OSCMSP345CLASSICPRINTER

India’s largest manufacturer of peripherals Dot Matrix Printers UPS systems Keyboardslll T H E L E T T E R Q U A L I T Y O F F I C E P R I N T E R MSP 345 136 col24 - wire300 cpsll Fastest Speed - 300cps Wide Operating Voltage - 150VAC~270VAC Nine Letter Quality Fonts Convertible Push & Pull Tractor Flexible Paper Handling - Top, Rear & Bottom CERTIFIED Dealer / Channel Partner / Contact Note: 1. All specifications are at standard operating conditions. 2. Specifications are subject to change without notice. 3. Always use original TVS-E MaxiPrint ribbons for better performance. Counterfeits can damage the printer. MSP 345 Product Specifications Ordering Information SKU / FRU No.Description 1345MS05MSP 345 Classic Standard ConfigurationCD ROM, Quick Reference Manual Insertion Plate, Convertible Push / Push Tractor, Black Ribbon Cartridge, Parallel Interface Cable Power Cord, Dust Cover. Optional 1FMSSIB007Serial Interface Unit Consumables 3M011058Black Ribbon Print Method Print Direction Print Head - Type Print Width Print Head Life Print Speed Resident Printer Fonts Paper Handling Paper Size Copy Capability** Consumables - Ribbon Serial Impact Dot Matrix Bi-directional Logic Seeking 24 Wire 136 Column 100 Million Characters 101215 High Speed Draft (cps)300 Draft (cps)250300375 Letter Quality (cps)83100125 DraftDraft, High Speed Draft Letter QualityRoman, Sans Serif, Courier, Prestige, Script, Script-C, Orator, OCR-B, Orator-S Letter Quality Scalable FontsRoman, Sans Serif (8 to 40 points) Paper Path-StandardTop, Rear and Bottom Continuous-Tractor Feed- StandardConvertible Push & Pull Continuous Form Width4 - 16” Cutsheets Width7.2 - 16.1” Paper Thickness (max) - Tractor feed0.3mm Paper Thickness (max) - Friction feed0.3mm 1+3 with carbon Fabric-Ink TypeHigh Density (Mobius Loop) Fabric Life***3 Million Characters Input Buffer (Kilo Bytes) Reliability-MTBF (Power on Hours) Acoustics - Noise Level Emulation Interface Electrical Specifications Environmental- Operating Conditions Physical Dimensions 40 ESC P/2, Proprinter XL24e KB 6,000 POH 55 dB(A) StandardCentronics IEEE-P1284A Parallel OptionalRS 232C Serial Operating Voltage150 VAC ~ 270 VAC Mains Frequency47 - 63 Hz Power (Standby)12 W o Temperature+5 to +45C Relative Humidity10% to 80% Size (WxDxH) mm608 x 379 x 147 Weight (Kg)7 *** Ribbon Life @ Draft 10 cpi. ** Max. possible copy capability. * LQ : Letter Quality. 1 kg = 2.2lbs; 1 inch = 2.54 cms. V e r 0 8 0 1 BRANCH OFFICES: lll llll llll Ahmedabad: Ph: (079) 685 7701 / 3 / 4, (079) 6855202 Bangalore: Ph: (080) 6565010, 6561679 Kolkata: Ph: (033) 4769611 - 4 Chennai: Ph: (044) 8550335, 8550856, 8526469, 8526598, 8526290 Delhi: Ph: (011) 4603367-9, 4603714 Hyderabad: Ph: (040) 7816667, 7847244, 7845144 Kerala: Ph: (0484) 360462/3/4, 355433 Madhya Pradesh: Ph: (Mobile) 98270-55382, 98270-32319 (Service) Mumbai: Ph: (022) 7668496/8, 7669362 Pune: Ph: (020) 5674508, 5675364 Punjab: Ph: (0172) 605581 Uttar Pradesh: Ph: (0522) 285614 / 282042 Taking IT to the heart of India TVS Electronics Limited 34, Developed Plots, South Phase, Industrial Estate Guindy, Chennai - 600 032. Tel.: +91-44-232 5506 & 232 5509 Fax: +91-44-2327577HEAD OFFICE: www.tvs-e.com EPA POLLUTION PREVENTER As an Energy Star Partner TVS Electronics determines that this product meets the Energy Star Guidelines for energy efficiency. Use only genuine TVSE high density ribbons for Long Print Head Life. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : OSCMSP345Classic Model No.: MSP 345 Classic LABEL Size: 50 X 20 mm LABEL Position: LABEL

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : OSCMSP345Classic Model No.: MSP 345 Classic LABEL Size: 50 X20 mm

Test Report --------------------------------------------------------------------------- 2/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Contents Chapter 1 Introduction Description of EUT ................................................................................................................... 3 Configuration of Test Setup ...................................................................................................... 4 List of Support Equipment ........................................................................................................ 5 Chapter 2 Conducted Emission Test Test Condition and Setup .......................................................................................................... 7 Conducted Test Placement ........................................................................................................8 Chapter 3 Radiated Emission Test Test Condition and Setup .......................................................................................................... 9 Radiated Test Placement .......................................................................................................... 10 Appendix A : Conducted test result ................................................................................................................ 11 Appendix B : Radiated test result ................................................................................................................... 12 Appendix C: List of Modifications ................................................................................................................ 13 Test Report --------------------------------------------------------------------------- 3/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Chapter 1 Introduction Description of EUT: The EUT is a Dot Matrix Printer. Test method: Pretest was found that the emission of operating mode is worse than standby mode. So, The final test is made at the operating mode. During the pretest, the EUT was at “operating” mode. The test voltage is 230Vac/50Hz. The test placement as the photographs showed is the worst case emission placed. (If the emission is close to the ambient, the resolution BW and view resolution will be reduced and the data will be recorded by detection of maximum hold peak mode.) The testing configuration of test setup is showing in the next page. Test Report --------------------------------------------------------------------------- 4/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Configuration of test setup Connections: PC: *Serial Port --- via a 76cm shielded RS-232 cable to an external modem *Monitor Port --- a monitor with 1.5m length data cable. *Keyboard Port --- a keyboard with 1.7m length data cable. *Mouse Port --- a mouse with 1.8m length of data cable. *Printer port --- to EUT. *USB Port A --- a joystick with 1.5m length shielded and no ferrite bead data cable *USB Port B --- a mouse with 1.5m length shielded and no ferrite bead data cable (Each port on PC is connected with suitable device) EUT: *Printer port --- via a 1.18m length braid shielded data cable to the printer port of PC. *Power port --- via a 2.0m length power cable to the power source. Power Source PS/2 Mouse Keyboard Monitor PC Modem USB Mouse USB Joystick EUT Test Report --------------------------------------------------------------------------- 5/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 List of support equipment Conducted (Radiated) test: PC : HP Brio 85xx 6/350 Model No. : D6928A Serial No. : SG91801443 FCC ID : Doc Approved Power type : 100 ~ 230VAC / 50 ~ 60Hz, 5A, Switching Power cord : Non-shielded, 2.33m long, Plastic, No ferrite core Keyboard : Logitech SK-720C Model No. : Y-SA2 Serial No. : SCC04514357 FCC ID : GYUR49SK Power type : By PC Data cable : Shielded, 1.73m long, with ferrite core Monitor : HP 15’ Color Monitor Model No. : D2827A Serial No. : KR91161719 FCC ID : C5F7NFCMC1518X Power type : 110 ~ 240 VAC / 50 ~ 60 Hz, Switching Power cord : Shielded, 1.83m long, No ferrite core Data cable : Shielded, 1.46m long, with two ferrite cores Mouse : HP Model No. : M-S34 Serial No. : LZB90714106 (LZB90714122) FCC ID : DZL211029 Power type : By PC Power cord : Non-shielded, 1.88m long, No ferrite core USB Mouse : Logitech Wheel Mouse Model No. : M-BJ-58 Serial No. : LN20901985 FCC ID : Doc Approved Power type : By PC Power cord : Non-shielded, 1.88m long, No ferrite core Test Report --------------------------------------------------------------------------- 6/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Modem : ACEEX Model No. : DM-1414V FCC ID : IFAXDM1414 Power type : 120VAC, 60Hz/ 9VAC, 1A Power cord : Non-shielded, 1.9m long, no ferrite cord Data cable : RS232, Shielded, 1.2m long, no ferrite core RJ11C x 2, 7’ long non-shielded, no ferrite core USB Joystick : Rockfire Model No. : QF-337uv Serial No. : 10600545 FCC ID : CE Approval Power type : Powered by PC Power cable : Shielded, 1.8m long, No ferrite bead data cable Test Report --------------------------------------------------------------------------- 7/13 Report No.: T5415608 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Chapter 2 Conducted emission test Test condition and setup: All the equipment is placed and setup according to the CISPR 22. The EUT is assembled on a wooden table that is 80 cm high, is placed 40 cm from the back-wall that is a vertical conducting plane. One LISN is for EUT, the other LISN is for support equipment. They are all placed on the conductive ground. The EUT’s LISN connect a line switch box for selecting L1 or L2, then connect to a preamplifier and spectrum for pretest. The spectrum measured from 150KHz to 30MHz. Conducted emission levels are detected at ma…

Text truncated - open the document above for the full version.

Conducted Test Placement: (Photographs) Radiated Test Placement: (Photographs)
