18 JUL 2001 SUMMERIZED PRODUCT INFORMATION MW-FBDA-PCS-A-10W CDMATDMAApplication IS95IS136Modulation 1850-1865 MHzUL 1930-1945 MHzDL Frequency range N.A.UL +30 dBmDL Output power 410No. of channels

QPX@STVQQG` 9PXI X 9PXI 6UUI A6I HPIDUPS ' ! ! ( !" # ! $  !"#$%&' A796Q8T X XDSDIB9D6BS6H #% 68 8I 8I! SAD7@S ! "# ( " #& VQGDI 6HQ ! !#

Page 1 of Rev- 4 01/2001 SPECIFICATIONS for PCS FIBER OPTIC BI-DIRECTIONAL AMPLIFIER UNIT Model No. MW-FBDA-PCS-A-10W Page 2 of Rev- 4 01/2001 FIBER OPTIC BDA GENERAL DESCRIPTION: The FBDA is an interface unit between optical signals carrying RF information, and RF antenna covering a defined user area. The system consists of up link and down link paths. The uplink path receives RF signals from the Mobile antenna and amplifies them and converts them to optical signals. These optical signals are sent to the BTS. The downlink path receives optical signals from the BTS, converts them to RF signals and amplifies these signals using a high power amplifier. The Mobile antenna transmits these RF signals. Block Diagram Description: Uplink Amplifier This is a low noise amplifier with a variable attenuator. Typical gain is 45 dB and attenuation up to 20 dB down. To adjust the gain, use a small screwdriver. Turn clockwise for max gain. The Led goes on at 0 dbm. Variable Step Attenuator This is an active step attenuator having 30 dB range with 2 dB steps. Power Amplifier This is a 10-Watt power amplifier. Typical gain is 46 dB. FiberOptic Transceiver This unit is made of a Fiber Optic Receiver (Laser to RF) and a Fiber Optic transmitter (RF to Laser). Duplexer This duplexer separates the uplink and the downlink path frequencies. It has sharp out of band attenuation for better isolation of receiving and transmitting paths. Page 3 of Rev- 4 01/2001 FUNCTIONAL BLOCK DIAGRAM FBDA SYSTEM BLOCK DIAGRAM Optical Fiber Downlink Uplink TO MOBILE TO BASE Fiberoptic Transmitter Fiberoptic Receiver Duplexer RX Variable Attenuator TX AMP Variable Attenuator Power Amplifier Mobile ANT. BTS High pwr ATTN. DUP. Tx Rx Rfiber RF IN RF Out optical out optical in Rfiber optical in optical Out FBDA RF section BASE SITE FIBEROPTIC CABLE RUN UP TO 20Km Page 4 of Rev- 4 01/2001 SPECIFICATIONS: Uplink (RX)Downlink (TX)Frequency Range 1850-1865 MHz1930-1945 MHz Noise Figure @+25 ° C @ max gain : 10.0 dB maxN.A. Manual Attenuation Range0 to 16 db continuous : 0 to 30dB in 2 dB steps Passband Gain @ min attenuation: 45 dB Nominal: 42 dB Nominal Passband Ripple: ± 1.0 dB typical Up-Link 3 rd Order Intermodulation Products @two tones 0 dBm each at Amplifier Output : 60 dBc typicalN.A. Down-Link 3 rd Order Intermodulation Products @two tones 27 dBm each at Output N.A.: 50 dBc typical Impedance Level: 50 Ohms VSWR In: 1.5 : 1 typ VSWR Out: 2.0 : 1 typ Page 5 of Rev- 4 01/2001 FBDA ALARM SPECIFICATIONS Remote Fault Indication (Summarized alarm) : Alarm is sent on the serial data link of the FO transmitter. Fault List: Power Supply Over-voltage or Under-voltage : Uplink Power Amplifier Over Current or Under Current : Downlink Preamplifier Over Current or Under Current : Downlink Power Amplifier Over Current or Under Current : FO Transceiver Over Current or Under Current : FO Receiver Power fall (Bad Optical Connection) Electrical Fault Indication LED : Illuminated LED on Monitor Box for each Electrical Fault Fiber Optic Connection Fault Indication LED : Illuminated LED on FO Transceiver when Optical Connection is performing Correctly. LED is OFF when FO Receiver Power falls. MECHANICAL SPECIFICATIONS: Size: 300 x 300 x 160 mm approx. Weight: 15 kg. Approx. Type: Weatherproof Enclosure* for Wall Mounted Installation Power Supply : 110 VAC / 1A ENVIRONMENTAL CONDITIONS: Operating temperature : - 30 ° C to + 50 ° C Storage temperature : - 30 ° C to + 70 ° C Weatherproof conditions: Protected to IP66 GENERAL : • AC cable pass through Liquid Tight “Gasket” Fitting. • Fiber cable pass through Liquid Tight “Gasket” Fitting. • Additional rain shield for better weather protection. Page 6 of Rev- 4 01/2001 MECHANICAL OUTLINE DRAWING

FBDAPCSA10W- PART LIST Part No. Decription Quantity 8A325N-S-13-2-0 FIBER OPTIC TRANCEIVER 1 300NA44000 PCS FIBER OPTIC DRIVED 1 PCM4Q5AKV-AGC RF AMP. 1800-2000MHz 10W 1 ZWS-100PF-15 POWER SUPPLY 1 CD1898/15SK-E1 DIPLEXER PCS BAND A 1 300JA1050 CHASIS 1 RG223-25N-16SMA-20CM CABLE ASSEMBLY W01 1 RG223-11SMA-16SMA-48 CABLE ASSEMBLY W02 1 RG223-11SMA(x2)-11CM CABLE ASSEMBLY W03 1 RG223-11SMA(x2)-44CM CABLE ASSEMBLY W04 1 RG223-11SMA-16SMA-36CM CABLE ASSEMBLY W05 1 RG223-11SMA-16SMA-50CM CABLE ASSEMBLY W06 1 300JA14000 BDA MONITOR 1 300JA10450 CASE REWORK 300JA10550 HEATSINK PG13.5 CABLE GLAND FOR OPTICAL FIBER 1 3801 METAL CORD GRIP FITTING 1 2408NL-04W-B40 FAN 1

FCC MPE Calculation RF Power = 1.0 W Cable Attenuation = 1 dB Power to Antenna = 0.794 W General Population Limit = 10 W/m 2 Antenna Gain = 10.1 dBi Numeric Antenna Gain = 10.2 Minimum Distance The user manual specifies 0.8 m minimum separation distance in section 2.7 which would result in a power density of: This provides a safety factor of 10 dB. m xP GP R D 254.0 104 794.02.10 4 = × == ππ 2 22 /1 8.04 794.02.10 4 mW x x R GP P D === ππ

Optical Fiber Downlink Uplink TO MOBILE TO BASE Fiberoptic Transmitter Fiberoptic Receiver Duplexer RX Variable Attenuator TX Power Amplifier Power Monitor PA AGC FBDA MONITOR CURRENT SENSORS OPTICAL ALARM SUMMERIZED ALARM OUT FAN POWER SUPPLY +13.5 V AC CORD +V IN FBDA-PCS-A-10W ELELCTRICAL SCHEMATICS
