1 Operation Manual ID-Tablet/10574 REVISION 0.9, 2010-07-22 The ID-Tablet is a RFID Read-/Write-Device (short: reader) which is compatible to read and write to Mifare® cards. The reader also supports ISO 14443A/B and all cards compliant to these standards. All functions of reader can be controlled over USB- interface which allows data exchange with a host computer. This includes: switch on/off RF-Field read/write to a transponder Mounting and Connection The reader generates a magnetic field with the frequency of 13.56MHz which is influenced by any electrically conductive material in close proximity to the device. When mounting the unit, a distance to any such material of minimum 10 cm is required to ensure that there will be no significant degradation of the performance in terms of read range and reliability. Mounting the unit directly to metal would result in a severe reduction of read range down to zero functionality. Care should be taken when testing the device after mounting at a problematic environment: Read ranges and performance vary from card to card and very much from card to tag or key-fob. When mounting multiple readers, the distance between readers should be minimum 0.5 m in order to avoid degradation of performance due to interference. Technical Data DC Electrical Characteristics Symbol Parameter Condition Min Typ Max. Units Vdd Supply Voltage 4 5 5.5 Vdc Idd Supply Current @ 5 Vdd 200 mA Idd1 Peak Supply Current Inrush 400 mA RF Characteristics Operating frequency: 13.56 MHz Data transmission modulation reader to card: ASK Data transmission modulation card to reader: ASK/load modulation 2 Pinout 4-Pin USB-A plug and Signal Descriptions Pin Name Type Description 1 PWR Power 5V Power Supply 2 D - Output USB-data inverted 3 D + Input USB-data 4 GND Power Signal and Power Ground Temperature Operating temperature range: 0...45°C Storage temperature range: -20...+60°C Thermal shock: 30°C/min maximum dT/dt Humidity Operating: 20% to 80% relative humidity; non condensing Non-operating: 5% to 90% relative humidity; non condensing General regulatory requirements FCC: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Canada: This Class B digital apparatus complies with Canadian ICES-003.Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada 3
BALTECH AG Lilienthalstraße 27 85399 Hallbergmoos Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 07.03.2008 Datum: Seite 1 von 1 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: July 27, 2010 FCC ID OKY1057400101A02 Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Jürgen Rösch
BALTECH AG Lilienthalstraße 27 85399 Hallbergmoos PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg FCC ID OKY1057400101A02 To Whom It May Concern: Please be advised that Baltech AG authorizes TÜV SÜD SENTON GmbH, Mr. Johann Roidt, to act on our behalf, until otherwise notified, for applications submitted to PHOENIX TEST-LAB GmbH (PTL). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C.862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Date: 28.07.2010 ______________________________________ Signatory Jürgen Rösch
PHOENIX TEST-LAB GmbH Koenigswinkel 10 D-32825 Blomberg Germany In reference to FCC ID OKY1057400101A02 Justification for Part 15 Unlicensed Modular Transmitter Approval according to DA 00-1407 1. Own RF Shielding Not complied, but subject to limited modular approval. The Grantee can demonstrate that it will retain control over the final installation of the device, such that compliance of the end product is assured. In such a case, an operating condition on the grant of equip- ment authorization for the module would state that the module is only approved for use when installed in devices produced by a specific manufacturer, typically the Grantee. Integration of this radio module into final host devices will only be performed by the Grantee himself or dedicated OEM integrators to assure always compliance of the final end-product with the FCC Regula- tions. 2. Buffered Modulation inputs Complied, see schematics diagrams 3. Own power supply regulation Complied, voltage regulated power supply on board, see schematic diagram 4. Antenna requirements Complied, integrated antenna 5. Test in stand-alone configuration Complied, see test report for details. Cable lengths typical to actual use. 6. Own FCC ID Complied, the exterior label will be "Contains FCC ID OKY1057400101A02" 7. The Modular Transmitter must comply with any specific rule and the manufacturer must provide adequate instructions The EUT is compliant with all applicable FCC rules. Detail instructions are given in the User guide. 8. RF Exposure requirements Not applicable since the unit operates under section 15.225 of the FCC rules. The reference guide contains general installation and operation instructions. MPE evaluation not required Johann Roidt TÜV SÜD SENTON GmbH TÜV SÜD SENTON GmbH • Äußere Frühlingstraße 45 • 94315 Straubing • Deutschland
Request for Confidentiality PHOENIX TESTLAB GmbH Date: July 27, 2010 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: OKY1057400101A02 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Technical Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure od this application and all accompanying documentation will not be made before the date of the GRANT for this application ́. Thank you for your attention in this matter. Applicant’s Company : TÜV SÜD SENTON GmbH address : Auessere Fruehlingstrasse 45, D-94315 Straubing Signature : Johann Roidt Job Title and Dept. : Technical Director
Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 69583-02308 (Edition 2) Page 1 of 81 Pages Prüfbericht / Test Report Nr. / No. 69583-02308 (Edition 2) Applicant: BALTECH AG Type of equipment: ID-TABLET Type designation: 10574 Order No.: Test standards: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207, 15.215 and 15.225 Industry Canada Radio Standards Specifications RSS-Gen Issue 2, Section 7.2.2 and RSS-210 Issue 7, Sections 2.2, 2.6, A2.6 (Category I Equipment) July 27, 2010 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69583-02308 (Edition 2) Page 2 of 81 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ............................................................ 3 2 Administrative Data ........................................................................................................ 4 3 Identification of the Test Laboratory ............................................................................... 5 4 Summary ........................................................................................................................ 6 5 Operation Mode and Configuration of EUT .................................................................... 7 6 Measurement Procedures .............................................................................................. 8 6.1 Bandwidth Measurements ....................................................................................... 8 6.2 Conducted AC Powerline Emission ......................................................................... 9 6.3 Radiated Emission Measurement 9 kHz to 30 MHz ............................................... 11 6.4 Radiated Emission in Fully or Semi Anechoic Room ............................................. 13 6.5 Radiated Emission at Alternative Test Site ............................................................ 15 6.6 Carrier Frequency Stability ..................................................................................... 17 7 Photographs Taken During Testing .............................................................................. 19 8 Test Results ................................................................................................................. 28 8.1 Occupied Bandwidth .............................................................................................. 30 8.2 Bandwidth of the Emission..................................................................................... 34 8.3 Designation of Emissions ....................................................................................... 36 8.4 Conducted Powerline Emission Measurement 150 kHz to 30 MHz ...................... 37 8.5 Spectrum Mask ...................................................................................................... 44 8.6 Radiated Emission Measurement 9 kHz to 30 MHz .............................................. 46 8.7 Radiated Emission Measurement 30 MHz to 1 GHz ............................................. 50 8.8 Carrier Frequency Stability ..................................................................................... 52 8.9 Exposure of Humans to RF Fields ......................................................................... 55 9 Referenced Regulations ............................................................................................... 57 10 Revision History ........................................................................................................... 58 11 Charts taken during testing .......................................................................................... 59 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69583-02308 (Edition 2) Page 3 of 81 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : 10574 Parts 2 : Serial number(s): Manufacturer: BALTECH AG Type of equipment: ID-TABLET Version: As received FCC ID: OKY1057400101A02 Additional parts/accessories: Technical data of EUT Application frequency range: 13.110 - 14.010 MHz Frequency range: 13.553 – 13.567 MHz Operating frequency: 13.56 MHz Type of modulation: ASK Pulse train: --- Pulse width: --- Number of RF-channels: 01 Channel spacing: --- Designation of emissions 3 : 5K00A1D Type of antenna: Integrated on printed board Size/length of antenna: Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 5.0 V minimum voltage: 4.25 V maximum voltage: 5.75 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69583-02308 (Edition 2) Page 4 of 81 Pages 2 Administrative Data Application details Applicant (full address): BALTECH AG Lilienthalstraße 27 D-85399 Hallbergmoos Contact person: Cemil Yatkin Order number: Receipt of EUT: June 28, 2010 Date(s) of test: June – July 2010 Note(s): Report details Report number: 69583-02308 Edition: 2 Issue date: July 27, 2010 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.com/senton eMail: [email protected] Test Report No. 69583-02308 (Edition 2) Page 5 of 81 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Com…
