P5L-FWTG32-1Fixed Wireless Terminal

Ericsson G32 / G36 Fixed Wireless Terminal for GSM/EDGE Mobile Networks User Guide E EN/LZT 151 235 R1D © Ericsson AB 2007 – All Rights Reserved Fixed Wireless Terminal: G32 & G36 3 Table of Contents Table of Contents .........................................3 Welcome ......................................................4 Fixed Wireless Terminal ................................6 Installation ....................................................9 Connecting Devices to the FWT..................16 Advanced Features.....................................24 PC Data Configurations ..............................34 Web-based Configuration ...........................56 Troubleshooting..........................................62 Technical Data............................................66 Accessories................................................69 Product Care and Safety ............................71 Warranty.....................................................75 Glossary .....................................................78 Index ..........................................................80 4 Fixed Wireless Terminal: G32 & G36 Welcome Welcome to the User Guide for the G32 / G36 Fixed Wireless Terminal. Important information: Some of the services described in this guide might not be supported by all networks. Please, contact your network operator for information on different network ser- vices operational in your GSM network. The latest version of this user guide can be downloaded from: http://www.ericsson.com/enterprise/library/manual.shtml Disposal of the product Your product should not be placed in municipal waste. Please check local regulations for disposal of electronic products. Copyright No part of this document may be reproduced without the written per- mission of the copyright owner. The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Ericsson shall have no liability for any error or damage of any kind result- ing from the use of this document. Fixed Wireless Terminal: G32 & G36 5 Warranty ERICSSON MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR- TICULAR PURPOSE. Ericsson shall not be liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance or use of this material. Declaration of Conformity Hereby, Ericsson Enterprise AB declares that this product is in confor- mity with the requirements and other relevant provisions of the European R&TTE directive 1999/5/EC. Details to be found at: http://ericsson.com/sdoc. FCC Statement This device complies with the limits for a Class B digital device, pursuant to part 15 and part 24 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residen- tial installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a par- ticular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter- ference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Changes or modifications not expressly approved by Ericsson could void the user’s authority to operate the equipment ICES Statement This Class B digital device complies with Canadian ICES-003. 6 Fixed Wireless Terminal: G32 & G36 Fixed Wireless Terminal Product Description The FWT is a flexible and cost-effective solution for connection to the wireless GSM network when there is no fixed line infrastructure or if you need additional telephone lines. The G36 can also be connected to a PBX so you can benefit from the Least Cost Routing (LCR) capabilities offered by most PBX vendors to optimize your costs by routing outgoing calls to mobile phones through the GSM network. The FWT allows automatic network searching between GSM 850/1900 or GSM 900/1800 frequencies, ensuring world wide coverage in the GSM networks. The FWT features the latest technology, which makes it perfect for eve- ryday communication: • Available in 2 dual dual-band GSM models (GSM 850/1900 or GSM 900/1800). • Telephone line providing high quality speech, G3 fax and up to V.90 data transmission. • EDGE (Enhanced Data Rates for GSM Evolution) is a 3G technology that delivers broadband-like speeds to GSM devices. • GPRS (General Packet Radio Service), which keeps you always connected and facilitates rapid transmission of data (ideal for e-mail and Internet browsing). • Embedded modem available over the USB port. • Battery back-up (optional). • PBX connectivity (only on the G36 model). Fixed Wireless Terminal: G32 & G36 7 Supplied Parts After unpacking, please check that the following parts and list of compo- nents are included: List of Components 1. FWT unit 2. Antenna 3. 4 x mounting screws 4. Power cable (USA, UK, EU or AUS) 5. AC/DC adapter 6. Wall mount bracket 7. Telephone and USB cable 8. Quick Guide and User Guide manuals 9. CD with USB driver 8 Fixed Wireless Terminal: G32 & G36 External Connector and Indicators Fixed Wireless Terminal: G32 & G36 9 Installation SIM Card Your network operator provides you with a SIM (Subscriber Identity Module) card. The SIM card contains information about your telephone number and the services included in your subscription. Preparing Your FWT You need to follow these steps before you install the FWT on the wall and finalize all connections.…

Text truncated - open the document above for the full version.

Limited Internal MARKING DRAWING 1 (2) Prepared (also subject responsible if other) No. EBC/FLEXSA (Titus Mavuso) 151 86-KRC 161 084/0 Uen Approved Checked Date Rev Reference EBC/FLEXSA (Bernd Kleyenstuber) 2008-01-08 F Type Label - KRC 161 084-089 Note 1 Note 2 Note 3 Note 4 Note 5 Note 6 Note 7 Note 8 Note 9 Note 10 G3xy 0889 INPUT: 7.5V = 0.8A TYPE: FWTG32 G H I J FCC ID: P5L-FWTG32-1 IC: 287X-FWTG32 KRC xxx xxxx/xRzz S/N: xxxxxxxxxx IMEI: xxxxxx-xx-xxxxxx-x Made in XXXyyWww Listed I.T.E. E226262 Notes: 1. Ericsson logotype according to 190 89-EN/LZT 108 901 2. CE 0889 logotype according to EN 60950-1 Notified body number (0889), according to the TTE Annex III certificate for the production plant. UL Symbol according to UL60950-1. Overall diameter of the UL mark is 4mm. Registered trademark® letter: “Helvetica Condensed Medium”. Rest of the lettering: ”Helvetica Condensed Black” 3. The WEEE symbol of the crossed out wheeled bin according to EN 61429 Amd. Marking of electrical and electronic equipment in accordance with article 11(2) of Directive 202/96/EC (WEEE). 4. TYPE: FWTG32 G H I J G = R-state identification of the software (CXP) module H = R-state identification of the hardware I = PCBA structure identification (ROA) J = R-state identification of the PCBA (ROA) Note: G, H, I and J fields according to 1/151 86-KRC 161 084 Limited Internal MARKING DRAWING 2 (2) Prepared (also subject responsible if other) No. EBC/FLEXSA (Titus Mavuso) 151 86-KRC 161 084/0 Uen Approved Checked Date Rev Reference EBC/FLEXSA (Bernd Kleyenstuber) 2008-01-08 F 5. FCC certification: FCC ID: P5L-FWTG32-1 6. Industry Canada: IC: 287X-FWTG32 7. Product number with revision state: KRC xxx xxx Rzz 8. Serial number xxxxxxxxxx 9. IMEI number: xxxxxx-xx-xxxxxx-x 10. Country of manufacture: Made in xxxxx Date of production: yyyy = year, ww = week All printing will be readable and permanent. Text should be centred. Material used for label marking is defined in product specification 1301-SVF 904 04 Printing dimensions: • Type size: min 1.1mm • Line spacing: min 1.0mm • Ericsson logo: min 2.25mm • CE symbol: min 5.0mm • Notified body (0889): same size as CE symbol

FWT G32 – top FWT G32 – bottom

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) Test Report Serial No: RFI/RPTE5/RP48122JD03A Supersedes Test Report Serial No: RFI/RPTE4/RP48122JD03A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: Tested By: Steven Wong Checked By: Tony Henriques Report Copy No: PDF01 Issue Date: 17 October 2007 Test Dates: 28 April to 12 May and 10 July 2006 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 2 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 3 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) Table of Contents 1. Client Information...............................................................................................................................4 2. Equipment Under Test (EUT)............................................................................................................5 3. Test Specification, Methods and Procedures..................................................................................8 4. Deviations from the Test Specification............................................................................................8 5. Operation of the EUT during Testing...............................................................................................9 6. Summary of Test Results..................................................................................................................10 7. Measurements, Examinations and Derived Results.......................................................................12 8. Measurement Uncertainty.................................................................................................................53 9. Measurement Methods......................................................................................................................54 Appendix 1. Test Equipment Used.......................................................................................................67 Appendix 2. Test Configuration Drawings........................................................................................... 69 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 4 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) 1. Client Information Company Name: Ericsson Enterprise AB Address: S-126 25 Stockholm Sweden Contact Name: Mr Sem Andersson RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 5 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: Flextronics Model Name or Number: Fixed Wireless Terminal G32a Serial Number: 632A2920000652 Hardware Version: 00 Software Version: 00 FCC ID Number: P5L-FWTG32 Country of Manufacture: South Africa Date of Receipt: 27 April 2006 Brand Name: FRIWO (AC Adapter) Model Name or Number: None stated Serial Number: 13 Country of Manufacture: Not stated Date of Receipt: 27 April 2006 2.2. Description of EUT The Fixed Wireless Terminal (FWT) provides fixed voice, data and fax services to areas with no fixed infrastructure in a cost efficient way, utilizing an existing GSM interface. 2.3. Modifications Incorporated in EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 6 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) 2.4. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Laptop PC Brand Name: Dell Model Name or Number: Latitude D610 Serial Number: PC370NT Cable Length and Type: USB cable, 1.5m Connected to Port: USB Port 2.5. Additional Information Related to Testing Power Supply Requirement: Nominal 110 V, 60 Hz AC Mains supply Internal backup supply of 6 V Intended Operating Environment: Within GSM coverage Equipment Category: Transceiver, GSM 850 / GSM 1900 Type of Unit: Base Station (fixed use) FCC Part 22 Transmit Frequency Range: 824.2 MHz to 848.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 824.2 Middle 190 836.6 Transmit Channels Tested: Top 251 848.8 Receive Frequency Range: 869.2 MHz to 893.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 869.2 Middle 190 881.6 Receive Channels Tested: Top 251 893.8 Maximum Power Output (ERP): 27.4 dBm RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE5/RP48122JD03A Page: 7 of 72 Issue Date: 17 October 2007 Test of: Ericsson Enterprise AB Fixed Wireless Terminal - G32a To: FCC Part 22: 2005 (Subpart H) and FCC Part 24: 2005 (Subpart E) Additional Information Related to Testing (Continued) FCC Part 24 Transmit Frequency Range: 1850.2 MHz to 1909.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bot…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 Test Report Serial No: RFI/RPTE1/RP49304JD07A This Test Report Is Issued Under The Authority Of Steve Flooks, Service Leader RPG: pp Brian Watson Checked By: Brian Watson Report Copy No: PDF01 Issue Date: 23 January 2008 Test Dates: 04 December 2007 to 13 December 2007 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 2 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 3 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 Table of Contents 1. Client Information............................................................................................................. 4 2. Equipment Under Test (EUT)..........................................................................................5 3. Test Specification, Methods and Procedures................................................................9 4. Deviations from the Test Specification........................................................................10 5. Operation of the EUT during Testing...........................................................................11 6. Summary of Test Results..............................................................................................12 7. Measurements, Examinations and Derived Results...................................................13 8. Measurement Uncertainty.............................................................................................43 9. Measurement Methods..................................................................................................44 Appendix 1. Test Equipment Used...................................................................................55 Appendix 2. Test Configuration Drawings.......................................................................57 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 4 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 1. Client Information 1.1. Client Address: Flextronics South Africa (Pty) Ltd 260 Surrey Avenue Ferndale Randburg 2194 South Africa Contact Name: Mr Bernd Kleyenstuber 1.2. Manufacturer Address: Ericsson AB S-126 25 Stockholm Sweden Contact Name: Sem Andersson RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 5 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Description: Fixed Wireless Terminal Brand Name: FWT G32a Model Name or Number: G32a Serial Number: TU8A305485 IMEI Number: 358211001172635 Hardware Version: R3A Software Version: R2A FCC ID Number: P5L-FWTG32-1 Country of Manufacture: Poland Date of Receipt: 04 December 2007 2.2. Accessories The following accessories were supplied with the EUT: Description: System Cable Brand Name: Ericsson Cable Length And Type: 2m twin core Connected to Port: System Connector 2.3. Description of EUT The Fixed Wireless Terminal (FWT) provides fixed voice, data and fax services to areas with no fixed infrastructure in a cost efficient way, utilizing an existing GSM infrastructure. 2.4. Modifications Incorporated in EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 6 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Antenna Brand Name: Ericsson Model Name or Number: Not Stated Serial Number: Not Stated Connected to Port: SMA Description: Telephone Cable Brand Name: Ericsson Model Name or Number: Not Stated Serial Number: Not Stated Cable Length and Type: 5m, RJ45 Connected to Port: RJ11 Description: AC/DC Adaptor Brand Name: Ericsson Model Name or Number: Not Stated Serial Number: Not Stated Connected to Port: DC power Description: Power Cord Brand Name: Ericsson Cable Length and Type: 1m, twin core Connected to Port: DC power Description: USB Cable Brand Name: Ericsson Cable Length and Type: 4.5m, USB Connected to Port: Mini USB RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/RPTE1/RP49304JD07A Page: 7 of 58 Issue Date: 23 January 2008 Test of: Ericsson AB FWT G32a To: FCC Part 22: 2007, FCC Part 24: 2007, RSS-132 Issue 2 September 2005, RSS-133 Issue 2 June 2005 & RSS-Gen Issue 2 June 2007 2.6. Additional Information Related to Testing Power Supply Requirement: Nominal 230/240 V, 50 Hz AC Mains Supply Nominal 110 V, 60 Hz AC Mains supply DC Supply of: 7.5 Vdc 1 A Intended Operating Environment: Within GSM coverage Equipment Cate…

Text truncated - open the document above for the full version.
