P87-ETR0001MP3 Player

1 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. External Photographs of EUT 2 / 2 ITN Test Lab. a Devision of ETRONICS Corporation.

1 / 1 ITN Test Lab. a Devision of ETRONICS Corporation. FCC ID Label Sample

1 / 3 ITN Test Lab. a Devision of ETRONICS Corporation. Internal photographs of EUT 32 MByte 32 MByte 2 / 3 ITN Test Lab. a Devision of ETRONICS Corporation. 64 MByte 64 MByte 3 / 3 ITN Test Lab. a Devision of ETRONICS Corporation. 128 MByte 128 MByte

1 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. Certificate of compliance Test report No.: ITN-02 008-EMC Applicant : Etronics Corporation. Applicant Address : 345-50, Gasan-Dong, Geumcheon-Gu, Seoul, Korea, 153-802 Product : MP3 Player FCC ID : P87-ETR0001 Model NO.: EAM-032 Receipt NO.: N/A Date of receipt Mar. 10, 2002 Date of Issue : April. 01, 2002 Testing Iocatlon : Etronics Corporation. 461, Tokjeong-Ri, Changan-Myun, Hwaseong-city, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 1992 Rule Parts : FCC Part 15 Subpart B Equipment Class : Class B Device Peripheral Test Result : The above mentioned preduct has been tested and passed. Prepared by : H.N.Choi Tested by : S.S.Oh / Engineer Approved By : J.W.Cho / Lab. Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : OK, Passed · Fall = falled · N/A = not applicable ☞ ＊ This test report is not permitted to copy partly without our permission. ＊ This test result Is dependent on only equipment to be used. ＊ This test result is based on single evaluation of one sample of the above mentioned. ＊ We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. 2 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. contents Contents 2 List of Tables 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Data 4 2.4 Test Environment 4 3. Descrioption of the tested samples 5 3.1 Rating and Physical characteristics 5 3.2 Submitted documents 5 4. Measurement conditions 6 4.1 Modes of operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 7 4.5 Uncertainty 7 5. Emission Test 8 5.1 Conducted Emissions 8 5.2 Radiated Emissions 10 ! List of Tables Table 1 List of test and measurement equioment 4 Table 2 Test Data, Conducted Emissions 11 Table 3 Test Data,Radiated Emissions (128Mbyte) 13 Table 4 Test Data,Radiated Emissions (64Mbyte) 13 Table 5 Test Data,Radiated Emissions (32Mbyte) 14 3 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Etronics Corp. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Etronics Corporation. 2.1 Location 461, Tokjeong-Ri, Changan-Myun, Hwaseong-city, Kyunggi-do, Korea, 445-944 The test site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. 4 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equlpment ·Conducted Emissions Kind of Equipment Type S/N Calibrated until EMI Reciver ESS 841432/010 08.2002 Artificial Mains Network 3825/2 8905-1506 08.2002 Conducted Cable N/A N/A 06.2002 ·Radiated Emissions Kind of Equipment Type S/N Calibrated EMI Reciver ESS 841432/010 08.2002 Spectrum Analyzer 8568B 3019A05457 08.2002 Amplifier 8447F 3113A04584 08.2002 Log Periodic Antenna UHALP9107 9107846 02.2003 Biconical Antenna BBA9106 91039103 02.2003 Open Site Cable N/A N/A 06.2002 Antenna Mast EMRT2014 N/A N/A Antenna & Turntable controller EMAT2015 N/A N/A 2.3 Test Date Date of Application : March. 12, 2002 Date of Test : March. 13, 2002 ∼ March. 31, 2002 2.4 Test Environment See each test item’s description 5 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 3. Description of the tested samples The EUT is MP3 player 3.1 Rating and Physical Characteristics Frequency response : 20Hz – 20kHz Memory size : 16/32/64/128(MB) Power source : 4.2V/570mA, built-in Li-polymer Battery Output power : 6.5mw + 6.5mw (1kHz,0dB/16Ω) Dimensions : 61(W)X61(H)X5(T)mm Weight : 48.5g (battlery included) Battery run time (fullcharged) : 6Hrs. 3.2 Submitted Documents N/A 6 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 4. Measurement Conditions The operating voltage of EUT is supplied by a MP3 player 4.1 Modes of Operation The EUT was in the follwing operation mode during all testing; The measurement was conducted under down-loading of data and PC operating Mode with interfaced by PC and USB cable. 4.2 List of Peripherals Descrlption Manufacturer Model Name Serial No. FCC ID Personal Computer Compaq Deskpro5120 3511N5 CNT75MDB65 Monitor Compaq 444T 607BA03BA398 BR8SM-1557 Keyboard Compaq RT101 120375-001B AQ6-MTN4XZ15 Mouse Compaq M-S34-6MD 141189-201 DZL210472 Adapter (for printer) Hewlett Packard C2182A 060795 N/A Printer Hewlett Packard C2164A ES64H130ZR B94C2164X 7 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 4.3 Type of Used Cables Description Length Type of shield Manufacturer Remark PC power cable 2.0m Non-Shield None Video interfacd cable 1.5m Shield None Keyboard interface cable 1.2m Non-Shield None Mouse interface cable 1.8m Non-Shield None Adapter cable 1.8m Non-Shield None For printer USB cable 1.8m Non-Shield None For EUT 4.4 Test Setup T he test setup photographs showed the external supply connections and interfaces. 4.5 Uncertainty 1) Rediated disturbance Uc (Combined standard Uncertainty) = ±3.45B Expanded uncertainty U = Kuc ∴ U = ± 6.9dB 2) Conducted disturbance Uc = ± 2.18dB U = Kuc – 2×Uc = ± 4.36B 8 / 14 ITN Test Lab. a Devision of ETRONICS Corporation. 5. Emission Test 5.1 Conducted Enissions Result : Passed The line-conducted facility is located inside a 3.0M ×4.0M ×7.0M shielded enclosure. The shidlding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 604-05. A1m×1.5m wooden table 80cm. High is placed 40cm away from the vertical wall and 1.5m away from the side wall of the shielded room. EMCO Model 3825/2 (10KHz-30MHz) 50ohm/50uH Lone-Impedance Stabilization Ne…

Text truncated - open the document above for the full version.

1 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. Test set up photos Photograph 1 : Setup for Conducted Emissions 2 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. Photograph 2 : Setup for Radiated Emissions
