OJ7968FRS0401Family Radio Transceiver

Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6A Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6B Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6C Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6D Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6E Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6F Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6G Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6H Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6I Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6J Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6K Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6L Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6M Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6N Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6O Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 6P

Date: Aug 17, 01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We would like to keep confidential our schematics, block diagram, operational description, and tuning procedure of our model FCC ID OJ7968FRS0401 as we have signed non-disclosure agreement with our customer not to disclose any technical information thereof relating to this model to a third party and we are obliged to abide by this agreement. We would appreciate if you will keep our product information confidential. Yours sincerely,

MODEL: VC968 FAMILY RADIO SERVICE DC 6V (1.5V X 4”AAA”/UM-3 BATTERIES) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and(2)this device must accept any interference received, including interference that may cause undesired operation. FCC ID: OJ7968FRS0401 Made in China Victory Concept Ind. Ltd. FCC ID: OJ7968FRS0401 Job #: 435AH1 Exhibit #: 1

TABLE OF CONTENTS LIST APPLICANT: VICTORY CONCEPT IND. LTD. FCC ID: OJ7968FRS0401 TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED & RF POWER OUTPUT PAGE 3......MODULATION CHARACTERISTICS AND OCCUPIED BANDWIDTH PAGE 4......METHOD OF MEASURING OCCUPIED BANDWIDTH PAGE 5......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 6......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 7......FREQUENCY STABILITY PAGE 8......LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3A........EXTERNAL PHOTO - FRONT VIEW EXHIBIT 3B........EXTERNAL PHOTO - REAR VIEW EXHIBIT 3C........INTERNAL PHOTO - SOLDER SIDE EXHIBIT 3D........INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 4.........BLOCK DIAGRAM EXHIBIT 5A-5C.....SCHEMATIC EXHIBIT 6A-6P.....USER'S MANUAL EXHIBIT 7A-7B.....CIRCUIT DESCRIPTION EXHIBIT 8A-8B.....TUNING PROCEDURE EXHIBIT 9.........AUDIO FREQUENCY RESPONSE GRAPH EXHIBIT 10A.......MODULATION LIMITING PLOT - 300 Hz EXHIBIT 10B.......MODULATION LIMITING PLOT - 1000 Hz EXHIBIT 10C.......MODULATION LIMITING PLOT - 3000 Hz EXHIBIT 11........AUDIO LOW PASS FILTER GRAPH EXHIBIT 12A.......OCCUPIED BANDWIDTH CW PLOT EXHIBIT 12B.......OCCUPIED BANDWIDTH PLOT EXHIBIT 13........TEST SETUP PHOTOGRAPH APPLICANT: VICTORY CONCEPT IND. LTD. FCC ID: OJ7968FRS0401 REPORT #: T:\CUS\V\VICTORY\435AH1\435AH1RPT.doc PAGE: TABLE OF CONTENTS GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2)VICTORY CONCEPT IND. LTD.will manufacture the FCCID: OJ7968FRS0401 FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. The UUT is a PTT Radio with a maximum duty cycle of 50%. VICTORY CONCEPT IND. LTD. RM. 1314-1315, KWONG SANG HONG CENTRE 151-153 HOI BUN ROAD, KWUN TONG KOWLOON HONG KONG 2.1033 (c) TECHNICAL_DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 6A-6P. 2.1033(c) (4) Type of Emission: 10K6F3E 95.631 Bn = 2M + 2DK M = 3000 D = 2.0K Bn = 2(3.0)+2(2.3) = 10.6K Authorized Bandwidth 12.5KHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.500Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varing the power. The Maximum Output Power Measured from this device is: .025 Watts effective radiated power. 95.647 The antenna is an intergral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 6.0 Volts DC Ice = 0.25A. Pin = 1.5 Watts APPLICANT: VICTORY CONCEPT IND. LTD. FCC ID: OJ7968FRS0401 REPORT #: T:\CUS\V\VICTORY\435AH1\435AH1.RPT PAGE #: 1 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included in as EXHIBIT 8A-8B. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 5A-5C of this report. The block diagram is included as EXHIBIT 4 of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identifica tion label is included as exhibit No. 1. and No. 2. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields - See EXHIBIT 3A-3D. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. 2.1046(a) RF_power_output. 95.639 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = .25 Watts ERP R.F. POWER OUTPUT HP TEST SET UP Spectrum Analyzer /-------\ /-----------------\ | | | | TRANSMITTER | | | | | UNDER TEST WITH | \--| | | INTERNAL ANTENNA| | | | \-----------------/ | | | | | \-------/ | | |<-- 3.0 meters-->| /-------------\ | SIGNAL | DIPOLE | Tuned, Calibrated | GENERATOR | ANTENNA | Antenna which may | |----------/ be raised from 1 \-------------/ to 4 meters above ground and changed in polarization Equipment placed 80cm above ground on a rotatable platform. APPLICANT: VICTORY CONCEPT IND. LTD. FCC ID: OJ7968FRS0401 REPORT #: T:\CUS\V\VICTORY\435AH1\435AH1.RPT PAGE #: 2 2.1047(a)(b) Modulation_characteristics: AUDIO_FREQUENCY_RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown in exhibit 9. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. 2.1047(b) Audio_input_versus_modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are shown in exhibits 10A - 10C. Curves are provided for audio input frequen cies of 300, 1000, and 3000 Hz. 95.637(b) Post Limiter Filter The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20KHz the filter must have an attenuation of 60log (f/3) greater that the attenuation at 1KHz. See the plot; exhibit 11. 2.989(c) EMISSION BANDWIDTH: 95.633(c) Data in the plots shows that the sidebands from greater than 50% to 100% of the authorized bandwidth must be attenuated by at least 25dB and from 100 to 250% the sidebands must be attenuated by at least 35dB. Beyond 250% the sidebands must be attenuated by at least 43+log10(TP). The transmitter was modulated wi…
