OSZ38000C2.4 GHz IEEE 802.11g WLAN Cardbus Card

Preliminary User manual FCC ID: OSZ38000C Page 1 of 10 Intersil ISL38000C PRISM GT IEEE802.11g Cardbus WLAN Card User Manual Version 0.1 Preliminary User manual FCC ID: OSZ38000C Page 2 of 10 Table of Contents 0-INTRODUCTION .................................................................................................... 3 1-CARDBUS INSTALLATION PROCEDURE....................................................... 3 1.1 I NSTALLING THE CARDBUS CARD INTO THE HOST PC NOTEBOOK................... 3 1.2 INSTALLING THE SOFTWARE DRIVERS................................................................ 3 1.3 WIRELESS LAN INSTALLATION GUIDE LINES AND AUTHORIZATION FOR USE.7 2-REGULATORY INFORMATION ........................................................................ 7 2.1 FCC I NFORMATION TO USER............................................................................. 7 2.2 FCC G UIDELINES FOR HUMAN EXPOSURE........................................................ 7 2.3 FCC E LECTRONIC EMISSION NOTICES............................................................. 7 2.4 FCC RADIO FREQUENCY INTERFERENCE STATEMENT.................................... 8 2.5 E XPORT RESTRICTIONS....................................................................................... 8 2.6 E UROPE - EU DECLARATION OF CONFORMITY................................................ 9 3-TECHNICAL SPECIFICATIONS....................................................................... 10 Preliminary User manual FCC ID: OSZ38000C Page 3 of 10 0-Introduction The Intersil ISL38000C WLAN NIC is a complete wireless high speed Network Interface Card (NIC) utilizing the Intersil PRISM GT ® chip set. It conforms to the IEEE 802.11g protocol and operates in the 2.45 GHz ISM frequency bands. It provides a complete reference design evaluation platform of hardware and software to system providers or integrators requiring wireless data communications capability and is ideal for integration into computer platforms. • Fully compliant with the IEEE 802.11g WLAN standards • FCC Certified Under Part 15 (pending) to Operate in the 2.45 Bands • Support for 54, 48, 36, 24, 18, 12, 9, and 6 Mbps OFDM, 11 and 5.5 Mbps CCK and legacy 2 and 1 Mbps data rates • Driver Supports Microsoft Windows ® 98/SE, ME, XP and 2000 (SR1) 1-Cardbus Installation procedure 1.1 Installing the Cardbus card into the host PC Notebook a-Turn Host PC off, then insert Cardbus card into Cardbus slot of notebook Host PC. CAUTION: 1-- This assembly is designed to operate with a supply voltage of 3.3V in laptop computers supporting the CARDBUS32 standard. 2-- Do not force engagement of the card in the CARDBUS32 slot. It is mechanically designed to prevent improper insertion. 1.2 Installing the software drivers a-Start windows b-When windows detects new hardware and asks for drivers, point to directory where the Intersil driver is located (for example floppy drive, cdrom , harddisk) to install. c-after drivers are installed, restart windows d-the Intersil WLAN icon will appear in system tray on the bottom right of the screen (see yellow arrow in fig. 01) fig, 01: Intersil WLAN icon Preliminary User manual FCC ID: OSZ38000C Page 4 of 10 e-double click the Intersil WLAN icon to open the WLAN settings, the following window will appear (see fig.02) fig, 02: Intersil WLAN settings window f-click on configuration tab and select which type of network is required (access point or Peer-to-peer mode), see fig. 03. fig, 03: WLAN network type setting window Preliminary User manual FCC ID: OSZ38000C Page 5 of 10 g-select what TX rate is required (default setting is fully automatic) see fig. 04. fig, 04: WLAN tx rate setting window h-select what encryption type is required, 64 or 128 bit WEP (default setting is disabled) see fig. 05. fig, 05: WLAN encryption rate setting window Preliminary User manual FCC ID: OSZ38000C Page 6 of 10 i-click on the status tab to see the connection status (fig.06). fig, 06: WLAN network status j-click on the about tab to see the software drivers versions and MAC address (fig.07). fig, 07: WLAN driver and MAC addres information Preliminary User manual FCC ID: OSZ38000C Page 7 of 10 1.3 Wireless LAN installation guide lines and Authorization for use Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by Intersil may void the user’s authority to operate the equipment. Intersil is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Intersil and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. The use of Wireless LAN devices may be restricted in some situations or environments for example: * On board of airplanes, or * In an explosive environment, or * In case the interference risk to other devices or services is perceived or identified as harmful. In case the policy regarding the use of Wireless LAN devices in specific organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.) is not clear, please first verify authorization to use these devices prior to operating the equipment. 2-Regulatory information 2.1 FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals 2.2 FCC Guidelines for Human Exposure Warning: In order to comply with RF exposure lim…

Text truncated - open the document above for the full version.

Preliminary User manual FCC ID: OSZ38000C Page 1 of 10 Intersil ISL38000C PRISM GT IEEE 802.11g Cardbus WLAN Card User Manual Version 0.2 Preliminary User manual FCC ID: OSZ38000C Page 2 of 10 Table of Contents 0-INTRODUCTION .................................................................................................... 3 1-CARDBUS INSTALLATION PROCEDURE....................................................... 3 1.1 I NSTALLING THE CARDBUS CARD INTO THE HOST PC NOTEBOOK................... 3 1.2 INSTALLING THE SOFTWARE DRIVERS................................................................ 3 1.3 WIRELESS LAN INSTALLATION GUIDE LINES AND AUTHORIZATION FOR USE.7 2-REGULATORY INFORMATION ........................................................................ 7 2.1 FCC I NFORMATION TO USER............................................................................. 7 2.2 FCC G UIDELINES FOR HUMAN EXPOSURE........................................................ 7 2.3 FCC E LECTRONIC EMISSION NOTICES............................................................. 7 2.4 FCC RADIO FREQUENCY INTERFERENCE STATEMENT.................................... 8 2.5 E XPORT RESTRICTIONS....................................................................................... 8 2.6 E UROPE - EU DECLARATION OF CONFORMITY................................................ 9 3-TECHNICAL SPECIFICATIONS....................................................................... 10 Preliminary User manual FCC ID: OSZ38000C Page 3 of 10 0-Introduction The Intersil ISL38000C WLAN NIC is a complete wireless high speed Network Interface Card (NIC) utilizing the Intersil PRISM GT ® chip set. It conforms to the IEEE 802.11g protocol and operates in the 2.45 GHz ISM frequency bands. It provides a complete reference design evaluation platform of hardware and software to system providers or integrators requiring wireless data communications capability and is ideal for integration into computer platforms. • Fully compliant with the IEEE 802.11g WLAN standards • FCC Certified Under Part 15 (pending) to Operate in the 2.45 Bands • Support for 54, 48, 36, 24, 18, 12, 9, and 6 Mbps OFDM, 11 and 5.5 Mbps CCK and legacy 2 and 1 Mbps data rates • Driver Supports Microsoft Windows ® 98/SE, ME, XP and 2000 (SR1) 1-Cardbus Installation procedure 1.1 Installing the Cardbus card into the host PC Notebook a-Turn Host PC off, then insert Cardbus card into Cardbus slot of notebook Host PC. CAUTION: 1-- This assembly is designed to operate with a supply voltage of 3.3V in laptop computers supporting the CARDBUS32 standard. 2-- Do not force engagement of the card in the CARDBUS32 slot. It is mechanically designed to prevent improper insertion. 1.2 Installing the software drivers a-Start windows b-When windows detects new hardware and asks for drivers, point to directory where the Intersil driver is located (for example floppy drive, cdrom , harddisk) to install. c-after drivers are installed, restart windows d-the Intersil WLAN icon will appear in system tray on the bottom right of the screen (see yellow arrow in fig. 01) fig, 01: Intersil WLAN icon Preliminary User manual FCC ID: OSZ38000C Page 4 of 10 e-double click the Intersil WLAN icon to open the WLAN settings, the following window will appear (see fig.02) fig, 02: Intersil WLAN settings window f-click on configuration tab and select which type of network is required (access point or Peer-to-peer mode), see fig. 03. fig, 03: WLAN network type setting window Preliminary User manual FCC ID: OSZ38000C Page 5 of 10 g-select what TX rate is required (default setting is fully automatic) see fig. 04. fig, 04: WLAN tx rate setting window h-select what encryption type is required, 64 or 128 bit WEP (default setting is disabled) see fig. 05. fig, 05: WLAN encryption rate setting window Preliminary User manual FCC ID: OSZ38000C Page 6 of 10 i-click on the status tab to see the connection status (fig.06). fig, 06: WLAN network status j-click on the about tab to see the software drivers versions and MAC address (fig.07). fig, 07: WLAN driver and MAC addres information Preliminary User manual FCC ID: OSZ38000C Page 7 of 10 1.3 Wireless LAN installation guide lines and Authorization for use Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by Intersil may void the user’s authority to operate the equipment. Intersil is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Intersil and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. The use of Wireless LAN devices may be restricted in some situations or environments for example: * On board of airplanes, or * In an explosive environment, or * In case the interference risk to other devices or services is perceived or identified as harmful. In case the policy regarding the use of Wireless LAN devices in specific organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.) is not clear, please first verify authorization to use these devices prior to operating the equipment. 2-Regulatory information 2.1 FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals 2.2 FCC Guidelines for Human Exposure Warning: In order to comply with RF exposure li…

Text truncated - open the document above for the full version.

Preliminary User manual FCC ID: OSZ38000C Page 1 of 10 Intersil ISL38000C PRISM GT IEEE802.11g Cardbus WLAN Card User Manual Version 0.1 Preliminary User manual FCC ID: OSZ38000C Page 2 of 10 Table of Contents 0-INTRODUCTION ....................................................................................................3 1-CARDBUS INSTALLATION PROCEDURE .......................................................3 1.1 I NSTALLING THE CARDBUS CARD INTO THE HOST PC NOTEBOOK...................3 1.2 INSTALLING THE SOFTWARE DRIVERS................................................................3 1.3 W IRELESS LAN INSTALLATION GUIDE LINES AND AUTHORIZATION FOR USE.7 2-REGULATORY INFORMATION.........................................................................7 2.1 FCC I NFORMATION TO USER.............................................................................7 2.2 FCC GUIDELINES FOR HUMAN EXPOSURE........................................................7 2.3 FCC ELECTRONIC EMISSION NOTICES..............................................................7 2.4 FCC R ADIO FREQUENCY INTERFERENCE STATEMENT.....................................8 2.5 EXPORT RESTRICTIONS.......................................................................................8 2.6 EUROPE - EU DECLARATION OF CONFORMITY.................................................9 3-TECHNICAL SPECIFICATIONS .......................................................................10 Preliminary User manual FCC ID: OSZ38000C Page 3 of 10 0-Introduction The Intersil ISL38000C WLAN NIC is a complete wireless high speed Network Interface Card (NIC) utilizing the Intersil PRISM GT Æ chip set. It conforms to the IEEE 802.11g protocol and operates in the 2.45 GHz ISM frequency bands. It provides a complete reference design evaluation platform of hardware and software to system providers or integrators requiring wireless data communications capability and is ideal for integration into computer platforms. ï Fully compliant with the IEEE 802.11g WLAN standards ï FCC Certified Under Part 15 (pending) to Operate in the 2.45 Bands ï Support for 54, 48, 36, 24, 18, 12, 9, and 6 Mbps OFDM, 11 and 5.5 Mbps CCK and legacy 2 and 1 Mbps data rates ï Driver Supports Microsoft Windows Æ 98/SE, ME, XP and 2000 (SR1) 1-Cardbus Installation procedure 1.1 Installing the Cardbus card into the host PC Notebook a-Turn Host PC off, then insert Cardbus card into Cardbus slot of notebook Host PC. CAUTION: 1-- This assembly is designed to operate with a supply voltage of 3.3V in laptop computers supporting the CARDBUS32 standard. 2-- Do not force engagement of the card in the CARDBUS32 slot. It is mechanically designed to prevent improper insertion. 1.2 Installing the software drivers a-Start windows b-When windows detects new hardware and asks for drivers, point to directory where the Intersil driver is located (for example floppy drive, cdrom , harddisk) to install. c-after drivers are installed, restart windows d-the Intersil WLAN icon will appear in system tray on the bottom right of the screen (see yellow arrow in fig. 01) fig, 01: Intersil WLAN icon Preliminary User manual FCC ID: OSZ38000C Page 4 of 10 e-double click the Intersil WLAN icon to open the WLAN settings, the following window will appear (see fig.02) fig, 02: Intersil WLAN settings window f-click on configuration tab and select which type of network is required (access point or Peer-to-peer mode), see fig. 03. fig, 03: WLAN network type setting window Preliminary User manual FCC ID: OSZ38000C Page 5 of 10 g-select what TX rate is required (default setting is fully automatic) see fig. 04. fig, 04: WLAN tx rate setting window h-select what encryption type is required, 64 or 128 bit WEP (default setting is disabled) see fig. 05. fig, 05: WLAN encryption rate setting window Preliminary User manual FCC ID: OSZ38000C Page 6 of 10 i-click on the status tab to see the connection status (fig.06). fig, 06: WLAN network status j-click on the about tab to see the software drivers versions and MAC address (fig.07). fig, 07: WLAN driver and MAC addres information Preliminary User manual FCC ID: OSZ38000C Page 7 of 10 1.3 Wireless LAN installation guide lines and Authorization for use Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by Intersil may void the userís authority to operate the equipment. Intersil is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Intersil and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. The use of Wireless LAN devices may be restricted in some situations or environments for example: * On board of airplanes, or * In an explosive environment, or * In case the interference risk to other devices or services is perceived or identified as harmful. In case the policy regarding the use of Wireless LAN devices in specific organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.) is not clear, please first verify authorization to use these devices prior to operating the equipment. 2-Regulatory information 2.1 FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals 2.2 FCC Guidelines for Human Exposure This equipment complies with the FCC radiation exposure l…

Text truncated - open the document above for the full version.

TNO Electronic Products & Services (EPS) B.V. Nederlandse Organisatie voor toegepast-natuurwetenschappelijk onderzoek / Netherlands Organisation for Applied Scientific Research Smidshornerweg 18 P.O. Box 15 9822 ZG Niekerk The Netherlands www.tno.nl T +31 594 505005 F +31 594 504804 E [email protected] Subject Cover letter Date December 19, 2002 Our reference 02K1256a Your reference - Page 1 of 1 Our General Terms and Conditions, as filed at the Chamber of Commerce in Groningen, are applicable to all orders given to TNO Electronic Products & Services (EPS) B.V. TNO Electronic Products & Services (EPS) B.V. is registered at the Chamber of Commerce in Groningen with no. 27247331. Return address: P.O. Box 15, 9822 ZG Niekerk, The Netherlands Telefication B.V. Attn.: W. Blom Edisonstraat 12a 6902 PK Zevenaar The Netherlands Dear Mr. Blom, On behalf of our customer Intersil Corporation, we hereby would like to apply for FCC certification of the following device: FCC ID : OSZ38000C Brand : Intersil Model number : ISL38000C Description : 2.4 GHz IEEE 802.11g WLAN Cardbus card Type : 2.4 GHz WLAN Cardbus card The following PDF files (exhibits) are electronically submitted: 1. Cover letter containing the request for FCC certification 2. Request for confidentiality 3. Form 731 4. Test report in conformity with 47 CFR Part 15 5. Bill of materials 6. Circuit diagram 7. Block diagram 8. Operational description 9. Interior photographs 10. Exterior photographs 11. Test setup photographs 12. SAR test report 13. SAR calibration data 14. Authorization letter 15. User manual 16. Label information Best regards, TNO Electronic Products & Services (EPS) B.V. P.A.J.M. Robben, B.Sc.E.E. Marketing Manager

TNO Electronic Products & Services (EPS) B.V. Nederlandse Organisatie voor toegepast-natuurwetenschappelijk onderzoek / Netherlands Organisation for Applied Scientific Research Smidshornerweg 18 P.O. Box 15 9822 ZG Niekerk The Netherlands www.tno.nl T +31 594 505005 F +31 594 504804 E [email protected] Subject Request for confidentiality Date December 19, 2002 Our reference 02K1256b Your reference - Page 1 of 1 Our General Terms and Conditions, as filed at the Chamber of Commerce in Groningen, are applicable to all orders given to TNO Electronic Products & Services (EPS) B.V. TNO Electronic Products & Services (EPS) B.V. is registered at the Chamber of Commerce in Groningen with no. 27247331. Return address: P.O. Box 15, 9822 ZG Niekerk, The Netherlands Telefication B.V. Attn.: W. Blom Edisonstraat 12a 6902 PK Zevenaar The Netherlands Dear Mr. Blom, Pursuant to section 0.457 of the FCC rules we herewith request the following exhibits, related to this application for FCC ID: OSZ38000C, to be withheld from public inspection and to be kept confidential. The contents of these exhibits may not be disclosed to other parties than Intersil Corporation and TNO Electronic Products & Services (EPS) B.V.: 1. Bill of materials 2. Circuit diagram 3. Operational description 4. Block diagram The reason for this request for confidentiality is that the information contained in the exhibits as listed above has been classified as company confidential. Disclosure of any portion of this information to other parties would cause substantial competitive harm. Best regards, TNO Electronic Products & Services (EPS) B.V. P.A.J.M. Robben, B.Sc.E.E. Marketing Manager

www.intersil.com ING Bank: 65.02.63.049 Swift code: INGBNL2A VAT / BRW: NL8039.66.659.B.01 Chamber of Commerce Utrecht: 30139807 Date 18 December 2002 Your reference -- Our reference 2002-mansup-519f Subject Agent authorization letter for FCC ID: OSZ38000C To whom it may concern To whom it may concern, This letter confirms the agreement that; TNO Electronic Products & Services (EPS) B.V. Smidshornerweg 18 9822 TL Niekerk The Netherlands is authorized as an agent for Company Intersil Corp. The Netherlands Address, City Rembrandtlaan 1a, Bilthoven Country The Netherlands Phone number +31 30 2296060 Fax number +31 30 2296061 and is authorized to sign application forms and act on behalf of Intersil Corp. The Netherlands and is authorized to receive and exchange data between Intersil Corp. The Netherlands and European/non-European national authorities regarding the -certification of- and/or -arranging type approvals for the following product: Intersil model ISL38000C IEEE802.11g WLAN Cardbus Card with FCC ID: OSZ38000C This authorization will expire on July 1, 2003 or upon earlier written notice from Intersil Corp. The Netherlands. Yours sincerely, Derick Sariredjo ( [email protected] ) Intersil Corp. The Netherlands ( www.intersil.com ) Rembrandtlaan 1a, 3723 BG Bilthoven, The Netherlands Phone: +31.30.225.9742 Fax: +31.30.229.6061

TNO Electronic Products & Services (EPS) B.V. Nederlandse Organisatie voor toegepast-natuurwetenschappelijk onderzoek / Netherlands Organisation for Applied Scientific Research Smidshornerweg 18 P.O. Box 15 9822 ZG Niekerk The Netherlands www.tno.nl T +31 594 505005 F +31 594 504804 E [email protected] Subject Cover letter Date January 31, 2003 Our reference 02K1256a Your reference - Page 1 of 1 Our General Terms and Conditions, as filed at the Chamber of Commerce in Groningen, are applicable to all orders given to TNO Electronic Products & Services (EPS) B.V. TNO Electronic Products & Services (EPS) B.V. is registered at the Chamber of Commerce in Groningen with no. 27247331. Return address: P.O. Box 15, 9822 ZG Niekerk, The Netherlands Telefication B.V. Attn.: W. Blom Edisonstraat 12a 6902 PK Zevenaar The Netherlands Dear Mr. Blom, On behalf of our customer Intersil Corporation, we hereby would like to apply for FCC certification of the following device: FCC ID : OSZ38000C Brand : Intersil Model number : ISL38000C Description : 2.4 GHz IEEE 802.11g WLAN Cardbus card Type : 2.4 GHz WLAN Cardbus card The usage of this transmitter will be limited to the following specific host (notebook PC); brand: Hewlett-Packard, model: Omnibook 4150. The following PDF files (exhibits) are electronically submitted: 1. Cover letter containing the request for FCC certification 2. Request for confidentiality 3. Form 731 4. Test report in conformity with 47 CFR Part 15 5. Bill of materials 6. Circuit diagram 7. Block diagram 8. Operational description 9. Interior photographs 10. Exterior photographs 11. Test setup photographs 12. SAR test report 13. SAR calibration data 14. Authorization letter 15. User manual 16. Label information Best regards, TNO Electronic Products & Services (EPS) B.V. P.A.J.M. Robben, B.Sc.E.E. Marketing Manager

To: Wouter Blom [email protected] From: Tim Harrington [email protected] FCC Equipment Authorization Branch Re: FCC ID: OSZ38000C Applicant: Intersil Corporation Correspondence Number: 6644 731 Confirmation Number: TC949855 Date of Original E-Mail: 01/22/2003 Subject: audit 1) User manual says EIRP<18dBm. EMC report sect. 4.2 - could not determine if this is conducted or radiated. Please submit test setup and procedure info for EMC sect. 4.2, and if that is radiated include raw data with conversion to conducted power. The user manual has been revised with regards to the output power statement. The EMC report has been revised to clarify the test method for measuring RF output power. The RF output power was measured conducted and directly at the antenna terminal. 2) Please confirm/show whether antennas are present in internal photos. The exhibit with the interior photographs has been revised. Red arrows now indicate the position of the integral antennas of the device. 3) Please confirm/demonstrate that touch (possible antenna detuning effects) rather than small gap at side position is maximum SAR. The SAR test report has been revised. Please refer to page 20 of the revised SAR test report. 4) What is expected SAR in notebook computer that does not have audio jacks under PCMCIA slot, i.e., slot bottom at 3-5 mm from notebook bottom? The SAR test report has been revised. Please refer to page 21 of the revised SAR report attached (table with an assessment of SAR values applying measured SAR values and the 1/r curve of field strength to show SAR values at different positions). Additional notes: (1) The card has been retested with a lower RF output power (less than 100 mW). The EMC report and SAR test report have been revised accordingly. The manufacturer will implement the modified RF power output firmware settings, as obtained during the retesting, in their manufacturing process. (2) The cover letter has been revised in order to indicate that the transmitter is intended for use in a dedicated host only. (3) The device was retested by CETECOM for RF output power with revised firmware RF output power settings. The RF output power of the device proved to be +19.9 dBm. This is a change of -0.3 dB (-6.7%) in RF output power as compared to the previously measured RF output power of +20.2 dBm. Given the fact that the overall combined measurement uncertainty of the measurement system is +/-13.6%, it was concluded that the difference of -0.3 dB (-6.7%) in RF output power would cause a change in worst-case SAR values which would fall within the measurement uncertainty range of the measurement system which was used during all measurements. It can therefore be justified that the SAR values, as measured at a RF output power of +20.2 dBm, can be represented as being the absolute worst-case values which could be measured at a RF output power of +19.9 dBm.

Testing and certification of, consultancy and research concerning, electronic and electric appliances, systems, installations and telecommunication systems TNO Electronic Products & Services (EPS) B.V. P.O. Box 15 9822 ZG Niekerk (NL) Smidshornerweg 18 9822 TL Niekerk (NL) Telephone: +31 594 505005 Telefax: +31 594 504804 E-mail: [email protected] Project number: 02121701.p02 Page 1 of 5 EXTERIOR PHOTOGRAPHS OF A 2.4 GHZ WLAN CARDBUS CARD, BRAND INTERSIL, MODEL ISL38000C. FCC listed Industry Canada : : 90828 IC3501 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: 2.4 GHz WLAN Cardbus card Intersil Corporation Intersil ISL38000C OSZ38000C Project number: 02121701.p02 Page 2 of 5 Description of test item Test item : 2.4 GHz WLAN Cardbus card Manufacturer : Intersil Corporation Brand : Intersil Model : ISL38000C Serial numbers : 02500007 and 02500003 Revision : n.a. Receipt number : 2 Receipt date : November 17, 2002 Applicant information Applicant's representative : Mr. D. Sariredjo Company : Intersil Corporation Address : Rembrandtlaan 1a Postal code : 3723 BG City : Bilthoven PO-box : 343 Postal code : 3720 AH City : Bilthoven Country : The Netherlands Telephone number : +31 30 2259742 Telefax number : +31 30 2296061 This report is in conformity with NEN-EN-ISO/IEC 17025. This report shall not be reproduced, except in full, without the written permission of TNO Electronic Products & Services (EPS) B.V. The test results relate only to the item(s) tested. Description of EUT: Manufacturer: Brand mark: Model: FCC ID: 2.4 GHz WLAN Cardbus card Intersil Corporation Intersil ISL38000C OSZ38000C Project number: 02121701.p02 Page 3 of 5 Table of contents 1 Exterior photographs. .............................................................................................................................................................. 4 1.1 Top view. ......................................................................................................................................................................... 4 1.2 Bottom view. ................................................................................................................................................................... 5 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: 2.4 GHz WLAN Cardbus card Intersil Corporation Intersil ISL38000C OSZ38000C Project number: 02121701.p02 Page 4 of 5 1 Exterior photographs. 1.1 Top view. Description of EUT: Manufacturer: Brand mark: Model: FCC ID: 2.4 GHz WLAN Cardbus…

Text truncated - open the document above for the full version.
