P87-ETR0003MP3 Player

1. Notice 1 2. Products3 System requirements3 Identifying the parts4 3. Use of Audiocard6 Figures Description6 Functions7 Remote control10 Charging display when USB cable is connected11 4. S/W installation12 Installing the USB driver12 Installing the USB downloader management program17 5. Using the USB downloader management program18 Main window18 File download window19 Toolbar19 Details about toolbar20 Popup menu28 Error messages and recovery30 6. Troubleshooting31 7. FAQ32 8. Specification34 9. Accessories/Sold Separate35 10. Help36 1. Hardware requirements 2. Software requirements Audio card USB downloader Mode changes Play(Power on) / Pause / Power off For Windows 98 For Windows ME/ 2000 For Windows XP Check the installation of USB driver

Toolbar Details about toolbar 1) When downloading MP3 or WAVE file(s) 2) When downloading audio CD file(s) Popup menu Remark: The pre-encoded files has .brm file name extension. If you want to save these files later, the program will automatically skip a compression action although a compression mode is set. You cannot play the files on your PC or any other MP3 player. Q. Program does not work even though has been installed. Q. USB cannot be recognized Q. Audio card cannot be recognized Q. The memory capacity in the audio card is 0. Q. The file on the audio card cannot be recognize.

1 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. External Photographs of EUT 2 / 2 ITN Test Lab. a Devision of ETRONICS Corporation.

1 / 1 ITN Test Lab. a Devision of ETRONICS Corporation. FCC ID Sample Label & Location Information Labelling Requirements ?? 2.928 The Label shown shall permanently affixed at a conspicuous location On the device and be readily visible to the user at the time of purchase. This device complies with part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may nay not cause harmful interference, and (2) this device must accept any interference receiver, including interference that may cause undesired operation.

1 / 1 ITN Test Lab. a Devision of ETRONICS Corporation. FCC ID Label Sample

1 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. Internal photographs of EUT 2 / 2 ITN Test Lab. a Devision of ETRONICS Corporation.

1 STROBE 2 SERIAL_IN 3 CLOCK 4 Q1 5 Q2 6 Q3 7 Q4 8 GND 9 QS 10 Q'S 11 Q8 12 Q7 13 Q6 14 Q5 15 OE 16 VCC 1 STROBE 2 SERIAL_IN 3 CLOCK 4 Q1 5 Q2 6 Q3 7 Q4 8 GND 9 QS 10 Q'S 11 Q8 12 Q7 13 Q6 14 Q5 15 OE 16 VCC Static LCD Circuit 9 GND 10 EEGNT 11 EEREQ 12 RXF 13 VCC 14 TXE 15 WR 16 RD 8 USBDM 7 USBDP 6 3V3OUT 5 TEST 4 RESET 3 VCC 2 EEDATA 1 ESSK 18 D7 17 GND 19 D6 20 D5 21 D4 22 D3 23 D2 24 D1 25 D0 26 VCC 27 XTIN 28 XTOUT 29 AGND 30 AVCC 31 RCCLK 32 EECS 8 VCC 1 A0 2 A1 3 A2 4 VSS 5 SDA 6 SCL 7 TEST 1 IN 3 GND 2 IN USB Transceiver Circuit Internal USB Charger DECODER PLL 1 MCLK 2 PDN 3 BICK 4 SDATA 5 LRCK 6 MT0 7 MT1 8 DEM 9 MUTEEN 10 BOOST 11 CKS 12 DIF 13 AOUTR 14 AOUTL 15 NC 16 HPGND 17 HPVCC 18 TST3 19 VCOM 20 VREF 21 VSS 22 VDD 23 TST2 24 TST1 1 A0 8 VCC 7 TEST 6 SCL 5 SDA 4 VSS 3 A2 2 A1 1 IN 3 IN 2 GND 17 AIN4/PD4 18 AIN5/PD5 19 AIN6/PD6 20 AIN7/PD7 21 VDDA 22 VSSA 23 VDD_3 16 AIN3/PD3 15 AIN2/PD2 14 AIN1/PD1 13 AIN0/PD0 12 PB7 11 PB6 10 PB5 9 PB4 8 PB3 7 PB2 6 PB1 5 PB0 4 (HS)PE7 3 (HS)PE6 2 (HS)PE5 1 (HS)PE4 58 OSC2 59 OSC1 60 VDD_2 62 PE1/RDI 63 NC 64 NC 61 PE0/TDO 49 PA4(HS) 50 PA5(HS) 51 PA6(HS) 52 PA7(HS) 53 ISPSEL 54 RESET 55 NC 56 NC 57 VSS_2 48 VSS_1 46 PA3 47 VDD_1 33 VDD_0 34 VSS_0 35 PC0/OCMP2_B 36 PC1/OCMP1_B 37 PC2(HS)/ICAP2_B 38 PC3(HS)/ICAP1_B 39 PC4/MISO/ISPDATA 40 PC5/MOSI 41 PC6/SCK/ISPCLK 42 PC7/SS 43 PA0 44 PA1 45 PA2 24 VSS_3 25 MCO/PF0 26 BEEP/PF1 27 PF2 28 NC 29 OCMP1_A/PF4 30 NC 31 ICAP1_A/(HS)PF6 32 EXTCLK_A/(HS)PF7 37 VCC 1 NC 2 NC 3 NC 4 NC 5 NC 6 GND 7 R/B 8 RE 9 CE 10 NC 11 NC 12 VCC 13 VSS 14 NC 15 NC 16 CLE 17 ALE 19 WP 18 WE 20 NC 21 NC 22 NC 23 NC 24 NC 25 NC 26 NC 27 NC 28 NC 29 I/O0 30 I/O1 31 I/O2 32 I/O3 33 NC 34 NC 35 NC 36 VSS 38 NC 39 NC 40 NC 41 I/O4 42 I/O5 43 I/O6 44 I/O7 45 NC 46 NC 47 NC 48 NC 2 VSS_1 3 SDA 4 SCL 5 SDI 1 VDD_1 10 SCKT 11 LRCKT 12 OCLK 13 VSS_2 14 VDD_2 6 SCKR 7 BIT_EN 8 SRC_INT 9 SDO 28 OUT_CLK/DATA_REQ 27 VSS_5 26 RESET 25 SCAN_EN 24 TEST_EN 23 VDD_4 22 VSS_4 21 XTI 20 XTO 19 FILT 18 PVSS 17 PVDO 16 VDD_3 15 VSS_3 Low Bat. PWR BATTERY 5 VOUT 4 NC 3 CE 2 VIN 1 VSS Battery Pack 5 VOUT 4 NC 3 CE 2 VIN 1 VSS OSC 2 4

1 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. Certificate of compliance Test report No.: ITN-02 008-EMC Applicant : Etronics Corporation. Applicant Address : 345-50, Gasan-Dong, Geumcheon-Gu, Seoul, Korea, 153-802 Product : MP3 Player FCC ID : P87-ETR0003 Model NO.: SMP3 Receipt NO.: N/A Date of receipt June. 17, 2003 Date of Issue : June 03, 2003 Testing Iocatlon : Etronics Corporation. 461, Tokjeong-Ri, Changan-Myun, Hwaseong-city, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 1992 Rule Parts : FCC Part 15 Subpart B Equipment Class : Class B Device Peripheral Test Result : The above mentioned preduct has been tested and passed. Prepared by : H.N.Choi Tested by : S.S.Oh / Engineer Approved By : J.W.Cho / Lab. Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : OK, Passed Fall = falled N/A = not applicable This test report is not permitted to copy partly without our permission. This test result Is dependent on only equipment to be used. This test result is based on single evaluation of one sample of the above mentioned. We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. 2 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. contents Contents 2 List of Tables 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Data 4 2.4 Test Environment 4 3. Descrioption of the tested samples 5 3.1 Rating and Physical characteristics 5 3.2 Submitted documents 5 4. Measurement conditions 6 4.1 Modes of operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 7 4.5 Uncertainty 7 5. Emission Test 8 5.1 Conducted Emissions 8 5.2 Radiated Emissions 10 ÿ List of Tables Table 1 List of test and measurement equioment 4 Table 2 Test Data, Conducted Emissions 11 Table 3 Test Data,Radiated Emissions 13 3 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Etronics Corp. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Etronics Corporation. 2.1 Location 461, Tokjeong-Ri, Changan-Myun, Hwaseong-city, Kyunggi-do, Korea, 445-944 The test site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. 4 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equlpment Conducted Emissions Kind of Equipment Type S/N Calibrated until EMI Reciver ESS 841432/010 08.2002 Artificial Mains Network 3825/2 8905-1506 08.2002 Conducted Cable N/A N/A 06.2002 Radiated Emissions Kind of Equipment Type S/N Calibrated EMI Reciver ESS 841432/010 08.2002 Spectrum Analyzer 8568B 3019A05457 08.2002 Amplifier 8447F 3113A04584 08.2002 Log Periodic Antenna UHALP9107 9107846 02.2003 Biconical Antenna BBA9106 91039103 02.2003 Open Site Cable N/A N/A 06.2002 Antenna Mast EMRT2014 N/A N/A Antenna & Turntable controller EMAT2015 N/A N/A 2.3 Test Date Date of Application : May 24, 2003 Date of Test : May 24, 2003 June 16, 2003 2.4 Test Environment See each test item’s description 5 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 3. Description of the tested samples The EUT is MP3 player 3.1 Rating and Physical Characteristics Sampling rate : 8KHz – 50KHz Control CPU : 8 Bit CICS(16K ROM/512B RAM) DAC : IIS Audio format interface. 20Bit sigma delta Pwer consumption : 300mW (3.3VDC) Dimensions : 56(W)X91(H)X5(T)mm Weight : 49.0g (battlery included) Playing time (fullcharged) : 8Hour. Battery Specification : Li-Polymer:570mAh Charging time form USB : 0.5C(2hour) Control CPU : 8Bit CICS(16K ROM/512B RAM) Control CPU : 8Bit CICS(16K ROM/512B RAM) Memory : NAND Flash(16Mbyte-256Mbyte) Physical External : 9-Pin(3Pin-Analog/6Pin-Power & USB digital) 3.2 Submitted Documents N/A 6 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 4. Measurement Conditions The operating voltage of EUT is supplied by a MP3 player 4.1 Modes of Operation The EUT was in the follwing operation mode during all testing; The measurement was conducted under down-loading of data and PC operating Mode with interfaced by PC and USB cable. 4.2 List of Peripherals Descrlption Manufacturer Model Name Serial No. FCC ID Personal Computer SAMSUNG MA10 A32192DT400609 N/A Monitor SAMSUNG 155S N208H4NT422423 N/A Keyboard SAMSUNG SEM-DT35 3V002032 N/A Mouse Logitech M-S48a HCA20912082 JNZ201213 7 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 4.3 Type of Used Cables Description Length Type of shield Manufacturer Remark PC power cable 2.0m Non-Shield None Video interfacd cable 1.5m Shield None Keyboard interface cable 1.2m Non-Shield None Mouse interface cable 1.8m Non-Shield None 4.4 Test Setup The test setup photographs showed the external supply connections and interfaces. 4.5 Uncertainty 1) Rediated disturbance Uc (Combined standard Uncertainty) = 3.45B Expanded uncertainty U = Kuc U = 6.9dB 2) Conducted disturbance Uc = 2.18dB U = Kuc – 2Uc = 4.36B 8 / 13 ITN Test Lab. a Devision of ETRONICS Corporation. 5. Emission Test 5.1 Conducted Enissions Result : Passed The line-conducted facility is located inside a 3.0M 4.0M 7.0M shielded enclosure. The shidlding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 604-05. A1m1.5m wooden table 80cm. High is placed 40cm away from the vertical wall and 1.5m away from the side wall of the shielded room. EMCO Model 3825/2 (10KHz-30MHz) 50ohm/50uH Lone-Impedance Stabilization Networks(LISNs) are bonded to the shielded room. The EUT is powered from the EMCO LISN and the support equipment…

Text truncated - open the document above for the full version.

1 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. Test set up photos Photograph 1 : Setup for Conducted Emissions 2 / 2 ITN Test Lab. a Devision of ETRONICS Corporation. Photograph 2 : Setup for Radiated Emissions
