OSZ37300PCISL37300PC

1 TM File NumberFN8026 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 321-724-7143 |Intersil and Design is a trademark of Intersil Americas Inc. Copyright © Intersil Americas Inc. 2001, All Rights Reserved PRELIMINARY ISL37300P-EVAL PRISM 2.5 11Mbps Wireless Local Area Network PC Card The Intersil ISL37300P WLAN PC-Card (Note 1) is a complete wireless high speed Network Interface Card (NIC) utilizing the Intersil PRISM® 2.5 Direct Sequence Spread Spectrum Wireless Transceiver chip set. It provides a complete PRISM 2.5 reference design evaluation platform of hardware and software to system providers or integrators requiring wireless data communications capability and is ideal for integration into computer platforms. The Evaluation kit (ISL37300P-EVAL) includes two WLAN PC Cards designed to Intersil’s Prism reference design, Microsoft Windows® Driver, Local Area Network evaluation software, Prism Test Utilities (PTU) software and documentation to complete the evaluation. It supports the IEEE 802.11b network specification for Direct Sequence Spread spectrum DSSS signaling, providing data rates of 1, 2, 5.5, and 11 Mbps. Evaluation kit software updates are available on the Intersil Web Site. Access Points will be available from a number of suppliers, enabling a totally wireless network solution. Typical operating ranges are shown in Table 1.. Features • FCC Certified Under Part 15 to Operate in 2.4GHz ISM Band (Approval Pending) • Support for 11, 5.5, 2 and 1 Megabit Per Second (Mbps) Data Rates • Supports the lEEE 802.11 Direct Sequence Specification • Driver Supports Microsoft® Windows® 95, 98, 98SE, 2000, NT and ME • Supports Dual Diversity Antennas • Advanced RAKE Receiver Design with AGC • Provides Wireless Data Communications at Full Ethernet Speed • Designed to Fully Support PC-card Defined Mechanical and Environmental Stress Conditions • Intelligent Power Control, Including IEEE 802.11 Power Save Mode • Complete Reference Design, the ISL37300P CD is available to ensure Minimum Time-to-Market NOTES: 1. Throughout this document, all references to ‘PC Card’, ‘WLAN adapter’, ‘adapter’, or ‘card’ refer to a card assembly conforming to the mechanical size specifications of the PC Card. 2. The range will vary in different operating environments due to effects such as building construction. 3. At present, PTTU supports Windows 95, 98 and 98SE. An upgrade is in process which will add support for NT. Packaging TABLE 1. TYPICAL OPERATING RANGE(NOTE 2, ) DATA RATE (Mbps)INDOOR RANGEOUTDOOR RANGE 11120 feet (37 meters)500 feet (152 meters) 5.5200 feet (61 meters)800 feet (243 meters) 2240 feet (73 meters)1300 feet (396 meters) 1300 feet (91 meters)1750 feet (533 meters) Ordering Information PART NUMBERDESCRIPTIONCARDS/ SET ISL37300P-EVALWLAN Evaluation Kit2 Data SheetAugust 2001 tle jec tho w () ato CI ar e e O es C W ar 2 Functional Overview The WLAN PC-Card is designed to operate in the 2.4GHz ISM frequency band, channels 1 to 11, as specified by the FCC in the USA. The card will also operate on channels 12 through 14, where permitted by local regulatory authorities. Radio equipment must be certified in a country prior to use. Refer to Table 4 for a list of countries and agencies that have approved the ISL37300P-EVAL for operation. The Intersil PRISM Chip Set allows for high level integration for reduced size, increased throughput, improved radio performance and faster time to market. The WLAN PC-card implements Direct Sequence Spread Spectrum DSSS technology providing superior noise and signal jamming immunity including less severe impact from unintentional radiators such as microwave ovens. The user can connect the PC-card in an ad-hoc peer to peer networking scheme, allowing for instant network setup in any office environment. By using an access point, the wireless LAN can be set up to allow for a greater number of users to interconnect, and to increase the coverage area. With a portal (i.e. Access Point), the wireless LAN can be easily connected into an existing wired LAN, allowing for easy expansion of the service. Compared to the PRISM II chip set, the PRISM 2.5 generation offers: • Low loss front end designed for maximum range • Higher level of chip integration and less peripheral components to reduce material costs • Support of optional IEEE 802.11 Short Preamble for significantly increased data throughput • Has a Type II PC Card form factor A complete Reference Design for the ISL37300P is available to ensure minimum time-to-market. This information contains details for manufacturing a PC Card WLAN assembly, including Gerber PC board files, a Bill of Material with component sourcing, mechanical drawings, a detailed Radio Description with debug directions and a test plan. Related Literature To learn more about what the IEEE 802.11 is, refer to: • Tech Brief TB337, Intersil Corporation, “A Brief Tutorial on Spread Spectrum and Packet Radio”[1]. For a more detailed description of radio operation, please refer to: • Application Note AN9968, Intersil Corporation, “ISL37300P- EVAL PRISM 2.5 PCMCIA Wireless LAN Radio Description” [2] The ISL3873 Media Access Controller (MAC) Protocol Handler The ISL3873 MAC/Baseband Processor and its firmware are responsible for running the IEEE 802.11 protocol in the WLAN card. This section describes the features of IEEE 802.11 that are implemented. The functions supported by the STA (station) Firmware are: • CSMA /CA (Carrier Sense Multiple Access with Collision Avoidance) with Random Backoff •WEPSecurity • Short/Long Preamble with multirate • RTS/CTS Handshake (Ready To Send / Clear To Send) and NAV Management (Network Allocation Vector) • MAC Level Acknowledgments (Media Access Control) • Re-Transmission of Unacknowledged Frames • Duplicate Detection and Rejection • Broadcast and Multicast Frames • Fragmentation and Re-Assembly • Power Management (Planned) • Timestamp Synchronization…

Text truncated - open the document above for the full version.

1 TM File NumberFN8026 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 321-724-7143 |Intersil and Design is a trademark of Intersil Americas Inc. Copyright © Intersil Americas Inc. 2001, All Rights Reserved PRELIMINARY ISL37300P-EVAL PRISM 2.5 11Mbps Wireless Local Area Network PC Card The Intersil ISL37300P WLAN PC-Card (Note 1) is a complete wireless high speed Network Interface Card (NIC) utilizing the Intersil PRISM® 2.5 Direct Sequence Spread Spectrum Wireless Transceiver chip set. It provides a complete PRISM 2.5 reference design evaluation platform of hardware and software to system providers or integrators requiring wireless data communications capability and is ideal for integration into computer platforms. The Evaluation kit (ISL37300P-EVAL) includes two WLAN PC Cards designed to Intersil’s Prism reference design, Microsoft Windows® Driver, Local Area Network evaluation software, Prism Test Utilities (PTU) software and documentation to complete the evaluation. It supports the IEEE 802.11b network specification for Direct Sequence Spread spectrum DSSS signaling, providing data rates of 1, 2, 5.5, and 11 Mbps. Evaluation kit software updates are available on the Intersil Web Site. In addition to the evaluation kit, acomplete PRISM chipset WLAN reference design package (ISL37300P-CD) is available. It contains all the documentation needed for manufacturing of the Prism 2.5 PCMCIA wireless network card including: Cadence/Allegro Layout, Gerber files, Concept schematic, Bill of Materials, assembly and mechanical drawings, test plan, and even a copy of the application for FCC equipment authorization. Customers who license the reference design also receive password access to Intersil’s Premier Web site for up to the minute updates on hardware and software Access Points will be available from a number of suppliers, enabling a totally wireless network solution. Typical operating ranges are shown in Table 1.. Features • FCC Certified Under Part 15 to Operate in 2.4GHz ISM Band (Approval Pending) • Support for 11, 5.5, 2 and 1 Megabit Per Second (Mbps) Data Rates • Supports the lEEE 802.11 Direct Sequence Specification • Driver Supports Microsoft® Windows® 95, 98, 98SE, 2000, NT and ME • Supports Dual Diversity Antennas • Advanced RAKE Receiver Design with AGC • Provides Wireless Data Communications at Full Ethernet Speed • Designed to Fully Support PC-card Defined Mechanical and Environmental Stress Conditions Packaging TABLE 1. TYPICAL OPERATING RANGE(NOTE 2, ) DATA RATE (Mbps)INDOOR RANGEOUTDOOR RANGE 11120 feet (37 meters)500 feet (152 meters) 5.5200 feet (61 meters)800 feet (243 meters) 2240 feet (73 meters)1300 feet (396 meters) 1300 feet (91 meters)1750 feet (533 meters) Ordering Information PART NUMBERDESCRIPTIONCARDS/ SET ISL37300P-EVALWLAN Evaluation Kit2 Data SheetAugust 2001 tle jec tho w () ato CI ar e e O es C W ar 2 • Intelligent Power Control, Including IEEE 802.11 Power Save Mode • Complete Reference Design, the ISL37300P CD is available to ensure Minimum Time-to-Market NOTES: 1. Throughout this document, all references to ‘PC Card’, ‘WLAN adapter’, ‘adapter’, or ‘card’ refer to a card assembly conforming to the mechanical size specifications of the PC Card. 2. The range will vary in different operating environments due to effects such as building construction. 3. At present, PTTU supports Windows 95, 98 and 98SE. An upgrade is in process which will add support for NT. Functional Overview The WLAN PC-Card is designed to operate in the 2.4GHz ISM frequency band, channels 1 to 11, as specified by the FCC in the USA. The card will also operate on channels 12 through 14, where permitted by local regulatory authorities. Radio equipment must be certified in a country prior to use. Refer to Table 4 for a list of countries and agencies that have approved the ISL37300P-EVAL for operation. The Intersil PRISM Chip Set allows for high level integration for reduced size, increased throughput, improved radio performance and faster time to market. The WLAN PC-card implements Direct Sequence Spread Spectrum DSSS technology providing superior noise and signal jamming immunity including less severe impact from unintentional radiators such as microwave ovens. The user can connect the PC-card in an ad-hoc peer to peer networking scheme, allowing for instant network setup in any office environment. By using an access point, the wireless LAN can be set up to allow for a greater number of users to interconnect, and to increase the coverage area. With a portal (i.e. Access Point), the wireless LAN can be easily connected into an existing wired LAN, allowing for easy expansion of the service. Compared to the PRISM II chip set, the PRISM 2.5 generation offers: • Low loss front end designed for maximum range • Higher level of chip integration and less peripheral components to reduce material costs • Support of optional IEEE 802.11 Short Preamble for significantly increased data throughput • Has a Type II PC Card form factor A complete Reference Design for the ISL37300P is available to ensure minimum time-to-market. This information contains details for manufacturing a PC Card WLAN assembly, including Gerber PC board files, a Bill of Material with component sourcing, mechanical drawings, a detailed Radio Description with debug directions and a test plan. Related Literature To learn more about what the IEEE 802.11 is, refer to: • Tech Brief TB337, Intersil Corporation, “A Brief Tutorial on Spread Spectrum and Packet Radio”[1]. For a more detailed description of radio operation, please refer to: • Application Note AN9968, Intersil Corporation, “ISL37300P- EVAL PRISM 2.5 PCMCIA Wireless LAN Radio Description” [2] The ISL3873 Media Access Controller (MAC) Protocol Handler The ISL3873 MAC/Baseband Processor and its firmware are responsible for running the IEEE 802.11 protocol in the WLAN card. This section describes the features of I…

Text truncated - open the document above for the full version.

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com FCC DECLARATION OF CONFORMITY (DoC) Applicant’s Name & Address:INTERSIL CORP. Rembrandtlaan 1a 3723 BG Bilthoven, Netherlands Mr. Derick Sariredjo Phone: +31.30.225.9742 Mobile: +31.62.732.8048 Fax: +31.30.229.6061 email address: [email protected] US Representative’s Name & Address:INTERSIL CORPORATION 2401 Palm Bay Rd. NE Palm Bay, Florida USA 32905 Mr. Bartow Willingham Phone: 321-729-4955 Fax: 321-724-7886 e-mail address: [email protected] FCC DoC Assessed Test Lab.:UltraTech Engineering Labs Inc. 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Equipment Type/Environment: Computing Devices for Home and Office Use Trade Name / Model No.: PRISM 2.5 PCMCIA PC Card, Model ISL37300P Year of Manufacture: 2001 Standard(s) to which Conformity is Declared: The PRISM 2.5 PCMCIA PC Card, Model ISL37300P, supplied by INTERSIL CORPORATION, has been tested and found to comply with FCC PART 15, SUBPART B - CLASS B COMPUTING DEVICES FOR HOME & OFFICE USE. For detailed information please refer to the engineering test report, UltraTech File No.: CLS-061F15B, dated June 15, 2001. I, the undersigned, hereby declare that the equipment as tested is representative within manufacturing tolerance to units. ApplicantLegal Representative in U.S / Manufacturer. Mr. Derick Sariredjo Phone: +31.30.225.9742 Mobile: +31.62.732.8048 Fax: +31.30.229.6061 email address: [email protected] INTERSIL CORP. Rembrandtlaan 1a 3723 BG Bilthoven, Netherlands Mr. Bartow Willingham Phone: 321-729-4955 Fax: 321-724-7886 e-mail: [email protected] INTERSIL CORPORATION 2401 Palm Bay Rd. NE Palm Bay, Florida USA 32905

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com «June 7, 2001» FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject:Authority to Act as an Agent to FCC Applicant:«INTERSIL CORPORATION» Product:«PRISM 2.5 PCMCIA» Model:«ISL37300P» FCC ID:«OSZ37300PC» Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application to F.C.C. for authorization of equipment under F.C.C. Rules. I also certify that the information provided, properly described the device or system for which authorization is required. Regards Robert Rood Prism Radio Team Manager

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com ANNEX 5 - COVER LETTERS «June 7, 2001» FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant:«INTERSIL CORPORATION» Product:«PRISM 2.5 PCMCIA» Model:«ISL37300P» FCC ID:«OSZ37300PC» Dear Sir/Madam, We, «INTERSIL CORPORATION», would like to request that the schematic diagrams and system block diagrams, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. The detailed confidential materials are listed as follows: No. Title Drawing No. Sheet No. 1 Intersil Radio Schematic ISL37300P 3 of 3 2 Intersil Bill of Material for ISL37300P If you have any queries, please do not hesitate to contact us: OUR TELEPHONE NO.:(321)-724-7000 Yours truly, Robert Rood Prism Radio Team Manager

June 13, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:FCC Certification Authorization Application under FCC PART 15, Subpart C, Sec. 15.247 - Direct Sequence Spread Spectrum Transmitters operating in the frequency band 2400 - 2483.5 MHz. Product:PRISM 2.5 PCMCIA Model No.:ISL37300P FCC ID:OSZ37300PC Dear Sir/Madam As appointed agent for INTERSIL CORP., we would like to submit the application to the Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site for detailed information. • Modular Transmitter Approval Request:- This application is subject to the FCC certification for a modular transceiver, please kindly refer to the Section 6.5 of the submitted test report for clarification of compliance for this modular transmitter with FCC Public Notice DA 00-1407. • Compliance with RF Exposure Requirements: - The transmitter complies with FCC 2.1093 and FCCOET Bulletin 65 (August 1997) with maximum 0.00 W/Kg with body tissue. Please refer to attached SAR test report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl 2 3000 Bristol Circle Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] [email protected] UltraTech Group of Labs

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com ANNEX 5 - COVER LETTERS «June 7, 2001» FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant:«INTERSIL CORPORATION» Product:«PRISM 2.5 PCMCIA» Model:«ISL37300P» FCC ID:«OSZ37300PC» Dear Sir/Madam, We, «INTERSIL CORPORATION», would like to request that the schematic diagrams and system block diagrams, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. The detailed confidential materials are listed as follows: No. Title Drawing No. Sheet No. 1 Intersil Radio Schematic ISL37300P 3 of 3 2 Intersil Bill of Material for ISL37300P 3 Block Diagrams in FCC OET “block diagram” folder 4 Technical Description (2 files) in FCC OET “operational Descript” and “Users Manual” foler NOTE: The Technical documents included in FCC OET “Operational Description” and “Users Manual” folders are confidential information. They are not provided to end-users since Intersil does not sell this product to end-users. The OEM manufacturers who received these documents must sign a confidential agreement with Intersil . If you have any queries, please do not hesitate to contact us: OUR TELEPHONE NO.:(321)-724-7000 Yours truly, Robert Rood Prism Radio Team Manager INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com «June 7, 2001» FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant:«INTERSIL CORPORATION» Product:«PRISM 2.5 PCMCIA» Model:«ISL37300P» FCC ID:«OSZ37300PC» Dear Sir/Madam, We, «INTERSIL CORPORATION», would like to request that the schematic diagrams and system block diagrams, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. The detailed confidential materials are listed as follows: No. Title Drawing No. Sheet No. 1 Intersil Radio Schematic ISL37300P 2 Intersil Block Diagram for ISL37300P 3 Operational Overview Description AN9864 If you have any queries, please do not hesitate to contact us: OUR TELEPHONE NO.:(321)-724-7000 Yours truly, Robert Rood Prism Radio Team Manager

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com ANNEX 3 - EXTERNAL PHOTOS OF THE EUT INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com SHIELDING FOR EQUIPMENT

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com ANNEX 7 - FCC ID LABEL & LOCATION OF THE LABEL FCC LABEL LOCATION ON OUTSIDE OF BOTTOM SHIELD

INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com ANNEX 4 - INTERNAL PHOTOS OF THE EUT INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com SHIELDING FOR EQUIPMENT INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com SHIELDING FOR EQUIPMENT INTERSIL CORPORATION | 2401 Palm Bay Road NE | Palm Bay, FL 32905 | 407-724-7000 | www.intersil.com

1 TM PRISM ® 2.5, 11Mbps Chip Set Overview USB Interface Intersil’s latest chip set, PRISM® 2.5, demonstrates the continuing progress Intersil is making toward more highly integrated, feature-rich WLAN silicon high performance solutions for future adapters smaller than present PCMCIA cards. Wireless LAN adapters in smaller forms (CompactFlash, MiniPCI, CardBus or embedded modules) are necessary for wide deployment of wireless connectivity in small devices such as laptops, palmtops, PDAs, and digital cameras, to name just a few. PRISM 2.5 makes a major step by integrating the Baseband Processor (BBP) and Medium Access Controller (MAC) - digital functions done by separate ICs in the PRISM II set. The PRISM 2.5 set also includes die shrinks of the power amplifier and RF/IF converter in much smaller form factors (micro-lead frame packages). • ISL3984 - 2.4GHz Power Amplifier and Detector • ISL3685 - 2.4GHz RF/IF Converter and Synthesizer • HFA3783 - I/Q Modulator/Demodulator Synthesizer • ISL3873 - Integrated MAC and Baseband Processor • ISL3183 - 748MHz VCO SPECIFICATIONS Variable Data Rates11, 5.5, 2 and 1Mbps Frequency Band2.4GHz ISM Band BER1x10 -5 at -83dBm Dual ModeIEEE802.11, 1 and 2Mbps 5.5 and 11Mbps Range100m Indoors (Note) Power ConsumptionSame as PRISM I, 2Mbps NOTE: Range test using AND-C-107 omnidirectional antenna. PRISM 2.5, 11Mbps ORDERING INFORMATION PART NUMBERDESCRIPTION ISL39842.4GHz Power Amplifier and Detector ISL3984IR16 Ld, 4x4mm MLFP ISL3984IR961000 pcs. Tape and Reel ISL36852.4GHz RF/IF Converter and Synthesizer ISL3685IR44 Ld, 7x7mm MLFP ISL3685IR961000 pcs. Tape and Reel HFA3783I/Q Modulator/Demodulator and Synthesizer HFA3783IN48 Ld, 7x7mm LQFP HFA3783IN961000 pcs. Tape and Reel ISL3873Wireless LAN Integrated Medium Access Controller with Baseband Processor ISL3873IKV192 Ld, 14x14mm BGA ISL3873IK961000 pcs. Tape and Reel 1-888-INTERSIL or 321-724-7143|Intersil and Design is a trademark of Intersil Corporation.|Copyright © Intersil Americas Inc. 2001 PRISM® is a registered trademark of Intersil Americas Inc. PRISM logo is a trademark of Intersil Americas Inc. File Number4983.1OverviewJanuary 2001 2 All Intersil products are manufactured, assembled and tested utilizing ISO9000 quality systems. Intersil Corporation’s quality certifications can be viewed at websitewww.intersil.com/quality/iso.asp. Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design and/or specifications at any time without notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and reliable. How- ever, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries. For information regarding Intersil Corporation and its products, see web sitewww.intersil.com PRISM 2.5 11Mbps Chip Set Block Diagram (USB) PRISM 2.5 11Mbps Chip Set Block Diagram (PCI) 6 7 6 6 6 6 7 1 1 AGC CTL RAKE TX ALC AND DEMOD RF DAC IF DAC I ADC Q ADC TX DAC TX ADC I DAC Q DAC MOD I/O AND FILTER IF I/Q LO HFA3783 (FILE #4633) IF I/Q MOD/DEMOD RF LO PLL ISL3984 PA ON-CHIP ROM ISL3873 (FILE #4868) PC CARD HOST INTERFACE USB HOST INTERFACE PHY INTER- FACE (FILE #4862) LO PCMCIA, ISA SERIAL CONTROL (MMI) ISL3873 (MDI) MICRO- PRO- GRAMMED MAC ENGINE WEP ENGINE MEM- ORY CON- TROLLER USB ON-CHIP RAM MAC/BBP THRESH. DETECT. MEDIUM ACCESS CONTROLLER BASEBAND PROCESSOR 44MHz PLL VCO OSC VCO HOST COMPUTER INTERFACE FLASH MEMORY SRAM RX TX LNA 32kHz OSC ISL3685 (FILE #4860) RF/IF CONVERTER ISL3183 6 7 6 6 6 6 7 1 1 AGC CTL RAKE TX ALC AND DEMOD RF DAC IF DAC I ADC Q ADC TX DAC TX ADC I DAC Q DAC MOD I/O AND FILTER IF I/Q LO HFA3783 (FILE #4633) IF I/Q MOD/DEMOD RF LO PLL ISL3984 PA ON-CHIP ROM ISL3874 (FILE #4868) PC CARD HOST INTERFACE USB HOST INTERFACE PHY INTER- FACE (FILE #4862) LO PCMCIA, ISA SERIAL CONTROL (MMI) ISL3873 (MDI) MICRO- PRO- GRAMMED MAC ENGINE WEP ENGINE MEM- ORY CON- TROLLER PCI ON-CHIP RAM MAC THRESH. DETECT. MEDIUM ACCESS CONTROLLER BASEBAND PROCESSOR 44MHz PLL VCO OSC VCO HOST COMPUTER INTERFACE FLASH MEMORY SRAM RX TX LNA 32kHz OSC ISL3685 (FILE #4860) RF/IF CONVERTER ISL3183 PRISM® 2.5, 11Mbps Chip Set Overview

2 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 June 22, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Verification Testing in accordance with SAR (Specific Absorption Rate) requirements using guidelines established in: IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C) Industry Canada RSS-102 (Issue 1) ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Product:PRISM 2.5 PCMCIA Model:ISL37300P Dear Sir/Madam The product sample has been tested in accordance with SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1)and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1), and the results and observation were recorded in the engineering report, Our File No.: CLS- 061-SAR Enclosed you will find a copy of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P.Eng Vice President - Engineering Encl. UltraTech Group of Labs June 22, 2001 Intersil Corp. Rembrandtlaan 1a File No.: CLS-061-SAR 3723 BG Bilthove,, Netherlands, MD 21046 NOT TRANSFERABLE This Verification Certificate is hereby issued to the named GRANTEE and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below: GRANTEE'S NAME: INTERSIL CORP. PRODUCT UNDER TEST:PRISM 2.5 PCMCIA MODEL NO.:ISL37300P FCC ID:OSZ37300PC OPERATING FREQUENCY RANGE:2,412 ~ 2,462 MHz NOMINAL RF OUTPUT POWER:45.7 mW pk MAXIMUM S.A.R.:< 0.01 W/Kg APPLICABLE STANDARDS:SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2001 (No. 1) • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA ) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST Technology ( NIST) Approved by: Tri M. Luu, P.Eng. V.P. – Engineering UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] PRISM 2.5 PCMCIA Model No.: ISL37300P Tested For INTESIL CORP Rembrandtlaan 1a 3723 BG Bilthoven, Nethelands In Accordance With SAR (Specific Absorption Rate) Requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2001 (No. 1) UltraTech's File No.: CLS-061-SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: June 22, 2001 Report Prepared by: JaeWook ChoiTested by: JaeWook Choi, SAR Engineer Issued Date: June 22, 2001Test Dates: February 12, 2001 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SPECIFIC ABSORPTION RATIO (SAR)Page …
