OTVSBTFR541-2Family Radio Transceiver

Safety Information For FRS UNIT Your wireless handheld portable transceiver contains a low power transmitter. When the Push-To-Talk (PTT) button is pushed, it sends out radio frequency (RF) signals. This device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless devices. CAUTION: To maintain compliance with the FCC’s RF Exposure guidelines, hold the transmitter and antenna at least 2 inches (5 centimeters) from your face and speak in a normal voice, with the antenna pointed up and away from the face. If you wear the handset on your body while using the headset accessory, use only the AUDIOVOX supplied belt clip for this product and ensure that the antenna is at least 2 inches (5 centimeters) from your body when transmitting. Use only the supplied antenna. Unauthorized antennas, modifications, or attachments could damage the transmitter and may violate FCC regulations. NORMAL POSITION: Hold the transmitter approximately 2 inches from your face and speak in a normal voice, with the antenna pointed up and away. FCC ID: OTVSBTFR541-2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

26.00 mm 9 . 0 0 m m 1 0 . 5 0 m m 30.00 mm or

APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 TEST REPORT: PAGE 1-2....COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 3......RF POWER OUTPUT PAGE 4......MODULATION CHARACTERISTICS PAGE 5......AUDIO FREQUENCY RESPONSE PLOT PAGE 6......MODULATION LIMITING PLOT – 300 Hz PAGE 7......MODULATION LIMITING PLOT – 1000 Hz PAGE 8......MODULATION LIMITING PLOT – 3000 Hz PAGE 9......AUDIO LOW PASS FILTER PLOT PAGE 10......OCCUPIED BANDWIDTH PAGE 11......OCCUPIED BANDWIDTH PLOT – CW PAGE 12......OCCUPIED BANDWIDTH PLOT – 2.5K TONE PAGE 13......METHOD OF MEASURING OCCUPIED BANDWIDTH PAGE 14......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 15......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 16......FREQUENCY STABILITY PAGE 17......LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE AND SKETCH OF LOCATION EXHIBIT 2.........EXTERNAL PHOTO - FRONT VIEW EXHIBIT 3.........EXTERNAL PHOTO - REAR VIEW EXHIBIT 4.........INTERNAL PHOTO – COMPONENT VIEW – W SHIELD EXHIBIT 5.........INTERNAL PHOTO - COMPONENT SIDE –W/O SHIELD EXHIBIT 6.........INTERNAL PHOTO - SOLDER EXHIBIT 7.........BLOCK DIAGRAM EXHIBIT 8.........SCHEMATIC EXHIBIT 9.........USER'S MANUAL EXHIBIT 10........CIRCUIT DESCRIPTION EXHIBIT 11........TUNING PROCEDURE EXHIBIT 12........TEST SET UP PHOTO APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 1 of 17 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2)SB TELCOM CO., LTD.will manufacture the FCCID: OTVSBTFR541-2 FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. The UUT is a PTT Radio with a maximum duty cycle of 50%. SB TELCOM CO., LTD. #25-49, JUAN5-DONG, NAM-KU INCHEON KOREA 2.1033 (c) TECHNICAL_DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 6A-6J. 2.1033(c) (4) Type of Emission: 9K8F3E 95.631 Bn = 2M + 2DK M = 3000 D = 1900 Bn = 2(3000)+2(1900) = 9.8K Authorized Bandwidth 12.5 kHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.500Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varying the power. 95.647 The antenna is an integral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 6.0 Volts DC Ice = 0.20A. Pin = 1.2 Watts APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 2 of 17 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included in the IN USER'S MANUAL. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 5 of this report. The block diagram is included as EXHIBIT 4 of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identifica tion label is included as exhibit No. 2. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields - See EXHIBIT 3A-3H. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 3 of 17 2.1046(a) RF_power_output. 95.639 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = 200 milliWatts ERP R.F. POWER OUTPUT TEST SET UP HP Spectrum Analyzer TRANSMITTER UNDER TEST WITH INTERNAL ANTENNA <-- 3.0 meters--> SIGNAL DIPOLE Tuned, Calibrated GENERATOR ANTENNA Antenna which may be raised from 1 to 4 meters above ground and changed in polarization Equipment placed 80cm above ground on a rotatable platform. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 4 of 17 2.1047(a)(b) Modulation_characteristics: AUDIO_FREQUENCY_RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown on page 5. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. 2.1047(b) Audio_input_versus_modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are shown in pages 6-8. Curves are provided for audio input frequen cies of 300, 1000, and 3000 Hz. 95.637(b) Post Limiter Filter The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20KHz the filter must have an attenuation of 60log (f/3) greater that the attenuation at 1KHz. See the plot; page 9. APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 5 of 17 SB Telcom Co. LTD. FR541-2 -60 -55 -50 -45 -40 -35 -30 -25 100100010000 Frequency dBmV audio response APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR541-2 REPORT #: T:\S\SBTELE\1284ak1\1284AK1TestReport.doc Page 6 of 17 Modulation Limiting SB Telcom Co. LTD. FR541-2 0 500 1000 1500 2000 2500 -36.5-26.5-16.5-6.5 dBmV Deviation 300 Hz APPLICANT: SB TEL…
