OTVSBTFR558WB

TABLE OF CONTENTS LIST APPLICANT: SB TECHNOLOGY CO., LTD. FCC ID: OTVSBTFR558WB TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED & RF POWER OUTPUT PAGE 3......MODULATION CHARACTERISTICS AND OCCUPIED BANDWIDTH PAGE 4......METHOD OF MEASURING OCCUPIED BANDWIDTH PAGE 5......OCCUPIED BANDWIDTH CW PLOT PAGE 6......OCCUPIED BANDWIDTH PLOT PAGE 7......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 8......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 9......FREQUENCY STABILITY PAGE 10.....LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3A........EXTERNAL PHOTO - FRONT VIEW EXHIBIT 3B........EXTERNAL PHOTO - REAR VIEW EXHIBIT 3C-3D.....INTERNAL PHOTO - SOLDER SIDE EXHIBIT 3E-3F.....INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 4A........BLOCK DIAGRAM - RF EXHIBIT 4B........BLOCK DIAGRAM - CPU EXHIBIT 5A........SCHEMATIC - RF EXHIBIT 5B-5C.....SCHEMATIC - CPU EXHIBIT 6A-6E.....USER'S MANUAL EXHIBIT 7A-7D.....THEORY OF OPERATION EXHIBIT 8A-8B.....TUNING PROCEDURE EXHIBIT 9.........AUDIO FREQUENCY RESPONSE GRAPH EXHIBIT 10A.......MODULATION LIMITING PLOT - 300 Hz EXHIBIT 10B.......MODULATION LIMITING PLOT - 1000 Hz EXHIBIT 10C.......MODULATION LIMITING PLOT - 3000 Hz EXHIBIT 11........AUDIO LOW PASS FILTER GRAPH EXHIBIT 12........TEST SET UP PHOTO APPLICANT: SB TECHNOLOGY CO., LTD. FCC ID: OTVSBTFR558WB REPORT #: T:\CUS\S\SBTECH\665BK0\665BK0.RPT PAGE: TABLE OF CONTENTS GENERAL INFORMATION REQUIRED FOR TYPE ACCEPTANCE 2.1033(c)(1)(2) SB TECHNOLOGY CO., LTD. will manufacture the FCCID: OTVSBTFR558WB FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. The UUT is a PTT Radio with a maximum duty cycle of 50%. SB TECHNOLOGY CO., LTD. #613-9, NAMCHON-DONG NAMDONG-KU, INCHEON KOREA 2.1033 (c) TECHNICAL DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 6A-6E. 2.1033(c) (4) Type of Emission: 10K8F3E 95.631 Bn = 2M + 2DK M = 3000 D = 2.40K Bn = 2(3.0)+2(2.40) = 10.8K Authorized Bandwidth 12.5KHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.500Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varing the power. The Maximum Output Power Rating: 300 milliWatts effective radiated power. 95.647 The antenna is an intergral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 4.5 Volts DC Ice = 0.12A. Pin = 0.54 Watts 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included in exhibit 8A-8B. FCC ID: OTVSBTFR558WB PAGE #: 1 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 5A-5C of this report. The block diagrams are included as EXHIBIT 4A-4B of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identifica tion label is included as exhibit No. 1 and 2. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields - See EXHIBIT 3A-3F. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. 2.1046(a) RF power output. 95.639 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = 300 milliWatts ERP R.F. POWER OUTPUT HP TEST SET UP Spectrum Analyzer /-------\ /-----------------\ | | | | TRANSMITTER | | | | | UNDER TEST WITH | \--| | | INTERNAL ANTENNA| | | | \-----------------/ | | | | | \-------/ | | |<-- 3.0 meters-->| /-------------\ | SIGNAL | DIPOLE | Tuned, Calibrated | GENERATOR | ANTENNA | Antenna which may | |----------/ be raised from 1 \-------------/ to 4 meters above ground and changed in polarization Equipment placed 80 centimeters above ground on a rotatable platform. APPLICANT: SB TECHNOLOGY CO., LTD. FCC ID: OTVSBTFR558WB REPORT #: T:\CUS\S\SBTECH\665BK0\665BK0.RPT PAGE #: 2 2.1047(a)(b) Modulation characteristics: AUDIO FREQUENCY RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown in exhibit 9. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. See Exhibit 9. 2.1047(b) Audio input versus modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation for audio input frequen cies of 300, 1000, and 3000 Hz are shown in Exhibit 10A-10C. 95.637(b) Post Limiter Filter The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20KHz the filter must have an attenuation of 60log (f/3) greater that the attenuation at 1KHz. 2.989(c) EMISSION BANDWIDTH: 95.633(c) Data in the plots show that the sidebands from greater than 50% to 100% of the authorized bandwidth must be attenuated by at least 25dB and from 100 to 250% the sidebands must be attenuated by at least 35dB. Beyond 250% the sidebands must be attenuated by at least 43+log10(TP). The transmitter was modulated with 2500 Hz, adjusted for 50% modulation plus 16 dB. The spectrum analyzer was set with the unmodulated carri…

Text truncated - open the document above for the full version.

Modulation Limiting SB Tech. Co. LTD. OTVFR558WB 0 200 400 600 800 1000 1200 1400 1600 0 102030405060 rms mVolts Deviation 300 Hz SB TECHNOLOGY CO., LTD. FCC ID : OTVSBTFR458WB JOB # : 665BK0 EXHIBIT # : 10A

Modulation Limiting SB Tech. Co. LTD. OTVFR558WB 0 500 1000 1500 2000 2500 0 20406080100 rms mVolts Deviation 1000 Hz SB TECHNOLOGY CO., LTD. FCC ID : OTVSBTFR458WB JOB # : 665BK0 EXHIBIT # : 10B

Modulation Limiting SB Tech. Co. LTD. OTVFR558WB 0 500 1000 1500 2000 2500 3000 0 1020 3040 5060 rms mVolts Deviation 3000 Hz SB TECHNOLOGY CO., LTD. FCC ID : OTVSBTFR458WB JOB # : 665BK0 EXHIBIT # : 10C
