FCC ID: P3OS4517 External Photos FCC ID: P3OS4517 External Photos FCC ID: P3OS4517 External Photos FCC ID: P3OS4517

FCC ID: P3OS4517

FCC ID: P3OS4517 Internal Photos FCC ID: P3OS4517 Internal Photos

EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 1 of 22 Pages Straubing, 10 February 2004 T E S T - R E P O R T No. 55106-30770 for E51 (S4517B) Remote Control Transmitter Applicant: META System S. p. A. Test Specification: FCC Code of Federal Regulations, Part 15 Subpart C, Section 15.231 Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 2 of 22 Pages Table of Contents 1. Administrative Data....................................................................................3 2. Identification of Test Laboratory.................................................................4 3. Operation Mode of EUT.............................................................................5 4. Configuration..............................................................................................6 5. Measuring Methods...................................................................................7 5.1. Field Strength of Emissions, Prescans in a fully-anechoic room (30 MHz – 1 GHz).......................................................................8 5.2. Fieldstrength of Emissions, Measurement at Open Area Test Site (30 MHz – 1 GHz).................................................................9 5.3. Fieldstrength of Emissions above 1 GHz...........................................10 6. Photographs Taken During Testing.........................................................11 7. List of Measurements...............................................................................16 8. Referenced Regulations..........................................................................21 Charts taken during testing...............................................................................22 EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 3 of 22 Pages 1. Administrative Data Test item (EUT) Type designation E51 (S4517B) Serial number(s): 001 Type of equipment: Remote Control Transmitter Parts/accessories: FCC-ID: P3OS4517 Technical data Frequency range 433.05 – 434.79MHz Operational frequency 433.92 MHz Type of modulation 10K0A1D Pulse frequency N/A Pulse width N/A Antenna Integrated Power supply Applicant: (full address) META System S. p. A. Via Majakovskij, 10/b/c/d/e I-42100 Reggio Emilia Italy Contract identification: --- Contact person: Mr. Giorgio Maldini Manufacturer: META System S. p. A. Application details Receipt of EUT: 19. November 2003 Date of test: November – December 2003 Note: Responsible for testing: M. Steindl Responsible for test report: M. Steindl EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 4 of 22 Pages 2. Identification of Test Laboratory DETAILS OF THE TEST LABORATORY COMPANY NAME: Senton GmbH EMI/EMC Test Center ADDRESS: Aeussere Fruehlingsstrasse 45 D-94315 Straubing Germany LABORATORY ACCREDITATION: DAR-Registration No. TTI-P-G 062/94-01 FCC TEST SITE LISTING 90926 INDUSTRY CANADA TEST SITE REGISTRATION IC 3050 NAME FOR CONTACT PURPOSES: Mr. Johann Roidt TELEPHONE: (+49) (0)9421 5522-0 FAX: (+49) (0)9421 5522-99 PERSONNEL INVOLVED IN THIS TEST REPORT LABORATORY MANAGER: Mr. Johann Roidt RESPONSIBLE FOR TESTING: Mr. Martin Steindl RESPONSIBLE FOR TEST REPORT: Mr. Martin Steindl SUMMARY OF TEST RESULTS The tested sample complies with the requirements set forth in the FCC Code of Federal Regulations Part 15, Subpart C, Section 15.231 EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 5 of 22 Pages 3. Operation Mode of EUT While one button is pressed, the transmitter continuously sends the corresponding datagram. When the button is released, the transmitter stops working instantly. EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 6 of 22 Pages 4. Configuration Configuration of the EUT The EUT was fixted in a pneumatic system, which triggered the EUT continiously. Cables connected to the EUT Not applicable Peripheral devices connected to the EUT Not applicable EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 7 of 22 Pages 5. Measuring Methods EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 8 of 22 Pages 5.1. Field Strength of Emissions, Prescans in a fully-anechoic room (30 MHz – 1 GHz) Rules and Specifications: Sections 15.109 & 15.231 Guide: ANSI C63.4 1997 Measurement Procedure: Radiated emissions are measured over the frequency range from 30 MHz to 1 GHz. Measurements were made in both the horizontal and vertical planes of polarization in a fully anechoic room using a spectrum analyzer with the detector function set to peak and resolution bandwidth set to 100 kHz. All tests were performed at a test-distance of 3 meters. Hand-held or body-worn devices are rotated through three orthogonal axes to determine which attitude and configuration produces the highest emission relative to the limit and therefore shall be used for final testing. EUT Fully anechoic chamber 3 m test distance Spectrum Analyzer Test instruments used: No. Type Model Serial Number Manufacturer 01 Spectrum Analyzer FSP 30 100063 Rohde & Schwarz 113 Preamplifier CPA9231A 3393 Schaffner 141 Biconical antenna HK 116 829708/006 Rohde & Schwarz 143 Log. periodic antenna 3147 9112-1054 EMCO 003 Fully anechoic room No. 2 1452 Albatross Projects EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 9 of 22 Pages 5.2. Fieldstrength of Emissions, Measurement at Open Area Test Site (30 MHz – 1 GHz) Rules and Specifications: Sections 15.109 & 15.231 Guide: ANSI C63.4 1997 Measurement Procedure: Measurement Procedure: For final testing an open-area test-side was used. Radiated emissions are measured…

Text truncated - open the document above for the full version.

EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 12 of 22 Pages Test setup for radiated emission measurement (fully anechoic room) EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 13 of 22 Pages EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 14 of 22 Pages EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: P3OS4517 Test Report No.: 55106-30770 Page 15 of 22 Pages Test setup for radiated emission measurement (open-area test-side)
