OW5BST301Booster

User Instructions Car Booster Instructions:1 ) Instructions for m **It is important to mount antenna using cable provided or suitable cable having an 8.0 db loss for 4dbi magnetic mount antenna and 3.6 db loss for 5 dbi glass mount antenna in order to comply with FCC rules concerning MPE (Maximum Permissible Exposure) safety limits**Magnetic Mount: Place centered, only on vehicle roof or 8 inches(20cm)away from any vehicle occupant or nearby persons.Glass mount: Must be positioned to provide a minimum distance o f 12 inches (30 cm) from any of the vehicle occupants or nearby persons.Run the co-ax cable along the head liner or along the floor under the carpet and bring up to the position of the booster.Connect co-ax cable to side of booster marked “Antenna”.3) Connect the 100cm cable from cell phone to side of booster marked “Signal Adapter”. When using with Cell Phone:connect cell phone adapter cable from cell phone to 100cm cable.When using with Car Kit: connect Car Kit antenna out, to 100cm cable. ) Place the Booster in a suitable location under the dashboard and plug in power cord to cigarette lighter socket of vehicle.2ounting antenna to vehicle: 4) Tighten all connections securely and move the switch located at the side of the booster to the “on” position. A green light will indicate that the unit is now ready for use.PLEASE NOTE: It is normal for the booster to be quite warm while the phone is in use. NOTE: This equipment has been tested and found to comply withthe limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that int erference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the useris encouraged to try to correct the interference by one of more of the following measures:Reorient or relocate the receiving antenna · Increase the separation between the equipment and receiver · Connect the equipment into an outlet on a circuit different from that to which the receiver is c onnected. · Consult the dealer or an experienced radio/TV technician for help. Typical Car Installation Cellular Phone Hands Free In-car Kit Antenna Car Kit Ant Out Cellular AntennaAdapter Car Booster Car Antenna

User Instruction Manual Model BST301 Dual Band Glass Mount Antenna (Optional) AC/DC Power Supply (Optional)Allows Use of Booster In Home Or Office Adapter Cables (Order Separately) Dual Band Mag Mount Antenna Specifications: Model:BST301 Frequency Range (Mhz) Uplink806-821 Downlink851-866 Output PowerMax 3 Watt Gain Uplink+25dB Downlink+19dB Power Consumption Stand ByDC 12V/0.2A In UseDC12V/1.6A RFConnector FME-Female Weight200g Dimensions115 x 68 x 19mm Hands Free Communication SmoothTalker Hands Free Communication SmoothTalker Mobile Communication Technologies Inc. Contact Us On The Internet At www.smoothtalker.com MCT

360 Industrial Pkwy South Unit#1 Aurora, Ontario. L4G 3V7 Tel#905 7263444 Fax# 905 726 4233 FEDERAL COMMUNICATIONS COMMISSION C/O M ello n Bank Three M ello n Bank Center 525 William Penn Way 27 th Floor, Rm 153-2713 Pittsburg, PA 15259-0001 Attn: Wholesale Lockbox Supervisor Subject: Grantee Code Application & Authority to Act as Agent to FCC Applicant: Mobile Communication Technologies Inc Contact: Mr. Tom Vagenas (Director Operations) Product: Linear Amplifier Model: BST 301 FCC ID: ______________ Jan 29/01. Dear Sir/Madam, We hearby apply for FCC Grantee code and authorize: MPB Technologies Inc. 302 Leggat Dr. Unit#100 Kanata, Ontario. Canada. K2K 1Y5 to act as our on our behalf as our authorized agent. Yo urs truly, Tom Vagenas

360 Industrial Pkwy South Unit#1 Aurora, Ontario. L4G 3V7 Tel#905 7263444 Fax# 905 726 4233 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for w ithholding from public disclosure the schematic diagrams and parts list pursuant to an application for certification. Applicant: Mobile Communication Technologies Inc Product: Linear Amplifier Model: BST 301 FCC ID: «OW5BST301» Dear Sir/Madam, We, Mobile Communication Technologies Inc., would like to request that the schematic diagram and the parts list, submitted as separate files with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact us by our Tel number 905 726-3444: Yo urs truly, Tom Vagenas

BST301 Outside View

Contact us at: www.smoothtalker.com Model BST301 Frequency:TX 806-821MHz Output Power:Max 3 watt Structure: Full Duplex Gain: TX Max 22dB RX Max 19dB RX 851-866MHz Variable Gain R.F. Booster S/N#XXX123 FCC ID: OW5BST301 Hands Free Communication SmoothTalker

BST301 Component Side B ST301 Heatsink S ide

MP B Technologies Inc. M34R2460 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. ISO/IECGuide25: 1990 ISO 9002: 1987 Test Report Prepared By: Electronics Test Centre MPB Technologies Inc. Unit 100 302 Legget Drive Kanata Ontario K2K 1Y5 MPBT Report No.: M34R2460Customer No.: PO# 208 Report for FCC Part 1 .1310 MPE FCC Part 15 Subpart B FCC Part 90 Subpart I F o r P riva t e M o bile Tra nsmit t e r Amplif ie rs f o r T.D.M.A. Cellular Radio-Telephone Service Testing of the BST301 iDEN Motorola Truncking Booster Test Personnel: D.Beck Prepared for: Mobile Communications Technologies INC. 360 Industrial Parkway South, Unit #1 Aurora, ON L4G 3V7 _________________________ Client Acceptance Authorized Signatory February 23, 2001 M34R2197 _________________________ Dan Zanette Lab Supervisor Electromagnetic Services Electromagnetics Division Authorized Signatory Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Page 2 of 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. T ABLE OF C ONTENTS 1.0 INTRODUCTION 1.1SCOPE 1.2APPLICANT 1.3APPLICABILITY 1.4TEST SAMPLE DESCRIPTION 1.5GENERAL TEST CONDITIONS AND ASSUMPTIONS 1.6SCOPE OF TESTING 1.6.1 VARIATIONS IN TEST METHODS 1.6.2 TEST SAMPLE MODIFICATIONS 2.0 TEST CONCLUSION 2.1EMISSIONS – AC PORT CONDUCTED 2.2DIGITAL EMISSIONS, RADIATED 2.3EFFECTIVE RADIATED POWER (ERP) LIMIT 2.4EMISSION LIMITATIONS FOR CELLULAR – OCCUPIED BANDWIDTH 2.5EMISSION LIMITATIONS FOR CELLULAR – OUT OF BAND 2.6MAXIMUM PERMISSIBLE EXPOSURE (MPE) 3.0 TEST FACILITY 3.1LOCATION 3.2GROUNDING PLANE 3.3POWER 3.4EMISSIONS PROFILE 3.5TEST CONFIGURATION 4.0 TEST EQUIPMENT 4.1RADIATED EMISSIONS 4.2CONDUCTED EMISSIONS 4.3EMI SPECTRUM ANALYZER AND RECEIVER 4.3.1 Spectrum Analyzer 4.3.2 Receiver A PPENDICES APPENDIX A:SAMPLE DESCRIPTION APPENDIX B:TEST REPORT DATA SHEETS & PLOTS APPENDIX C:TEST EQUIPMENT REPORT APPENDIX D:PHOTOGRAPHS APPENDIX E:SUPPLEMENTARY DATA Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Page 3 of 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 1.0 INTRODUCTION 1.1SCOPE The purpose of this report is to present the findings and results of compliance testing performed in accordance with FCC Part(s) 1, 15, 90 (1996). 1.2APPLICANT This test report has been prepared for MCT Inc. 1.3APPLICABILITY All test procedures, limits, and results defined in this document apply to the, which shall be referred to herein as the Equipment Under Test ( EUT ). The results contained in this report relate only to the item(s) tested. This re port doe s not imply product e ndorse me nt by NVLAP or the Canadian or US governments. If multiple units, the test samples provided for testing were intended for use together. 1.4TEST SAMPLE DESCRIPTION The following testing is for a Mobile Motorola iDEN Truncking Booster ProductPart NumberSerial Number Power Requirements Peripheral Equipment BST301 iDEN Motorola Truncking Booster BST 301 (Sample# 1758) 12 VDC Signal Generator/ Cellular Phone Tx Gain (dB): 22.0 Measured at: 813.5 MHz Tx Maximum Power Output (dBm): 34.77 = 3 Watts Band of operation Tx: 806-821 MHz Measured at: 813.5 MHz Rx Gain (dB): 19.0 Measured at: 858.5MHz Band of operation Rx: 851 – 866 MHz Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Page 4 of 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 1.5GENERAL TEST CONDITIONS AND ASSUMPTIONS The EUT was setup and exercised using the configurations, modes of operation and arrangements defined in this report only. All inputs and outputs to and from other equipment associated with the EUT were adequately simulated. Where relevant, the EUT was only tested using the monitoring methods and test criteria defined in this report. All testing, unless otherwise noted, was performed under the following environmental conditions: Temperature:17 to 23 ° C Humidity:45 to 75 % Barometric Pressure: 68 to 106 kPa 1.6SCOPE OF TESTING Tests were performed in accordance with FCC Parts 1,15,90 (1996). 1.6.1 VARIATIONS IN TEST M ETHODS There were no variations from the test procedures outlined above. 1.6.2 TEST SAMPLE MODIFICATIONS No test sample modifications were made Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Page 5 of 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 2.0 TEST CONCLUSION The EUT was subjected to the following tests. Compliance status is assessed as PASS, FAIL, or MARGINAL PASS The following table summarizes the test results and details the tests performed in terms of the specification and class or level applied, the unique test sample identification, and the EUT modification state, the mode of operation, and configuration. Te s t Case Test TypeSpecificationClass/ Level CriteriaTest Sample ConfigEngineering / Qualification Resul t 2.1DC Port Conducted Emissions FCC Part 15, (Subpart B) BNA Sample #1758 TestQualification PASS 2.2Radiated Emissions (Field Strength Spurious) FCC Part 15, (Subpart B) BNA Sample #1758 TestQualification PASS 2.3ERPFCC Part 22 (Subpart H) NANA Sample #1758 TestQualification PASS 2.4Emission Mask (OCC BW) FCC Part 9065.4 dBNA Sample #1758 TestQualification PASS 2.5Emission Mask (Out of band/Spurious) FCC Part 90.210 (Subpart I) 58.4 dBNA Sample #1758 TestQualification PASS 2.6MPEFCC Part 1.1310 BNA Sample #1758 TestQualification PASS STATEMENT OF COMPLIANCE The clie nt e quipme nt re fe rre d to in this re port was found to comply with the re quire me nts of FCC regulations as summarized above. Test Sample: BST301 iDEN…

Text truncated - open the document above for the full version.

Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 11 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 2.5EMISSION LIMITATIONS FOR CELLULAR – OUT OF BAND Test Summary Test Lab: MPB Technologies Inc. Ottawa Test Personnel: D. BECK Test Date: February 9, 2001 Product: BST301 iDEN Motorola Truncking Booster Test Description Objectives/CriteriaSpecifications On any frequency twice or more then twice the fundamental frequency, the mean power of emissions must be attenuated below the mean power of the unmodulated carrier by a minimum of 60 or 43+10logP dB. FCC PART 90: 1996, Subpart H Section 90.210 f c – 10xf c 43+10logP dB Note: dB refers to attenuation from the mean power of the unmodulated carrier. f c refers to frequency of the carrier f d refers to displacement frequency from the carrier in kHz P refers to the mean power of the unmodulated carrier wave. Test Result: PASS Comments: P <= 3.0W,Therefore 43 + LogP dB is 58.4dB. 58.4 dB down from unmodulated carrier is the limit for that frequency range of the mask. Refer to Test Report Data sheets for more detail. Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 12 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 2.6MAXIMUM PERMISSIBLE EXPOSURE (MPE) Test Summary Test Lab: MPB Technologies Inc. Ottawa Test Personnel: D. BECK Test Date: February 7, 2001 Product: BST301 iDEN Motorola Truncking Booster Test Description Objectives/CriteriaSpecifications For devices to be operated more then 20 cm from the users body, the equipment shall not exceed that listed in the table based on an averaging time of 30 minutes and that the limit is for the general population/uncontrolled exposure. Power Density Requirements, FCC Part 1.1310 Frequency mW/cm² 0.3 – 1.34 (100) 1.24 – 30 (180/f²) 30-300 0.2 300-1500 f/1500 1500-10000 1 Test Result: PASS Comments: Limit distance is at 8.8 inches from antenna. Statement to be incorporated shall read as follows: The glass mount antenna must be mounted in a location that will provide a minimum of 12 inches separation between it and vehicle occupants in order to meet the MPE (Maximum Permissible Exposure) limit and requirements in accordance with FCC CFR 47 Part 1.1301. The maximum permissible power output limit is at 8.8 inches from the antenna, this is equivalent to 0.557mW/cm 2 . Max Output measured at 824 MHz was 0.194 mW/cm 2 at 12 inches . Refer to Test Report Data sheets for more detail. All measurements were performed while the EUT was transmitting a CW signal which is deemed to be worst case. Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 13 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 3.0 TEST FACILITY 3.1LOCATION The EUT was tested for Electromagnetic Compatibility at the Electronics Test Centre, located in Kanata, Ontario, Canada. 3.2GROUNDING PLANE The EUT was located on a wooden table 80 cm above the ground plane. The EUT was grounded according to the Clients specifications. 3.3POWER AC power was supplied via a CORCOM RFI feed through, 60-Ampere wall mounted filter. Bonding to hydro ground is via one inch grounding braid straps. 3.4EMISSIONS PROFILE Conducted electromagnetic emission profiles were generated throughout the tests and are included in the Test Report Data sheets. Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 14 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 3.5TEST CONFIGURATION The following diagrams illustrate the configuration of the EUT test and measurement equipment used for CISPR Radiated and Conducted Emissions Testing. EUT Power & I/O turntable 80 cm Radiated Emissions CISPR 11/22 3/10 meters IME woodtable Conducted Emissions CISPR 11 / 22 EUT AC Power 80 cm Preamp IME LISN 40 cm Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 15 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. 4.0 TEST EQUIPMENT The following equipment was utilized for this procedure. All measurement devices are calibrated annually, traceable to NIST. Please refer to Appendix C for calibration data. 4.1RADIATED EMISSIONS a)Spectrum Analyzer b)Receiver with CISPR Quasi-peak Adapter c)Power Isolation Transformers d)Biconilog antenna (25 MHz to 2 GHz) e)Antenna mast positioner, and controller f)Flush-mounted turntable, and controller 4.2CONDUCTED EMISSIONS a)Spectrum Analyzer b)Line Impedance Stabilization Network, 50 μ H c)CISPR Quasi-peak Adapter d)Power Isolation Transformer e)Personal Computer and EMI/EMC Software 4.3EMI SPECTRUM ANALYZER AND RECEIVER 4.3.1 Spectrum Analyzer Range 1 of 2 Start Frequency0.15 MHz Stop Frequency30 MHz TransducerLISN per CISPR 16 Quasi-Peak Bandwidth9 kHz Spectrum Analyzer BW10 kHz Video Bandwidth100 kHz Reference Level100 dB μ V Range 2 of 2 Start Frequency30 MHz Stop Frequency1000 MHz TransducerBiconilog Antenna Quasi-Peak Bandwidth120 kHz Spectrum Analyzer BW120 kHz Video Bandwidth1 MHz Reference Level100 dB μ V 4.3.2Receiver TransducerBiconilog Antenna Quasi-Peak Bandwidth120 kHz Measurement Window20 dB μ V Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e 16 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. Appendix A CLIENT SAMPLE DESCRIPTION New ! Repeat MPBT PersonnelDateProject/Work Order D. BECKFeb 7, 2001M34R2…

Text truncated - open the document above for the full version.

Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e30 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. TEST REPORT DATA Customer No: 208MPBT No.: M34R2460Test Date: Feb-15-2001 T EST C OMP ./P ART : SAMPLE 1758 T EST D ESCRIPTION : E.R.P L IMIT T EST C RITERIA : MIL-SPECS./STDS.:FCC PART 90, S ECTION 90.219Q UAL ! E NG .: F ACILITY : MPB T ECHNOLOGIES I NC . T EST E NGINEER : D. B ECK I NTERNAL : QA P ERSONNEL :O TH ER : T EMP .: 21 C H UMIDITY : 35 % T EST P ROCEDURES D ETAILS /D EVIATIONS P ASS F AIL I NIT The ERP proliferated by a system or sub-system shall not exceed the limits for the specifications as stated. 3Watts ! D.B The maximum power output(s) measured shall be within ! D.B + 2dB to 0dB of the manufacturer’s rating(s) of RF Pow er output. Limit = 5 Watts Limit = 36.99 dBm Max Power = 34.77 dBm / 3.0Watts ERP: Power AMP -Loss Cable +Gain An t ERP= 34.77dB-3.6dB+5dB= 36.17dBm or 4.14 Watts MPBT: D.B.C USTOMER : M.C.T. INC. 3 OF 6 Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e31 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST 301 T RUNCKING B OOSTER Sample #1758 Signal GenSpec ALosses* CalculatedGain FrequencyRF Out (dBm)Reading(dB)Out (dBm)(dB) (dBm) 80610-18.821.833.523.5 80710-18.621.833.723.7 813.510-20.3 21.8 3222 851-13-20 21.8 617.1 855-13-44.621.87.720.7 866-13-45.221.87.120.1 Note: *Losses Include Cable1 (0.9), Cable2 (0.9), Coupler (20), LOSSES= 21.8 Signal Gen RF Out taken at 1dB compression point The EUT complies with maximum power output requirements. Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e32 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. TEST REPORT DATA Customer No: 208MPBT No.: M34r2460Test Date: Feb 7, 2001 T EST C OMP ./P ART : S AMPLE 1758 T EST D ESCRIPTION : E MISSION L IMITATIONS F OR C ELLULAR – O CCUPIED B ANDWIDTH T EST C RITERIA : MIL-SPECS./STDS.:FCC P ART 90 S UBPART G, S ECTION 90.219Q UAL : ! E NG .: F ACILITY : MPB T ECHNOLOGIES I NC . T EST E NGINEER : D. B ECK I NTERNAL : QA P ERSONNEL :O TH ER : T EMP .: 21 C H UMIDITY : 20 % T EST P ROCEDURES D ETAILS /D EVIATIONS P ASS F AIL I NIT The EUT must meet the specifications of either (b) or (c) Mask (b)(f c – 45 kHz) to (f c – 20 kHz), 26 dB (f c + 20 kHz) to (f c + 45 kHz), 26 dB 0 to (f c – 45 kHz) , 60 or 43 + 10logP dB (f c + 45 kHz) to (2 x f c ), 60 or 43 + 10logP dB Mask (c)(f c – 20 kHz) to (f c – 12 kHz), 117log(f d /12)dB (f c + 12 kHz) to (f c + 20 kHz), 117log(f d /12) dB 0 to (f c – 20 kHz), 100log(f d /12) or 60 or 43 + 10logP dB (f c + 20 kHz) to (2 x f c ), 100log(f d /12) or 60 or 43+10logP dB Note: dB refers to attenuation from the mean power of the unmodulated carrier OR For equipment which does not perform modulation and only amplifies the RF signal, pass/fail criteria shall be based on the following: a) The 20 dB bandwidth of the modulated carrier shall be the same (input signal vs. output signal). ! D.B. b) The difference of the amplitudes between the input signal and the output signal shall remain consistent (+/- 0.5 dB), for the 20 dB bandwidth of the modulated carrier. ! D.B. MPBT: D.B ECK C USTOMER : M.C.T. INC. 4 OF 6 Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e33 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST 301 iDEN Construction Detail Sample 1758 Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e34 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 TDMA @ 806mhZ / 2-Tone f1=806 MHZ,f2=807 MHz with 20 dB external PAD Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e35 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 TDMA @ 821 / Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e36 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 TDMA @ 858.5 / Sig IN vs. Sig OUT Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e37 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Uplink 813.5 MHz Midband TDMA 13.5dB m input Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e38 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Peak Gain 23 dB Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e39 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Gain versus F requency B andpass

Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e40 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Input –8.1 dB m Output 12.4 dBm Gain output plus cable loss = 22.3 dB MID BAND Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e41 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 FCC 90.210 Part G Emission Mask G Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e42 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 iDEN Signaling Characteristics Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e43 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Two Tone Intermodulation P roducts Mid Passband Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e44 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Down Link P ass B and Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e45 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Down Link P ass B and 3 dB B and Width Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e46 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Down Link P ass B and 20 dB B and Width Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e47 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Up Link P ass B and Center Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e48 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Up Link P ass B and 3 dB Points Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e49 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 Up Link P ass B and 20 dB Points Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e50 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. TEST REPORT DATA Customer No: 208MPBT No.: M34R2460Test Date: Feb-, 2000 T EST C OMP ./P ART : S AMPLE 642 T EST D ESCRIPTION : E MISSION L IMITATIONS F OR C ELLULAR – SPURIOUS T EST C RITERIA : MIL-SPECS./STDS.:FCC P ART 90, S UB I , S ECTION 90.210, (G PART (3)) Q UAL : ! E NG .: F ACILITY : MPB T ECHNOLOGIES I NC . T EST E NGINEER : D. B ECK I NTERNAL : QA P ERSONNEL :O TH ER : T EMP .: 21 C H UMIDITY : 20 % T EST P ROCEDURES D ETAILS /D EVIATIONS P ASS F AIL I NIT Attenuated from Mean Power Output by at least ! D.B. 60 dB or 43+10logP dB=58.34 dB 2 nd Harmonic ! D.B. 3 rd Harmonic ! D.B. 4 th Harmonic ! D.B. 5 th Harmonic ! D.B. 6 th Harmonic ! D.B. 7 th Harmonic ! D.B. 8 th Harmonic ! D.B. 9 th Harmonic ! D.B. 10 th Harmonic ! D.B. MPBT: D. B ECK C USTOMER : M.C.T. INC. 5 OF 6 Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e51 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 FCC 90.210 Part G Emission Mask G Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e52 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 FCC 90.210 Part G Emission Mask G Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e53 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. BST301 Truncking Booster Sample 1758 FCC 90.210 Part G Emission Mask G Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e54 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. TEST REPORT DATA Customer No: 1129MPBT No.: M34R2460Test Date: February 8, 2001 T EST C OMP ./P ART : S AMPLE 642 T EST D ESCRIPTION : M AXIM UM P ERMISSIBLE E XPOSURE T EST C RITERIA : GENERAL EXPOSURE LIMITS MIL-SPECS./STDS.:FCC PART 1 S UBPART I, S ECTION 1.1310Q UAL ! E NG .: F ACILITY : MPB T ECHNOLOGIES I NC . T EST E NGINEER : D. B ECK I NTERNAL : QA P ERSONNEL :O TH ER : T EMP .: 15 C H UMIDITY : 20% T EST P ROCEDURES D ETAILS /D EVIATIONS P ASS F AIL I NIT FCC Part 1 Subpart I Frequency mW/cm² Section 1.1310 0.3 – 1.34 (100) 1.24 – 30…

Text truncated - open the document above for the full version.

Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e22 o f 63 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Inc. PEAK FREQUENCY [MHz] EMISSION LEVEL[dBuV] 301001000 20 40 60 80 100 FCC Part 15 RE Class A & B BST301 BOOSTER I/P=812.0 MHz @ 11dBm BOOSTER AND ANTENNA V-POL 9 Feb 2001 16:41:07EMI-TEST CLASS A (QP) CLASS B (QP) hp hp Radiated Emissions BST301 Truncking Booster Sample 1758 Vertical P olarization Test Sample: BST301 iDEN Motorola Truncking Booster Report No.: M34R2460 MP B Technologies Inc.February 26, 2001 M34R2197 Pag e23 o f 63 This report shall not be reproduced, exce…
