MobileAccessVE CELL-PCS Full Band Operational Description P/N: 709C004904 REV: A01 Date: JULY 2011 User Manual Operational Description System Architecture Main Elements - The MobileAccessVE solution is based on the following main elements:  VE Control Unit (VCU) – installed in the communication room or shaft. Converges the Ethernet and RF signals and provides secure, central management to up to 12 VAPs or (Slave) VCUs in any combination. The same unit model can be configured either as Master or Slave depending on the installation topology:  Master VE Control Unit (Master VCU) – Installed in the main communication IDF/Telco closet, interfaces to the service provider’s RF equipment, and provides secure, central management to up to twelve VCUs and VAP devices in any combination.  Slave VE Control Unit (Slave VCU) – Used to expand coverage to additional floors. Installed in the IDF/Telco closet of the relevant floor. Each Slave VCU interfaces the Master VCU and up to twelve VAPs and twelve Ethernet connections. The Master and Slave VCUs are connected using dedicated CAT-6/7 cables. VCUs distribute wireless service signals to each VAP along with PoE and where relevant Ethernet signals from the Ethernet switch, throughout the existing CAT-5e/6 infrastructure.  VE Access Pod (VAP) – These are pluggable antennas distributed at strategic locations on the floor to provide Ethernet connection to an IP device and wireless coverage of the service via integrated internal (or external) antennas. Power to VAPs is provided via PoE from the VCU. Up to twelve VAPs can be connected to a single VCU using LAN cables (CAT-5e or higher). Note: If the total number of VAPs in the deployment exceeds 72, consult with MobileAccess support. The following figure shows the Multi-tier Dual-Band VE solution architecture. Figure 1. VE Multi-Tier Basic Architecture Note: If the Master VCU supports VAPs (in addition to VCUs), the relevant Ethernet ports are also connected to an Ethernet switch. Operational Description Note: Connecting both VAPs and slave VCUs to the master VCU simultaneously is supported only with VE network elements running SW version 2.6 and above 1.1 System Elements This section describes the interfaces of the VE Control Units and Access Pods. 1.1.1 VE Control Unit (VCU) The VCU can operate as either Master/Standalone or Slave. The front panel supports all the RF, control and optic interfaces, while the rear panel contains the power and alarms interfaces. 1.1.1.1 VCU Front Panel The VCU front panel provides interfaces to RF, management VAP, and VCU interfaces. The type of RF interfaces may vary depending on the VCU model. Below are two models: the top model supports only Duplex N-type interface, while the bottom model supports both Simplex and Duplex QMA connections. Figure 2: Example of VCU with both Simplex and Duplex RF Connectors Duplex QMA connectors Simplex QMA connectors (2 per service) Operational Description Interfaces Description RF Source RF connections to the RF source: simplex or duplex, N-type or QMA depending on the model. Management Relevant only for Master or Standalone VCU. RJ45 WEB management connection to Master or Standalone VCU. VE Access Pod Ports 1-12 VAP and or VCU connections (in any combination): Master VCU – Connections to Slave VCUs or VAPs. Slave VCU – Connections to VAPs. Ethernet Ports 1-12 Ethernet switch connections. Relevant for VCUs with connected VAPs. Connect according to corresponding VAP connections. Master Relevant for Slave VCUs. Connection towards Master VCU VE Access Pod Ports. Reset N/A in current version. Interfaces Description PWR and ACT LEDs PWR - VCU power source: Green - Power OK Disabled - No power received by VCU ACT VCU activity LED: Solid Green – During initialization Blinking Green – Normal operation Fast Blinking Green – User activated VCU Identify on this VCU VAP Status (One LED per Port) Status of the corresponding unit (VAP or VCU) Blinking Green – Unit is initializing Solid Green – Normal operation of unit Solid Orange – Unit is faulty, or unmanaged. This can be due to mismatch type, VoIP phone, etc. Fast Blinking Green – User selected “Identify” command on the unit Off – No VAP or VCU connected to this port. RF (One LED per Service) Status of connected RF capacity source: Green – Master VCU only. Normal RF level Orange – Master VCU only. RF level is either too low, too high, or service has been turned off by the user. Off – VCU is Slave. Master Status of the connection to the Master VCU: Off – Master mode (not connected to VCU) Blinking Green – During attachment process with Master VCU Solid green – Slave (IF-IF) mode and connected to Master Table 1: VCU Ports Description Operational Description 1.1.1.2 VCU Rear Panel The rear panel includes the following: power switch, AC input, AUX alarms, and service personnel connections. Figure 3. VCU Rear Panel Table 2 VCU Rear Panel Description Connector Description Console RS232 local connection for service personnel (D-Type 9) Alarms AUX Alarms Connections In Master/Slave configuration - relevant only for Master VCU. Power Input Standard 3-pins AC power connector equipped with an ON/OFF switch. 90- 264V AC, 47-63 Hz AC; 350W power consumption maximum. 1.1.2 VE Access Pod (VAP) Each VAP supports:  Internal antennas and two interfaces for external antennas. By default, the VAP is set to transmit through the integrated internal antennas. To use the external antennas connectors, select the “External Antenna” option in VAP Config-Service RF tab of the VE Web GUI application  An Ethernet port for physical Ethernet connection to devices such as a computer, IP phone or Wi-Fi Access Point.  Two LED status indictors. The VAP can be mounted on the wall or placed on a flat surface. Brackets are provided for each type of installation. PWR On/Off Switch AC Connector AUX Alarms Console Connector Operational Description The following figure shows the desktop VAP. Figure 4. VE Access Pod-Front Table 2: VAP LEDs…

Text truncated - open the document above for the full version.

8391 Old Courthouse Road, Suite 300 Vienna, VA 22182 27 July 2011 Declaration The Mobileaccess VE system is Plug & Play. No manual tune‐up procedure required. Thank you, Steve Blum Product Manager MobileAccess Networks Inc. Office 541 758-2880 Mobile 541 990-3470

R.F Exposure/Safety Calculation for Mobile Access VE CELL-PCS System The E.U.T. is wall or ceiling mounted. The typical distance between the E.U.T. and the general population is >20 cm for wall or ceiling mounted operation. Calculation of Maximum Permissible Exposure (MPE) Based on Section 1.1307(b)(1) Requirements 2 1 cm mW (a) FCC limit at 1960 MHz is: 2 588.01500/ cm mW f FCC limit at 881.5 MHz is: Using table 1 of Section 1.1310 limit for general population/uncontrolled exposures, the above level is an average over 30 minutes. (b) The power density produced by the E.U.T. is P t - Transmitted Peak Power (worst case) G T - Antenna Gain ,dBi R- Distance from Transmitter ) Pe(cak power density at worst case continuous transmission: Modulation Pt G T (dBi) ) m) m) (m W) Antenna type R (cm S AV 2 (mW/c Spec 2 (mW/c CDMA 8 31.99 Integral 0 20 0.006 0.58 GSM 30.90 Integral 0 20 0.006 1.0 W-CDMA 45.71 Integral 0 20 0.009 1.0 CDMA 8 31.99 External 10 20 0.064 0.58 GSM 30.90 External 10 20 0.061 1.0 W-CDMA 45.71 External 10 20 0.091 1.0 2 4R GP tt  S

DATE: 26 July 2011 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for Mobile Access Networks Equipment under test: VE CELL PCS Full Band Distributed Antenna System comprising: 1. VE Control Unit 2. VE Access Pod 1. VCU-FB-CELL-PCS-12E 2. VAP-FB-CELL-PCSE Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Moses, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E108762.00 Mobile Access Networks Page 1 of 87 FCC ACC M Ver 1.1 05Mayl 2000 Test Report E108762.00 Mobile Access Networks Page 2 of 87 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for Mobile Access Networks VE CELL PCS Full Band Distributed Antenna System comprising: 1. VE Control Unit 2. VE Access Pod FCC ID: OJFVECELLPCSFB This report concerns: Original Grant: X Class II change: Class I change: Equipment type: PCS Licensed Transmitter Limits used: 47CFR Parts 2, 22, 24 Measurement procedure used is ANSI C63.4-2003. Substitution Method used as in ANSI/TIA-603-C: 2004 Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Steve Blum ITL (Product Testing) Ltd. Mobile Access Networks Kfar Bin Nun 8391 Old Courthouse Rd., Suite #300 D.N. Shimshon 99780 Vienna, VA. 22182 Israel U.S.A. e-mail [email protected] Tel: +1-541-758-2880 Fax: +1-703-848-0260 e-mail: [email protected] TABLE OF CONTENTS 1 GENERAL INFORMATION ------------------------------------------------------------------------------- 5 1.1 Administrative Information.................................................................................5 1.2 List of Accreditations .........................................................................................6 1.3 Product Description ...........................................................................................7 1.4 Test Methodology..............................................................................................8 1.5 Test Facility .......................................................................................................8 1.6 Measurement Uncertainty .................................................................................8 2 SYSTEM TEST CONFIGURATION--------------------------------------------------------------------- 9 2.1 Justification........................................................................................................9 2.2 EUT Exercise Software .....................................................................................9 2.3 Special Accessories ..........................................................................................9 2.4 Equipment Modifications ...................................................................................9 2.5 Configuration of Tested System ......................................................................10 3 CONDUCTED AND RADIATED MEASUREMENT TEST SET-UPS PHOTO --------------11 4 CONDUCTED EMISSION DATA-----------------------------------------------------------------------13 4.1 Test Specification ............................................................................................13 4.1 Test Procedure................................................................................................13 4.2 Results.............................................................................................................13 4.3 Test Instrumentation Used, Conducted Measurement ...................................18 5 PEAK OUTPUT POWER CDMA -----------------------------------------------------------------------19 5.1 Test Specification ............................................................................................19 5.2 Test procedure ................................................................................................19 5.3 Results Table ..................................................................................................21 5.4 Test Equipment Used......................................................................................22 6 OCCUPIED BANDWIDTH CDMA----------------------------------------------------------------------23 6.1 Test Specification ............................................................................................23 6.2 Test Procedure................................................................................................23 6.3 Results Table ..................................................................................................26 6.4 Test Equipment Used......................................................................................27 7 OUT OF BAND EMISSIONS AT ANTENNA TERMINALS CDMA ----------------------------28 7.1 Test Specification ............................................................................................28 7.2 Test procedure ................................................................................................28 7.3 Results Table ..................................................................................................30 7.4 Test Equipment Used......................................................................................31 8 BAND EDGE SPECTRUM CDMA ---------------------------------------------------------------------32 8.1 Test Specification ............................................................................................32 8.2 Test procedure ................................................................................................32 8.3 Results Table ..................................................................................................33 8.4 Test Equipment Used......................................................................................34 9 OUT OF BAND EMISSIONS (RADIATED) CDMA …
