OJFE62-N3-37Remote Unit

Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 1 Everon 6200 A3-E3-N3 Specification Sheet Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 2 Features 1200MHz Transmission Bandwidth over 1 fiber 8 x 3GPP Band per Remote Sub 6GHz Up to 200MHz IBW Dry contact Alarm 25dBm Maximum Output Power per Band Support Band or Channel Selective filter Cascading up to 6 levels E62-A3 - Access Unit Chassis The E62-A3 – Access Unit Chassis is a standard 19-inch 2U rack-mounted shelf (1U fan unit included), which serves as the host for Everon™ 6200. The E62-A3 provides coupling access to radio signal sources of multi- operator, multi-system, and multi-band, forming digital optical signals and distributing static capacity distribution to fiber-connected other type devices. One A3 supports up to eight optical interfaces connected to E3s (Expansion Unit) or N3RUs (Remote Unit). This document describes the installation procedure for the E62-N3 remote unit. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC License to operate this device. NOTE: Only authorized person can enter the area where the antenna is installed. And the person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 3 E62-AU-AC – Active Combiner Module The E62-AU-AC – Active Combiner Module is the interface to the operator base station signal source equipment. Each module has four QMA ports for signal input from the maximum four operators. One Access Unit can be equipped with up to four modules. In accordance with wireless service provider standards, it is not advised to use digital repeaters as a signal source for Corning solutions. E62-E3-O - Expansion Unit The E62-E3-O – Expansion Unit is a standard 19-inch 1U rack-mounted shelf, which serves as the interface between the Primary A3 and the Remote Unit for the capacity expansion of system. E62-N3RU – Low Power Remote Unit Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 4 The E62-N3RU is a low-power remote unit supporting cellular technologies on fiber optic cable using the CPRI protocol. The N3 is ideal for multi-operator multi-band, static capacity distribution deployments of cellular services in small-to-medium coverage areas. The N3 supports up to four 25 dBm RF channels. The N3 converts an optical signal to RF and then transmits at the relevant 3GPP band and receives the analog RF signal, conditions it, and converts it back to optical for routing to the E3 or A3. The socket-outlet shall be easily accessible. Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Specifications E62-A3 - Access Unit Chassis Supported Bands Band 3GPP Band Downlink Uplink Max IBW 600MHz 71 617-652 663-698 35 700 LU 12 & 13 729-756 699-716 & 777-787 27 700MHz LUPS 12 & 13 & 14 728-768 698-716 & 776-798 40 850E MHz 26 859-894 814-849 35 1900MHz 25 1930-1995 1850-1915 65 2100MHz 66E 2110-2200 1710-1780 90 2300MHz 30 2350-2360 2305-2315 10 2500MHz TDD 41 2496-2690 2496-2690 194 C-Band-1 n78 3450-3800 3450-3800 200 Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 5 C-Band-2 n77 3700-3980 3700-3980 200 Interface Access Unit RF Interface QMA Female Optical Connector Type 8 x 25 GBps SFP+ Interfaces 6 to 8 optical connections to E3-O or N3 2 optical connections to Secondary A3s Transmission Rate 25 GB/s AU-AC modules 4 x AU-AC modules per chassis (RF interface with BTS) Full 3GPP Band per Module (up to 200 MHz) Band Support 12x 3GPP bands over 1 fiber core (using 2 x Secondary A3) Dry contact Alarms 1x RJ45 (2x in, 2x out) Maintenance Interface Ethernet RJ45 AU-AC power level (dB) 0dBm to +15 dBm Input Power Range for each port Electrical Electromagnetic Compatibility/Interference (EMC/EMI) 3GPP TS38.113 Maximum Power Consumption 85W AC Power 100-240v AC, 50/60Hz DC Power 48VDC ± 20% Environmental Mean Time Between Failure (MTBF) > 220,000 hours Operating Temperature -10°C to +45°C Storage Temperature -40°C to +85°C Humidity 0% to 90% (Noncondensing) Cooling Active Installation Wall or 19-in Rack Ingress Protection Rating IP30 (Indoor) Mechanical AU (Width / Height / Depth / Weight) 440mm / 88mm / 329mm / 8.0kg 17.32in / 3.46in / 12.95in / 17.64lb E62-E3-O - Expansion Unit Interface Optical Connector Type 16 x 25 GBps SFP+ Interfaces 14x optical connections to N3RU 1x optical connection to Primary A3 or upper level E3 1x optical connection to lower level E3 Transmission Rate 25 GB/s Cascading Up to 5 x E3-O per Optical connection Dry contact Alarms 1x RJ45 (2x in, 2x out) Maintenance Interface Ethernet RJ45 Electrical Electromagnetic Compatibility/Interference (EMC/EMI) 3GPP TS38.113 Maximum Power Consumption 65 W AC Power 100-240 VAC, 50/60 Hz DC Power 48VDC ± 20% Environmental Corning Optical Communications E62-A3-E3-N3 Specification Sheet | 28 March 28, 2022 | Page 6 Mean Time Between Failure (MTBF) > 22…

Text truncated - open the document above for the full version.

Corning Restricted Corning Optical Communication LLC Date: 2022-7-05 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: OJFE62-N3-37 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Corning Optical Communication LLC. This authorization is valid until further written notice from the applicant. Name (Printed): Jyotin Basrur Title: Senior Director, Product Line Management Signature: On behalf of Company: Corning Optical Communication LLC Telephone: 774 772 0814

Corning Restricted Corning Optical Communication LLC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Corning Optical Communication LLC 6 Concord Road Shrewsbury Massachusetts United States 01545 Regarding: Confidentiality Request regarding application for FCC ID: OJFE62-N3-37 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Tune-up BOM The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Jyotin Basrur Title: Senior Director, Product Line Management Company Name: Corning Optical Communication LLC

Compliance Certification Services (Kunshan) Inc. Page: 1 of 7 Appendix Photographs of External photo for KSCR2206001045AT Test Model No.: E62-N3 Compliance Certification Services (Kunshan) Inc. Page: 2 of 7 EUT Constructional Details (EUT Photos) Internal Antenna Compliance Certification Services (Kunshan) Inc. Page: 3 of 7 Compliance Certification Services (Kunshan) Inc. Page: 4 of 7 Compliance Certification Services (Kunshan) Inc. Page: 5 of 7 External Antenna Compliance Certification Services (Kunshan) Inc. Page: 6 of 7 Compliance Certification Services (Kunshan) Inc. Page: 7 of 7

P/N:E62-N3-4-3537-I REL: V1.0 S/N:362215XXXX REV: A00 MAC: xx :xx:xx:xx:xx:xx Everon 6200 50 30 CLASS 1 LASER PRODUCT 30 33 FCC ID φOJFE62-N3-37 FCC ID φOJFE62-N3-37 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING! This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC License to operate this device. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. 40 20 40 20 Remote Unit, E62-N3 801239 Made in China 07-2022 Input: 48V 2A

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 Appendix Photographs of Internal photo for KSCR2206001045AT Test Model No.: E62-N3 Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Internal Antenna Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 External Antenna Compliance Certification Services (Kunshan) Inc. Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 1 of 7 1 of 7 Eric Lin EMC Lab Manager 1 Cover Page RF MPE REPORT Application No.: KSCR2206001045AT FCC ID: OJFE62-N3-37 Applicant: Corning Optical Communications LLC Address of Applicant: 6 Concord Road, Shrewsbury, MA 01545 United States Manufacturer: Corning Optical Communications LLC Address of Manufacturer: 6 Concord Road, Shrewsbury, MA 01545 United States Factory: Sunwave Communications Co., Ltd Address of Factory: 581 Houju Avenue, Binjinag District, Hangzhou, China Equipment Under Test (EUT): EUT Name: Remote Unit Model No.: E62-N3 Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2022-06-24 Date of Test: 2022-06-26 to 2022-07-15 Date of Issue: 2022-07-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 2 of 7 Revision Record Version Description Date Remark 00 Original 2022-07-19 / Authorized for issue by: Damon Zhou / Project Engineer Eric Lin / Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 3 of 7 2 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 CONTENTS ................................................................................................................................................ 3 3 GENERAL INFORMATION ........................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ........................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS ................................................................................................................. 4 3.3 TEST LOCATION .................................................................................................................................... 5 3.4 TEST FACILITY ...................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................. 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ........................................................................... 6 5 MEASUREMENT AND CALCULATION .................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................. 7 5.2 MPE CALCULATION .............................................................................................................................. 7 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 4 of 7 3 General Information 3.1 General Description of E.U.T. Power supply: DC 48V 3.2 Technical Specifications Frequency Band: 3700MHz to 3980MHz Antenna Type: External&Internal Antenna Gain: 3dBi (Provided by manufacturer) Modulation Type: 5G NR: CP-OFDM: QPSK, 16QAM, 64QAM, 256QAM MIMO: 4T4R MIMO,2T2R MIMO,SISO Temperature Range: -10°C to 45°C Note: The antenna gain value is provided by the customer. The test lab will not be responsible for wrong test result due to incorrect information about antenna gain values. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 5 of 7 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC (Designation Number: CN1172) Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED (CAB identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI (Member No.: 1938) The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-20134, R-11600, C-11707, T-11499, G-10216 respectively. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 6 of 7 4 Test Standards and Limits 4.1 FCC Radiofrequency radiation exposure limits: According to§1.1310, the limit for general population/uncontrolled exposures Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: 5G N77 is 1mW/cm 2 . Compliance Certification Services (Kunshan) Inc. Report No.: KSCR220600104503 Page: 7 of 7 5 Measurement and Calculation 5.1 M…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 12 Appendix A for Bandwidth 5GNR Band n77_ SCS 30K Intra-band Continuous CA Nominal Bandwidth Modulation Test result (MHz) 99% OBW 26dB bandwidth LCH MCH HCH LCH MCH HCH 10 QPSK 8.631 8.614 8.605 9.292 9.270 9.203 20 QPSK 18.259 18.223 18.260 19.120 19.180 19.160 40 QPSK 37.830 37.815 37.771 39.440 39.430 39.360 60 QPSK 57.907 57.816 57.842 60.270 60.180 60.400 80 QPSK 77.475 77.144 77.361 80.470 80.270 80.350 100 QPSK 97.547 97.096 97.664 100.600 100.600 100.700 10+10 QPSK 18.045 18.034 18.550 19.020 19.650 19.990 80+80 QPSK 155.890 155.030 156.54 161.900 162.200 161.700 60+60+60 QPSK 177.150 175.900 176.810 190.200 183.000 198.600 40+40+40+40 QPSK 157.050 157.070 158.650 166.600 162.800 168.100 20+20+20+20+20 QPSK 97.894 98.724 97.812 124.800 135.100 119.200 20+20+20+20+20+20 QPSK 117.340 117.030 118.550 148.900 150.500 150.700 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 10M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 2 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 3 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 40M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 4 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 60M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 5 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 80M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 6 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 100M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 7 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 10M+10M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 8 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 80M+80M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 9 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 60M+60M+60M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 10 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 40M+40M+40M+40M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 11 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M QPSK Low channel QPSK Middle channel QPSK High channel Compliance Certification Services (Kunshan) Inc. Page: 12 of 12 5GNR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M+20M QPSK Low channel QPSK Middle channel QPSK High channel

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Appendix B for Conducted band edge 5G NR Test Data: BW Arrange SCS (kHz) Frequency Modulation RB Allocation Test Result Size Offset Single Carrier 10 30 LCH / MCH / HCH QPSK Full 0 Pass 20 LCH / MCH / HCH QPSK Full 0 Pass 2 Carriers contiguous 10+10 30 LCH / MCH / HCH QPSK Full 0 Pass 80+80 LCH / MCH / HCH QPSK Full 0 Pass 3 Carriers contiguous 60+60+60 30 LCH / MCH / HCH QPSK Full 0 Pass 4 Carriers contiguous 40+40+40+40 30 LCH / MCH / HCH QPSK Full 0 Pass 5 Carriers contiguous 20+20+20+ 20+20 30 LCH / MCH / HCH QPSK Full 0 Pass 6 Carriers contiguous 20+20+20 +20+20+20 30 LCH / MCH / HCH QPSK Full 0 Pass Note: 1) Test results of QPSK/16QAM/64QAM/256QAM and different RB configuration have been evaluated, and only the worst results are recorded. Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 10M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 20M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 40M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 60M _ Low channel+ High channel Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 80M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 100M _ Low channel+ High channel Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 10M+10M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 80M+80M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 60M+60M+60M _ Low channel+ High channel Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 40M+40M+40M+40M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M _ Low channel+ High channel 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M+20M _ Low channel+ High channel Compliance Certification Services (Kunshan) Inc. Page: 6 of 6

Compliance Certification Services (Kunshan) Inc. Page: 1 of 54 Appendix C for Conducted Spurious Emission 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 10M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 2 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 3 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 4 of 54 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 20M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 5 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 6 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 7 of 54 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 40M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 8 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 9 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 10 of 54 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 60M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 11 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 12 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 13 of 54 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 80M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 14 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 15 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 16 of 54 5G NR Band n77 _ SCS 30K, Nominal Bandwidth: 100M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 17 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 18 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 19 of 54 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 10M+10M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 20 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 21 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 22 of 54 5G NR Band n77 _ SCS 30K In…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 28 of 54 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 40M+40M+40M+40M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 29 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 30 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 31 of 54 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 32 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26GHz QPSK Middle channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 33 of 54 QPSK High channel - 9kHz~150KHz QPSK High channel – 150KHz~30MHz QPSK High channel - 30MHz~1GHz QPSK High channel -1GHz~12.75GHz QPSK High channel – 12.75GHz~26GHz QPSK High channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 34 of 54 5G NR Band n77 _ SCS 30K Intra-band Continuous CA, Nominal Bandwidth: 20M+20M+20M+20M+20M+20M QPSK Low channel - 9kHz~150KHz QPSK Low channel – 150KHz~30MHz QPSK Low channel - 30MHz~1GHz QPSK Low channel -1GHz~12.75GHz QPSK Low channel – 12.75GHz~26GHz QPSK Low channel - 26GHz~44GHz Compliance Certification Services (Kunshan) Inc. Page: 35 of 54 QPSK Middle channel - 9kHz~150KHz QPSK Middle channel – 150KHz~30MHz QPSK Middle channel - 30MHz~1GHz QPSK Middle channel -1GHz~12.75GHz QPSK Middle channel – 12.75GHz~26G…
