P9M-ATLASPhottix Atlas II 2.4 GHz Flash Trigger

Phottix Atlas II - 2.4 GHz Flash Trigger Instructions 2 7 9 1011 13 14 15 3 1 12 5 8 6 4 16 2 Parts 1. Power Switch 2. Transmit / Receive Mode Switch 3. DC Power Port 4. Channel Selector Switch 5. Test / Shutter Button 6. Flash Hot Shoe Connection 7. Camera Hot Shoe Connection 8. Locking Ring 9. Flash in/out Port 10. Flash out Port 11. Shutter Release Port 12. Antennae 13. Tripod Lug 14. Battery Cover 15. Battery Compartment 16. Status LED 3 1. The Phottix Atlas II hot shoe connection is designed to re speedlight-type ashes that are triggered by the center contact. Some ashes (by Nissin, Sigma, and other manufac- turers) may not be triggered by the center hot shoe contact but by specic secondary contacts. Please check your ash manual for specics. These ashes can be red by PC Sync cable if available. 2. The Atlas II is designed to work in Manual Exposure mode and has no TTL functions. 3. Transmit or receive mode must be set on the transceivers, the Atlas II will not do both at the same time. 4. The Phottix Atlas II is not compatible with previous Phottix Atlas series ash triggers. En INSTRUCTION MANUAL Tip:Turn o all devices – ashes/strobes, cameras, and Phottix Atlas II transceivers - when connecting and disconnecting devices. The Phottix Atlas II has limited compatibility with Phottix Odin, Strato II Multi 5-in-1 and Phottix Strato 4-in-1 Wireless Trigger Systems. 1. Phottix Odin TCUs set on Channel 1, 2, 3 or 4 and in any group will trigger the Phottix Atlas II set on Channel 1, 2, 3 or 4. Other Odin TCU functions will not work with the Atlas II. Using Odin TCUs in HSS mode may cause issues with ash sync when using the Atlas II. 2. Phottix Strato II Transmitter set on Channel 1, 2, 3 or 4 and in any group will trigger the Phottix Atlas II set on Channel 1, 2, 3 or 4. Please Note Compatibility 4 1. Press the battery cover in while pushing it away from the Atlas II. The battery cover will snap open. 2. Lift the battery cover. 3. Insert AA batteries as shown. 4. Close the battery cover and push the cover back into the locked position. 1. The Test / Shutter Button will test re remote For Remote Use See: Using the Atlas II as a wireless remote and Using the Atlas II as a wired remote below. 1. The Status LED on the front of the Phottix Atlas II will ash green when it is ready to 3. Phottix Strato transmitters will trigger the Atlas II on Channels 1 to 4. 4. The Atlas II will not trigger Strato II Multi or Odin receivers. 5. The Atlas II will trigger Strato receivers. Inserting Batteries Test / Shutter Button Status LED ashes/strobes or take a photo as a wireless remote when the Phottix Atlas II is set in Tx (transmit mode). 2. The Test / Shutter Button takes a photo when used as a wired remote and connected to a camera with a Phottix Accessory Cable. 3. To Test: Press the Test / Shutter Button – remote ashes connected to Phottix Atlas II transceivers set in Rx (receive mode) and on the same channel, will re. 5 En INSTRUCTION MANUAL 1. To turn on the Phottix Atlas II – move the power switch to the “ON” position. 2. To turn o the Phottix Atlas II – move the power switch to the “OFF” position. 1. Set the Transmit / Receive Mode Switch to Tx for transmit mode. This can be used on a camera hot shoe to trigger remote ashes or to take photos when using the Atlas II as a wire- Turning units on/o Setting Channels Setting Transmit or Receive Mode less remote shutter release. 2. Set the Transmit / Receive Mode Switch to Rx for receive mode. This can be used to trigger remote ashes or cameras when using the Atlas II as a wireless remote shutter release. 1. The Phottix Atlas II has four channel settings. 2. Move the Channel Selector Switch to 1, 2, 3, or 4 to select a channel. 3. Make sure all Phottix Atlas II transceivers, both on the camera and attached to ashes/strobes, are on the same channel. 4. Atlas II transceivers in Rx (receive) mode set to channels di erent from the channel set on the Atlas II set to Tx (transmit) mode will not re. transmit or receive signals. The LED will turn solid red when a signal is sent or received. 2. When the battery power is very low, the Status LED will ash green light every 0.5 seconds. Please change the batteries (see above). 6 1. Turn o the camera and Phottix Atlas II transceiver. 2. Slide the Atlas II transceiver into the camera’s hot shoe mount. 3. Turn the Atlas II locking ring until tight. 4. Set the Transmit / Receive Mode Switch on the Atlas II to Tx (transmit mode). 5. Turn on the Phottix Atlas II and the camera. 6. Set the camera and ash to Manual mode. 1. Turn o the ash and the Phottix Atlas II transceiver. Connecting to the camera hot shoe Connecting a ash to the Atlas II hot shoe 2. Slide the ash into the transceiver’ s hot shoe mount. 3. Lock the ash with the ash’ s locking mechanism. 4. Set the Transmit / Receive Mode Switch on the Atlas II to Rx (receive mode). 5. Turn on the Phottix Atlas II and ash. 6. Set the ash to Manual mode. * It is not unusual for the ash to discharge once after turning on the Phottix Atlas II. 1. Turn o the ash/strobe and the Phottix Atlas II transceiver. Connecting a ash or studio light by cable 7 2. Connect a compatible cable to the Phottix Atlas II Flash in/out port or Flash out port. 3. Connect the opposite end of the cable to the ash or studio strobe (A 6.3 mm adaptor is included for studio strobes with larger ports). 4. Set the Transmit / Receive Mode Switch on the Atlas II to Rx (receive mode). 5. Turn on the ash/strobe, Phottix Atlas II and camera. 6. Set the ash/strobe to Manual mode. * It is not unusual for the ash to discharge once after turning on the Phottix Atlas II. Connecting a local ash on a bracket (The Atlas II will trigger a local ash on a bracket and a remote manual ash/strobe equipped with a Phottix Atlas II) En INSTRUCTION MANUAL 1. Turn o the camera, ash/strobe and the Phottix Atlas II transceiver. 2. Mount a Phottix Atlas II in the camera’ s hot shoe port. 3. …

Text truncated - open the document above for the full version.

Phottix Atlas II - 2.4 GHz Flash Trigger Instructions 2 7 9 1011 13 14 15 3 1 12 5 8 6 4 16 2 Parts 1. Power Switch 2. Transmit / Receive Mode Switch 3. DC Power Port 4. Channel Selector Switch 5. Test / Shutter Button 6. Flash Hot Shoe Connection 7. Camera Hot Shoe Connection 8. Locking Ring 9. Flash in/out Port 10. Flash out Port 11. Shutter Release Port 12. Antennae 13. Tripod Lug 14. Battery Cover 15. Battery Compartment 16. Status LED 3 1. The Phottix Atlas II hot shoe connection is designed to re speedlight-type ashes that are triggered by the center contact. Some ashes (by Nissin, Sigma, and other manufac- turers) may not be triggered by the center hot shoe contact but by specic secondary contacts. Please check your ash manual for specics. These ashes can be red by PC Sync cable if available. 2. The Atlas II is designed to work in Manual Exposure mode and has no TTL functions. 3. Transmit or receive mode must be set on the transceivers, the Atlas II will not do both at the same time. 4. The Phottix Atlas II is not compatible with previous Phottix Atlas series ash triggers. En INSTRUCTION MANUAL Tip:Turn o all devices – ashes/strobes, cameras, and Phottix Atlas II transceivers - when connecting and disconnecting devices. The Phottix Atlas II has limited compatibility with Phottix Odin, Strato II Multi 5-in-1 and Phottix Strato 4-in-1 Wireless Trigger Systems. 1. Phottix Odin TCUs set on Channel 1, 2, 3 or 4 and in any group will trigger the Phottix Atlas II set on Channel 1, 2, 3 or 4. Other Odin TCU functions will not work with the Atlas II. Using Odin TCUs in HSS mode may cause issues with ash sync when using the Atlas II. 2. Phottix Strato II Transmitter set on Channel 1, 2, 3 or 4 and in any group will trigger the Phottix Atlas II set on Channel 1, 2, 3 or 4. Please Note Compatibility 4 1. Press the battery cover in while pushing it away from the Atlas II. The battery cover will snap open. 2. Lift the battery cover. 3. Insert AA batteries as shown. 4. Close the battery cover and push the cover back into the locked position. 1. The Test / Shutter Button will test re remote For Remote Use See: Using the Atlas II as a wireless remote and Using the Atlas II as a wired remote below. 1. The Status LED on the front of the Phottix Atlas II will ash green when it is ready to 3. Phottix Strato transmitters will trigger the Atlas II on Channels 1 to 4. 4. The Atlas II will not trigger Strato II Multi or Odin receivers. 5. The Atlas II will trigger Strato receivers. Inserting Batteries Test / Shutter Button Status LED ashes/strobes or take a photo as a wireless remote when the Phottix Atlas II is set in Tx (transmit mode). 2. The Test / Shutter Button takes a photo when used as a wired remote and connected to a camera with a Phottix Accessory Cable. 3. To Test: Press the Test / Shutter Button – remote ashes connected to Phottix Atlas II transceivers set in Rx (receive mode) and on the same channel, will re. 5 En INSTRUCTION MANUAL 1. To turn on the Phottix Atlas II – move the power switch to the “ON” position. 2. To turn o the Phottix Atlas II – move the power switch to the “OFF” position. 1. Set the Transmit / Receive Mode Switch to Tx for transmit mode. This can be used on a camera hot shoe to trigger remote ashes or to take photos when using the Atlas II as a wire- Turning units on/o Setting Channels Setting Transmit or Receive Mode less remote shutter release. 2. Set the Transmit / Receive Mode Switch to Rx for receive mode. This can be used to trigger remote ashes or cameras when using the Atlas II as a wireless remote shutter release. 1. The Phottix Atlas II has four channel settings. 2. Move the Channel Selector Switch to 1, 2, 3, or 4 to select a channel. 3. Make sure all Phottix Atlas II transceivers, both on the camera and attached to ashes/strobes, are on the same channel. 4. Atlas II transceivers in Rx (receive) mode set to channels di erent from the channel set on the Atlas II set to Tx (transmit) mode will not re. transmit or receive signals. The LED will turn solid red when a signal is sent or received. 2. When the battery power is very low, the Status LED will ash green light every 0.5 seconds. Please change the batteries (see above). 6 1. Turn o the camera and Phottix Atlas II transceiver. 2. Slide the Atlas II transceiver into the camera’s hot shoe mount. 3. Turn the Atlas II locking ring until tight. 4. Set the Transmit / Receive Mode Switch on the Atlas II to Tx (transmit mode). 5. Turn on the Phottix Atlas II and the camera. 6. Set the camera and ash to Manual mode. 1. Turn o the ash and the Phottix Atlas II transceiver. Connecting to the camera hot shoe Connecting a ash to the Atlas II hot shoe 2. Slide the ash into the transceiver’ s hot shoe mount. 3. Lock the ash with the ash’ s locking mechanism. 4. Set the Transmit / Receive Mode Switch on the Atlas II to Rx (receive mode). 5. Turn on the Phottix Atlas II and ash. 6. Set the ash to Manual mode. * It is not unusual for the ash to discharge once after turning on the Phottix Atlas II. 1. Turn o the ash/strobe and the Phottix Atlas II transceiver. Connecting a ash or studio light by cable 7 2. Connect a compatible cable to the Phottix Atlas II Flash in/out port or Flash out port. 3. Connect the opposite end of the cable to the ash or studio strobe (A 6.3 mm adaptor is included for studio strobes with larger ports). 4. Set the Transmit / Receive Mode Switch on the Atlas II to Rx (receive mode). 5. Turn on the ash/strobe, Phottix Atlas II and camera. 6. Set the ash/strobe to Manual mode. * It is not unusual for the ash to discharge once after turning on the Phottix Atlas II. Connecting a local ash on a bracket (The Atlas II will trigger a local ash on a bracket and a remote manual ash/strobe equipped with a Phottix Atlas II) En INSTRUCTION MANUAL 1. Turn o the camera, ash/strobe and the Phottix Atlas II transceiver. 2. Mount a Phottix Atlas II in the camera’ s hot shoe port. 3. …

Text truncated - open the document above for the full version.

Phottix (HK) Ltd. PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 08.08.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Phottix Atlas II 2.4 GHz Flash Trigger Model Name Atlas II Brand Name We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Mr. Laurence Position General manager Company Name Phottix (HK) Ltd. Address 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Tel +852 25750739 Fax +852 25728207 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Phottix (HK) Ltd. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Phottix (HK) Ltd. FCC ID : P9M-ATLAS FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Mr. Laurence Position General manager Company Name Phottix (HK) Ltd. Address 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Tel +852 25750739 Fax +852 25728207 Email [email protected]

Phottix (HK) Ltd. PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 08.08.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Phottix Atlas II 2.4 GHz Flash Trigger Model Name Atlas II Brand Name We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Mr. Laurence Position General manager Company Name Phottix (HK) Ltd. Address 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Tel +852 25750739 Fax +852 25728207 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Phottix (HK) Ltd. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Phottix (HK) Ltd. FCC ID : P9M-ATLAS FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Mr. Laurence Position General manager Company Name Phottix (HK) Ltd. Address 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Tel +852 25750739 Fax +852 25728207 Email [email protected]

Label location 20mm 15mm FCC ID: P9M-ATLAS

Label location 20mm 15mm FCC ID: P9M-ATLAS

ANTENNA

ANTENNA

Shenzhen Certification Technology Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen 518126, P.R. China. FCC ID: P9M-ATLAS Page 1 of 30 TEST REPORT FCC ID: P9M-ATLAS Applicant : Phottix (HK) Ltd. Address : 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Equipment under Test (EUT): Name :Phottix Atlas II 2.4 GHz Flash Trigger Model : Atlas II Standards : FCC PART 15, SUBPART C : 2011 (Section 15.249) Report No. : STE120725952 Date of Test : August 1-5, 2012 Date of Issue : August 6, 2012 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: STE120725952 FCCID: P9M-ATLAS Page 2 of 30 TABLE OF CONTENT Description Page 1 General Information--------------------------------------------------------------------------------------3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility-----------------------------------------------------------------------4 2 EMC Equipment List-----------------------------------------------------------------------------------4 3 Test Procedure---------------------------------------------------------------------------------------------5 4 Summary of Measurement---------------------------------------------------------------------------6 4.1 Summary of test result-----------------------------------------------------------------------------6 4.2 Test mode--------------------------------------------------------------------------------------------6 5 POWER LINE CONDUCTED EMISSION---------------------------------------------------------8 5.1 Conducted Emission Limits(15.209&249)--------------------------------------------------8 5.2 Test Setup------------------------------------------------------------------------------------------8 5.3 Test Procedure------------------------------------------------------------------------------------9 5.4 Test Results----------------------------------------------------------------------------------------9 6 Radiation Emission----------------------------------------------------------------------------------12 6.1 Radiation Emission Limits(15.209&249 (a))----------------------------------------------12 6.2 Test Setup-----------------------------------------------------------------------------------------13 6.3 Test Procedure-----------------------------------------------------------------------------------14 6.4 Test Equipment Setting For emission test.-----------------------------------------------15 6.5 Test Condition------------------------------------------------------------------------------------15 6.6 Test Result----------------------------------------------------------------------------------------15 7 Occupied bandwidth---------------------------------------------------------------------------------19 7.1 Test limit-------------------------------------------------------------------------------------------19 7.2 Method of measurement-----------------------------------------------------------------------19 7.3 Test Setup-----------------------------------------------------------------------------------------19 7.4 Test Results---------------------------------------------------------------------------------------19 8 Band Edge Check-------------------------------------------------------------------------------------21 8.1 Test limit-------------------------------------------------------------------------------------------21 8.2 Test Procedure-----------------------------------------------------------------------------------21 8.3 Test Setup-----------------------------------------------------------------------------------------21 8.4 Test Result----------------------------------------------------------------------------------------21 9 Antenna Requirement-------------------------------------------------------------------------------22 9.1 Standard Requirement-------------------------------------------------------------------------22 9.2 Antenna Connected Construction-----------------------------------------------------------22 9.3 Result-----------------------------------------------------------------------------------------------22 10 Photographs of Test Setup------------------------------------------------------------------------23 11 Photographs of EUT---------------------------------------------------------------------------------26 Report No.: STE120725952 FCCID: P9M-ATLAS Page 3 of 30 1 General Information 1.1 Description of Device (EUT) Trade Name : Phottix EUT : Phottix Atlas II 2.4 GHz Flash Trigger Model No. : Atlas II Type of Antenna : Integral Antenna Antenna Specification : 0 dBi Operation Frequency : 2464MHz Channel number : 1 (4 channels of the same frequency, just not the same encoding) Modulation type : GFSK Power Supply : DC 3V form battery or DC 5V form adapter adapter : Manufacturer: Phottix (HK) Ltd. Model:TKY-003-0510-120 Applicant : Phottix (HK) Ltd. Address : 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Manufacturer : Phottix (HK) Ltd. Address : 10/F Block A, Yip Fat Factory Building, Phase 1, 77 Hoi Yuen Rd, Kwun Tong, Kln, Hong Kong Report…

Text truncated - open the document above for the full version.

Photos of Radiated emission Photos of Conducted emission

Photos of Radiated emission Photos of Conducted emission
