PCOAS03VGA Card

MORPHEUS GEFORCE3 User’s Manual Version 1.0 Notice This device has been approved by EMI for home. It can be used in all areas including residential area. 2 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. - Consult the dealer of an experienced radio/TV technician for help. NOTE : The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. 3 Table of Contents Chapter 1 Introduction • Features of MORPHEUS GEFORCE3 • System Configuration and Each Part Description Chapter 2 Installation • Installation of display drivers Windows 98 Windows ME Windows 2000 Windows NT • Installation of application programs Chapter 3 How to use programs • Using MORPHEUS GEFORCE3’s utilities • Watching VIDEO CD • Listening to MP3 audio Addendum • Q & A 4 Chapter 1. Introduction Contents of the package Thank you for purchasing the MORPHEUS GEFORCE3. Please make sure that you have a full content of the MORPHEUS GEFORCE3 after removing the package. MORPHEUS GEFORCE3 Board It is equipped in AGP slot of system main board. Installation CD It is an installation CD that contains drivers and programs. User’s manual It describes the installation and use of application programs. 5 Features of MORPHEUS GEFORCE3 * Powered by nVIDIA’s GeForce 3 * Two new Hypertexel pipelines * Up to 20million triangles per second at peak rates * Full scene anti-aliasing and Per-Pixel Shading * Maximum resolution up to 2048x1536 at 75 Hz * 32MB Video Memory support * Integrated 350MHz RAMDAC * AGP 4X/2X with Fast Writes and Execute Mode * DirectX 7.0/OpenGL support * DVD acceleration * 100% hardware triangle setup engine * Transform and Lighting (T&L) Engine * Sigma MP3 Player * Flash ROM BIOS for BIOS update * GigaTexel Shading processing two texture per pixel * Optimized drivers for Windows9x, NT40 and Windows2000 6 System Configuration and Each Part Description ! !! ! System Configuration To use the MORPHEUS GEFORCE3 effectively, you need the following configuration. CPU & Main board IBM-PC compatible main board in compliance with AGP 2.0 (More than Intel 440BX or VIA Apollo pro) Intel Pentium II/III CPU or compatible O/S Windows98 Windows98SE WindowsNT4.0 (more than service pack 3) Windows 2000 Windows Me (Sigma VCD /MP3 are for Windows 98(SE).) Software Microsoft DirectX6.1 System memory 32MB or more Peripherals 50MB free hard disk space CD-ROM drive MS Compatible mouse Sound blaster compatible sound card (recommended) 3.5” Floppy Drive Multi-scan monitor 7 ! !! ! Part Description 1. Monitor connector is connected to the monitor and outputs video signals. 2. Feature connector is a connection jumper for connection with other multimedia products. To use the function, you need to refer to the manual provided by its manufacturer. 3. ROM BIOS is the location of the memory containing basic program code to control the VGA in your system. 4. Video memory is a storage place to have the contents to be displayed on the screen. It is called as Frame buffer or Video buffer. 64MB high speed SDRAM or DDR SGRAM are provided as standard, which is the maximum amount of memory supported by the MORPHEUS GEFORCE 3. 8 Chapter 2 Installation Installation of display drivers Windows 98 SE In case of installing the MORPHEUS GEFORCE 3 with Windows 98 SE If you have installed Windows 98 newly, your system recognizes the video card as “Standard PCI Graphics Adapter [VGA]”. If it has not been set correctly, switch display to “Standard PCI Graphics Adapter [VGA]” and processed the following procedures. 1. Insert the installation CD into the CD-ROM Drive. 2. Click the right mouse button on the Windows screen and select “Properties” on the dialog box. 3. Select “Settings” in “Display properties”. 4. Click “Advanced”, “Adapter” then click “Change...”. 5. “Update Device Driver Wizard” appears then click “Next”. 6. Select “Search for a better driver than the one your device is using now. [Recommended]”. Click “Next” again. 9 7. Select “Specify a location”. ( Do not select other items.) 8. Select “WIN9X” folder on “GEFORCE3” folder of CD-ROM drive by using “Browse...” button then click “Next”. 9. If it recognizes “NVIDIA GEFORCE 3”, click “ Next” again. 10. The appropriate drivers will be copied and the system will be configured automatically. 11. Click “Finish”. 12. If a dialog box appears asking if you want to restart your system, select “Yes”. 10 In case of exchanging the VGA card to the MORPHEUS GEFORCE 3 in Windows 98 SE 1. When Windows 98 SE begins, the “Add new hardware wizard” dialog box will appear then click “Next”. 2. Select “Search for the best driver for your device. [Recommended]” and click “Next”. 3. Sel…

Text truncated - open the document above for the full version.

          CRTC 2M X 32 AGP 2X / 4X MONITOR Voltage VIP / Fea ture Con (1.52V) Data,Add,Consignal Data,Add,C onsignal Pixel Data.Cl ock, H.VSYNC IIC Clo ck.Data BIOS 14.31818Mhz CLOCK Geforce 3 Voltage(3.47V) DDR SDRAM Total : 64M Voltage(2.59V) MORPHEUS Geforce3 BT868/869ENCODER TV


        !"   #  $




SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-01081 FCC ID : PCOAS03 External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-01081 FCC ID : PCOAS03

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01081 FCC ID : PCOAS03 FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫ ∫∫∫∫∫∫∫∫ ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID : PCOAS03 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01081 FCC ID : PCOAS03 Internal Photographs of EUT

SK TECH CO., LTD. Page 1 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 Certificate of Compliance Test Report No.: SKTOS-01081 NVLAP CODE : 200220-0 Applicant: Sigmacom Co., Ltd. Applicant Address: 4F Anyang Nonghyub B/D, #1588-9, Kwanyang-Dong, Dongan-Ku, Anyang-City, 431-060, Korea Product: VGA CARD FCC ID: PCOAS03 Model No.: MORPHEUS Geforce 3 Receipt No.: SKE20010521-410 Date of receipt: May 21, 2001 Date of Issue: May 29, 2001 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 1992 Rule Parts: FCC part 15 Subpart B Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by:E.K. Seong Tested by:K.W.Song/Engineer Approved by: J.Y.Hyun /Lab.Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ☞☞ ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 》》 》》》》 》》 Contents 《《 《《《《 《《 Contents 2 List of Tables 2 List of Figures 2 List of Photographs 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical Characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 7 4.5 Uncertainty 7 5. EMISSION Test 8 5.1 Conducted Emissions 8 5.2 Radiated Emissions 12 》 》》 》List of Tables Table 1 List of test and measurement Equipment 4 Table 2 Test Data, Conducted Emissions 11 Table 3 Test Data, Radiated Emissions 13 》 》》 》List of Figures Figure 1 Spectral Diagram, LINE-PE 9 Figure 2 Spectral Diagram, Neutral-PE 10 SK TECH CO., LTD. Page 3 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ANSI C63.4/1992 for measurement of radio interference. SK TECH CO., LTD. Page 4 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment ! Conducted Emissions Kind of Equipment Type S/N Calibrated until EMI Receiver ESHS 10 862970/019 04.2002 Artificial Mains Network KNW-407 M63284 07.2001 EMI Receiver ESHS10 385871/002 11.2001 Artificial Mains Network ESH3-Z5 836679/018 11.2001 Conducted Cable N/A N/A 07.2001 ! Radiated Emissions Kind of Equipment Type S/N Calibrated until EMI Receiver ESVS 10 825120/013 04.2002 Spectrum Analyzer R3361A 11730187 07.2001 Amplifier 8447F 3113A05153 05.2001 Log Periodic Antenna UHALP9107 91071238 04.2002 Biconical Antenna BBA9106 N/A 04.2002 Open Site Cable N/A N/A 07.2001 Antenna Mast 5907 N/A N/A Antenna & Turntable controller 5906 91X519 N/A Amp & Receiver connection cable N/A N/A 07.2001 Amp & Spectrum connection cable N/A N/A 07.2001 50Ω Switcher MP59B M93083 07.2001 2.3 Test Date Date of Application : May 21, 2001 Date of Test : May 28, 2001 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 3. Description of the tested samples The EUT is the VGA Card. 3.1 Rating and Physical Characteristics ! CPU & Main board IBM-PC compatible main board in compliance with AGP 2.0 (More than Intel 440BX or VIA Apollo pro) Intel Pentium II/III CPU or compatible ! O/S Windows 98 Windows 98SE Windows NT 4.0 (more than service pack 3) Windows 2000 Windows Me (Sigma VCD / MP3 are for Windows 98(SE).) ! Software Microsoft DirectX6.1 ! System memory 32MB or more ! Peripherals 50MB free hard disk space DC-ROM drive MS Compatible mouse Sound blaster compatible sound card (recommended) 3.5” Floppy Drive Multi-scan monitor 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 4. Measurement Conditions The operating voltage of EUT is supplied by the PC. (PC Input Voltage : AC 120V, 60Hz ) 4.1 Modes of Operation The EUT was in the following operation mode during all testing; The EUT installed in PC. And connected with Monitor. Tested in mode of scrolling “H” on the screen. 4.2 List of Peripherals Description Manufacturer Model Name Serial No. FCC ID Monitor Samsung SyncMaster750P PG17H3NK100247 DoC Printer H.P 2225C 3245S12493 DSI6XU2225 Keyboard JING MOLD LKB-0107 90604277 N/A Mouse 1 Logitech M-S48 LZA91457567 DZL211153 Mouse 2 Logitech M-BE55 LZE02551778 DoC Mouse 3 A4 Tech AM-5E 951237243 H8GAM555P JoyStick Logitech J-ZA10 LZS01651409 DoC Speaker FAN HAI DIAN CMK660 None DoC Mic LG Electronics None None N/A Personal Computer Mother board Micro-Star MS-6161 96K6262664G1144716 DoC Power supply HIPRO HP-235ATXA6 F3-9911252206 DoC FDD Drive Panasonic JU-257A604P 62638 DoC HDD Quantum Pro Drive LPS 9442203B DoC CD-ROM Drive LG GCD-R560B 6023002365 BEJGCD-R560B SK TECH CO., LTD. Page 7 of 13 SKT SKTOS-01081 FCC ID : PCOAS03 4.3 Type of Used Cables Des…
