P6PSND331S331

Contents 1Copyright and Legal Information1 2Your phone3 3Getting started6 4Making a call10 5Answering a call12 6Calls list and contact list13 7Menu navigation16 8Messages17 9Internet menu25 10Sounds29 11Extras32 12Settings37 13Services40 14Troubleshooting42 15Safety Information46 16Regulatory Compliance and SAR Statements50 17End User License Agreement56 18Warranty Statement59 1 1 Copyright and Legal Inform ation 1 Copyright and Legal Information The wireless phone described in this manual is approved for use in GSM 850 and 1900 networks. Copyright Information Part number: 8E30-1F261-50000, Edition 1. Copyright Sendo 2004. All rights reserved. Printed in the Netherlands. SENDO is a registered trademark, or trademark, of Sendo International Ltd. and/or its affiliates. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Sendo is prohibited. T9 Text Input is a registered trademark of Tegic Communications. All rights reserved. T9 Text input is licensed under one or more of the following U.S. Patents: 5,818,437, 5,953,541, 5,945,928, 6,011,554 and additional patents are pending worldwide. DISCLAIMER The information contained in this user guide is written for the Sendo phone model 331. Sendo reserves the right to make changes and improvements to the products and any of the features of the products described in this document without prior notice THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. SENDO RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. UNDER NO CIRCUMSTANCES SHALL SENDO BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. Export Information This phone may be subject to export regulation of the United Kingdom and other countries. Diversion contrary to law is prohibited. You must comply with all applicable export laws, restrictions and regulations of the United Kingdom or foreign agencies or authorities, and shall not export, or transfer for the purpose of re-export, the phone or any part of the phone in violation of any applicable restrictions, laws or regulations, or without all necessary approvals. For Your Safety You should observe and follow the guidelines given in this manual for the safe and efficient use of your phone. Failure to comply with these guidelines and requirements may void your warranty and may invalidate any approvals given to the phone. Please see the Important Safety section of this manual before you use the phone. 2 1 Copyright and Legal Information Approved Accessories Warning Use only batteries, chargers and accessories approved by Sendo for use with this phone model. The use of any other types may invalidate any warranty applying to the phone, and may be dangerous. For availability of approved accessories, please check with your dealer or visit www.sendo.com. When you disconnect the power cord of any accessory, grasp and pull the plug, not the cord. Network Services A number of features included in this guide are called network services. They are services provided by wireless service providers. Before you can take advantage of any of these network services, you must subscribe to these service(s) from your home wireless service provider and obtain instructions for their use. Some of these network services may not be available when roaming on a network other than your home network. FCC/Industry Canada Notice This phone may cause TV or radio interference (for example, when using the phone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using the phone if such interference cannot be eliminated. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. 3 2 Your phone 2 Your phone Layout ! Wrist/neck strap loop – Used to attach a wrist strap or neck strap. "Earpiece #Display – Graphical indicators, menu options and other information are shown here. $Up and down keys – Used to scroll through menus and options. %Left soft key – This key performs the function immediately above it on the display &Right soft key (and Power key) – A long press of this key will switch the phone on and off. A short press of this key performs the function immediately above it on the display. 'Quick access key – The function of this key will vary depending on the model of your phone. It provides quick access to a certain function such as messaging. (Clear key – This erases text or takes you back to your previous step, depending on the context. A long press of this key takes you back to the main screen. )Charger/accessories connector - Insert the charger connector here. This connector is also used to connect appropriate accessories such as a hands-free kit. 4 2 Your phone Menus Send Read Chat Delete all Voice mail Broadcast Settings Languages Time/Date Alarm Screensaver Call handling Security Display Games Pictures Animations Menus Messages Settings Services Extras SIM Toolkit 1 2 3 4 5 6 1 2 3 4 5 6 Commands Network sel. Send number Cost/timers Divert Call waiting Available menu items and features will vary by model of phone and network operator. Please review your phone’s menu to determine the menu items and features available on your phone. Sounds Ringer More Ringtones Melodies Volume Key tones On/Off melody Vibrator Events 1 2 3 4 5 6 7 1 1 2 3 4 5 6 7 7 8 2 3 Home Bookmarks Settings Options 1 2 3 4 Internet 5 2 Your phone Symbol description Main screen Battery level - low *** Battery level - high Battery charging Signal strength - weak Signal strength - strong GPRS ser…

Text truncated - open the document above for the full version.

13 February 2004 Telecommunication Certification Body Radio Frequency Investigation Ltd. Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ England Subject: Certification Application FCC ID: P6PSND331 It is requested that the following information is to be held confidential on behalf of Sendo International Ltd. FCC Rules Part 0.459 fers. 8J60-1F000-03000-SCH_1.pdf One File 8 (Eight) Pages 8J60-1F000-03000-ASY_1.pdf One File 2 (Two) Pages SND331_S331_BOM_Rev_3.xls One File 1 (One) File SND331_S331 Block Diagram.doc One File 2 (Two) Pages Means for determining and stabilizing frequency.doc One File 3 (Three) Pages Detailed description of modulation system.doc One File 3 (Three) Pages SP11440.doc One File 21 (Twenty one) Pages The above files are confidential to Sendo. The above files give reference to the schematics, board layout and parts list of the product undergoing approval. Disclosure of this information could cause substantial competitive harm, due to the technical content of the files, as they explicitly detail the technical design of the product under approval. The above files are controlled internally by Sendo via appropriate document management procedures/control and are submitted in this instance, in confidence, for the purpose of obtaining product approval. None of the above files are available to the public in any way. The above material should remain confidential at all times. Yours sincerely Mike Roper Head of Validation & Approvals

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) Measurements were performed on the DASY4 System. Test Report Serial No: RFI/SARB2/RP45705JD03A RADIO FREQUENCY INVESTIGATION LTD. Calibration Data S.No. RFI/SARB2/RP45705JD03A Operations Department Page 2 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD. Calibration Data S.No. RFI/SARB2/RP45705JD03A Operations Department Page 3 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) Calibration Data This appendix contains the calibration data and certificates. RADIO FREQUENCY INVESTIGATION LTD. Calibration Data S.No. RFI/SARB2/RP45705JD03A Operations Department Page 4 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) Measurements were performed on the DASY4 System. Test Report Serial No: RFI/SARB2/RP45705JD03A Supersedes Test Report Serial No: RFI/SARB1/RP45705JD03A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Joe Lomako Tested By: Richelieu Quoi Release Version No: PDF01 Issue Date: 02 March 2004 Test Dates: 11 December 2003 It should be noted that the standard, OET Bulletin 65 Supplement C: (2001-01) is not listed on RFI’s current UKAS schedule and is therefore “not UKAS accredited”. This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RADIO FREQUENCY INVESTIGATION LTD. TEST REPORT S.No. RFI/SARB2/RP45705JD03A Operations Department Page 2 of 64 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD. TEST REPORT S.No. RFI/SARB2/RP45705JD03A Operations Department Page 3 of 64 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) Table of Contents 1. Client Information ............................................................................................................. 4 2. Equipment Under Test (EUT) ........................................................................................... 5 3. Test Specification, Methods And Procedures................................................................ 7 4. Deviations From The Test Specification......................................................................... 8 5. Operation Of The EUT During Testing ............................................................................ 9 6. Summary Of Test Results .............................................................................................. 10 7. SAR Measurement System ............................................................................................ 19 8. SAR Safety Limits ...........................................................................................................20 9. Details of SAR Evaluation .............................................................................................. 21 10. Evaluation Procedures ................................................................................................. 22 11. System Validation ......................................................................................................... 23 12. Simulated Tissues ........................................................................................................ 24 13. Tissue Parameters ........................................................................................................ 25 14. DASY4 Systems Specifications................................................................................... 26 15. Validation results ..........................................................................................................27 16. Measurement Uncertainty ........................................................................................... 31 Appendix 1. Test Equipment Used .................................................................................... 34 Appendix 2. SAR Distribution Scans ................................................................................ 35 Appendix 3. Test Configuration Photographs ................................................................. 37 Appendix 4. Calibration Data ............................................................................................. 39 Appendix 5. Photographs of EUT ...................................................................................... 41 Test Report Serial No: RFI/SARB2/RP45705JD03A Supersedes Test Report Serial No: RFI/SARB1/RP45705JD03A RADIO FREQUENCY INVESTIGATION LTD. TEST REPORT S.No. RFI/SARB2/RP45705JD03A Operations Department Page 4 of 64 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) 1. Client Information 1.1. Client Details Company Name: Sendo Ltd Address: Hatchford Brook Hatchford Way Sheldon Birmingham B26 3RZ Contact Name: Mr M Roper 1.2. Test Laboratory Company Name: Radio Frequency Investigation Ltd. Address: Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ. Contact Name: Mr J Lomako RADIO FREQUENCY INVESTIGATION LTD. TEST REPORT S.No. RFI/SARB2/RP45705JD03A Operations Department Page 5 of 64 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name Sendo Model Name or Number S331 FCC ID Number P6PSND331 IMEI Number 004400004474589 Battery Batch Number 8D48 – 1K140 – 20000 (No Individual Identification) Country Of Manufacture Netherlands Date Of Receipt 08 December 2003 Brand Name Sendo (Personal Hands…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ SAR DISTRIBUTION SCANS FROM RADIO FREQUENCY INVESTIGATION LTD. Test of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) Measurements were performed on the DASY4 System. Test Report Serial No: RFI/SARB2/RP45705JD03A RADIO FREQUENCY INVESTIGATION LTD. SAR Distribution Scans S.No. RFI/SARB2/RP45705JD03A Operations Department Page 2 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD. SAR Distribution Scans S.No. RFI/SARB2/RP45705JD03A Operations Department Page 3 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) SAR Distribution Scans This appendix contains SAR Distribution Scans. Plot Number Title 001 LHS_Tilt_660 002 LHS_Tilt_850 003 LHS_Touch_660 004 LHS_Touch_850 005 LHS_Worstcase_High_660 006 LHS_Worstcase_High_850 007 RHS_Right_512 008 RHS_Tilt_660 009 RHS_Tilt_850 010 RHS_Touch_660 011 RHS_Touch_810 012 RHS_Touch_850 013 System Performance Check_D850 014 System Performance Check_D1900 015 Validation 1900 016 Validation 850 RADIO FREQUENCY INVESTIGATION LTD. SAR Distribution Scans S.No. RFI/SARB2/RP45705JD03A Operations Department Page 4 of 4 Issue Date: 02 March 2004 Test Of: Sendo Ltd. S331 Dual Band Mobile Handset with PHF and Case Accessory To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. Page 1 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_1900-6.htm09/12/2003 Date: 09/12/03 Test Laboratory: RADIO FREQUENCY INVESTIGATION LTD. DUT: Sendo; Type: S331; Serial: 004400004474589 Communication System: DCS 1900; Frequency: 1879.8 MHz;Duty Cycle: 1:8.3 Medium: 1900MHz HSL (σ = 1.41613 mho/m, ε r = 39.8763, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1528; ConvF(4.8, 4.8, 4.8); Calibrated: 29/07/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn450; Calibrated: 19/05/2003 - Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 116 0 dB = 0.155mW/g Page 2 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_1900-6.htm09/12/2003 Tilt position - Middle/Area Scan 2 (81x111x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 8.59 V/m Power Drift = -0.4 dB Maximum value of SAR = 0.146 mW/g Tilt position - Middle/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.219 W/kg SAR(1 g) = 0.142 mW/g; SAR(10 g) = 0.0811 mW/g Reference Value = 8.59 V/m Power Drift = -0.4 dB Maximum value of SAR = 0.155 mW/g Page 1 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_850-2.htm08/12/2003 Date: 08/12/03 Test Laboratory: RADIO FREQUENCY INVESTIGATION LTD. DUT: Sendo; Type: S331; Serial: 004400004474589 Communication System: 850 MHz; Frequency: 836.4 MHz;Duty Cycle: 1:8.3 Medium: 900MHz HSL (σ = 0.886287 mho/m, ε r = 41.7172, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1528; ConvF(6.4, 6.4, 64); Calibrated: 29/07/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn450; Calibrated: 19/05/2003 - Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 116 Tilt position - Middle/Area Scan 2 (81x111x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 12.5 V/m Power Drift = -0.08 dB 0 dB = 0.158mW/g Page 2 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_850-2.htm08/12/2003 Maximum value of SAR = 0.164 mW/g Tilt position - Middle/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.205 W/kg SAR(1 g) = 0.149 mW/g; SAR(10 g) = 0.104 mW/g Reference Value = 12.5 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.157 mW/g Tilt position - Middle/Zoom Scan (7x7x7) (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.2 W/kg SAR(1 g) = 0.146 mW/g; SAR(10 g) = 0.1 mW/g Reference Value = 12.5 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.158 mW/g Page 1 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_1900-5.htm09/12/2003 Date: 09/12/03 Test Laboratory: RADIO FREQUENCY INVESTIGATION LTD. DUT: Sendo; Type: S331; Serial: 004400004474589 Communication System: DCS 1900; Frequency: 1879.8 MHz;Duty Cycle: 1:8.3 Medium: 1900MHz HSL (σ = 1.41613 mho/m, ε r = 39.8763, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1528; ConvF(4.8, 4.8, 4.8); Calibrated: 29/07/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn450; Calibrated: 19/05/2003 - Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 116 0 dB = 0.16mW/g Page 2 of 2 file://C:\Documents and Settings\Administrator\My Documents\45705_JD03_LHS_1900-5.htm09/12/2003 Touch position - Middle/Area Scan 2 (81x111x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 9.9 V/m Power Drift = -0.2 dB Maximum value of SAR = 0.204 mW/g Touch position - Middle/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.277 W/kg SAR(1 g) = 0.19 mW/g; SAR(10 g) = 0.112 mW/g Reference Value = 9.9 V/m Power Drift = -0.2 dB Maximum value of SAR = 0.207 mW/g Touch position - Middle/Zoom Scan (7…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 and 24 Test Report Serial No: RFI/MPTB1/RP45705JD02A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Tony Henriques Tested By: Steven Wong pp Release Version No: PDF01 Issue Date: 17 February 2004 Test Dates: 06 January 2004 to 22 January 2004 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 2 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 3 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT) .......................................................................................5 3. Test Specification, Methods And Procedures ............................................................9 4. Deviations From The Test Specification ...................................................................11 5. Operation Of The EUT During Testing ......................................................................12 6. Summary Of Test Results...........................................................................................14 7. Measurements, Examinations And Derived Results................................................16 8. Test Results FCC Part 22............................................................................................17 9. Measurement Methods – Part 22 ...............................................................................38 10. Test Results FCC Part 24..........................................................................................46 11. Measurement Methods – Part 24 .............................................................................72 12. Measurement Uncertainty ........................................................................................80 Appendix 1. Test Equipment Used ................................................................................81 Appendix 2. Test Configuration Drawings....................................................................83 RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 4 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 1. Client Information Company Name: Sendo Ltd. Address: Hatchford Brook Hatchford Way Sheldon Birmingham B26 3RZ Contact Name: Mr C Thornton RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 5 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: Sendo Model Name or Number: S331 Unique Type Identification: SND331 IMEI Number: 004400004474589 FCC ID Number: P6PSND331 Country of Manufacture: Czech Republic Date of Receipt: 06 January 2004 2.2. Description Of EUT The equipment under test is a dual band GSM 850/1900 MHz mobile telephone. 2.3. Modifications Incorporated In EUT During the course of testing the EUT was not modified. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 6 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 2.4. Additional Information Related To Testing Power Supply Requirement: Internal 3.8 V (nominal) lithium ion battery Declared Battery End Point Voltage 3.5 VDC (min) to 4.2 VDC (max) Power Supply Requirement: (AC Battery Charger) Nominal 110 V 60 Hz AC Mains supply Intended Operating Environment: Within GSM Network Coverage Equipment Category: Portable Type of Unit: Transceiver Interface Ports: Charger/Personal Handsfree (single port) Highest Fundamental Frequency 1909.8 MHz Highest Unintentionally Generated Frequency 1989.9 MHz RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB1/RP45705JD02A Operations Department Page 7 of 86 Issue Date: 17 February 2004 Test Of: Sendo Ltd. S331 GSM Mobile Telephone Handset To: FCC Part 22 & 24 Additional Information Related To Testing (Continued) GSM 850 Transmit Frequency Range 824 to 848 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 824.2 Middle 190 836.6 Transmit Channels Tested Top 251 848.8 GSM 850 Receive Frequency Range 869 to 894 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 869.2 Middle 190 881.6 Receive Channels Tested Top 251 893.8 Maximum Power Output (ERP) 26.6 dBm GSM 1900 Transmit Frequency Range 1850 to 1910 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1850.2 Middle 660 1879.8 Transmit Channels Tested Top 810 1909.8 GSM 1900 Receive Frequen…

Text truncated - open the document above for the full version.
