PAGTR-002Transmitter

REMOTE CONTROLLER RECEIVER MODEL -- RC-001 (FCC ID:PAGRC-001) -- RC-002 (FCC ID:PAGRC-001) TRANSMITTER MODEL -- TR-002A (FCC ID:PAGTR-002) TR-002B (FCC ID:PAGTR-002) TR-002C (FCC ID:PAGTR-002) TR-002D (FCC ID:PAGTR-002) FEDERAL COMMUNICATIONS COMMISSION This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. SPECIFICATIONS Frequency --- 315MHz Transmitter Power Input --- DC 12V Alkaline Battery (size 23A) Receiver Power Input --- AC 125V Electrical Outlet Receiver Power Output --- 13 Amps / 125 Volts Resistive 13 Amps / 125 Volts General Purpose 1000W Tungsten INSTALLATION 1. Mount the receiver on wall near grounded electrical outlet. Nail or screw head must extend at least 3/16” out from wall. Hang the receiver from slot on back of unit onto nail or screw. Plug the power supply cord of the receiver into outlet. Then plug device cord into the receptacle at bottom of the receiver. 2. Install battery into the transmitter. OPERATION 1. Press ON button on the transmitter to turn the receiver ON. 2. Press OFF button on the transmitter to turn the receiver OFF.

Model: TR-002A; TR-002B; TR-002C; TR-002D FCC ID: PAGTR-002

FCC ID : PAGTR-002 FRONT SIDE OF EUT Number 1 152202-01.jpg FCC ID : PAGTR-002 REAR SIDE OF EUT Number 2 152202-02.jpg

FCC ID : PAGTR-002 Mechanical Construction (Front) Number 1 152202-03.jpg FCC ID : PAGTR-002 Mechanical Construction (Rear) Number 2 152202-11.jpg FCC ID : PAGTR-002 Mechanical Construction Number 3 152202-04.jpg FCC ID : PAGTR-002 Front side of Main Board Number 4 152202-05.jpg FCC ID : PAGTR-002 Rear side of Main Board Number 5 152202-06.jpg FCC ID : PAGTR-002 Mechanical Construction (Front) Number 6 152202-07.jpg FCC ID : PAGTR-002 Mechanical Construction (Rear) Number 7 1 52202-08.jpg FCC ID : PAGTR-002 Mechanical Construction (Front) Number8 152202-9.jpg FCC ID : PAGTR-002 Mechanical Construction (Rear) Number9 152202-10.jpg FCC ID : PAGTR-002 Mechanical Construction (Front) Number10 152202-13.jpg FCC ID : PAGTR-002 Mechanical Construction (Rear) Number11 152202-14.jpg

Product : Transmitter FCC ID : PAGTR-002 Mounting Type : Portable Input Power : DC 12V Battery Models : 1. TR-002A ( 1 to 2 Transmitter ) There are the following four buttons on the TR-002A to turn on or turn off two different receivers. 1.1 channel 1 on 1.2 channel 1 off 1.3 channel 2 on 1.4 channel 2 off 2. TR-002B ( 1 to 3 Transmitter ) There are the following six buttons on the TR-002B to turn on or turn off three different receivers. 2.1 channel 1 on 2.2 channel 1 off 2.3 channel 2 on 2.4 channel 2 off 2.5 channel 3 on 2.6 channel 3 off 3. TR-002C ( 1 to 4 Transmitter ) There are the following eight buttons on the TR-002C to turn on or turn off four different receivers. 3.1 channel 1 on 3.2 channel 1 off 3.3 channel 2 on 3.4 channel 2 off 3.5 channel 3 on 3.6 channel 3 off 3.7 channel 4 on 3.8 channel 4 off 4. TR-002D ( 1 to 1 Transmitter ) There are the following two buttons on the TR-002D to turn on or turn off one receiver. 4.1 channel 1 on 4.2 channel 1 off Functional Description : 1. Encoding As illustrated in Figure 1, there are 12 pins (A0 – A7, AD8 – AD11) on IC that can be hard wired to VDD or ground. The bits A0 – A7 forms a CODE to select one of 256 functions, while the bits AD8 – AD11 forms a DATA to select one of 16 functions. These 12 pins are connected to buttons and preset at the factory. Once a button is pressed, an unique combination of CODE and DATA intended to turn on or turn off a particular channel is read into IC. 2. Resonance The press of button also activates the resonance circuitry inside IC to generate a 315 MHz signal. 3. Wave Carrying The encoded CODE and DATA is integrated into 315 MHz signal in the form of wave carrier. 4. Transmission The encoded CODE and DATA carried on 315 MHz signal is transmitted sequentially by transmitter circuitry. The same CODE and DATA will be transmitted four times to ensure the effective receipt by receiver. Figure 2 is a functional block diagram Figure 3 is a transmission flowchart. No Yes No Yes Power on Standby mode Transmission enabled? Code word transmitted continuously Transmission still enabled? Code word transmitted continuously

FCC ID: LWNF21-6D FCC ID: PAGTR-002 FCC ID: PAGTR-002 FCC ID: PAGTR-002 FCC ID: PAGTR-002

FCC TEST REPORT Report No. : F152202 SPORTON International Inc. FCC ID : PAGTR-002 TEL : 886-2-2696-2468 Page No. : 1 of 30 FAX : 886-2-2696-2255 Issued Date : May 28, 2001 FCC TEST REPORT for 47 CFR, Part 15, Subpart C Equipment : TRANSMITTER Model No. : TR-002A, TR-002B, TR-002C, TR-002D FCC ID : PAGTR-002 Filing Type : Certification Applicant : KAB ENTERPRISE CO., LTD. 21-1Fl., No. 33, Sec. 1, Min Sheng Rd., Panchiao City, Taipei Hsien, Taiwan, 220 R.O.C. ??The test result refers exclusively to the test presented test model / sample. ??Without the written authorization of the test lab., the Test Report may not be copied. ??Certificate or Test Report must not be used by the applicant to claim the product in this test report endorsement by NVLAP or any agency of U.S. government. SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No. : F152202 SPORTON International Inc. FCC ID : PAGTR-002 TEL : 886-2-2696-2468 Page No. : 2 of 30 FAX : 886-2-2696-2255 Issued Date : May 28, 2001 Table of Contents CERTIFICATE OF COMPLIANCE..............................................................................................................3 1. General Description of Equipment under Test......................................................................................4 1.1. Applicant.......................................................................................................................................................................................4 1.2. Manufacturer.................................................................................................................................................................................4 1.3. Basic Description of Equipment under Test..................................................................................................................................4 1.4. Feature of Equipment under Test.................................................................................................................................................4 2. Test Configuration of Equipment under Test........................................................................................5 2.1. Test Manner..................................................................................................................................................................................5 2.2. Description of Test System...........................................................................................................................................................6 2.3. Connection Diagram of Test System.............................................................................................................................................6 2.4. A plot shows the EUT meet the requirement of 15.231(c).............................................................................................................7 3. Test Software........................................................................................................................................9 4. General Information of Test................................................................................................................10 4.1. Test Facility.................................................................................................................................................................................10 4.2. Standard for Methods of Measurement.......................................................................................................................................10 4.3. Test in Compliance with..............................................................................................................................................................10 4.4. Frequency Range Investigated...................................................................................................................................................10 4.5. Test Distance..............................................................................................................................................................................10 5. Test of Conducted Powerline..............................................................................................................11 6. Test of Radiated Emission..................................................................................................................12 6.1. Major Measuring Instruments......................................................................................................................................................12 6.2. Test Procedures..........................................................................................................................................................................13 6.3. Typical Test Setup Layout of Radiated Emission........................................................................................................................14 6.4. Test Result of Radiated Emission...............................................................................................................................................15 7. Antenna Factor & Cable Loss.............................................................................................................27 8. EMI Suppression Component List......................................................................................................28 9. List of Measuring Equipments Used...................................................................................................29 10. Uncertainty of Test Site....................................................................................................................30 Appendix A. Photographs of EUT..................................................................................................A1 ~ A6 FCC TEST REPORT Report No. : F152202 SPORTON Interna…

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No. : F152202 SPORTON International Inc. FCC ID : PAGTR-002 TEL : 886-2-2696-2468 Page No. : 1 of 1 FAX : 886-2-2696-2255 Issued Date : May 28, 2001 1.1. Photographs of Radiated Emission Test Configuration ??The photographs show the configuration that generates the maximum emission. FRONT VIEW REAR VIEW
