OTVATT701Family Radio Transceiver

APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 TEST REPORT: PAGE 1-2....COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 3......RF POWER OUTPUT PAGE 4......MODULATION CHARACTERISTICS PAGE 5......AUDIO FREQUENCY RESPONSE PLOT PAGE 5......MODULATION LIMITING PLOT – 300 Hz PAGE 6......MODULATION LIMITING PLOT – 1000 Hz PAGE 6......MODULATION LIMITING PLOT – 3000 Hz PAGE 7......AUDIO LOW PASS FILTER PLOT PAGE 8......OCCUPIED BANDWIDTH PAGE 9......OCCUPIED BANDWIDTH PLOT – CW PAGE 10......OCCUPIED BANDWIDTH PLOT PAGE 11......METHOD OF MEASURING OCCUPIED BANDWIDTH PAGE 12......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 13......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 13......FREQUENCY STABILITY PAGE 15-19...LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3.........EXTERNAL PHOTOS EXHIBIT 4.........INTERNAL PHOTOS EXHIBIT 5.........BLOCK DIAGRAM EXHIBIT 6.........SCHEMATIC EXHIBIT 7.........USER'S MANUAL EXHIBIT 8........CIRCUIT DESCRIPTION EXHIBIT 9........TUNING PROCEDURE APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 1 of 19 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2)SB TELCOM CO., LTD. will manufacture the FCCID: OTVATT701 FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. The UUT is a PTT Radio with a maximum duty cycle of 50%. SB TELCOM CO., LTD. #25-49, JUAN5-DONG, NAM-KU INCHEON KOREA 2.1033 (c) TECHNICAL_DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 7. 2.1033(c) (4) Type of Emission: 10K4F3E 95.631 Bn = 2M + 2DK M = 3000 D = 2200 Bn = 2(3000)+2(1900) = 9.8K Authorized Bandwidth 12.5 kHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.50 Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varying the power. 95.647 The antenna is an integral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 4.5 Volts DC Ice = 0.203A. Pin = 0.92 Watts APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 2 of 19 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included in the 9. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 6 of this report. The block diagram is included as EXHIBIT 5 of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identifica tion label is included as exhibit No. 2. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields - See EXHIBIT 3-4. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 3 of 19 2.1046(a) RF power output. 95.639 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = 0.17Watts ERP R.F. POWER OUTPUT TEST SET UP Agilent Spectrum Analyzer TRANSMITTER UNDER TEST WITH INTERNAL ANTENNA <-- 3.0 meters--> SIGNAL DIPOLE Tuned, Calibrated GENERATOR ANTENNA Antenna which may be raised from 1 to 4 meters above ground and changed in polarization Equipment placed 80 cm above ground on a rotatable platform. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 4 of 19 2.1047(a)(b) Modulation characteristics: AUDIO FREQUENCY RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown on page 5. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. 2.1047(b) Audio input versus modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are shown in pages 5-6. Curves are provided for audio input frequen cies of 300, 1000, and 3000 Hz. 95.637(b) Post Limiter Filter The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20 kHz the filter must have an attenuation of 60log (f/3) greater that the attenuation at 1KHz. See the plot; page 7. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 5 of 19 SB Telcom OTVATT701 -60 -55 -50 -45 -40 -35 -30 100100010000 Frequency dBmV audio response Modulation Limiting SB Telcom OTVATT701 0 500 1000 1500 2000 2500 -45-35-25-15-5 dBmV Deviation 300 Hz APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 6 of 19 Modulation Limiting SB Telcom OTVATT701 0 500 1000 1500 2000 2500 -55-45-35-25-15 dBmV Deviation 1000 Hz Modulation Limiting SB Telcom OTVATT701 0 500 1000 1500 2000 2500 3000 -66-56-46-36-26-16 dBmV Deviation 3000 Hz APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVATT701 REPORT #: S\SBTELE\484KT2\484KT2TestReport.doc Page 8 of 19 2.1049(c) EM…
