OJR-HT1056Mini Crescent bluetooth speaker

1 / 5 User’s Manual Thank you for purchasing our Mini Crescent Bluetooth speaker. Read carefully and follow all instructions in this User's Manual before you use the Mini Crescent Bluetooth speaker. Keep this User's Manual in a convenient location for future reference. Safety Instructions This product is specially designed based on the full attention to safety; in order to make sure the accident-free operation, please abide the guidelines listed below: z Always position the unit on a stable and level surface. Unstable surface can cause the unit to topple and fall, resulting in possible damage or injury. z Do not drop, unpack, open, beat, curve, prink and burn the unit. z Avoid using the unit nearby basins or sinks where it may come in contact with water. z Protect the using of the unit from any overheating devices (such as radiator, heating installation, cooking stove or other heating devices) z The cable should never be severely bent, pinched or twisted. Especially at the connection point of the plug and the socket. z Due to safety issues, disconnect the plug from the socket under the weather of thunderstorms. z If the unit will not be used for an extended period of time, unplug the power cord and place the unit appropriately. z Power off the unit first before unplug the power cable from the outlet. z Regardless of what reasons cause the unit damage, please ask for the maintenance personnel to repair z If you want to do the cleaning, please turn off the unit and unplug the power cable from the outlet first. z Set the volume properly to prevent injury to the unit and your health. Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. WARNING: z The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. z No naked flame sources, such as lighted candles, should be placed on the apparatus. z CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Package Contents 1. Mini Crescent Bluetooth speaker main unit x 1 2. USB charging cable x 1 3. AUX cable x 1 4. User’s manual x 1 Fit Models z Apply to：all iPhone and iPad series, Smartphones, Laptop, Tablets and other Bluetooth devices. z Work with any device with standard 3.5mm earphone jack via the included aux cable for connecting, such as MP3,PSP, Mobile phone...,etc. Outstanding Features Mini Crescent Bluetooth speaker is a Bluetooth speaker device. This unit is compatible with all wireless Bluetooth devices such as iPad, iPhone, Smartphones, Laptops, Tablets and other Bluetooth devices. It is portable, wireless, hands-free. Just place it anywhere 2 / 5 in a room and enjoy pristine streaming audio from cell phone, computer, or other Bluetooth devices. Bring music, movies, and all your mobile audio vibrantly to life--all in the palm of your hand z Compatible with all wireless Bluetooth devices （iPhone，Phones，Smartphones，Laptops，Netbooks， Bluetooth dongles） z Working range is up to 8m, z Portable design, built-in rechargeable battery, up to 4 hours of continuous play z Built-in microphone, it can frees you to share clean-sounding conference calls or personal calling anywhere--in the office, car, at home, alone, or with a group z Aux in, work with any device with standard 3.5mm earphone jack z Aux out, turn the speaker into a Bluetooth receiver to work with more powerful music play system z Pretty lozenge metal mesh and good hand-feeling rubber casing, showing the high quality and taste Part Names Main unit Basic Operation z Power on/power off 1. Power on the unit: Slide the ON/OFF switch to “ ON” to turn on the unit, the Bluetooth indicator lights up at once 2. Power off the unit：Slide the ON/OFF switch to “ OFF” to turn off the unit, the Bluetooth indicator goes out in the meanwhile. z Connection 1. Work with phone • After powered on, a short Bluetooth hint sound comes out from the unit, the Bluetooth function is on, the Bluetooth indicator lights up at the same time, these show the unit is entering pairing mode. • Turn on the Bluetooth function in your phone, and search the Bluetooth device, then, your phone will find the device named “mini speaker”, enter the password “0000”, a short Bluetooth hint sound will come from the unit, these remind you it has been paired successfully. • After paired for the first time, your phone and the unit can auto-pair without enter the password, just chose the device “mini speaker” in the list, and then you phone will connect the unit swiftly. Note: Please take the User’s manual of your cell phone for the details about Bluetooth connection. 2. Work with tablet PC • Please refer to the above phone connection operation steps. 1. Bluetooth indicator 2. Volume – 3. Multi-function button (play/pause button & answer key) 4. Volume + 5. Microphone 6. Line out 7. LINE IN 8. USB charging port 9. Charging indicator 10. ON/OFF switch 3 / 5 3. Work with laptop/ notebook computer /PC • As the Bluetooth version for laptop/ notebook computer /PC is various, the connection methods are different as well, if you can not connect with the unit for play on first use, you may need to install a new version of the Bluetooth driver in your laptop in advance. Please reference the instructions of laptop for details. z Play mode 1. Bluetooth mode: play the audio signal from Bluetooth device connected with the unit. 2. LINE IN mode: play the audio signal from the audio device with “LINE IN” port. Note: As long as the Aux cable is connected to the speaker, it will not play …

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 E-CORE TECHNOLOGY (CHINA) CO., LTD. (2012-10-10) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OJR-HT1056 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Signature ____________________________________ LC Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

General Appearance of the EUT Only for Charging

DONGGUAN EMTEK CO., LTD. REPORT NO.: ED120905012S Page 2 of 42 Copy of marking plate Note: - The above markings are the minimum requirements required by the safety standard. For the final production, the additional markings which do not give rise to misunderstanding may be added. -The high of “CE” and “WEEE” at least 5mm and 7mm. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label Location On EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：OJR-HT1056 EUT Specification EUT Mini Crescent bluetooth speaker Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -4.37dBm (0.000366W) Antenna gain (Max) 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel number Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 1 2402 0.366 0 7.281e-5 1 40 2441 0.308 0 6.127e-5 1 79 2480 0.288 0 5.729e-5 1 Signature ____________________________________ LC Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120905006E FCC ID: OJR-HT1056 DATE: 10/15/2012 Page 1 of 43 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Mini Crescent bluetooth speaker MODEL No.: HT1056, ISOUND-5204, ISOUND-5205 TRADE MARK: dreamGEAR, LLC FCC ID: OJR-HT1056 REPORT NO: KAD120905006E ISSUE DATE: October 15, 2012 Prepared for E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120905006E FCC ID: OJR-HT1056 DATE: 10/15/2012 Page 2 of 43 VERIFICATION OF COMPLIANCE Applicant: E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Manufacturer: E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Product Description: Mini Crescent bluetooth speaker Trade Mark: dreamGEAR, LLC Model Number: HT1056, ISOUND-5204, ISOUND-5205 (Note: These samples are the same except trade name and model number, so we prepare HT1056 for EMC test.) Serial Number: N/A File Number: KAD120905006E Date of Test: September 05, 2012 to October 15, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120905006E FCC ID: OJR-HT1056 DATE: 10/15/2012 Page 3 of 43 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 3. SUMMARY OF TEST RESULTS ....................................................................................... 12 4. DESCRIPTION OF TEST MODES .................................................................................... 12 5. CONDUCTED EMISSIONS TEST ..................................................................................... 13 5.1 MEASUREMENT PROCEDURE:................................................................................................................ 13 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 13 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 13 5.4 MEASUREMENT RESULT:........................................................................................................................ 13 5.5 CONDUCTED MEASUREMENT PHOTOS: ................................................................................................. 16 6. RADIATED EMISSION TEST ............................................................................................ 17 6.1 MEASUREMENT PROCEDURE................................................................................................................. 17 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 18 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 19 6.4 MEASUREMENT RESULT......................................................................................................................... 19 6.5 RADIATED MEASUREMENT PHOTOS: ..................................................................................................... 25 7. CHANNEL SEPARATION TEST ....................................................................................... 26 7.1 MEASUREMENT PROCEDURE......................................................…

Text truncated - open the document above for the full version.

Setup Photos
