OJR-HT1053Soundwave Bluetooth speaker

1 / 5 User’s Manual Thank you for purchasing our Soundwave Bluetooth speaker Read carefully and follow all instructions in this User's Manual before you use the Soundwave speaker. Keep this User's Manual in a convenient location for future reference Safety Instructions This product is specially designed based on the full attention to safety; in order to make sure the accident-free operation, please abide the guidelines listed below: z Always position the unit on a stable and level surface. Unstable surface can cause the unit to topple and fall, resulting in possible damage or injury z Do not drop, unpack, open, beat, curve, prink and burn the unit z Avoid using the unit nearby basins or sinks where it may come in contact with water z Do not place any ware with full water on the top of the unit, such as vase, glass, pot, and please avoid placing candle on the speaker surface as well z Protect the using of the unit from any overheating devices (such as radiator, heating installation, cooking stove or other heating devices) z Regardless of what reasons cause the unit damage, please ask for the maintenance personnel to repair z If you want to do the cleaning, please turn off the unit and unplug the power cable from the outlet first z Set the volume properly to prevent injury to the unit and your health Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. WARNING: z The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. z No naked flame sources, such as lighted candles, should be placed on the apparatus. z CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Package Contents 1. Soundwave Bluetooth speaker main unit x 1 2. USB charging cable x 1 3. Aux cable x 1 4. User’s manual x 1 Fit Models z Apply to：all iPhone and iPad series, Samsung smartphones, Tablets and other Bluetooth devices z Work with any device with standard 3.5mm earphone jack via the included Aux cable for connecting, such as MP3,PSP, Mobile phone...,etc Outstanding Features Soundwave speaker is compatible with all wireless Bluetooth devices such as iPhone, iPad, Samsung smartphones, Tablets and other Bluetooth devices. It is portable, wireless, hands-free. Just place it anywhere in a room and enjoy pristine streaming audio from your phone, computer, or other Bluetooth devices. Bring music, movies, and all your mobile audio vibrantly to life--all in the palm of your hand z Go Anywhere and Go Wireless 2 / 5 Easily connects with mobile phones, computers, tablets, iPods or any other Bluetooth device Wireless working range is up to 8 meters, no cords, no hassle z Calling and Conference on the Go With a powerful, built-in microphone, it can frees you to share clean-sounding conference calls or personal calling anywhere--in the office, car, at home, alone, or with a group z User-friendly Touch control，easy to use Built-in rechargeable battery, up to 6 hours of continuous play z Crafted outlook and function design Boxy shape and unique fence design with classical and fashion combined LINE IN, almost work with any player LINE OUT, turn the speaker into a Bluetooth receiver to work with more powerful music play system Sleep mode to save the battery for long time play Part Names Main unit Basic Operation z Power on/power off 1. Power on the unit: Press the ON/OFF button to turn on the unit, the Bluetooth indicator lights up at once 2. Power off the unit: Press the ON/OFF button again to turn off the unit, the Bluetooth indicator goes out in the meanwhile. z Connection 1. Work with phone • Power on the unit, and coming with a short Bluetooth hint sound form the unit, the Bluetooth function is on, the Bluetooth indicator lights up at the same time, these show the unit is enter pairing mode. • Turn on the Bluetooth function in your phone, and search the Bluetooth device, then, your phone will find the device named “BiJELA HT1053”, click and with a short Bluetooth hint sound come from the unit, that remind you it has been paired successfully. 2. Work with tablet PC 1. Microphone 2. ON/OFF Button 3. Volume - 4. Multi-function button (play/pause button & answer key) 5. Volume + 6. Bluetooth indicator 7. Charging indicator 8. USB charging port 9. Line in 10. Line out 3 / 5 • Please refer to the above phone connection operation steps. 3. Work with laptop/ notebook computer /PC • As the Bluetooth version for laptop/ notebook computer /PC is various, the connection methods are different as well, if you cannot connect with the unit for play on first use, you may need to install a new version of the Bluetooth driver in your laptop in advance. Please reference the instructions of laptop for details. z Play mode 1. Bluetooth mode: Play the audio signal from Bluetooth device connected with the unit. 2. AUX mode: Play the audio signal from the audio device with “LINE IN” port. Note: As long as the Aux cable is connected to the speaker, it will not play the music from Bluetooth z Play the music Play the audio signal from Bluetooth device 1. Follow the above connection steps to pair the Bluetooth device and the unit. 2. Enter in the Bluetooth device audio play menu, choose your favorite music to play. 3. Press the multi-function button to pause or play your music as you need. LINE IN： 1. Plug one end of the supplied Aux cable to the “LINE IN” port in the back of unit, and then plug the other end of the cable to audio device. 2. Choose directly your favorite music in the audio de…

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 E-CORE TECHNOLOGY (CHINA) CO., LTD. (2012-12-27) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OJR-HT1053 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Signature ____________________________________ LC Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

General Appearance of the EUT

Label Location On EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：OJR-HT1053 EUT Specification EUT Soundwave Bluetooth speaker Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 5.287dBm (0.003378W) Antenna gain (Max) 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m ) Magnetic Field Strength(A/m ) Power Density(mW/cm 2 ) Averag e Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-10000 0 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-10000 0 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) op-mode 1 2402 5.287 0 1.052e-03 1 op-mode 2 2441 4.789 0 9.527e-04 1 op-mode 3 2480 3.863 0 7.685e-04 1 op-mode 6 2402 5.155 0 1.026e-03 1 op-mode 7 2441 4.481 0 8.915e-04 1 op-mode 8 2480 3.528 0 7.019e-04 1 op-mode 10 2402 5.022 0 9.991e-04 1 op-mode 11 2441 4.288 0 8.531e-04 1 op-mode 12 2480 3.027 0 6.022e-04 1 Signature ____________________________________ LC Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

TRF No. FCC Part 15.247/A Page 1 of 56 Report No. KAD121208017E ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Soundwave Bluetooth speaker MODEL No.: HT1053 TRADE MARK: N/A FCC ID: OJR-HT1053 REPORT NO: KAD121208017E ISSUE DATE: December 20, 2012 Prepared for E-CORE TECHNOLOGY(CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, Longhua, Shenzhen, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 TRF No. FCC Part 15.247/A Page 2 of 56 Report No. KAD121208017E VERIFICATION OF COMPLIANCE Applicant: E-CORE TECHNOLOGY(CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, Longhua, Shenzhen, China Manufacturer: E-CORE TECHNOLOGY(CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, Longhua, Shenzhen, China Product Description: Soundwave Bluetooth speaker Trade Mark: N/A Model Number: HT1053 Serial Number: N/A Kind of Device: Bluetooth Ver. 2.1+EDR File Number: KAD121208017E Date of Test: December 08, 2012 to December 20, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. TRF No. FCC Part 15.247/A Page 3 of 56 Report No. KAD121208017E Table of Contents 1. GENERAL INFORMATION ....................................................................................... 5 1.1 PRODUCT DESCRIPTION............................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S)............................................................................................ 5 1.3 TEST METHODOLOGY.................................................................................................................. 5 1.4 SPECIAL ACCESSORIES................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS........................................................................................................ 5 1.6 TEST FACILITY............................................................................................................................. 6 2. SYSTEM TEST CONFIGURATION ........................................................................... 7 2.1 EUT CONFIGURATION.................................................................................................................. 7 2.2 EUT EXERCISE............................................................................................................................ 7 2.3 TEST PROCEDURE....................................................................................................................... 7 2.4 LIMITATION.................................................................................................................................. 8 2.5 CONFIGURATION OF TESTED SYSTEM........................................................................................ 11 3. SUMMARY OF TEST RESULTS ............................................................................. 12 4. DESCRIPTION OF TEST MODES........................................................................... 13 5. CONDUCTED EMISSIONS TEST ........................................................................... 14 5.1 MEASUREMENT PROCEDURE: .................................................................................................... 14 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 14 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 14 5.4 MEASUREMENT RESULT: ............................................................................................................ 14 5.5 CONDUCTED MEASUREMENT PHOTOS: ...................................................................................... 17 6. RADIATED EMISSION TEST .................................................................................. 18 6.1 MEASUREMENT PROCEDURE..................................................................................................... 18 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 18 6.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 19 6.4 MEASUREMENT RESULT............................................................................................................. 20 6.5 RADIATED MEASUREMENT PHOTOS:........................................................................................... 26 7. CHANNEL SEPARATION TEST ............................................................................. 27 7.1 MEASUREMENT PROCEDURE..................................................................................................... 27 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 27 7.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 27 7.4 MEASUREMENT RESULTS:.......................................................................................................... 27 8. 20DB BANDWIDTH TEST ....................................................................................... 33 8.1 MEASUREMENT PROCED…

Text truncated - open the document above for the full version.

Setup Photos
