OJFRN510SCRN-510-28G1 Radio Node

Corning Restricted and Confidential Proprietary - Controlled content SCRN-510 Hardware Installation Guide| DOC-SCRN-510-HIG_i4| 16 October, 2020| Page 1 Small Cell Radio Node - SCRN-510 Hardware Installation Guide DOC-SCRN-510-HIG_i4 Issue 4 Related Literature | Search www.Corning.com/opcomm. Click Required Resources. Revision History IssueDateSummary of Changes 130JUL20Initial release for SCRN-510 Small Cell Radio Node 230AUG20Issue 2 removes UMTS references 301OCT20Issue 3 adds FCC Statement 416OCT20Issue 4 adds an additional Regulatory Statement Corning Restricted and Confidential Proprietary - Controlled content SCRN-510 Hardware Installation Guide | DOC-SCRN-510-HIG_i4 | 16 October, 2020 | Page 2 FCC Statement Safety Precautions Corning strongly recommends reviewing and adhering to the following cautions and notices before installing and operating the SCRN-510. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. RF Exposure warning statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum 40 cm between the radiator and your body. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC. This device can be expected to comply with part 15 of the FCC Rules provided it is assembled in exact accor- dance with the instructions provided with this kit. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received includ- ing interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pur- suant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tion manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. WARNING: This warning symbolizes danger that may cause severe injury or death. Before installing or servicing equipment ensure that you are aware of all hazards involved with electrical circuitry and become familiar with applicable safety standards and national and local electrical codes and any other relevant standards. WARNING: Do not locate outdoor antennas near overhead power lines or other power circuits that might come into contact with the antennas and their wiring. Contacting such circuits during installa- tion can cause severe injury or death. Refer to national and local electrical codes and any other rele- vant standards for more safety information. WARNING: Ensure that you install a suitable lightning arrestor for outside antenna installations. WARNING: Do not use or service any equipment with outdoor connections during electrical storms due to risk of lightning. WARNING: All electrical equipment must be properly grounded. Refer to national and local electrical codes and any other relevant standards for electrical grounding information. WARNING: If an external antenna starts to fall during installation, for models that are designed for external antennas, let it drop as it may contact a power line or other electrical circuitry that might cause severe injury or death. Corning Restricted and Confidential Proprietary - Controlled content SCRN-510 Hardware Installation Guide| DOC-SCRN-510-HIG_i4| 16 October, 2020| Page 3 Other Cautions NOTE: This device does not require professional installation. CAUTION: ESD can damage the SCRN-510 and internal components. Ensure that the SCRN-510 and associated antenna equipment is installed and serviced according to national and local ESD stan- dards. CAUTION: Ensure that the antenna cable conforms to the environment in which it is used. CAUTION: Do not open the SCRN-510 casing. E-RAN wireless system equipment must only be ser- viced by Corning-accredited personnel. Opening the SCRN-510 casing voids the warranty. Corning Restricted and Confidential Proprietary - Controlled content SCRN-510 Hardware Installation Guide| DOC-SCRN-510-HIG_i4| 16 October, 2020| Page 4 Table of Contents FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Other Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Section 1. About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Section 2. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Section 3. Radio Node Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Section 3.1 Radio Node Cover-Side and Mounting-Side Views . . . . . . . 7 Section 4. Connectors, SFP+ and Micro-USB Ports, and Status LED . . . . . . . .8 Section 4.1 Duplex Phoenix Power Cable Ports . . . . . . . . . . . . . . . . . . . . .8 Section 4.2 SFP+ Transceiver Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Section 4.3 Micro-USB Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Section 4.4 Status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Section 5. System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

SCS-F018: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Website: https://www.cps.bureauveritas.com/ P roject and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 Updated References and Contact info 6.0 7.0 Aug-30-202 SCS-F018: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 7.0 10/9/2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Corning Optical Co mmunication Wireless hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: OJFRN510 Product Description: SCRN-510 Radio Node Model: SCRN-51 0-28G1 We affirm that between Bureau Veritas Consumer Product Services, Inc. and Corning Optical Communication Wire less, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Title: Director, Market Development Contact information / address: p. 703 855 1773, address: 8253 1st Ave., Vienna, VA 22182

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Website: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 10/9/2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: OJFRN510 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Title: Director, Market Development Contact information / address: p. 703 855 1773, address: 8253 1 st Ave., Vienna, VA 22182 i Permanent confidentiality may be requested in accordance with FCC KDB 726920

© 2020 Corning Incorporated. All Rights Reserved. FSM board Front side © 2020 Corning Incorporated. All Rights Reserved. © 2020 Corning Incorporated. All Rights Reserved. NXP board front Side © 2020 Corning Incorporated. All Rights Reserved. NXP board Back Side © 2020 Corning Incorporated. All Rights Reserved. Power Board Front Side © 2020 Corning Incorporated. All Rights Reserved. Power Board Back side © 2020 Corning Incorporated. All Rights Reserved. SFP2NXP board

© 2020 Corning Incorporated. All Rights Reserved. NXP Board © 2020 Corning Incorporated. All Rights Reserved. © 2020 Corning Incorporated. All Rights Reserved. © 2020 Corning Incorporated. All Rights Reserved. Qualcomm FSM Module board © 2020 Corning Incorporated. All Rights Reserved. © 2020 Corning Incorporated. All Rights Reserved. Qualcomm Antenna module © 2020 Corning Incorporated. All Rights Reserved. Qualcomm Antenna Module

Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 FCC ID: OJFRN510 Test Model: SCRN-510-28G1 Series Model: N/A Issued Date: 11/05/2020 Applicant: Corning Optical Communication Address: 475 Sycamore Dr, Milpitas, CA 95035, U.S.A. Manufacturer: Corning Optical Communication Address: 475 Sycamore Dr, Milpitas, CA 95035, U.S.A. Issued By: Bureau Veritas Consumer Products Services, Inc. Lab Address: 775 Montague Expressway, Milpitas, CA 95035 Test Location (1): 775 Montague Expressway, Milpitas, CA 95035 FCC Registration / Designation Number: 540430 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any government agencies. Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Calculation Result of Maximum Radiated Power ................................................................................ 6 3 Conclusion ............................................................................................................................................ 6 Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued FCC_RF_SL20031101-SPC-001_MPE Initial Release 10/15/2020 FCC_RF_SL20031101-SPC-001_MPE Rev_1.0 Update Per review 10/19/2020 FCC_RF_SL20031101-SPC-001_MPE Rev_2.0 Update Per review 10/26/2020 FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Correct device type to fixed and base station 11/05/2020 Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: 5G mmWave SmallCell Radio Node Brand: COC Wireless Test Model: SCRN-510-28G1 Sample Status: Engineering sample Applicant: Corning Optical Communication Standards: FCC Part 2 (Section 2.1091) KDB 447498 D01 General RF Exposure Guidance v06 IEEE C95.3 -2002 The above equipment has been tested by Bureau Veritas Consumer Products Services, Inc., Milpitas Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: 11/05/2020 Deon Dai / Test Engineer Approved by : , Date: 11/05/2020 Shuo Zhang / Engineer Reviewer Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (Mw/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) Where Pd = power density in Mw/cm 2 Pout = output power to antenna in Mw G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 40cm away from the body of the user. So, this device is classified as fixed and base station device. 2.4 Antenna Gain Ant. No. Freq. range (MHz) Ant. Type Ant. Gain (dBi) Connector Type 5G NR Antenna 27500~28350 Patch Array 22.5 N/A Report No.: FCC_RF_SL20031101-SPC-001_MPE Rev_3.0 Page No. 6 / 6 Report Format Version: 6.1.1 2.5 Calculation Result of Maximum Radiated Power Frequency (GHz) E.I.R.P (dBm) Dista…

Text truncated - open the document above for the full version.

Virginia Diodes, Inc Certificate of Conformance To:Virginia Diodes, IncFrom:Agilent Technogies 1424 Fountaingrove Parkway Dock 4LS Santa Rosa, CA 95403 United States Packing List No: 141195 Today's Date: 10/06/20 Shipping Date: 06/19/14 PO Number: 9000666533 Attn: Mike Skaggs Phone: 1-707-577-3492 Quantity Description Unit Shipped Order - Job Number 1EA14097B-01VDIWR15.0SGX WR15.0SGX - Frequency Extender; SN: VDI SGX 007. 1EA14097B-02VDIWR15.0SAX WR15.0SAX - Frequency Extender; SN: VDI SAX 012. 1EA14097B-03VDI15.0SWG2-40 WR12SWG - Waveguide Straight with Attenuation; SN: 2-40. The VDI product(s) in this shipment meet(s) the guidelines for performance specifications established in accordance with the corresponding Purchase Order. Data presented in the User Guide, where applicable, has been obtained in accordance with VDI’s Quality Management System. All instruments, used to obtain data, which require calibration have been calibrated with equipment traceable to the National Institute of Standards and Technology (NIST) and through NIST to the International System of Units (SI). Virginia Diodes, Inc ________________________________________ Authorized Signature Page 1 of 1 Virginia Diodes, Inc Certificate of Conformance To:Virginia Diodes, IncFrom:Agilent Technogies 1424 Fountaingrove Parkway Dock 4LS Santa Rosa, CA 95403 United States Packing List No: 141195 Today's Date: 10/06/20 Shipping Date: 06/19/14 PO Number: 9000666533 Attn: Mike Skaggs Phone: 1-707-577-3492 Quantity Description Unit Shipped Order - Job Number 1EA14097B-01VDIWR15.0SGX WR15.0SGX - Frequency Extender; SN: VDI SGX 007. 1EA14097B-02VDIWR15.0SAX WR15.0SAX - Frequency Extender; SN: VDI SAX 012. 1EA14097B-03VDI15.0SWG2-40 WR12SWG - Waveguide Straight with Attenuation; SN: 2-40. The VDI product(s) in this shipment meet(s) the guidelines for performance specifications established in accordance with the corresponding Purchase Order. Data presented in the User Guide, where applicable, has been obtained in accordance with VDI’s Quality Management System. All instruments, used to obtain data, which require calibration have been calibrated with equipment traceable to the National Institute of Standards and Technology (NIST) and through NIST to the International System of Units (SI). Virginia Diodes, Inc ________________________________________ Authorized Signature Page 1 of 1

Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 1 / 231 Report Format Version: 6.1.1 FCC Test Report Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 FCC ID: OJFRN510 Test Model: SCRN-510-28G1 Received Date: 09/14/2020 Test Date: 09/28/2020 ~ 11/02/2020 Issued Date: 11/03/2020 Applicant: Corning Optical Communication Address: 475 Sycamore Dr, Milpitas, CA 95035, U.S.A. Manufacturer: Corning Optical Communication Address: 475 Sycamore Dr, Milpitas, CA 95035, U.S.A. Issued By: Bureau Veritas Consumer Products Services, Inc. Lab Address: 775 Montague Expressway, Milpitas, CA 95035, USA Test Location (1): 775 Montague Expressway, Milpitas, CA 95035, USA FCC Registration / Designation Number: 540430/4842D This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any government agencies. Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 2 / 231 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Duty Cycle of Test Signal .................................................................................................................. 10 3.4 Description of Support Units .............................................................................................................. 11 3.4.1 Configuration of System under Test ................................................................................................... 11 3.5 General Description of Applied Standards ........................................................................................ 12 4 Test Types and Results ...................................................................................................................... 13 4.1 Modulation characteristics ................................................................................................................. 13 4.1.1 Limits of Modulation characteristics .................................................................................................. 13 4.1.2 Test Results ....................................................................................................................................... 13 4.2 Equivalent Isotropic Radiated Power (EIRP) Density Measurement ................................................ 14 4.2.1 Limits of EIRP Density Measurement ................................................................................................ 14 4.2.2 Test Setup .......................................................................................................................................... 14 4.2.3 Test Instruments ................................................................................................................................ 15 4.2.4 Test Procedures ................................................................................................................................. 17 4.2.5 Test Settings ...................................................................................................................................... 18 4.2.6 Deviation fromTest Standard ............................................................................................................. 18 4.2.7 EUT Operating Conditions ................................................................................................................. 19 4.2.8 Test Results ......................................................................…

Text truncated - open the document above for the full version.

Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 46 / 231 Report Format Version: 6.1.1 QPSK-4CC(Worse case plots) Beam ID: 139 Low Channel_1 Low Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 47 / 231 Report Format Version: 6.1.1 Low Channel_3 Low Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 48 / 231 Report Format Version: 6.1.1 Middle Channel_1 Middle Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 49 / 231 Report Format Version: 6.1.1 Middle Channel_3 Middle Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 50 / 231 Report Format Version: 6.1.1 High Channel_1 High Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 51 / 231 Report Format Version: 6.1.1 High Channel_3 High Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 52 / 231 Report Format Version: 6.1.1 64QAM-4CC(Worse case plots) Beam ID: 11 Low Channel_1 Low Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 53 / 231 Report Format Version: 6.1.1 Low Channel_3 Low Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 54 / 231 Report Format Version: 6.1.1 Middle Channel_1 Middle Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 55 / 231 Report Format Version: 6.1.1 Middle Channel_3 Middle Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 56 / 231 Report Format Version: 6.1.1 High Channel_1 High Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 57 / 231 Report Format Version: 6.1.1 High Channel_3 High Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 58 / 231 Report Format Version: 6.1.1 64QAM-4CC(Worse case plots) Beam ID: 139 Low Channel_1 Low Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 59 / 231 Report Format Version: 6.1.1 Low Channel_3 Low Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 60 / 231 Report Format Version: 6.1.1 Middle Channel_1 Middle Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 61 / 231 Report Format Version: 6.1.1 Middle Channel_3 Middle Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 62 / 231 Report Format Version: 6.1.1 High Channel_1 High Channel_2 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 63 / 231 Report Format Version: 6.1.1 High Channel_3 High Channel_4 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 64 / 231 Report Format Version: 6.1.1 Conducted Power Measurement Band n261 Beam ID 11 EUT position Z-plane Receive Antenna polarization Vertical QPSK-1CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2071666 27550 39.21 22.5 16.71 2077916 27925 39.76 22.5 17.26 2084166 28300 39.37 22.5 16.87 64QAM-1CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2071666 27550 37.76 22.5 15.26 2077916 27925 39.70 22.5 17.20 2084166 28300 39.45 22.5 16.95 QPSK-4CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2074166 27700.02 39.63 22.5 17.13 2077918 27925.14 39.58 22.5 17.08 2081666 28150.02 39.63 22.5 17.13 64QAM-4CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2074166 27700.02 39.57 22.5 17.07 2077918 27925.14 39.68 22.5 17.18 2081666 28150.02 39.59 22.5 17.09 Report No.: FCC_RF_SL20031101-SPC-001 Rev_5.0 Page No. 65 / 231 Report Format Version: 6.1.1 Band n261 Beam ID 139 EUT position Z-plane Receive Antenna polarization Horizontal QPSK-1CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2071666 27550 38.66 22.5 16.16 2077916 27925 39.30 22.5 16.80 2084166 28300 39.48 22.5 16.98 64QAM-1CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2071666 27550 38.65 22.5 16.15 2077916 27925 39.25 22.5 16.75 2084166 28300 39.57 22.5 17.07 QPSK-4CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2074166 27700.02 39.42 22.5 16.92 2077918 27925.14 39.69 22.5 17.19 2081666 28150.02 39.67 22.5 17.17 64QAM-4CC Channel No. Freq. (MHz) EIRP (dBm) Ant. Gain (dBi) Conducted Power (dBm) 2074166 27700.02 39.40 22.5 16…

Text truncated - open the document above for the full version.
