PCO-WMT-1000IWiViEW

WiViEW WMT-1000I WMT-1000O USER’S MANUAL Version 1.0 Notice This device has been approved by FCC for a home appliance and is suitable for all residential areas. z © 2006 Copyright SIGMACOM CO., LTD. All right reserved z All trademarks are the properties of their respective owner. z The information contained herein is subjected to change without notice. 1 WMT-1000O Specification ■ Power Supply Adaptor IN: 100-240V~50/60Hz 0.5A OUT: 12V, DC 1.25A ■ Power Consumption : 2.5mW/MHz ■ Digital Modulation : OFDM ■ Channel 3Channel (5180MHz, 5200MHz, 5220MHz), BAND WIDTH : 20MHz ■ VIDEO OUTPUT : Composite, S-Video, Component (480i) ■ AUDIO OUTPUT : 2-Channel Stereo ■ FRONT LED Lamps : Power (Red), Signal (Green) ■ Physical Specification Size (W * H * D) : 42 * 230 * 195 (Without Stand) 85 * 240 * 195 (With Stand) Operating Temperature : -10°C ~ +50°C Storage Temperature : -10°C ~ +70°C 2 WMT-1000I Specification ■ Power Supply Adaptor IN: 100-240V~50/60Hz 0.5A OUT: 12V, DC 1.25A ■ Power Consumption : 2.5mW/MHz ■ Digital Modulation : OFDM ■ Channel 3Channel (5180MHz, 5200MHz, 5220MHz), BAND WIDTH : 20MHz ■ VIDEO INPUT : Composite, S-Video, Component (480i, 480p, 720p, 1080i) ■ AUDIO INPUT : 2-Channel Stereo ■ PC Interface : USB ■ 2-Input IR Blaster ■ FRONT LED Lamps : Power (Red), Signal (Green) ■ Physical Specification Size (W * H * D) : 42 * 230 * 195 (Without Stand), 85 * 240 * 195 (With Stand) Operating Temperature : -10°C ~ +50°C Storage Temperature : -10°C ~ +70°C 3 Overview of WiVIEW Safety notice and Warning FCC notice to users and product statements THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This appliance and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. 4 European CE notice to users and product statements This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC). Hereby, Sigmacom Co., Ltd declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For further information, please contact http://www.sigmacom.co.kr/eng/main/ Operating Matrix 1. Connect video-out of PC or VIDEO out-put device(DVD player, DVR) to video-in of the WMT-1000I(server) with cable. 2. Connect video-in of TV or other displays to image-out of the WMT-1000O(client) with cable. 3. WMT-1000I encode a video data into MPEG2 and transmit encoded data to WMT000O in the band of 5180khz,5200khz and 5220khz in 802.11a protocol. 4. After WMT-1000O receives the encoded data, WMT-1000O decode the data into analog signal and transmits to TV or other displays. 5. According PC connection, remotecontrol transmits PC control-signal to WMT- 1000O and WMT-1000O transmit the signal to WMT-1000I by wireless and WMT-10001 transmits the signal to PC by USB port. Contents Overview of Wi-VIEW Safety notices and warnings Checking Wi-VIEW package Each part description Using remote control - Controlling Wi-VIEW - Controlling SMC(Sigma Multimedia Center) - Installing batteries Placing Wi-VIEW on the stand 5 Hardware Installation Connecting Wi-VIEW Connecting to WMT-1000I of Wi-VIEW - Connecting satellite receiver or cable TV receiver - Connecting VCR - Connecting DVD Player or Game console - Using the remote control of external video device Connecting to WMT-1000O of Wi-VIEW - Connecting analog TV set - Connecting HDTV Ready set Main functions Using the remote control of menu screen Starting Wi-VIEW Setting Input Setting Output Adjusting image quality Setting OSD language Additional functions - Checking Wi-VIEW’s information - Setting screen saver - checking network status Using SMC (Sigma Multimedia Center) Basic screen content Description of each button of the remote control SMC function 1) TV - Running TV program - Setting antenna - Setting TV channel (registered/preferred) - EPG(Electronic Programming Guide) - Reservation - Multi-screen 2) Music 6 3) Picture 4) Video 5) DVD 6) Radio 7) Setup - Standard setting - TV setting - File setting - Multimedia setting 7 Accessories Thank you for purchasing the Wi-VIEW. When removing the package, make sure that the following contents are included. If you find any missing part, please contact our near dealer or distributor. Holder – 2EA WMT-1000I - 1 EA Remote control WMT-1000O - 1 EA Sound(2RCA) cable Power Adaptor - 2EA IR Blaster cable Composite (3 RCA) cabl…

Text truncated - open the document above for the full version.

55 44 33 22 11 D D C C B B A A RF_Module Matrix II DDR 8M X 16 16MByte SAA7136 Audio/VideoDecoder Wireless LAN IntegratedMedium Access Controllerwith Baseband Processor Power 1Power 1Power 1Power 1 3.3V1.8V 5V 2.5V External DCPOWER 12V 3.3V1.8V5V2.5V 24.576MHzx-tal 27MHzOSC 40MHzOSC 2.5V 3.3V 2.5V 5V WMT-1000I Diagram Antenna YPbPr A2-R A2-L Comp S-Video USB IR Blaster XCode II-N Video Network Processor DDR 8M X 16 16MByte 3.3V2.5V1.8V 3.3V2.5V1.8V IR Blaster Serial EEPROMM25P80Serial EEPROMM25P80 A1-R A1-L USB ComtrollerCY7C63723 5V Digital Modulation : OFDM

SK TECH CO., LTD. Page 1 of 2 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I

SK TECH CO., LTD. Page 1 of 1 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. WiViEW Model: WMT-1000I Rated Input: 12V ,1.25A Made in Korea THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PCO-WMT-1000I SGM-WMT-1000I

SK TECH CO., LTD. Page 1 of 1 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I FCC ID Label Sample WiViEW Model: WMT-1000I Rated Input: 12V ,1.25A Made in Korea THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PCO-WMT-1000I SGM-WMT-1000I

SK TECH CO., LTD. Page 1 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I Internal Photographs of EUT SK TECH CO., LTD. Page 2 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 3 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 4 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 5 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 6 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 7 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I SK TECH CO., LTD. Page 8 of 8 SKT SKTFCE-060330-030 FCC ID : PCO-WMT-1000I

SPECIFICATION FOR APPROVAL CUSTOMER DATE DESCRIPTION CUSTOMER P/N Part No. 2005/11/24 T1W1424A1 WPS008 5G Swivel Type Antenna RP-SMA (M) (Black) CIWPS008SC 1 Table of Contents Table of Contents ......... 1 Specification ......... 2 Antenna Drawing ......... 3 Electrical Properties Return Loss ......... 4 V. S . W. R ......... 5 Radiation Pattern ......... 6-7 Material Data Sheet Coaxial Cable ......... 8-10 Hinge ......... 11 2 SPECIFICATION 1. Description 5GHz Swivel Type Antenna With RP-SMA (M) 2. Customer Sigmacom Co., Ltd 3. Model No. WPS008 4. Part No. T1W1424A1 5. Standard IEEE 802.11a/g Wireless LAN 6. Antenna Profile 133.5 (157) mm length (see Drawing) 7. Color Black 8. Electrical Characteristics Operating Frequency 5.15~5.35/5.725~5.85 GHz Antenna Type PCB Polarization Type Linear Type of Radiation Toroidal Antenna Gain 3.0 dBi Typical Impedance 50 Ohm nominal V.S.W.R. 2.0:1 Max. 9. Mechanical Characteristics Swivel 90 degrees Connector RP-SMA (M) Core N/A 10. Raw Material Coaxial Cable MIL-C-17 RG-178 B/U Housing ABS+PC(FR-2000) Hinge PC+ALLOY 3 Data: 94/11/24 Revised J. L. Lin Approval ScaleFREE UNITmm Page 1/1 Sandy Checked Mandy Drawed Customer Part No. Part No. Part Name 4 Electrical Properties Return Loss 6.8 GHz 10 dB/ -80 dB 20 dB MAGdB CH110 dB/REF 0 dB START4.5 GHzSTOP7 GHz200 MHz/ OFS CPL FIL 10k10k FIL 10k10k CAL S22 1 2 3 4 5 6 6: -11.58 dB 5.85 GHz 1: -11.97 dB 5.15 GHz 2: -13.27 dB 5.25 GHz 3: -13.76 dB 5.35 GHz 4: -17.32 dB 5.725 GHz 5: -14.06 dB 5.8 GHz 〈 0 dB 5 Electrical Properties V. S . W. R 6.8 GHz 1 U/ 1 U 11 U SWRLINCH11 U/REF 1 U START4.5 GHzSTOP7GHz200 MHz/ FIL 10k10k FIL 10k10k OFS CPL CAL S22 1 2 3 4 5 6 6: 1.692 U 5.85 GHz 1: 1.688 U 5.15 GHz 2: 1.538 U 5.25 GHz 3: 1.522 U 5.35 GHz 4: 1.327 U 5.725 GHz 5: 1.435 U 5.8 GHz 〈 1U 6 Electrical Properties Radiation Pattern – H Plane 7 Electrical Properties Radiation Pattern – E Plane 8 Coaxial Cable Data Sheet RG-178 9 10 11 z Hinge - PC+ALLOY

Operational Description This product, WiViEW, is an audio/video transmission system operating 5.2 GHz bands with OFDM technique. The system consists of INPUT (Model WMT-1000I, server/master mode) and OUTPUT (Model WMT-1000O, client/slave mode). The INPUT transmits A/V signals fed from Satellite or cable TV receiver, VCR, DVD Player, Game console, etc. to the OUTPUT to which an analog TV or HDTV ready TV set is connected. The transfer rate could be 6/9/12/18/24/36/48/54 Mbps. The transmitter has a unique antenna connector, Reverse-Polarity SMA type. Under normal use condition, the user has to keep at least 20 cm separation distance between radiator and the body of the user. For more detailed instruction, please refer to the user's manual. FCC 15.407(c) states: the device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met. Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packet (ACKs, CTS, PSPoll, etc.) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore the transmitter will be on only while one of the aforementioned packets are being transmitted.

SK TECH CO., LTD. Page 1 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I FCC-Certificate of Compliance Test Report No.: SKTFCE-060330-030 NVLAP CODE : 200220-0 Applicant: Sigmacom Co.,LTD. Applicant Address: DaeGo Bldg, 6F 1591-10 Gwanyang-dong Dongan-gu, Anyang,431-060 Korea Manufacturer : Sigmacom Co.,LTD. Manufacturer Address: DaeGo Bldg, 6F 1591-10 Gwanyang-dong Dongan-gu, Anyang,431-060 Korea Product: WiViEW FCC ID: PCO-WMT-1000I Model No.: WMT-1000I Receipt No.: SKTEU06-0156 Date of receipt: Mar. 17, 2006 Date of Issue: Mar. 30, 2006 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 2003 Rule Parts: FCC part 15 Subpart B, CISPR 22 Equipment Class : Class B Digital Device Peripheral Other Aspects : This Class B Digital apparatus complies with Canadian IECS-003 Test Result: The above mentioned product has been tested and passed. Prepared by: S.Y.Ye Tested by:H.P.Kim/Engineer Approved by: D.H.Kang /Manager& Chief Engineer Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I 》》 Contents 《《 Contents 2 List of Tables 2 List of Figures 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical Characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 8 4.5 Uncertainty 9 5. EMISSION Test 10 5.1 Conducted Emissions 10 5.2 Radiated Emissions 14 》List of Tables Table 1 List of test and measurement Equipment 4 Table 2 Test Data, Conducted Disturbance 11 Table 3 Test Data, Radiated Emissions 15 》List of Figures Figure 1 Spectral Diagram, LINE-PE 12 Figure 2 Spectral Diagram, NEUTRAL-PE 13 SK TECH CO., LTD. Page 3 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK TECH Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ISO/IEC 17025 for general requirements for the competence of testing and calibration laboratories. This laboratory is recognized as a Conformity Assessment Body(CAB) for CAB’s, Designation Number: KR0007 by FCC, is accredited by NVLAP for NVLAP Lab. Code : 200220-0 and DATech for DAR-Registration No.:DAT-P-076/97-0. SK TECH CO., LTD. Page 4 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Conducted Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESHS10 835871/002 09.2006 Artificial Mains Network ESH3-Z5 836679/018 08.2006 z Radiated Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESIB40 100277 02.2007 Amplifier 8447F 3113A0515308.2006 Log Periodic Antenna UHALP9107 1819 11.2006 Biconical Antenna BBA9106 91031626 11.2006 Antenna Turntable Driver 5907 91X518 N/A Antenna Turntable controller 5906 91X519 N/A 2.3 Test Date Date of Application : Mar. 17, 2006 Date of Test : Mar. 20, 2006 ~ Mar. 24, 2006 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I 3. Description of the tested samples The EUT is a WiViEW.(Video transmitter) 3.1 Rating and Physical Characteristics Specifications •Power Supply Adaptor IN:100-240V~50/60Hz 0.5A OUT:12V, DC 1.25A •Power consumption:12W (Max at Power on) •Digital Modulation:OFDM •Channel 3Channel(5180MHz, 5200MHz, 5220MHz), BAND WIDTH:20MHz •VIDEO INPUT: Composite, S-Video, Component(480i, 480p, 720p, 1080i) •AUDIO INPUT:2-Channel Stereo •PC Interface: USB •2-Input IR Blaster •FRONT LED Lamps: Power(Red), Signal(Green) •Physical Specification Size(W*H*D):42*230*195(Without Stand), 85*240*195(With Stand) Operating Temperature: 0°C~+40°C Storage Temperature:-10°C~+70°C 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 15 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I 4. Measurement Conditions Operating voltage of the EUT is AC120V, 60Hz. 4.1 Modes of Operation The EUT transmitted the video signal from pc to the WMT-1000O with radio transmission . Then the video signal was display on the Color Video Monitor. 4.2 List of Peripherals Equipment Manufacturer Model Name Serial No. WiViEW Sigmacom Co., LTD WMT-1000O N/A Adaptor (For EUT) HUA JUNG COMP CO., LTD. HAPU05F5 5C5004100001 PC Samsung Electronics DM-P40 Z39699AXC00334V Color Video Monitor HITRON SYSTEMS INC CVM 1054 X M5020001 LCD Monitor Erae Electronics Co., Ltd. ELM-728 2925BJ1021104 Adaptor (For LCD Monitor) TPV Electronics Co., Ltd. ADPC12416BB 12416BG54738591 Adaptor (For WiViEW) HUA JUNG COMP CO., LTD. HAPU05F5 5C5004100001 Keyboard(PS2) Jing Mold Enterprise Co., Ltd. LKB-0107 20103462 Mouse(USB) LG LMULGBS01I 04CU000258 SK TECH CO., LTD. Page 7 of …

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKT SKTFCE-060330-030 FCC ID :PCO-WMT-1000I Photograph 2: Setup for Radiated Emissions
