OTVSBTFR531-2family radio tranceiver

9 . 5 0 m m 26.00 mm

Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: Table of Contents TABLE OF CONTENTS LIST APPLICANT: SB TELCOM CO., LTD. FCC ID: OTVSBTFR531-2 TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED & RF POWER OUTPUT PAGE 3......AUDIO FRENQUENCY RESPONSE PAGE 4-5....MODULATION CHARACTERISTICS PAGE 6......AUDIO LOW PASS FILTER PAGE 7......EMISSION BANDWIDTH PAGE 8......OCCUPIED BANDWIDTH PLOT PAGE 9......OCCUPIED BANDWIDTH CW PLOT PAGE 10.....METHOD OF MEASURING OCCUPIED BANDWIDTH PAGE 11.....FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 12.....METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 13.....FREQUENCY STABILITY PAGE 14.....LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3A........EXTERNAL PHOTO - FRONT VIEW EXHIBIT 3B........EXTERNAL PHOTO - REAR VIEW EXHIBIT 3C........INTERNAL PHOTO – COMPONENT SIDE EXHIBIT 3D........INTERNAL PHOTO – COPPER SIDE EXHIBIT 4.........BLOCK DIAGRAM EXHIBIT 5.........SCHEMATIC EXHIBIT 6A-6D.....USER'S MANUAL EXHIBIT 7A-7C.....CIRCUIT DESCRIPTION EXHIBIT 8A-8B.....TUNING PROCEDURE EXHIBIT 9.........TEST SETUP PHOTOGRAPH Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 1 of 14 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2)SB TELCOM CO., LTD.will manufacture the FCCID: OTVSBTFR531-2 FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. The UUT is a PTT Radio with a maximum duty cycle of 50%. SB TELCOM CO., LTD. #25-49, Juan5-Dong Nam-Ku, Incheon, Korea 2.1033 (c) TECHNICAL_DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 6A-6D. 2.1033(c) (4) Type of Emission: 10K6F3E 95.631 Bn = 2M + 2DK M = 3000 D = 2.0K Bn = 2(3.0)+2(2.3) = 10.6K Authorized Bandwidth 12.5KHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.500Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varing the power. 95.647 The antenna is an intergral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 6.0 Volts DC Ice = 0.25A. Pin = 1.5 Watts Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 2 of 14 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included in the IN Exhibit 8A-8B. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 5A-5B of this report. The block diagram is included as EXHIBIT 4 of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identifica tion label is included as exhibit No. 1. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields - See EXHIBIT 3A-3D. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. 2.1046(a) RF_power_output. 95.639 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = 230 milliWatts ERP R.F. POWER OUTPUT TEST SET UP HP Spectrum Analyzer TRANSMITTER UNDER TEST WITH INTERNAL ANTENNA <-- 3.0 meters--> SIGNAL DIPOLE Tuned, Calibrated GENERATOR ANTENNA Antenna which may be raised from 1 to 4 meters above ground and changed in polarization Equipment placed 80cm above ground on a rotatable platform. Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 3 of 14 2.1047(a)(b) Modulation_characteristics: AUDIO_FREQUENCY_RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown below. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. SB Technology FR531-2 -60 -55 -50 -45 -40 -35 -30 100100010000 Frequency dBmV audio response Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 4 of 14 2.1047(b) Audio_input_versus_modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are shown in exhibits are shown below. Curves are provided for audio input frequencies of 300, 1000, and 3000 Hz. Modulation Limiting SB Technology FR531-2 0 500 1000 1500 2000 2500 -45-35-25-15-5 dBmV Deviation 300 Hz Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 5 of 14 Modulation Limiting SB Technology FR531-2 0 500 1000 1500 2000 2500 -55-45-35-25-15 dBmV Deviation 1000 Hz Modulation Limiting SB Technology FR531-2 0 500 1000 1500 2000 2500 3000 -66-56-46-36-26-16 dBmV Deviation 3000 Hz Applicant: SB Telcom Co., Ltd. FCC ID: OTVSBTFR531-2 Report #: S\SBTECH\1154AK1\1154AK1Testreport.doc Page #: 6 of 14 95.637(b) Post Limiter Filter The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20KHz the filter must have an attenuation of 60log (f/3) greater that the attenuation at 1K…
