OJR-HT2011Pureplay Pro Bluetooth speaker

1 / 4 User’s Manual Thank you for purchasing our Pureplay Pro Bluetooth speaker. Read carefully and follow all instructions in this User's Manual before you use the speaker. Keep this User's Manual in a convenient location for future reference. Safety Instructions This product is specially designed based on the full attention to safety; in order to make sure the accident-free operation, please abide the guidelines listed below: z Always position the unit on a stable and level surface. Unstable surface can cause the unit to topple and fall, resulting in possible damage or injury. z Do not drop, unpack, open, beat, curve, prink and burn the unit. z Avoid using the unit nearby basins or sinks where it may come in contact with water. z Do not place any ware with full water on the top of the unit, such as vase, glass, pot, and please avoid placing candle on the speaker surface as well. z Protect the using of the unit from any overheating devices (such as radiator, heating installation, cooking stove or other heating devices) z Regardless of what reasons cause the unit damage, please ask for the maintenance personnel to repair z If you want to do the cleaning, please turn off the unit and unplug the power cable from the outlet first. z Set the volume properly to prevent injury to the unit and your health. Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. WARNING: z No naked flame sources, such as lighted candles, should be placed on the apparatus. Package Contents 1. Pureplay Pro Bluetooth speaker main unit x 1 2. Power adapter x 1 3. Aux cable x 1 4. User’s manual x 1 Fit Models z Apply to：all iPhone and iPad series, Smartphones, Laptop, Tablets and other Bluetooth devices. z Work with any device with standard 3.5mm earphone jack via the included aux cable for connecting, such as MP3,PSP, Mobile phone...,etc. Outstanding Features Pureplay Pro Bluetooth speaker is compatible with all wireless Bluetooth devices such as the iPad, iPhone, Smartphones, Laptops, Tablets and other Bluetooth devices, makes your life full of fun. Additionally, the “AUX IN” function let the unit work with any device with standard 3.5mm earphone jack, this function provides you more entertainment options. z Subwoofer built-in, delivers natural and immersive sound with deep, rich bass z Compatible with all wireless Bluetooth devices(iPad, iPhone, Smartphones, Laptops, Tablets and other Bluetooth devices) z Working range is up to 8m 2 / 4 z Generous design for bedroom or house saloon decoration z Aux in, work with any device with standard 3.5mm earphone jack z Automatic connection, only one time pairing Part Names Main unit Basic Operation z Connecting the Power Cord and Power Adaptor 1. Plug the supplied power adapter into the wall outlet, and then, connect the DC end of power cord into the “DC IN” socket on the unit. z Power on/power off 1. Power on the unit: Press the power button on the unit, the red power indicator will light up. 2. Power off the unit：Hold the power button for 3 seconds to power off the unit, the red power indicator goes out. z Connection 1. Work with phone （1） Power on the unit, the Bluetooth function turns on automatically, a short Bluetooth hint sound comes out form the unit, , the blue Bluetooth indicator flashes at the same time, these show the unit is entering pairing mode. （2） Turn on the Bluetooth function in your phone, search the Bluetooth device named “BiJELA HT2011”, select the device and enter the password “0000”, the phone will remind you it has been paired successfully. （3） After paired for the first time, your phone and the unit can auto-pair without enter the password, just chose the device “BiJELA HT2011”in the list, and then your phone will connect the unit swiftly. Note:Please take the User’s manual of your cell phone for the details about Bluetooth connection. 2. Work with tablet PC Please refer to the above phone connection operation steps. 3. Work with laptop/ notebook computer /PC As the Bluetooth version for laptop/ notebook computer /PC is various, the connection methods are different as well, if you can not connect with the unit for play on the first use, you may need to install a new version of the Bluetooth driver in your laptop in advance. Please reference the instructions of laptop for details. z Play mode Press the source switch to choose the play mode 1. Multi-function button (Power button & source switch) 2. Play/Pause button ( Built-in Bluetooth LED indicator) 3. Volume wheel 4. AUX IN 5. DC IN 6. Anti-slip pad 3 / 4 1. Bluetooth mode: play the audio signal from Bluetooth device connected with the unit. 2. AUX mode: play the audio signal from the audio device with “AUX IN” port. z Play the music Play the audio signal from Bluetooth device 1. Follow the above connection steps to pair the Bluetooth device and the unit. 2. Enter in the Bluetooth device audio play menu, choose your favorite music to play. 3. Press the multi-function button to pause or play your music as you need. AUX IN： 1. Plug one end of the supplied aux cable to the “AUX IN” port in the back of unit, and then plug the other end of the cable to audio device. 2. Choose directly your favorite music in the audio device to play 3. Press the multi-function button to pause or play your music as you need. z Adjusting the volume Rotate the volume wheel on the unit or control the Bluetooth device volume directly to adjust the volume. Technical parameters Note: All specifications are subject to change without notice. Product Name: Pureplay Pro Bluetooth speaker…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 E-CORE TECHNOLOGY (CHINA) CO., LTD. (2012-09-15) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, E-CORE TECHNOLOGY (CHINA) CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Pureplay Pro Bluetooth speaker(M/N: HT2011) FCC ID: OJR-HT2011 We affirm that between SIEMIC and _ E-CORE TECHNOLOGY (CHINA) CO., LTD. _, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Signature ____________________________________ Liucheng Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 E-CORE TECHNOLOGY (CHINA) CO., LTD. (2012-09-14) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OJR-HT2011 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Signature ____________________________________ Liucheng Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

General Appearance of the EUT

FCC ID: OJR-HT2011 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label Location On EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：OJR-HT2011 EUT Specification EUT Pureplay Pro Bluetooth speaker Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -7.69dBm (0.00017W) Antenna gain (Max) 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) op-mode 1 2402 0.142 0 2.83e-5 1 op-mode 2 2441 0.107 0 2.13e-5 1 op-mode 3 2480 0.095 0 1.89e-5 1 op-mode 6 2402 0.170 0 3.38e-5 1 op-mode 7 2441 0.136 0 2.71e-5 1 op-mode 8 2480 0.110 0 2.19e-5 1 op-mode 10 2402 0.142 0 2.83e-5 1 op-mode 11 2441 0.129 0 2.57e-5 1 op-mode 12 2480 0.103 0 2.05e-5 1 Signature ____________________________________ Liucheng Liu [email protected] Tel: +86 755-2967 4909 Fax: +86 755-8170 8411 E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China

DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120829036E FCC ID: OJR-HT2011 DATE: 09/13/2012 Page 1 of 51 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Pureplay Pro Bluetooth speaker MODEL No.: HT2011 TRADE MARK: BiJELA FCC ID: OJR-HT2011 REPORT NO: KAD120829036E ISSUE DATE: September 13, 2012 Prepared for E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120829036E FCC ID: OJR-HT2011 DATE: 09/13/2012 Page 2 of 51 VERIFICATION OF COMPLIANCE Applicant: E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Manufacturer: E-CORE TECHNOLOGY (CHINA) CO., LTD. 3rd Building, Weidonglong Industry, Heping East Road, LongHua, Shenzhen, China Product Description: Pureplay Pro Bluetooth speaker Trade Mark: BiJELA Model Number: HT2011 Serial Number: N/A Kind of Device: Bluetooth Ver. 2.1+EDR File Number: KAD120829036E Date of Test: July 05, 2012 to September 13, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120829036E FCC ID: OJR-HT2011 DATE: 09/13/2012 Page 3 of 51 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 3. SUMMARY OF TEST RESULTS ....................................................................................... 12 4. DESCRIPTION OF TEST MODES .................................................................................... 12 5. CONDUCTED EMISSIONS TEST ..................................................................................... 13 5.1 MEASUREMENT PROCEDURE:................................................................................................................ 13 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 13 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 13 5.4 MEASUREMENT RESULT:........................................................................................................................ 13 5.5 CONDUCTED MEASUREMENT PHOTOS: ................................................................................................. 16 6. RADIATED EMISSION TEST ............................................................................................ 17 6.1 MEASUREMENT PROCEDURE................................................................................................................. 17 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 18 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 19 6.4 MEASUREMENT RESULT......................................................................................................................... 19 6.5 RADIATED MEASUREMENT PHOTOS: ..................................................................................................... 25 7. CHANNEL SEPARATION TEST ....................................................................................... 26 7.1 MEASUREMENT PROCEDURE................................................................................................................. 26 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ..........................…

Text truncated - open the document above for the full version.

Setup Photos
