OV5-WDSBWireless Data Server

PROOF PROOF WirelessData Server OPERATOR'S MANUAL WirelessData Server OMPFP21155ISSUEF0 (ENGLISH) *OMPFP21155* CALIFORNIA Proposition65 Warning Dieselengineexhaustand someof its constituents are knownto the Stateof Californiato causecancer, birth defects,and otherreproductiveharm. If this productcontainsa gasolineengine: WARNING The engineexhaustfrom this productcontains chemicalsknownto the Stateof Californiato cause cancer, birth defectsor otherreproductiveharm. The Stateof Californiarequiresthe abovetwo warnings. AdditionalProposition65 Warningscan be foundin this manual. John DeereAg ManagementSolutions PRINTEDIN U.S.A. PROOF PROOF Foreword THANKYOUfor purchasinga JohnDeereproduct. READTHISMANUALcarefullyto learnhow to operate and serviceyour productcorrectly. Failureto do so couldresultin personalinjuryor equipmentdamage. This manualand safetysignson your productmay also be availablein otherlanguages.(Seeyour JohnDeere dealerto order.) THISMANUALSHOULDBE CONSIDEREDa permanentpart of your productand shouldremainwith the productwhenyou sell it. MEASUREMENTSin this manualare givenin both metricand customaryU.S. unit equivalents.Use only correctreplacementpartsand fasteners.Metricand inch fastenersmay requirea specificmetricor inch wrench. RIGHT-HANDANDLEFT-HANDsidesare determined by facingin the directionthe machineor implementwill travelwhengoingforward. WRITEPRODUCTIDENTIFICATIONNUMBERS(P.I. N.) in the Operator’s Manual.Accuratelyrecordall the numbersto help in tracingthe productshouldit be stolen.Your dealeralso needsthesenumberswhenyou orderparts.File a backupof the identificationnumbers in a safe locationoff the machineor awayfrom the product. WARRANTYis providedas part of JohnDeere's supportprogramfor customerswho operateand maintaintheir equipmentas describedin this manual. The warrantyis explainedon the warrantycertificateor statementwhichyou shouldhavereceivedfrom your dealer. This warrantyprovidesyou the assurancethat John Deerewill backits productswheredefectsappearwithin the warrantyperiod.In somecircumstances,John Deerealso providesfield improvements,oftenwithout chargeto the customer, evenif the productis out of warranty. Shouldthe equipmentbe abused,or modified to changeits performancebeyondthe originalfactory specifications,the warrantywill becomevoid and field improvementsmay be denied. If you are not the originalownerof this product,it is in your interestto contactyour localJohnDeeredealerto informthemof this unit'sserialnumber. This will help JohnDeerenotifyyou of any issuesor product improvements. SerialNumber: JS56696,0000C4C-19-03FEB17 John DeereTechnicalInformation Bookstore Productfunctionalitymay not be fully representedin this documentdue to productchangesoccurringafter time of printing.Readthe latestOperator’s Manualprior to operation.To obtaina copy, see your dealeror visit techpubs.deere.com. CZ76372,000071F-19-08OCT19 Introduction PROOF PROOF Page Safety RecognizeSafetyInformation....................... 05-1 UnderstandSignalWords............................ 05-1 FollowSafetyInstructions............................ 05-1 PracticeSafeMaintenance.......................... 05-2 Use Stepsand HandholdsCorrectly................ 05-2 HandleElectronicComponentsand Brackets Safely................................................ 05-2 Use ElectronicDisplayProperly..................... 05-2 PreventElectricalShockand Fires................. 05-3 Avoid Exposureto HighRadioFrequency Fields................................................ 05-3 RemoteControls...................................... 05-3 Regulatoryand ComplianceInformation Notificationsto User.................................. 20-1 FederalCommunicationsCommission(FCC) Notificationsto User............................... 20-1 IndustryCanadaNotificationsto User.............. 20-2 Paraguay—GeneralDisclaimer...................... 20-3 ParaguayDealer...................................... 20-3 Brazil—Declarationof Conformity................... 20-4 IdentifyDateCode.................................... 20-4 CustomsUnion–EAC................................. 20-4 EU Declarationof Conformity........................ 20-6 SystemOverview Theoryof Operation................................ 30A-1 ComponentOverview MobileDevice......................................... 40-1 StarFire™Receiver................................... 40-1 GreenStar™Displayor Generation4 Display..... 40-1 WirelessDataServer................................. 40-2 WirelessDataServerCoaxialCableand Antenna............................................. 40-2 SettingUp—GreenStar™3 2630 Display ConfigureWirelessDataServer................... 50B-1 ConnectDeviceto WirelessDataServer........ 50B-1 Set Up Display...................................... 50B-2 SettingUp—Generation4 Display ConfigureWirelessDataServer................... 50C-1 ConnectDeviceto WirelessDataServer........ 50C-2 Set Up Display...................................... 50C-2 Operating Navigateto WirelessDataServerPage.......... 70A-1 ViewWirelessDataServerMainPage........... 70A-1 Page Operating–ManagingData On WirelessData Server Navigateto WirelessDataServerPage.......... 70B-1 DeleteDatafrom WirelessDataServer.......... 70B-1 Operating–UpdatingSoftware UpdateWirelessDataServer...................... 70C-1 UpdateMobileApplication......................... 70C-1 Operating–ResettingWirelessPassword Navigateto WirelessDataServerPage.......... 70D-1 ResetWirelessPassword.......................... 70D-1 Troubleshooting Navigateto WirelessDataServerPage............ 80-1 WirelessDataServerDiagnostics.................. 80-1 AdditionalSupportMaterial.......................... 80-1 Troubleshooting—MobileDevice.................... 80-2 Maintenance PreseasonChecklist................................. 100-1 Post-seasonChecklist............................... 100-1 DailyChecklist........................................ 100-1 OriginalInstructions.All information,illustrationsand specificationsin this manualare basedon…

Text truncated - open the document above for the full version.

Deere & Company One John Deere Place, Moline, IL 61265, USA Phone: 515-253-7177 Fax: 515-253-6258 E-m ail: Post NancyE@J ohnDeere.c om Nancy E. Post Director-Embedded Solutions June 08, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:OV5-WDSB CONFIDENTIALITY REQUEST Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules,Deere & Company hereby requests permanent confidential treatment of information accompanying this application as outlined below: ƒSchematics ƒBill of Materials/Parts List ƒBlock Diagrams ƒTheory of Operation Deere & Company alsohereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days after the Grant Date of Equipment Authorizations: ƒInternal Photos ƒExternal Photos ƒUser Manual ƒTest Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. This document is solely submitted for purposes of review for the certification and for no other purpose and should not be disclosed to any third parties without prior written consent of Deere & Company. Signed: Nancy E. Post Director-Embedded Solutions Deere & Company One Deere Place, Moline, IL 61265, USA. Deere & Company One John Deere Place, Moline, IL 61265, USA Phone: 515-253-7177 Fax: 515-253-6258 E-m ail: Post NancyE@J ohnDeere.c om Nancy E. Post Director-Embedded Solutions

Report Reference # 092-72155767-000 Page 2 of 9 2020-04-21 Attachment No. #2 Project: 092-72155767-000 Manufacturer: Deere & Company Model: WDSB Top view Report Reference # 092-72155767-000 Page 3 of 9 2020-04-21 Attachment No. #2 Project: 092-72155767-000 Manufacturer: Deere & Company Model: WDSB Back view

C 1234 4321 D C B A D A SYM DATE(YYYY-MM-DD)APPROVEDCHANGE DOCDESCRIPTIONZONE MIN NOTE 6 6 2X MIN5 (12X )1.2 38.11 50.81 2X 1.2 MIN5 3 +0.5 0 MIN6.6 MIN3 MIN5 MIN7.7 MIN5 MIN2 ()1.5 ()12.9 2X MIN1 MIN1.2 1.5 (4X R)1.6 PFP20663 JD90 1/1 A PART NUMBER VERSION SHEET REV PFP20663 JD901/1A PART NUMBERVERSIONSHEETREV CONFIDENTIAL AND PROPRIETARY TO DEERE & COMPANY. UNAUTHORIZED USE, DISCLOSURE, OR REPRODUCTION PROHIBITED. COPYRIGHT DEERE & COMPANY. ALL RIGHTS RESERVED. ORIGINATOR CORY J VAN WYNGARDEN ORIGINATION DATEREFERENCES: METRIC SCALE 2019-12-16JDS-G1132:1MATERIAL NAME LABEL SIZE JDM F7C1 C COMPLIANCE, WIRELESS DATA SERVER POLYESTER WITH ACRYLIC ADHESIVE CAGE CODE SEKURE IDENT RET-02-051x025-Z3 DEERE & COMPANY MOLINE, ILLINOIS 61265 VERSION OR EQUIVALENT JD90 SHEET 1/1 PART NUMBER PFP20663 REVISION A MODEL RLMODEL REVDRW REVDRW RL DevelopA.10A.10Develop 1. TEXT AND COMPLIANCE MARKS LOCATED AND PROPORTIONED APPROXIMATELY AS SHOWN 2. FILL BLOCK TEXT AND COMPLIANCE MARKS PER REQUIREMENTS 3. TEXT COLOR: JDM F9RL, LABEL GLOSS BLACK 4. LABEL COLOR: JDM F9WR, REFLECTIVE WHITE (SILVER) 5. MATERIALS PER JDM H31 6. COMPLIANCE MARK PER UN ECE 324 ADDENDUM 9: REGULATION NO. 10 ANNEX 1 (E/ECE/324/Add.9/Rev.5) 7. COMPLIANCE MARK PER EUROPEAN COMMISSION COUNCIL DECISIONS 765/2008/EC AND 768/2008/EC 8. COMPLIANCE MARK PER AUSTRALIAN COMMUNICATIONS AND MEDIA AUTHORITY REQUIREMENTS AS/NZS 4417.1-2012. HEIGHT 3 MIN. 9. COMPLIANCE MARK PER SOUTH AFRICA GOVERNMENT GAZETTE NO. 36786 10. COMPLIANCE MARK PER CUSTOMS UNION TR CU DECISION NO. 711 11. COMPLIANCE MARK PER UKRAINE TECHNICAL REGULATION ON ELECTROMAGNETIC COMPATIBILITY ANNEX III. HEIGHT 5 MIN. 12. COMPLIANCE MARK PER ARGENTINE COMISION NACIONAL DE COMUNICACIONES RESOLUTION NO. 82/2015. MARK WIDTH 5 MIN. TEXT HEIGHT 1 MIN. 13. COMPLIANCE MARK PER BRAZIL NATIONAL TELECOMMUNICATIONS AGENCY RESOLUTION 242/200 ANNEX III 14. COMPLIANCE MARK PER PARAGUAY CONATEL RESOLUCION DIRECTORIO NO. 1193/2017 15. COMPLIANCE MARK PER MEXICAN OFFICIAL STANDARD NOM-106-SCF1-2000. NYCE TEXT TO BE HELVETICA TYPEFACE NOTE 7 NOTE 8 NOTE 10 NOTE 11 NOTE 13 NOTE 12 NOTE 14 SEE DETAIL A NOTE 15 NOTE 9 DETAIL A SCALE 4:1 A INITIAL DRAFT600347PN2020-04-09 CORY J. VAN WYNGARDEN

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA FCC ID: OV5-WDSB FCC Rule Part: 47 CFR Part 2.1091 Project Number: 72155767 Manufacturer: Deere & Company Model: Wireless Data Server; Model: WDSB RF Exposure Model(s): WDSBFCC ID: OV5-WDSB Report: AT72155767-2C1Page 2 General Information: Applicant: Deere & Company Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: External Dipole Max Antenna Gain: 5 dBi Maximum Transmitter Conducted Power: 20.9dBm, 123.03mW Maximum System EIRP: 25.9 dBm, 389.1 mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Table 1: MPE Calculation Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/cm 2 ) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Distance (cm) Power Density (mW/cm 2 ) 246220.91.00123.0353.162200.0774

5945 Cabot Pkwy, Suite 100, Alpharetta, GA 30005 Certification Test Report FCC ID: OV5-WDSB IC: 11137A-WDSB FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Report Number: AT72155767-1C1 Manufacturer: Deere & Company Model: Wireless Data Server; Model: WDSB Test Begin Date: February 21, 2020 Test End Date: April 6, 2020 Report Issue Date: June 2, 2020 FOR THE SCOPE OF ACCREDITATION UNDER Certificate Number: 2955.09 This report must not be used by the client to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the Federal Government. PreparedBy:Reviewedby: Jeremy PickensRyan McGann Senior Wireless EngineerSenior Engineer TÜV SÜD America Inc.TÜV SÜD America Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of TÜV SÜD America Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 31 pages 5945 Cabot Pkwy, Suite 100, Alpharetta, GA 30005 TABLE OF CONTENTS 1GENERAL .............................................................................................................................. 3 1.1PURPOSE ................................................................................................................................... 3 1.2PRODUCT DESCRIPTION ............................................................................................................ 3 1.3TEST METHODOLOGY AND CONSIDERATIONS ........................................................................... 4 2TEST FACILITIES ............................................................................................................... 5 2.1LOCATION ................................................................................................................................. 5 2.2LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS .......................................... 5 2.3RADIATED EMISSIONS TEST SITE DESCRIPTION ........................................................................ 6 2.3.1Semi-Anechoic Chamber Test Site ........................................................................................... 6 2.4CONDUCTED EMISSIONS TEST SITE DESCRIPTION ..................................................................... 7 2.4.1Conducted Emissions Test Site ................................................................................................. 7 3APPLICABLE STANDARD REFERENCES ..................................................................... 8 4LIST OF TEST EQUIPMENT ............................................................................................. 8 5SUPPORT EQUIPMENT...................................................................................................... 9 6EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ............................................. 9 7SUMMARY OF TESTS........................................................................................................10 7.1ANTENNA REQUIREMENT –FCC15.203 ..................................................................................10 7.2POWER LINE CONDUCTED EMISSIONS –FCC15.207,ISEDCANADA:RSS-GEN 8.8 ..............10 7.2.1Measurement Procedure .........................................................................................................10 7.2.2Measurement Results ..............................................................................................................10 7.36DB/99%BANDWIDTH –FCC15.247(A)(2),ISEDCANADA:RSS-2475.2(A)/RSS-GEN6.7 11 7.3.1Measurement Procedure .........................................................................................................11 7.3.2Measurement Results ..............................................................................................................11 7.4FUNDAMENTAL EMISSION OUTPUT POWER –FCC15.247(B)(3),ISEDCANADA:RSS-247 5.4(D) 14 7.4.1Measurement Procedure .........................................................................................................14 7.4.2Measurement Results ..............................................................................................................14 7.5EMISSION LEVELS ....................................................................................................................15 7.5.1Emissions into Non-restricted Frequency Bands – FCC 15.247(d); ISED Canada: RSS-247 5.5 ............................................................................................................................................15 7.5.2Emissions into Restricted Frequency Bands – FCC: 15.205, 15.209; ISED Canada: RSS-Gen 8.9 / 8.10..................................................................................................................................20 7.6MAXIMUM POWER SPECTRAL DENSITY IN THE FUNDAMENTAL EMISSION –FCC15.247(E) ISEDCANADA:RSS-2475.2(B) ................................................................................................................23 7.6.1Measurement Procedure .........................................................................................................23 7.6.2Measurement Results ..............................................................................................................23 7.7DUTY CYCLE ...........................................................................................................................25 7.7.1Measurement Procedure .........................................................................................................25 7.7.2Measurement Results ..............................................................................................................25 8ESTIMATION OF MEASUREMENT UNCERTAINTY .................................................26 9CONCLUSION ......................................................................................................................26 APPENDIX A: PLOTS .....................…

Text truncated - open the document above for the full version.

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: OV5-WDSB IC: 1137A-WDSB FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Project Number: 72155767 Manufacturer: Deere & Company Model: Wireless Data Server, Model: WDSB Test Setup Photos Model(s): WDSBFCC ID: OV5-WDSBIC: 1137A-WDSB Project: 72155767Page 2 Figure 1: Equipment Under Test – Radiated Emissions – Antenna Port Conducted Measurements Model(s): WDSBFCC ID: OV5-WDSBIC: 1137A-WDSB Project: 72155767Page 3 Figure 2: Equipment Under Test – Radiated Emissions <30MHz Figure 3: Equipment Under Test – Radiated Emissions <30MHz Model(s): WDSBFCC ID: OV5-WDSBIC: 1137A-WDSB Project: 72155767Page 4 Figure 4: Equipment Under Test – Radiated Emissions <1GHz Figure 5: Equipment Under Test – Radiated Emissions <1GHz Model(s): WDSBFCC ID: OV5-WDSBIC: 1137A-WDSB Project: 72155767Page 5 Figure 6: Equipment Under Test – Radiated Emissions >1GHz Figure 7: Equipment Under Test – Radiated Emissions >1GHz Model(s): WDSBFCC ID: OV5-WDSBIC: 1137A-WDSB Project: 72155767Page 6 Figure 8: Equipment Under Test – Radiated Emissions >18GHz
