSEMBLY W02 1 SM86-11SMA-16SMA-9.5CM CABLE ASSEMBLY W03 1 SM86-11SMA-16SMA-36CM CABLE ASSEMBLY W04 1 SM86-11SMA(x2)-26CM CABLE ASSEMBLY W05 1 SM86-11SMA-16SMA-31CM CABLE ASSEMBLY W06 1 300LA30250 BASE 1 300HA63000 COVER ASSEMBLY 1 300LA30450 HEAT SINK RIGHT 1 300LA30550 HEAT SINK LEFT 1 PS001A0620/2800 CONN. PWR-FILTER AC PLUG 1

FCC MPE Calculation Indoor Antenna RF Power = 1.0 W Cable Attenuation = 1 dB Power to Antenna = 0.794 W General Population Limit = (851/150) = 5.67 W/m 2 Antenna Gain = 2.0 dBi Numeric Antenna Gain = 1.58 Minimum Distance The user manual specifies 0.2 m minimum separation distance on page 6 which would result in a power density of: This provides a safety factor of 3.6 dB. m xP GP R D 133.0 67.54 794.058.1 4 = × == ππ 2 22 /50.2 2.04 794.058.1 4 mW x x R GP P D === ππ

FCC MPE Calculation Outdoor Antenna RF Power = 0.250 W Cable Attenuation = 1 dB Power to Antenna = 0.199 W General Population Limit = (806/150) = 5.37 W/m 2 Antenna Gain = 10.1 dBi Numeric Antenna Gain = 10.2 Minimum Distance The user manual specifies 0.3 m minimum separation distance on page 6 which would result in a power density of: This provides a safety factor of 4.8 dB. m xP GP R D 173.0 37.54 199.02.10 4 = × == ππ 2 22 /79.1 3.04 199.02.10 4 mW x x R GP P D === ππ

Duplexer Downlink Duplexer Uplink LNA Attenuator Power Monitor PA AGC LNA Attenuator Power Monitor PA AGC CBDA-ESMR-10W80-A ELECTRICAL SCHEMATICS TO BASE TO MOBILE POWER SUPPLY +13.5 V AC IN POWER ON LED

&%'$(605:/$<287 83/,1.35($03 83/,1.32:(5$03 '83/(;(5 32:(56833/< '83/(;(5 '2:1/,1.32:(5$03 '2:1/,1.35($03

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

Master: PT90PLMT Date: February 25, 2001 Test Report:1W03670 Applicant:Elisra Electronic Systems Ltd. 48 Mivtza Kadesh Street 51203, Bene-Beraq, Isreal Equipment Under Test:MW-CBDA-ESMR-10W80A (EUT)Bi-Directional Amplifier FCC ID:OIWCBDAESMR10W80 In Accordance With:FCC Part 22 & 90 Tested By:Nemko Canada Inc. (Formerly KTL Ottawa Inc.) 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: G. Westwell, Wireless Technologist Date: Total Number of Pages:26 Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 2 of 26 Table of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. General Equipment Specification ........................................................................... 5 Section 3. RF Power Output .....................................................................................................8 Section 4. Occupied Bandwidth................................................................................................ 9 Section 5. Spurious Emissions At Antenna Terminals.......................................................... 14 Section 6. Field Strength of Spurious Emissions................................................................... 23 Section 7. Test Equipment List ............................................................................................... 25 Section 8. Test Diagrams ......................................................................................................... 26 Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 3 of 26 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22 & 90. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit AMP Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Russell Grant, Wireless Group Manager Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any us e whic h a third p a rty ma k e s o f this re p o rt, o r a ny re lia nc e o n o r d e c is io ns to b e ma d e b a s e d o n it, a re the re s p o ns ib ility of such third parties. Nemko Canada Inc. accepts no responsibility fo r d a ma ge s , if a ny, s uffe re d b y a ny third p a rty a s a re s ult o f d e c is io ns ma d e o r a c tio ns b a s e d o n this re p o rt. This report applies only to the items tested. Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 4 of 26 Summary Of Test Data Name Of TestPara. No.Result RF Power Output2.1046Complies Audio Frequency Response2.1047N/A Audio Low-Pass Filter Response2.1047N/A Modulation Limiting2.1047N/A Occupied Bandwidth2.1049Complies Spurious Emissions at Antenna Terminals 2.1051Complies Field Strength of Spurious Emissions2.1053Complies Frequency Stability2.1055N/A Transient Frequency Behavior——N/A Footnotes For N/A’s:This equipment is a bi-directional amplifier and does not use any frequency generating or modulation circuits. . Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 5 of 26 Section 2.General Equipment Specification Manufacturer:Elisra Electronic Systems Ltd. Model No.:MW-CBDA-ESMR-10W80A Serial No.:01041090 Date Received In Laboratory:April 27, 2001 Nemko Identification No.:Item #1 Uplink:806-821MHz, 24dBm Downlink:851-866MHz, 30dBm Emission:D7W Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 6 of 26 Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 7 of 26 Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 8 of 26 Section 3.RF Power Output Para. No.: 2.1046 Test Performed By: Russell GrantDate of Test: May 2, 2001 Minimum Standard:± 1dB Test Results:Complies. Measurement Data:Uplink:24dBm Downlink:30dBm The per channel output power is de-rated according to the number of channels. N tPowerRatedOutpu Where N is the number of channels. Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 9 of 26 Section 4.Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Russell GrantDate of Test: May 2, 2001 Minimum Standard:N/A Test Results:Complies. Measurement Data:See attached graphs. The modulated input/output signals were compared in order to ensure that there is no degradation in the occupied bandwidth. Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 10 of 26 Nemko Canada Inc. FCC PART 22 & 90 PRIVATE LAND MOBILE TRANSMITTER PROJECT NO.: 1W03670 EQUIPMENT: MW-CBDA-ESMR-10W80A Bi-Directional Amplifier FCC ID: OIWCBDAESMR10W80 Page 11 of 26 Nemko Canada Inc. FCC PART 22 &…
