OJFPS-MP-08Remote Unit

CorningOpticalCommunications UserManual | Page1 GENERALINFORMATION PS-MPisadualportdigitaltransportplatformsupportingpublicsafetycoverageonfibre opticcableusingtheCPRIprotocol.ItadoptsFeed-ForwardTechnology,allowingfor deploymentoflegacynarrowbandsolutionswhilestillbenefitingfromthedigital transmissionandfilteringfunctionality.ThisplatformisidealforP25,DMR,PMR,GSM-R& Tetratechnologyeitherasstandaloneorcomplimentarywithwidebandcellular deployments. ThePS-MPsystemsupportsprogrammablebandorchannelselective.ThePS-MPsupports upto37dBmoutputperban.ThePS-MPconvertsanopticalsignaltoRFandthentransmits attherelevantbandandreceivestheanalogRFsignal,conditionsit,andconvertsitbackto opticalforroutingtothePS-AU. Medium-Power(PS-MP/PS-AU-AIR) UserProgrammingManual PublicSafety ThisdocumentdescribestheUserManualforthePS-MPunit. ThisisNOTaCONSUMERdevice.ItisdesignedforinstallationbyFCCLICENSEESand QUALIFIEDINSTALLERS.YouMUSThaveanFCCLICENSEorexpressconsentofanFCC Licensetooperatethisdevice.NOTE:Onlyauthorizedpersoncanentertheareawherethe antennaisinstalled.Andthepersonisfullyawareofthepotentialforexposureandcanexercise controloverhisorherexposurebyleavingtheareaorbysomeotherappropriatemeans. AwarenessofthepotentialforRFexposureinaworkplaceorsimilarenvironmentcanbeprovided throughspecifictrainingaspartofaRFsafetyprogram. CorningOpticalCommunications UserManual | Page2 1.Content 1.CONTENT .................................................................................................................................................................................................... 2 2.PREFACE ..................................................................................................................................................................................................... 4 WARNINGS ........................................................................................................................................................................................................... 4 SITECONSIDERATIONS ............................................................................................................................................................................................ 4 ENVIRONMENTALCONSIDERATIONS .......................................................................................................................................................................... 5 WARNINGMARKS .................................................................................................................................................................................................. 5 3.INSTALLATIONPREPARATION ................................................................................................................................................................... 7 UNPACKINGANDINSPECTING ................................................................................................................................................................................... 7 InspectingthePackingContainer ................................................................................................................................................................. 7 UnpackingtheDevice ................................................................................................................................................................................... 7 VerifyingtheContents .................................................................................................................................................................................. 8 InspectingtheDevice .................................................................................................................................................................................... 8 INSTALLATIONPREPARATION .................................................................................................................................................................................... 8 SiteInvestigation .......................................................................................................................................................................................... 8 InstallationTools ........................................................................................................................................................................................... 9 TorqueSettings ............................................................................................................................................................................................. 9 Clearance ...................................................................................................................................................................................................... 9 Grounding ..................................................................................................................................................................................................... 9 4.INSTALLINGTHEACCESSUNIT(PS-AU) .................................................................................................................................................. 10 ACCESSORIESLIST ................................................................................................................................................................................................ 10 RACKINSTALLATION ............................................................................................................................................................................................. 11 WALLINSTALLATION ............................................................................................................................................................................................. 16 PS-AUMOUNTINGDIMENSIONSPACING ......................................................................…

Text truncated - open the document above for the full version.

Corning Restricted Corning Optical Communication LLC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Corning Optical Communication LLC, 6 Concord Road, Shrewsbury, MA 01545 United States For FCC ID: OJFPS-MP-08; Model number: PS-MP According to: FCC KDB 935210 D02 Signal Boosters Certification v04r02 For PART 90 booster device, Section V (g) requirement: (g) Attestation (must be non-confidential exhibit, signed by the applicant; signature by test lab, agent, or TCB is not acceptable) should include: (1) Warning label messages and Class B disclosure will be also shown in online and point-of-sale marketing materials and on outside packaging of device: For PART 20 booster device, IV.(d) requirement: (d)) Attestation (must be non-confidential exhibit, signed by the applicant; signature by test lab, agent, or TCB is not acceptable) should include: (1) Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device We Corning Optical Communication Wireless declared our Warning label messages and Class B disclosure will be also shown in online and point-of-sale marketing materials and on outside packaging of device. WARNING: This is a part 20 and part 90 class B signal booster device. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. You MUST register Class B signal boosters (as defined in 47 CFR 90.219) online at www.fcc.gov/signal-boosters/registration. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. Sincerely, Name (Printed): Jyotin Basrur Title: Senior Director, Product Line Management Signature： On behalf of Company: Corning Optical Communication LLC Corning Restricted © 2020 Corning Incorporated. All Rights Reserved.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Corning Optical Communication LLC Address 6 Concord Road, Shrewsbury, MA 01545 Grantee Code OJF FCC ID OJFPS-MP-08 Authorized Contact Name Jyotin Basrur Contact Email [email protected] Contact Phone 774 772 0814 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:2021/12/08 Print Name: Jyotin Basrur Title: Senior Director, Product Line Management *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Corning Restricted Corning Optical Communication LLC Date: 2021-12-08 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: OJFPS-MP-08 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Corning Optical Communication LLC. This authorization is valid until further written notice from the applicant. Name (Printed): Jyotin Basrur Title: Senior Director, Product Line Management Signature: On behalf of Company: Corning Optical Communication LLC Telephone: 774 772 0814

Corning Restricted Corning Optical Communication LLC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Corning Optical Communication LLC 6 Concord Road, Shrewsbury, MA 01545 Regarding: Confidentiality Request regarding application for FCC ID: OJFPS-MP-08 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Tune-up BOM The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Jyotin Basrur Title: Senior Director, Product Line Management Company Name: Corning Optical Communication LLC

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Page 1 of 6 External Photos Applicant: Corning Optical Communications LLC Address of Applicant: 6 Concord Road, Shrewsbury, MA 01545 United States Equipment Under Test (EUT): Product Name: Remote Unit Model No.: PS-MP Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 Page 2 of 6 Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 Page 3 of 6 Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 Page 4 of 6 Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 Page 5 of 6 Compliance Certification Services (Kunshan) Inc. Page: 6 of 6 Page 6 of 6 End

Made in China 07-2021 P/N: E62-PS-MP-AC-7-8 REL: V1.0 S/N: 362130XXXX REV: A0 Input: 100-240V~ 3A 50/60Hz FCC ID ： OJFPS-MP-08 PS-MP Remote Unit, PS-MP Everon 6200 TM CLASS 1 LASER PRODUCT Type 4 Enclosure WARNING! This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS . You MUST have an FCC LICENSE or express consent of an FCC License to operate this device. You MUST register Part 90 Class Bsignal Boosters (as defined in 47 CFR 90.219) online at www.fcc.gov/signal-boosters /registration. Unauthorized use may result in significant forfeiture penalties, includingpenalties in excess of $100,000 for each continuingviolation. Part90 and Part 20 Signal Booster THIS IS A 90.219 CLASS B DEVICE

Compliance Certification Services (Kunshan) Inc. Page: 1 of 14 Page 1 of 14 Internal Photos Applicant: Corning Optical Communications LLC Address of Applicant: 6 Concord Road, Shrewsbury, MA 01545 United States Equipment Under Test (EUT): Product Name: Remote Unit Model No.: PS-MP Compliance Certification Services (Kunshan) Inc. Page: 2 of 14 Page 2 of 14 Compliance Certification Services (Kunshan) Inc. Page: 3 of 14 Page 3 of 14 Compliance Certification Services (Kunshan) Inc. Page: 4 of 14 Page 4 of 14 Compliance Certification Services (Kunshan) Inc. Page: 5 of 14 Page 5 of 14 Compliance Certification Services (Kunshan) Inc. Page: 6 of 14 Page 6 of 14 Compliance Certification Services (Kunshan) Inc. Page: 7 of 14 Page 7 of 14 Compliance Certification Services (Kunshan) Inc. Page: 8 of 14 Page 8 of 14 Compliance Certification Services (Kunshan) Inc. Page: 9 of 14 Page 9 of 14 Compliance Certification Services (Kunshan) Inc. Page: 10 of 14 Page 10 of 14 Compliance Certification Services (Kunshan) Inc. Page: 11 of 14 Page 11 of 14 Compliance Certification Services (Kunshan) Inc. Page: 12 of 14 Page 12 of 14 Compliance Certification Services (Kunshan) Inc. Page: 13 of 14 Page 13 of 14 Compliance Certification Services (Kunshan) Inc. Page: 14 of 14 Page 14 of 14 End

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR210900006302 Page: 1 of 7 Eric Lin Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: KSCR2109000063CR FCC ID: OJFPS-MP-08 Applicant: Corning Optical Communications LLC Address of Applicant: 6 Concord Road, Shrewsbury, MA 01545 United States Manufacturer: Corning Optical Communications LLC Address of Manufacturer: 6 Concord Road, Shrewsbury, MA 01545 United States Factory: Sunwave Communications Co., Ltd Address of Factory: 581 Huoju Avenue, Binjiang District, Hangzhou, China Equipment Under Test (EUT): EUT Name: Remote Unit Model No.: PS-MP Trade mark: CORNING Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2021-10-08 Date of Test: 2021-10-18 to 2021-11-26 Date of Issue: 2021-11-29 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR210900006302 Page: 2 of 7 Revision Record Version Description Date Remark 00 Original 2021-11-29 / Authorized for issue by: Damon Zhou / Project Engineer Eric Lin / Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR210900006302 Page: 3 of 7 2 Contents Page 1 COVER PAGE.............................................................................................................................................. 1 2 CONTENTS .................................................................................................................................................. 3 3 GENERAL INFORMATION ......................................................................................................................... 4 3.1 DETAILS OF E.U.T.................................................................................................................................. 4 3.2 TEST LOCATION ..................................................................................................................................... 5 3.3 TEST FACILITY ....................................................................................................................................... 5 3.4 DEVIATION FROM STANDARDS ................................................................................................................ 5 3.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ............................................................................ 6 5 MEASUREMENT AND CALCULATION ..................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................... 7 5.2 MPE CALCULATION ................................................................................................................................ 7 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR210900006302 Page: 4 of 7 3 General Information Note: The antenna gain value is provided by the customer. The test lab will not be responsible for wrong test result due to incorrect information about antenna gain values. 3.1 Details of E.U.T. Product Name: Remote Unit Model No.: PS-MP Trade Mark: CORNING Power Supply: AC 100~240V 50/60Hz or DC 48V Test Voltage AC 120V/60Hz Rated power: 150W Type of Modulation LTE Frequency Band: CQPSK/12.5kHz FM/TETRA in 851MHz to 869MHz Normal Output Power: 37dBm (downlink) System Gain: 47 ± 2dB Power Control Method: ALC Antenna Type: External Antenna Antenna Gain: Max Antenna Gain 0.0 dBi(Provided by manufacturer) Compliance Certification Services (Kunshan) Inc. Report No.: KSCR210900006302 Page: 5 of 7 3.2 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. 3.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC (Designation Number: CN1172) Compliance Certification Services Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED (CAB Identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development (ISED) Canada as an accredited testing laboratory. CAB Identifier: CN0072. • VCCI (Member No.: 1938) The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. 1 of 1 Appendix A - Input/output power and amplifier/booster gain Test Data: Mode Operation Band Frequency (MHz) Signal Type Signal Level (dBm) Input Power (dBm) Output Power (dBm) Total Output Power (dBm) ERP (W) Gain (dB) Downlink 851 ~ 869MHz 861.197 CW Pre-AGC -10 37.21 37.21 3.21 47.21 3dB Above AGC -7 37.28 37.28 3.26 / Remark: 1) The normal power is 37dBm and the measured output power which show in above table is within ± 2.0dB tolerance. 2) The ERP limit is 5W, the product satisfied with the limit. 3) ERP (dBm) = Total Output Power (dBm) + Antenna Gain (dBi) - 2.15 dB = 35.13 dBm = 3.26 W. Antenna Gain is 0.0dBi.

Compliance Certification Services (Kunshan) Inc. 1 of 4 Appendix B - Conducted Spurious Emissions Test Data: Channel Frequency Range (MHz) Worst Test Level (dBm) Limit (dBm) Result LCH 0.009 - 0.15 -33.774 -13.00 Pass 0.15 - 10 -44.137 -13.00 Pass 10 - 30 -51.879 -13.00 Pass 30 - 1000 -19.160 -13.00 Pass 1000 - 9000 -27.331 -13.00 Pass MCH 0.009 - 0.15 -33.502 -13.00 Pass 0.15 - 10 -44.901 -13.00 Pass 10 - 30 -50.897 -13.00 Pass 30 - 1000 -19.077 -13.00 Pass 1000 - 9000 -29.880 -13.00 Pass HCH 0.009 - 0.15 -33.384 -13.00 Pass 0.15 - 10 -44.886 -13.00 Pass 10 - 30 -51.663 -13.00 Pass 30 - 1000 -18.736 -13.00 Pass 1000 - 9000 -26.233 -13.00 Pass Compliance Certification Services (Kunshan) Inc. 2 of 4 Low Channel 9-150KHz 150KHz-10MHz 10-30MHz 30-1000MHz 1-9GHz Compliance Certification Services (Kunshan) Inc. 3 of 4 Middle Channel 9-150KHz 150KHz-10MHz 10-30MHz 30-1000MHz 1-9GHz Compliance Certification Services (Kunshan) Inc. 4 of 4 High Channel 9-150KHz 150KHz-10MHz 10-30MHz 30-1000MHz 1-9GHz

Compliance Certification Services (Kunshan) Inc. 1 of 2 Appendix C - Out-of-band/out-of-block emissions (including intermodulation). Test Data: Channel Spacing (kHz) Signal Level Worst Test Level (dBm) Limit (dBm) Result 6.25kHz Pre-AGC -30.802 -13.00 Pass 3dB Above AGC -30.396 -13.00 Pass 12.5kHz Pre-AGC -27.241 -13.00 Pass 3dB Above AGC -26.304 -13.00 Pass 25kHz Pre-AGC -29.236 -13.00 Pass 3dB Above AGC -29.285 -13.00 Pass Compliance Certification Services (Kunshan) Inc. 2 of 2 Channel Spacing: 6.25kHz Pre-AGC 3dB Above AGC Channel Spacing: 12.5kHz Pre-AGC 3dB above AGC Channel Spacing: 25kHz Pre-AGC 3dB above AGC

Compliance Certification Services (Kunshan) Inc. 1 of 2 Appendix D - Radiated Spurious Emissions Test Data: Downlink 851MHz to 869MHz: Low Channel Frequency Spurious Emission Level Limit Over limit (MHz) (Deg) Polaxis (dBm) dBm (dB) 203.5 152.0 Horizontal -57.5 -13.0 -44.5 495.0 141.0 Horizontal -42.0 -13.0 -29.0 852.4 8.0 Horizontal -46.3 -13.0 -33.3 2496.0 46.0 Horizontal -45.5 -13.0 -32.5 6341.1 33.0 Horizontal -38.4 -13.0 -25.4 11460.4 72.0 Horizontal -35.5 -13.0 -22.5 97.7 74.0 Vertical -46.5 -13.0 -33.5 448.1 54.0 Vertical -49.7 -13.0 -36.7 705.7 212.0 Vertical -48.2 -13.0 -35.2 2505.4 180.0 Vertical -46.9 -13.0 -33.9 6343.7 118.0 Vertical -46.3 -13.0 -33.3 12084.7 270.0 Vertical -37.3 -13.0 -24.3 Middle Channel Frequency Spurious Emission Level Limit Over limit (MHz) (Deg) Polaxis (dBm) dBm (dB) 123.2 280.0 Horizontal -41.0 -13.0 -28.0 387.4 244.0 Horizontal -47.4 -13.0 -34.4 719.6 357.0 Horizontal -48.4 -13.0 -35.4 2494.4 242.0 Horizontal -34.4 -13.0 -21.4 6341.9 114.0 Horizontal -39.1 -13.0 -26.1 9640.3 149.0 Horizontal -33.2 -13.0 -20.2 182.3 42.0 Vertical -40.3 -13.0 -27.3 438.4 109.0 Vertical -43.0 -13.0 -30.0 752.6 58.0 Vertical -52.9 -13.0 -39.9 2502.8 292.0 Vertical -39.3 -13.0 -26.3 6329.6 332.0 Vertical -33.9 -13.0 -20.9 10852.5 82.0 Vertical -35.2 -13.0 -22.2 Compliance Certification Services (Kunshan) Inc. 2 of 2 High Channel Frequency Spurious Emission Level Limit Over limit (MHz) (Deg) Polaxis (dBm) dBm (dB) 163.1 152.0 Horizontal -51.0 -13.0 -38.0 447.6 273.0 Horizontal -46.8 -13.0 -33.8 758.8 328.0 Horizontal -33.0 -13.0 -20.0 2491.6 249.0 Horizontal -37.4 -13.0 -24.4 6346.6 144.0 Horizontal -39.0 -13.0 -26.0 11552.7 26.0 Horizontal -41.8 -13.0 -28.8 89.7 29.0 Vertical -46.1 -13.0 -33.1 314.7 209.0 Vertical -37.6 -13.0 -24.6 762.6 240.0 Vertical -51.2 -13.0 -38.2 2507.1 173.0 Vertical -42.9 -13.0 -29.9 6340.9 260.0 Vertical -37.8 -13.0 -24.8 9881.7 201.0 Vertical -34.4 -13.0 -21.4 Remark: We only show the worst test result, which is the test of the external antenna with 50 ohm impedance. No emissions were detected within 20dB below the limit for the Downlink direction. The cabinet radiation was measured with the equipment transmitting a CW signal into a non-radiating 50 Ohm load at maximum output power on a signal frequency. Measured were performed in the lowest, middle and highest frequency for the Downlink. The spectrum was searched from 30MHz to 18GHz or 10th Harmonic for downlink.

Compliance Certification Services (Kunshan) Inc. 1 of 11 Appendix E - Input-versus-output signal comparison Test Data: Downlink: 851MHz to 869MHz Occupied Bandwidth Channel Spacing (kHz) Test Frequency F 0 (MHz) Signal Level Signal Type 99% Occupied Channel Bandwidth (MHz) 6.25kHz (CQPSK) 861.197 Pre-AGC Input 4.881 Output 4.879 861.197 3dB Above AGC Input 4.879 Output 4.881 12.5kHz (FM) 861.197 Pre-AGC Input 9.783 Output 9.789 861.197 3dB Above AGC Input 9.781 Output 9.786 25kHz (TETRA) 861.197 Pre-AGC Input 20.968 Output 20.979 861.197 3dB Above AGC Input 20.983 Output 20.966 Compliance Certification Services (Kunshan) Inc. 2 of 11 6.25kHz CQPSK Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 3 of 11 12.5kHz FM Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 4 of 11 25kHz TETRA Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output ` Compliance Certification Services (Kunshan) Inc. 5 of 11 Emission masks Channel Spacing (kHz) Test Frequency F 0 (MHz) Signal Level Signal Type Result 6.25kHz (CQPSK) MASK H 852.500* Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass 12.5kHz (FM) MASK D 861.197 Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass 25kHz (TETRA) MASK G 861.197 Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass Remark 1 *: For frequencies falling within 851-854MHz, we only chose the middle channel as the representative test. Remark 2: The Total Power Ref is the same value as the unmodulated carrier output power (P). Compliance Certification Services (Kunshan) Inc. 6 of 11 6.25kHz CQPSK _ Mask H Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 7 of 11 12.5kHz FM _ Mask D Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 8 of 11 25kHz TETRA _ Mask G Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 9 of 11 Adjacent Channel Power Channel Spacing (kHz) Test Channel Signal Level Signal Type Result 25kHz (TETRA) Low Channel Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass Middle Channel Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass High Channel Pre-AGC Input Pass Output Pass 3dB Above AGC Input Pass Output Pass 25kHz TETRA _ Adjacent Channel Power _ Low Channel Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 10 of 11 25kHz TETRA _ Adjacent Channel Power _ Middle Channel Pre-AGC_ Input Pre-AGC_ Output 3dB Above Pre-AGC_ Input 3dB Above AGC_ Output Compliance Certification Services (Kunshan) Inc. 11 of 11 25kHz TETRA _ Adjacent Channel Power _ High Chann…
