9XCite™ Wireless OEM Module 9XCite Wireless OEM Module RF System Components Module Configuration Appendices Product Manual v1.0 For 9XCite Module Part Numbers: XC09-009... XC09-038... 355 South 520 West, Suite 180 Lindon, UT 84042 Phone: (801) 765-9885 Fax: (801) 765-9895 [email protected] M100043 12.02.2003 www.MaxStream.net XCite Wireless OEM Module – Product Manual v1.0 © 2003 MaxStream, Inc. All rights reserved No part of the contents of this manual may be transmitted or reproduced in any form or by any means without the written permission of MaxStream, Inc. 9XCite™ is a trademark of MaxStream, Inc. Phone: (801) 765-9885 Live Chat: www.maxstream.net E-Mail: [email protected] © 2003 MaxStream, Inc., Confidential and Proprietary ii XCite Wireless OEM Module – Product Manual v1.0 Contents 9XCite Wireless OEM Module 1 Powerfully Simple 1 Block Diagram 2 Module Pinout Signals 2 Timing Specifications 4 Mechanical Drawings 5 Electrical Characteristics 5 RF System Components 6 Serial Communications 6 UART-Interfaced Data Flow 6 RS-232 and RS-485/422 Data Flow 6 Interfacing Hardware 7 9XCite Development Kit 7 MaxStream Interface Board (Part Number: XIB-R) 7 MaxStream Interface Board Components & Features 8 Module Configuration 9 Command & Parameter Types 9 XCite Commands & Parameter Reference 10 Configuration Software 12 XCite-CTU Software 12 Serial Communications Software (for AT Commands Only) 12 Appendix A: FCC Certification 13 9XCite (900 MHz) Module - FCC Compliance 13 OEM Labeling Requirements 13 FCC Notice 14 9XCite (900 MHz) Approved Antenna List 15 Appendix B: Specifications 16 9XCite Wireless OEM Module Specifications 16 Appendix C: Additional Information 17 1-Year Warranty 17 9XCite Wireless OEM Module Part Numbers 18 Appendix D: Troubleshooting & FAQs 19 Contact MaxStream 19 © 2003 MaxStream, Inc., Confidential and Proprietary iii 9XCite Wireless OEM Module – Product Manual v1.0 9XCite Wireless OEM Module Powerfully Simple The 9XCite Module is a drop-in wireless solution that adds connectivity to any UART or serial device. It transfers a standard asynchronous serial data stream and features the following: • Continuous data stream of up to 38400 bps (factory-set, over-the-air baud rate) • Serial Interfacing from 1200 to 57600 bps • Software selectable between Hopping (FHSS) and Single Channel modes • Approved by the FCC under Part 15 of the FCC Rules and Regulations • Variable input supply voltage (2.85 – 5.50 VDC) This manual contains information critical to basic 9XCite Module operation. More detailed information is available in the “XCite Advanced Programming & Configuration” Manual. (Located on the MaxStream CD or on the web: www.maxstream.net/support_documentation.html ) Features: FCC Approved (USA) [Go to Appendix A for FCC Requirements] Devices that embed 9XCite Modules inherit MaxStream’s FCC certification. IC (Industry Canada) Certified ISM (Industrial, Scientific & Medical) frequency band MaxStream products manufactured under ISO 9002 registered standards since 2000. Indoor/Urban Range: Up to 300’ (90 m) Outdoor/LOS Range: Up to 1000’ (300 m) w/dipole antenna Receiver Sensitivity: -108 dBm (9600 Baud), -104 dBm (38400 Baud) Transmit Power Output: 1 mW [50 mW effective considering excellent receiver sensitivity] Advanced Networking capabilities (True Peer-to-Peer (no “master” required), Point-to-Point, Point-to-Multipoint, Multi-Drop) Specifications [Appendix B] 1-Year Warranty [Appendix C] Free Technical Support [Appendix D] © 2003 MaxStream, Inc., Confidential and Proprietary 1 9XCite Wireless OEM Module – Product Manual v1.0 Block Diagram Figure 1. 9XCite Module Block Diagram Interference Filter RF TX Buffer Transmitting Circuitry RF RX Buffer Receiving Circuitry RF Switch DIN Buffer Antenna Port DIN DOUT GND VCC CTS DOUT Buffer ‘Interference Filter’ reduces interference from pagers and cellular. Module Pinout Signals 9XCite Module pin signals and their functions: Table 1. J1 Pin Descriptions (Low-asserted signals distinguished with a horizontal line over signal name.) Module Pin Signal Name I/O When Active Description 1 O* low Clear-to-Send Flow Control 2 SLEEP (PWRDN) I* high Can be used to enter Sleep Mode 3 DO (Data Out) O* n/a Serial Data leaving the 9XCite Module (to the processor host) 4 DI (Data In) I n/a Serial Data entering the 9XCite Module (from the processor host) 5 I** low Request-to-Send 6 I* low Reset module 7 RX LED O high Receive LED low - Asserted during transmission 8 / PWR O high PWR – Indicates power is on 9 CONFIG I*** low Backup method for entering Command Mode. Primary method is with “+++” [See CC Parameter] 10 VCC I - 2.85 – 5.50 VDC variable 11 GND - - Ground * Pin utilizes 10K Ω Pull-Up resistor (Already installed in the module) ** Pin utilizes 10K Ω Pull-Down resistor (Already installed in the module) *** Pin utilizes 100K Ω Pull-Up resistor (Already installed in the module) For More Information Go to the "XCite Advanced Programming & Configuration" Manual for more detailed information about module signal pinouts. The advanced manual is available on the MaxStream CD or on the web: www.MaxStream.net Note When integrating the 9XCite Module onto a Host PC Board, all lines that are not used should be left disconnected (floating). Table 2. J2 Pin Descriptions Module Pin Pin Name 1 reserved 2 GND 3 GND 4 GND J2 Pins are used primarily for mechanical stability and may be left disconnected. © 2003 MaxStream, Inc., Confidential and Proprietary 2 9XCite Wireless OEM Module – Product Manual v1.0 Pinout Signal Overview The interface signals are available through the 11-pin header. All pins operate on VCC CMOS levels. Five signals that are commonly used in applications are: • DI (pin 4 – Data In) • DO (pin 3 – Data Out) • VCC (pin 10 – Power) • GND (pin 11 – Ground) • (pin 1 – Clear-to-Send) The remaining 6 pins (SLEEP (PWRDN), , , RX LED, /PWR, ) may be used for additional functionality. Go to the “XCite Advanced Programming & Configuration Manu…

Text truncated - open the document above for the full version.

Page 1 of 3 9XCite and Modular Transmitter Requirements Modular Transmitter Requirements Manufacturer Clarification A – In order to be considered a transmitter module, the device must be a complete RF transmitter, i.e., it must have its own reference oscillator (e.g., VCO), antenna, etc. The only connectors to the module, if any, may be the power supply and modulation/data inputs. The transmitter is complete with its own reference oscillator, antenna. The only connectors provided are the DC supply, Data, and RF ports. B – Compliance with FCC RF Exposure requirements may, in some instances, limit the output power of a module and/or the final applications in which the approved module may be employed. The radio complies with MPE per 2.1091 for use with mobile or fixed base stations. C – While the applicant for a device into which an authorized module is installed is not required to obtain a new authorization for the module, this does not preclude the possibility that some other form of authorization or testing may be required for the device (e.g., a WLAN into which an authorized module is installed must still be authorized as a PC peripheral, subject to the appropriate equipment authorization). The equipment complies with FCC Part 15, Subpart B, Class B – Unintentional radiators. D – In the case of a modular transceiver, the modular approval policy only applies to the transmitter portion of such devices. Pursuant to Section 15.101(b), the receiver portion will either be subject to Verification, or it will not be subject to any authorization requirements (unless it is a Scanning Receiver, in which case it is also subject to Certification, pursuant to Section 15.101(a)). The receiver operates in 902-928 MHz and complies with FCC Part 15, Subpart B – Radio Receivers. E – The holder of the grant of equipment authorization (Grantee) of the module is responsible for the compliance of the module in its final configuration, provided that the OEM, integrator, and/or end user has complied with all of the instructions provided by the Grantee which indicate installation and/or operating conditions necessary for compliance. End users must conform with the following instructions stated in the users’ manual: - Labeling requirement for equipment using this modular transmitter. - RF Exposure information for compliance with FCC Rules 2.1091 or 2.1093 are specified in the user manual for OEM, integrator, and/or end user. Page 2 of 3 Modular Transmitter Requirements Manufacturer Clarification 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with Part 15 limits... Such coupling may result in non-compliant operation. The modular transmitter has its own RF shielding. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The modular transmitter has buffered modulation/data inputs. 3. The modular transmitter must have its own power supply regulation. This is intended to ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. The modular transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c. The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Any antenna used with the module must be approved with the module; either at the time of initial authorization or through a Class II permissive change. The “professional installation” provision of Section 15.203 may not be applied to modules. The radio complies with Rules 15.203 and 15.204c. The radio may have either a permanently attached wire antenna or a unique antenna coupler (RPSMA or MMCX) for all other approved antennas. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed... The modular transmitter was tested in a stand-alone configuration. Page 3 of 3 Modular Transmitter Requirements Manufacturer Clarification 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module... The modular transmitter is labeled with its own FCC ID number. The label is fixed on the shield. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The user manual for the 9XCite contains adequate instructions relating to the usage, approved antennas, and power supply requirements of the modular transmitter. 8. The modular transmitter must comply with any applicable RF exposure requirements. The modular transmitter was tested to applicable RF exposure requirements.

ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 1 ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 2 ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 3 Monopole Antenna (A09-QW, 1.9dBi Quarter-wave wire antenna, Permanent) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 4 Multi-path Antenna (A09-D3PNF, 3dBi omni directional permanent mount multi-path antenna, RPN) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 5 Multi-path Antenna (A09-D3PNF, 3dBi omni directional permanent mount multi-path antenna, RPN) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 6 Dome Antenna (A09-D2PGPS, 2.1dBi GPS/900MHz multi-path antenna, RPSMA) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 7 Dome Antenna (A09-D2PGPS, 2.1dBi GPS/900MHz multi-path antenna, RPSMA) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 8 Panel Antenna (A09-P8TM, 8dBi Panel antenna, RPTNC) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 9 Panel Antenna (A09-P8TM, 8dBi Panel antenna, RPTNC) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 10 Omni directional Antenna (A09-F9TM, 9.1dBi Fiberglass Base Station antenna, RPTNC) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 11 Yagi Antenna (A09-Y15TM, 15.1dBi gain 13 element Yagi antenna, RPTNC) ANNEX 2 – EXTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A2 - 12 Yagi Antenna (A09-Y15TM, 15.1dBi gain 13 element Yagi antenna, RPTNC)

FCC IDENTIFIER LABELING LABEL THAT GOES ON THE SHIELD See Figure 1 and Figure 2. LABEL THAT IS PLACED IN USER MANUAL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. LABEL THAT GOES ON THE OUTSIDE BOX This device contains transmitter module: FCC ID: OUR-9XCITE The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: OUR-9XCITE IC: 4214A-9XCITE Figure 1 – FCC and IC Identification. Figure 2 – Label on module.

ANNEX 3 – INTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A3 - 1 ANNEX 3 – INTERNAL EUT PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A3 - 2

3 3 5 5 5 5 S S o o u u t t h h 5 5 2 2 0 0 W W e e s s t t S S u u i i t t e e # # 1 1 8 8 0 0 • • L L i i n n d d o o n n , , U U t t a a h h 8 8 4 4 0 0 4 4 2 2 P P H H 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 8 8 5 5 • • F F X X 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 9 9 5 5 • • w w w w w w . . m m a a x x s s t t r r e e a a m m . . n n e e t t Yagi Antenna Family Yagi Antennas A09-Y6 6.1dBi gain 2 element Yagi antenna RPN A09-Y7 8.1dBi gain 3 element Yagi antenna RPN A09-Y8 8.1dBi gain 4 element Yagi antenna RPN A09-Y9 9.1dBi gain 4 element Yagi antenna RPN A09-Y10 10.1dBi gain 5 element Yagi antenna RPN A09-Y11 11.1dBi gain 6 element Yagi antenna RPN A09-Y12 12.1dBi gain 7 element Yagi antenna RPN A09-Y13 13.1dBi gain 9 element Yagi antenna RPN A09-Y14 14.1dBi gain 10 element Yagi antenna RPN A09-Y14 15.1dBi gain 12 element Yagi antenna RPN A09-Y15 15.1dBi gain 13 element Yagi antenna RPN A09-Y15 15.1dBi gain 15 element Yagi antenna RPN A09-Y6TM 6.1dBi gain 2 element Yagi antenna RPTNC A09-Y7TM 8.1dBi gain 3 element Yagi antenna RPTNC A09-Y8TM 8.1dBi gain 4 element Yagi antenna RPTNC A09-Y9TM 9.1dBi gain 4 element Yagi antenna RPTNC A09-Y10TM 10.1dBi gain 5 element Yagi antenna RPTNC A09-Y11TM 11.1dBi gain 6 element Yagi antenna RPTNC A09-Y12TM 12.1dBi gain 7 element Yagi antenna RPTNC A09-Y13TM 13.1dBi gain 9 element Yagi antenna RPTNC A09-Y14TM 14.1dBi gain 10 element Yagi antenna RPTNC A09-Y14TM 15.1dBi gain 12 element Yagi antenna RPTNC A09-Y15TM 15.1dBi gain 13 element Yagi antenna RPTNC A09-Y15TM 15.1dBi gain 15 element Yagi antenna RPTNC Omni directional antenna family Base Station Antennas A09-F0NF 0dBi Fiberglass Base Station antenna RPN A09-F1NF 1dBi Fiberglass Base Station antenna RPN A09-F2NF 2.1dBi Fiberglass Base Station antenna RPN A09-F3NF 3.1dBi Fiberglass Base Station antenna RPN A09-F4NF 4.1dBi Fiberglass Base Station antenna RPN A09-F5NF 5.1dBi Fiberglass Base Station antenna RPN A09-F6NF 6.1dBi Fiberglass Base Station antenna RPN A09-F7NF 7.1dBi Fiberglass Base Station antenna RPN A09-F8NF 8.1dBi Fiberglass Base Station antenna RPN A09-F9NF 9.1dBi Fiberglass Base Station antenna RPN A09-W7NF 7.1dBi Wire Base Station antenna RPN A09-F0SM 0dBi Fiberglass Base Station antenna RPSMA A09-F1SM 1dBi Fiberglass Base Station antenna RPSMA A09-F2SM 2.1dBi Fiberglass Base Station antenna RPSMA _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Page 1 of 4 3 3 5 5 5 5 S S o o u u t t h h 5 5 2 2 0 0 W W e e s s t t S S u u i i t t e e # # 1 1 8 8 0 0 • • L L i i n n d d o o n n , , U U t t a a h h 8 8 4 4 0 0 4 4 2 2 P P H H 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 8 8 5 5 • • F F X X 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 9 9 5 5 • • w w w w w w . . m m a a x x s s t t r r e e a a m m . . n n e e t t A09-F3SM 3.1dBi Fiberglass Base Station antenna RPSMA A09-F4SM 4.1dBi Fiberglass Base Station antenna RPSMA A09-F5SM 5.1dBi Fiberglass Base Station antenna RPSMA A09-F6SM 6.1dBi Fiberglass Base Station antenna RPSMA A09-F7SM 7.1dBi Fiberglass Base Station antenna RPSMA A09-F8SM 8.1dBi Fiberglass Base Station antenna RPSMA A09-F9SM 9.1dBi Fiberglass Base Station antenna RPSMA A09-W7SM 7.1dBi Wire Base Station antenna RPSMA A09-F0TM 0dBi Fiberglass Base Station antenna RPTNC A09-F1TM 1dBi Fiberglass Base Station antenna RPTNC A09-F2TM 2.1dBi Fiberglass Base Station antenna RPTNC A09-F3TM 3.1dBi Fiberglass Base Station antenna RPTNC A09-F4TM 4.1dBi Fiberglass Base Station antenna RPTNC A09-F5TM 5.1dBi Fiberglass Base Station antenna RPTNC A09-F6TM 6.1dBi Fiberglass Base Station antenna RPTNC A09-F7TM 7.1dBi Fiberglass Base Station antenna RPTNC A09-F8TM 8.1dBi Fiberglass Base Station antenna RPTNC A09-F9TM 9.1dBi Fiberglass Base Station antenna RPTNC A09-W7TM 7.1dBi Wire Base Station antenna RPTNC Mag Mount Antennas A09-M0SM 0dBi gain Mag Mount antenna RPSMA A09-M2SM 2dBi gain Mag Mount antenna RPSMA A09-M3SM 3dBi gain Mag Mount antenna RPSMA A09-M5SM 5dBi gain Mag Mount antenna RPSMA A09-M7SM 7dBi gain Mag Mount antenna RPSMA A09-M9SM 9dBi gain Mag Mount antenna RPSMA A09-M0TM 0dBi gain Mag Mount antenna RPTNC A09-M2TM 2dBi gain Mag Mount antenna RPTNC A09-M3TM 3dBi gain Mag Mount antenna RPTNC A09-M5TM 5dBi gain Mag Mount antenna RPTNC A09-M7TM 7dBi gain Mag Mount antenna RPTNC A09-M9TM 9dBi gain Mag Mount antenna RPTNC Half-wave Antennas A09-HSM-7 3 dBi Straight half-wave antenna RPSMA A09-HASM-675 Articulated half-wave antenna RPSMA A09-HABMM-P6I 2 dBi Articulated half-wave antenna with 6” pigtail MMCX A09-HABMM-6-P6I 2 dBi Articulated half-wave antenna with 6” pigtail MMCX A09-HRSM 2.5 dBi Right-angle half-wave antenna RPSMA A09-HASM-7 2.0 dBi Articulated half-wave antenna RPSMA A09-HG Glass mounted half-wave antenna RPSMA A09-HATM Articulated half-wave antenna RPTNC Monopole Antenna Family _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Page 2 of 4 3 3 5 5 5 5 S S o o u u t t h h 5 5 2 2 0 0 W W e e s s t t S S u u i i t t e e # # 1 1 8 8 0 0 • • L L i i n n d d o o n n , , U U t t a a h h 8 8 4 4 0 0 4 4 2 2 P P H H 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 8 8 5 5 • • F F X X 8 8 0 0 1 1 - - 7 7 6 6 5 5 - - 9 9 8 8 9 9 5 5 • • w w w w w w . . m m a a x x s s t t r r e e a a m m . . n n e e t t A09-QW 1.9 dBi Quarter-wave wire antenna Permanent A09-QSM-3 1.9 dBi Quarter-wave straight antenna RPSMA A09-QSM-3H 1.9 dBi Heavy duty quarter-wave straight antenna RPSMA A09-QBMM-P6I 1.9 dBi Quarter-wave antenna with 6” pigtail MMCX A09-QHRN -1 dBi Miniature Helical Right Angle antenna solder Permanent A09-QHSN -1 dBi Miniature Helical Straight antenna solder Permanent A09-QHSM-2 1.9 dBi 2' straight RPSMA antenna RPSMA A09-QHRSM-2 1.9 dBi 2" RA RPSMA antenna RPSMA A09-QHRSM-170 1.9 dBi 1.7" RA RPSMA antenna RPSMA A09-QRSM-380 1.9 dBi 3.8" RA…

Text truncated - open the document above for the full version.

900 MHz Wireless OEM Module Model No.: 9XCite FCC ID: OUR-9XCITE Applicant: MaxStream, Inc. 355 South 520 West Suite 180 Lindon, UT USA, 84042 In Accordance With Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.247 Frequency Hopping Spread Spectrum (FHSS)/ Digital Transmission System (DTS) Operating in 902 - 928 MHz Band UltraTech's File No.: MXS-026F15C247 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: December 1, 2003 Report Prepared by: Dan Huynh Issued Date: December 1, 2003 Tested by: Mr. Hung Trinh, EMI/RFI Technician Test Dates: Sep. 29 - Oct. 14, 2003 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC Part 15, Subpart C, Section 15.247 – FHSS/DTS Contents i 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE ULTRATECH GROUP OF LABS File #: MXS-026F15C247 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 1, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST ........................................................................................................................................ 1 EXHIBIT 2. INTRODUCTION .......................................................................................................................................................... 2 2.1. SCOPE .......................................................................................................................................................................................... 2 2.2. RELATED SUBMITTAL(S)/GRANT(S)..................................................................................................................................... 2 2.3. NORMATIVE REFERENCES ..................................................................................................................................................... 2 EXHIBIT 3. PERFORMANCE ASSESSMENT ............................................................................................................................... 3 3.1. CLIENT INFORMATION ............................................................................................................................................................ 3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION............................................................................................................... 3 3.3. EUT’S TECHNICAL SPECIFICATIONS.................................................................................................................................... 4 3.4. ASSOCIATED ANTENNA DESCRIPTIONS ............................................................................................................................. 4 3.5. LIST OF EUT’S PORTS............................................................................................................................................................... 5 3.6. ANCILLARY EQUIPMENT ........................................................................................................................................................ 5 EXHIBIT 4. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS................................................. 6 4.1. CLIMATE TEST CONDITIONS ................................................................................................................................................. 6 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS............................................................................... 6 EXHIBIT 5. SUMMARY OF TEST RESULTS................................................................................................................................ 7 5.1. LOCATION OF TESTS................................................................................................................................................................ 7 5.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ................................................................................ 7 5.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES.......................................................... 7 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ................................................ 8 6.1. TEST PROCEDURES .................................................................................................................................................................. 8 6.2. MEASUREMENT UNCERTAINTIES ........................................................................................................................................ 8 6.3. MEASUREMENT EQUIPMENT USED ..................................................................................................................................... 8 6.4. ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUACTURER............................................................. 8 6.5. COMPLIANCE WITH FCC PART 15 – GENERAL TECHNICAL REQUIREMENTS ............................................................ 9 6.6. AC POWER LINE CONDUCTED EMISSIONS [47 CFR §15.107(a)] ..................................................................................... 11 6.7. PROVISIONS FOR FREQUENCY HOPPING & DIGITALLY MODULATED SYSTEMS [§ 15.247(a)(1) & (2)]............... 14 …

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 1 AC Power Line Conducted Emissions ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 2 AC Power Line Conducted Emissions ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 3 Radiated Emissions @ 3 Meters EUT with Monopole Antenna (A09-QW, 1.9dBi Quarter-wave wire antenna, Permanent) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 4 Radiated Emissions @ 3 Meters EUT with Monopole Antenna (A09-QW, 1.9dBi Quarter-wave wire antenna, Permanent) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 5 Radiated Emissions @ 3 Meters EUT with Multi-path Antenna (A09-D3PNF, 3dBi omni directional permanent mount multi-path antenna, RPN) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 6 Radiated Emissions @ 3 Meters EUT with Multi-path Antenna (A09-D3PNF, 3dBi omni directional permanent mount multi-path antenna, RPN) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 7 Radiated Emissions @ 3 Meters EUT with Dome Antenna (A09-D2PGPS, 2.1dBi GPS/900MHz multi-path antenna, RPSMA) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 8 Radiated Emissions @ 3 Meters EUT with Dome Antenna (A09-D2PGPS, 2.1dBi GPS/900MHz multi-path antenna, RPSMA) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 9 Radiated Emissions @ 3 Meters EUT with Panel Antenna (A09-P8TM, 8dBi Panel antenna, RPTNC) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 10 Radiated Emissions @ 3 Meters EUT with Panel Antenna (A09-P8TM, 8dBi Panel antenna, RPTNC) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 11 Radiated Emissions @ 3 Meters EUT with Omni directional Antenna (A09-F9TM, 9.1dBi Fiberglass Base Station antenna, RPTNC) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 12 Radiated Emissions @ 3 Meters EUT with Omni directional Antenna (A09-F9TM, 9.1dBi Fiberglass Base Station antenna, RPTNC) ANNEX 1 - TEST SETUP PHOTOS MaxStream, Inc. 900 MHz Wireless OEM Module, Model 9XCite FCC ID: OUR-9XCITE IC: 4214A-9XCITE A1 - 13 Radiated Emissions @ 3 Meters EUT with Yagi Antenna (A09-Y15TM, 15.1dBi gain 13 element Yagi antenna, RPTNC) ANN…
