OJFVE-WIMAX-25EVE WiMAX 2.5 GHz DISTRIBUTED ANTENNA SYSTEM

MobileAccessVE WiMAX Instant Coverage Solution User Manual PN: 709C004001 REV: A01 Date: FEB 2010 II MobileAccessVE WiMAX Instant Coverage Solution User Manual MobileAccess Worldwide Headquarters 8391 Old Courthouse Road Suite 300, Vienna, VA 22182 Tel: +1(866)436-9266, +1(703)848-0200 TAC: +1(800)787-1266, Fax: +1(703)848-0280 http://www.MobileAccess.com Preface Material III MobileAccessVE WiMAX Instant Coverage Solution User Manual Preface Material © Copyright 2010, MobileAccess Networks Inc. All Rights Reserved. This document contains confidential and proprietary information of MobileAccess and may not be copied, transmitted, stored in a retrieval system or reproduced in any format or media, in whole or in part, without the prior written consent of MobileAccess. Information contained in this document supersedes any previous manuals, guides, specifications, data sheets or other information that may have been provided or made available to the user. This document is provided for informational purposes only, and MobileAccess does not warrant or guarantee the accuracy, adequacy, quality, validity, completeness or suitability for any purpose of the information contained in this document. MobileAccess reserves the right to make updates, improvements and enhancements to this document and the products to which it relates at any time without prior notice to the user. MOBILEACCESS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THIS DOCUMENT OR ANY INFORMATION CONTAINED HEREIN. Policy for Warrantee and Repair MobileAccess tests and inspects all its products to verify their quality and reliability. MobileAccess uses every reasonable precaution to ensure that each unit meets their declared specifications before shipment. Customers should advise their incoming inspection, assembly, and test personnel about the precautions required in handling and testing our products. Many of these precautions can be found in this manual. The products are covered by the following warranties: General Warranty MobileAccess warrants to the original purchaser all standard products sold by MobileAccess to be free of defects in material and workmanship for one (1) year from date of shipment from MobileAccess. During the warranty period, MobileAccess will repair or replace any product that MobileAccess proves to be defective. This warranty does not apply to any product that has been subject to alteration, abuse, improper installation or application, accident, electrical or environmental over-stress, negligence in use, storage, transportation or handling. Specific Product Warranty Instructions All MobileAccess products are warranted against defects in workmanship, materials and construction, and to no further extent. Any claim for repair or replacement of units found to be defective on incoming inspection by a customer must be made within 30 days of receipt of shipment, or within 30 days of discovery of a defect within the warranty period. This warranty is the only warranty made by MobileAccess and is in lieu of all other warranties, expressed or implied. MobileAccess sales agents or representatives are not authorized to make commitments on warranty returns. Preface Material IV MobileAccessVE WiMAX Instant Coverage Solution User Manual Returns In the event that it is necessary to return any product against above warranty, the following procedure shall be followed: 1. Return authorization is to be received from MobileAccess prior to returning any unit. Advise MobileAccess of the model, serial number, and discrepancy. The unit may then be forwarded to MobileAccess, transportation prepaid. Devices returned collect or without authorization may not be accepted. 2. Prior to repair, MobileAccess will advise the customer of our test results and any charges for repairing customer-caused problems or out-of-warranty conditions etc. 3. Repaired products are warranted for the balance of the original warranty period, or at least 90 days from date of shipment. Limitations of Liabilities MobileAccess's liability on any claim, of any kind, including negligence for any loss or damage arising from, connected with, or resulting from the purchase order, contract, quotation, or from the performance or breach thereof, or from the design, manufacture, sale, delivery, installation, inspection, operation or use of any equipment covered by or furnished under this contact, shall in no case exceed the purchase price of the device which gives rise to the claim. EXCEPT AS EXPRESSLY PROVIDED HEREIN, MOBILEACCESS MAKES NO WARRANTY, EXPRESSED OR IMPLIED, WITH RESPECT TO ANY GOODS, PARTS AND SERVICES PROVIDED IN CONNECTION WITH THIS AGREEMENT INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. MOBILEACCESS SHALL NOT BE LIABLE FOR ANY OTHER DAMAGE INCLUDING, BUT NOT LIMITED TO, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH FURNISHING OF GOODS, PARTS AND SERVICE HEREUNDER, OR THE PERFORMANCE, USE OF, OR INABILITY TO USE THE GOODS, PARTS AND SERVICE. Reporting Defects The units were inspected before shipment and found to be free of mechanical and electrical defects. Examine the units for any damage that may have been caused in transit. If damage is discovered, file a claim with the freight carrier immediately. Notify MobileAccess as soon as possible. NOTE: Keep all packing material until you have completed the inspection Safety Warnings To comply with FCC RF exposure compliance requirement, adhere to the following warnings: Warning! The Access Pod with its built-in antenna must be installed with a separation distance of at least 20cm from all persons and must not be located in conjunction with any other antenna. Warning! The outside antenna must be installed with a separation of at least 20cm from all persons and must not be located in conjunction with any other anten…

Text truncated - open the document above for the full version.

Making Wireless an Indoor State of Mind FCC Confidential Authorization Date: 16 March 2010 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: OJFVE-WIMAX-25E In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, MobileAccess Networks hereby requests long-term confidential treatment of information accompanying this application as outlined below: CONF APPENDIX VE WIMAX 2.5 GHz VAP BlkDia.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU BlkDia.pdf CONF APPENDIX VE WIMAX 2.5 GHz VAP DIGITAL PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VAP RF PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU ARM PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU COMBINER PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU MULTI-TIER REFERENCE PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU RF IF PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU SPLITTER PartsLst.pdf CONF APPENDIX VE WIMAX 2.5 GHz VAP DIGITAL Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VAP RF Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU ARM Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU COMBINER Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU MULTI-TIER REFERENCE Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU RF IF Schem.pdf CONF APPENDIX VE WIMAX 2.5 GHz VCU SPLITTER Schem.pdf Making Wireless an Indoor State of Mind FCC Confidential Authorization The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Steve Blum Product Manager MobileAccess Networks 8391 Old Courthouse Rd Suite 300 Vienna VA 22182-3819 Unwired: 541-758-2880 Making Wireless an Indoor State of Mind On the web at www.MobileAccess.com

Making Wireless an Indoor State of Mind FCC Confidential Authorization Date: 16 March 2010 To: Timco Engineering Inc. To Whom It May Concern We hereby authorize Mr. Shaike Raz of I.T.L. (Product Testing) Ltd (ITL ) to act on our behalf regarding the FCC ID Certification Process for the following application: Product: VE WIMAX 2.5 GHz Distributed Antenna System FCC ID: OJFVE-WIMAX-25E Thank you, Sincerely, Steve Blum Product Manager MobileAccess Networks 8391 Old Courthouse Rd Suite 300 Vienna VA 22182-3819 Unwired: 541-758-2880 Making Wireless an Indoor State of Mind On the web at www.MobileAccess.com

2)This device must accept any interference received , This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1)This device may not cause harmful interference ,and operation. including interference that may cause undesired FCC ID: OJFVE-WIMAX-25E

MobileAccessVE WiMAX Operational Description MobileAccessVE WiMAX solution provides enhanced, cost effective in-building WiMAX coverage for enterprise environment. This solution is quickly and simply deployed using the existing cable infrastructure to provide instant MIMO or SISO WiMAX coverage without requiring the installation of new cables and without affecting existing LAN services. VE minimizes disruption while providing a scalable and flexible solution at a significantly lower total installation cost. The MobileAccessVE WiMAX Solution The VE solution consists of the following main components:  VE Control Unit (VCU) - interfaces with the Service Provider’s RF capacity sources and VE Access Pods (VAPs). It combines the WiMAX wireless services with the Ethernet service and distributes them to the VAPs over CAT-5e/6 cables. Each VCU can support up to 12 VAPs. Coverage can be expanded by connecting up to 12 Slave VCUs where the Master VCU interfaces to the RF capacity source and the Slave VCUs to the VAPs. Each VCU can serve as either Master or Slave depending on its connections.  VE Access Pods (VAPs) – distribute WiMAX wireless services and provide Ethernet/IP connectivity (and PoE pass-through) to connected IP appliances, such as WiFi APs and IP Phones. VAPs are distributed at strategic locations over one or more floors, and plug into RJ- 45 jacks, which are connected to the VCU via exiting CAT-5e/6 infrastructure. VAPs are remotely powered by the VCU utilizing PoE, eliminating the need for local powering. VAPs are equipped with internal antennas, as well as, with connectors for (optional) external antennas connection. Figure 1. MobileaccessVE WiMAX components Key Features and Benefits Low Deployment Cost  Connects over existing Cat 5/6 cabling infrastructure and existing Ethernet jacks  Simple installation - deployed in few hours, with minimum disturbance to the enterprise  VAPs are remotely powered using Power-over-Ethernet (PoE) – no local power required  Minimum macro-network impact with low power distributed coverage  Seamlessly coexists with the Enterprise LAN and does not consume LAN capacity Flexible & Scalable Architecture  Connects to all types of capacity sources: BTS, Picocells, Femtocells, and BDAs  Supports both MIMO and SISO  VAPs can be easily relocated for coverage modifications as needed  Ease of expansion provides ‘pay as you grow’ scalability  Support of connected IP devices (computers, IP phones etc) with Ethernet/IP pass through and PoE maximizes placement flexibility Carrier-Grade Management Remote end-to-end system monitoring, management and configuration using standard web browser and SNMP Figure 2. MobileaccessVE WiMAX architecture

R.F Exposure/Safety Calculation for VE WIMAX 2.5 GHz The E.U.T. is a WiMAX distributed antenna system. The “worst case” distance between the E.U.T. and the general population is 20 cm. Calculation of Maximum Permissible Exposure (MPE) Based on Section 1.1307(b)(1) Requirements 2 1 cm mW (a) FCC limits at 2600 MHz is: Using table 1 of Section 1.1310 limit for general population/uncontrolled exposures, the above level is an average over 30 minutes. (b) The power density produced by the E.U.T. is 2 4R GP S tt π = P t G T - Transmitted Power 287 mw R- Distance from Transmitter using 20cm worst case (c) Peak power density: 2 cm mW 3 2 1057 )20(4 287 S AV − ×== π

DATE: 22 March 2010 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for Mobile Access Networks Equipment under test: VE WIMAX 2.5 GHZ Distributed Antenna System 1. VE WIMAX 2.5 GHz VE Control Unit (VCU-WIMAX2.5-12E) 2. VE WIMAX 2.5 GHz VE Access Pod (VAP-WIMAX2.5E) Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E95781.00 Mobile Access Networks Page 1 of 79 FCC ACC M Ver 1.1 05Mayl 2000 Test Report E95781.00 Mobile Access Networks Page 2 of 79 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for FCC ID: OJFVE-WIMAX-25E This report concerns: Original Grant: X Class II change: Class I change: Equipment type: WiMAX Licensed Transmitter Limits used: 47CFR Part 27 Subpart C Measurement procedure used is ANSI C63.4-2003. Substitution Method used as in ANSI/TIA-603-B: 2002 Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Steve Blum ITL (Product Testing) Ltd. Mobile Access Networks Kfar Bin Nun 8391 Old Courthouse Rd., Suite #300 D.N. Shimshon 99780 Vienna, VA. 22182 Israel U.S.A. e-mail [email protected] Tel: +1-541-758-2880 Fax: +1-703-848-0260 e-mail: [email protected] TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 5 1.3 Product Description ........................................................................................... 6 1.4 Test Methodology .............................................................................................. 7 1.5 Test Facility ....................................................................................................... 7 1.6 Measurement Uncertainty ................................................................................. 7 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 8 2.1 Justification ........................................................................................................ 8 2.2 EUT Exercise Software ..................................................................................... 8 2.3 Special Accessories .......................................................................................... 8 2.4 Equipment Modifications ................................................................................... 8 2.5 Configuration of Tested System ........................................................................ 9 3. MAXIMUM PEAK OUTPUT POWER -----------------------------------------------------------------10 3.1 Test Specification ............................................................................................ 10 3.2 Test procedure ................................................................................................ 10 3.3 Results table .................................................................................................... 14 3.4 Test Equipment Used. ..................................................................................... 15 4. EMISSION BANDWIDTH---------------------------------------------------------------------------------16 4.1 Test Specification ............................................................................................ 16 4.2 Test Procedure ................................................................................................ 16 4.3 Results Table .................................................................................................. 23 1.1 Test Equipment Used. ..................................................................................... 24 5. CONDUCTED SPURIOUS EMISSIONS -------------------------------------------------------------25 5.1 Test Specification ............................................................................................ 25 5.2 Test procedure ................................................................................................ 25 5.3 Results table .................................................................................................... 55 5.4 Test Equipment Used. ..................................................................................... 56 6. BAND EDGE MEASUREMENTS ----------------------------------------------------------------------57 6.1 Test Specification ............................................................................................ 57 6.2 Test procedure ................................................................................................ 57 6.3 Results table .................................................................................................... 64 6.4 Test Equipment Used. ..................................................................................... 65 7. SPURIOUS RADIATED EMISSION -------------------------------------------------------------------66 7.1 Test Specification ............................................................................................ 66 7.2 Test Procedure ................................................................................................ 66 7.3 Test Results .................................................................................................... 69 7.4 Test Instrumentation Used, Radiated Measurements .................................... 70 8. FREQUENCY STABILITY -------------------------------------------------------------------------------71 9. APPENDIX A - CORRECTION FACTORS --------…

Text truncated - open the document above for the full version.
