PCU-JLDP-03Wireless remote controller

1、 Interface of the Control box 1---connect to 24~29VDC/3A power supply 9 10 4 2 3 1 5 6 7 8 1---connect to 24~29VDC/3A power supply 2---connect to Head Motor 24~29VDC/3A 3---connect to Feet Motor 24~29VDC/3A 4---connect to LED 12VDC/1A (optional) 5---connect to Feet Massage Motor 24~29VDC/0.3A 6---connect to Feet Massage Motor 24~29VDC/0.3A 7---connect to Head Massage Motor 24~29VDC/0.3A 8---connect to Head Massage Motor 24~29VDC/0.3A 9---wire control (anyone of 9 or 10 connect to another control box) 10--wire control (anyone of 9 or 10 connect to another control box) 2.Function description The control box must be used with the Remote Hand Control together. The detail please refer to the "Operating Manual of Remote Hand Control". 3.Preparing two bases for simultaneous operation The control system is designed to allow (2) split queen or (2) split king bases to work in unison with a onepiece mattress. In order for (2) adjustable bases to work simultaneously with one (1) hand control, only connect the two control boxes in the connector 9 or 10 with the cable. 5 6 7 8 4.FCC STATEMENT FCC ID: PCU-JLDP-03 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If thisinstallation. If this equipment does cause harmful interference to radio or television reception, which determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 OKIN Refined Electric Technology Co., Ltd. August 28, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, OKIN Refined Electric Technology Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: PCU-JLDP-03 Wireless remote controller Model name: JLDP.03 We affirm that between SIEMIC and OKIN Refined Electric Technology Co., Ltd, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Minglong Lei Title: General Manager OKIN Refined Electric Technology Co., Ltd. Address: Plant 4, No. 410, Xinyonglian Road, Wangjiangjing Development Zone, Jiaxing Zhejiang China Telephone: 0086-573-82281072 Fax : 0086-0573-82280968 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 OKIN Refined Electric Technology Co., Ltd. August 28, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: PCU-JLDP-03 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Minglong Lei Title: General Manager OKIN Refined Electric Technology Co., Ltd. Address: Plant 4, No. 410, Xinyonglian Road, Wangjiangjing Development Zone, Jiaxing Zhejiang China Telephone: 0086-573-82281072 Fax : 0086-0573-82280968 E-mail: [email protected]

External photos

Internal photos

NINGBO EMTEK CO., LTD. REPORT NO: KAN120803006E FCC ID: PCU-JLDP-03 DATE: 09/12/2012 Page 1 of 29 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART B &C REQUIREMENT OF Wireless remote controller MODEL No.: JLDP.03 FCC ID: PCU-JLDP-03 REPORT NO: KAN120803006E ISSUE DATE: September 12, 2012 Prepared for OKIN REFINED ELECTRIC TECHNOLOGY CO., LTD. Plant 4, No.410, Xinyonglian Road, Wangjiangjing Development Zone, Jiaxing Zhejiang China Prepared by NINGBO EMTEK CO., LTD 1F Building 4, 1177#, Lingyun Road, Ningbo National Hi-Tech Zone, Ningbo, Zhejiang, China TEL: 0086-574-27907998 FAX: 0086-574-27721538 NINGBO EMTEK CO., LTD. REPORT NO: KAN120803006E FCC ID: PCU-JLDP-03 DATE: 09/12/2012 Page 2 of 29 VERIFICATION OF COMPLIANCE Applicant: OKIN REFINED ELECTRIC TECHNOLOGY CO., LTD. Plant 4, No.410, Xinyonglian Road, Wangjiangjing Development Zone, Jiaxing Zhejiang China Product Description: Wireless remote controller Model Number: JLDP.03 File Number: KAN120803006E Date of Test: August 06, 2012 to September 11, 2012 We hereby certify that: The above equipment was tested by NINGBO EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.249. The test results of this report relate only to the tested sample identified in this report. Approved By Andy.wang/Manager NINGBO EMTEK CO., LTD. NINGBO EMTEK CO., LTD. REPORT NO: KAN120803006E FCC ID: PCU-JLDP-03 DATE: 09/12/2012 Page 3 of 29 Table of Contents 1. GENERAL INFORMATION........................................................................................................... 4 1.1. Product Description...................................................................................................................... 4 1.2. Related Submittal(s) / Grant (s) ................................................................................................... 4 1.3. Test Methodology ........................................................................................................................ 4 1.4. Special Accessories ...................................................................................................................... 4 1.5. Equipment Modifications............................................................................................................. 4 1.6. Test Facility.................................................................................................................................. 5 1.7. Measurement Uncertainty ............................................................................................................ 5 2. SYSTEM TEST CONFIGURATION ............................................................................................. 6 2.1. EUT Configuration ...................................................................................................................... 6 2.2. EUT Exercise ............................................................................................................................... 6 2.3. Requirement for Compliance ....................................................................................................... 6 2.4. Configuration of Tested System................................................................................................... 8 2.5. Description of support units ......................................................................................................... 8 3. SUMMARY OF TEST RESULTS ................................................................................................... 9 4. DESCRIPTION OF TEST MODES................................................................................................ 9 5. CONDUCTED EMISSIONS TEST .............................................................................................. 10 5.1. Measurement Procedure:............................................................................................................ 10 5.2. Test SET-UP............................................................................................................................... 10 5.3. Measurement Equipment Used: ................................................................................................. 10 5.4. Measurement Result:.................................................................................................................. 11 5.5. Conducted Measurement Photos:............................................................................................... 13 6. RADIATED EMISSION TEST ..................................................................................................... 14 6.1. Measurement Procedure............................................................................................................. 14 6.2. Measurement Equipment Used: ................................................................................................. 14 6.3. Test SET-UP............................................................................................................................... 14 6.4. Radiated Measurement Result ................................................................................................... 16 6.5. Radiated Measurement Photos:.................................................................................................. 24 7. BAND EDGES MEASUREMENT................................................................................................ 26 7.1. Standard Applicable ................................................................................................................... 26 7.2. Measurement Procedure..................................................................................…

Text truncated - open the document above for the full version.

Setup photos Conducted: Radiated: Above 1000MHz: 30M~1000MHz:
