The Wireless Network System provides coverage by routing RF signals from BTS (base transmit station) units, trough optic fibers to remote areas where the signals are converted back to RF and interfaced to antennas covering the remote area. All system elements can be remotely controlled and monitored from a single location. The system consists of the following elements: Base Unit (BU) – Convert the RF signal received from the RIU to an optic signal that is then split and routed via optic fiber to Remote Hub Units located in remote locations. Remote Hub Units (RHUs) – Convert the optic signal to an RF signal and feeds it to the antennas in the remote areas in order to provide the required coverage. The RHU provides coax connections to up to four antennas. The RHU filters and amplifiers the optic signal received from the BU according to the service it supports.

01 August 2012 Concerning the Mobile Access FCC ID: OJFMA1K-CP-HLN. No manual tune-up procedure required. Thank you, Steve Blum Product Manager Corning Mobileaccess 8391 Old Courthouse Rd Suite 300 Vienna VA 22182-3819 Corning MobileAccess 8391 Old Courthouse Road, Suite 300, Vienna, VA 22182 Tel: +1(866)436-9266, +1(703)848-0200 TAC: +1(800)787-1266, Fax: +1(703)848-0280 www.corning.com/mobileaccess

2 587.01500/ cm mW f= 2 1 cm mW R.F Exposure/Safety Calculation for 1000-CELL-PCS4E-HLN Remote Hub Unit The E.U.T. is rack or wall mounted. The typical distance between the E.U.T. and the general population is >40 cm. Calculation of Maximum Permissible Exposure (MPE) Based on Section 1.1307(b)(1) Requirements (a) FCC limit at 881.0 MHz is: FCC limit at 1960.0 MHz is: Using table 1 of Section 1.1310 limit for general population/uncontrolled exposures, the above level is an average over 30 minutes. (b) The power density produced by the E.U.T. is P t - Transmitted Peak Power (worst case) G T - Antenna Gain, dBi R- Distance from Transmitter (c) Peak power density at worst case continuous transmission: Band Modulation Pt (mW) Antenna type G T (dBi) R (cm) S AV (mW/cm 2 ) Spec (mW/cm 2 ) CELL CDMA 223.87 External 12.5 40 0.198 0.587 GSM 169.82 External 12.5 40 0.150 0.587 W-CDMA 275.42 External 12.5 40 0.244 0.587 LTE-64QAM 281.84 External 12.5 40 0.249 0.587 PCS CDMA 803.53 External 12.5 40 0.711 1 GSM 615.18 External 12.5 40 0.544 1 W-CDMA 963.83 External 12.5 40 0.852 1 LTE-64QAM 1047.13 External 12.5 40 0.926 1 2 4R GP S tt π =

Test Report E119931.00 Corning MobileAccess Page 1 of 91 FCC ACC M Ver 1.1 05Mayl 2000 DATE: 31 July 2012 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for Corning MobileAccess Equipment under test: Remote Hub Unit 1000-CELL-PCS4E-HLN* * See customer’s declaration on page 6. Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E119931.00 Corning MobileAccess Page 2 of 91 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for Corning MobileAccess Remote Hub Unit FCC ID: OJFMA1K-CP-HLN This report concerns: Original Grant: X Class II change: Class I change: Equipment type: PCS Licensed Transmitter Limits used: 47CFR Parts 22, 24 Measurement procedure used is ANSI C63.4-2003. Substitution Method used as in ANSI/TIA-603-C: 2004 Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Steve Blum ITL (Product Testing) Ltd. Mobile Access Networks Kfar Bin Nun 8391 Old Courthouse Rd., Suite #300 D.N. Shimshon 99780 Vienna, VA. 22182 Israel U.S.A. e-mail [email protected] Tel: +1-541-758-2880 Fax: +1-703-848-0260 e-mail: [email protected] Test Report E119931.00 Corning MobileAccess Page 3 of 91 FCC ACC M Ver 1.1 05Mayl 2000 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 5 1.1 Administrative Information ................................................................................. 5 1.2 List of Accreditations ......................................................................................... 7 1.3 Product Description ........................................................................................... 8 1.4 Test Methodology .............................................................................................. 8 1.5 Test Facility ....................................................................................................... 8 1.6 Measurement Uncertainty ................................................................................. 8 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 9 2.1 Justification ........................................................................................................ 9 2.2 EUT Exercise Software ..................................................................................... 9 2.3 Special Accessories .......................................................................................... 9 2.4 Equipment Modifications ................................................................................... 9 2.5 Configuration of Tested System ...................................................................... 10 3. CONDUCTED AND RADIATED MEASUREMENT TEST SET-UPS PHOTO -------------- 11 4. PEAK OUTPUT POWER CELL ------------------------------------------------------------------------ 12 4.1 Test Specification ............................................................................................ 12 4.2 Test procedure ................................................................................................ 12 4.3 Test Results..................................................................................................... 12 4.4 Test Equipment Used, Peak Output Power CELL .......................................... 15 5. OCCUPIED BANDWIDTH CELL ----------------------------------------------------------------------- 16 5.1 Test Specification ............................................................................................ 16 5.2 Test Procedure ................................................................................................ 16 5.3 Test Results..................................................................................................... 17 5.4 Test Equipment Used, Occupied Bandwidth, CELL ....................................... 30 6. OUT OF BAND EMISSIONS AT ANTENNA TERMINALS CELL ----------------------------- 31 6.1 Test Specification ............................................................................................ 31 6.2 Test procedure ................................................................................................ 31 6.3 Test Results..................................................................................................... 31 6.4 Test Equipment Used, Out of Band Emission at Antenna Terminals, CELL .. 36 7. BAND EDGE SPECTRUM CELL ---------------------------------------------------------------------- 37 7.1 Test Specification ............................................................................................ 37 7.2 Test procedure ................................................................................................ 37 7.3 Test Results..................................................................................................... 38 7.4 Test Equipment Used, Band Edge Spectrum, CELL ...................................... 43 8. OUT OF BAND EMISSIONS (RADIATED) CELL ------------------------------------------------- 44 8.1 Test Specification ............................................................................................ 44 8.2 Test Procedure ................................................................................................ 44 8.3 Test Results..................................................................................................... 45 8.4 Test Equipment Used, Out of Band Emissions (Radiated), CELL .................. 46 9. PEAK OUTPUT POWER PCS -------------------------------------------------------------------------- 47 9.1 Test Specification ...................................…
