PDYTP1325Compact Fluorescent Lamp

U SER ’ S M ANUAL Federal Communication Commission Interference Statement Products are applied to hotel, supermarkets, offices, families, etc. Rate voltage: 110V~120V. Rate Frequency: 60Hz. Caution: 1. Use only on 120 volt, 60 Hertz. 2. Never disassemble or modify-any changes could void the user’s authority to operate this device. 3. Not for use in totally enclosed fixtures. 4. Risk of electric shock-use in dry locations only. 5. This device is not intended for use with emergency exit fixtures or emergency exit lights. 6. This product could produce interference when used near a equipment or other critical navigation or communication equipment operating between 40~60KHz.If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamp or the appliance into a different outlet. 7. To prevent burns, do not touch the bulb during operation or immediately after switching off. 8. Not for use with dimmers, electronic timer or photocell devices or occupancy sensor. 9. Add weight of the device may cause instability of a freestanding portable. 10. Use only with portable table lamps in which the distance from the bottom of the base to the top of the lamp holder dose not exceed three times minimum base width. 11. Use only with portable table lamps which are provide with lap shades. 12. Use indoors with open, surface mounted and track fixtures.

F IGURE 1 C OMPACT F LUORESCENT L AMP (M/N: TP120-SL(B) S ERIES ) G ENERAL A PPEARANCE FIGURE 2 COMPACT FLUORESCENT LAMP (M/N: TP120-SL(F) SERIES) GENERAL APPEARANCE F IGURE 3 C OMPACT F LUORESCENT L AMP (M/N: TP120-S(B)) G ENERAL A PPEARANCE FIGURE 4 COMPACT FLUORESCENT LAMP (M/N: TP120-S(D) SERIES) GENERAL APPEARANCE F IGURE 5 T WIST L AMP (M/N: TP120-13SL) G ENERAL A PPEARANCE

Label Drawing

Label Location Information Refer to the below red arrow: (for example)

F IGURE 1 C OMPACT F LUORESCENT L AMP (M/N: TP120-15SL(F)) C OVER R EMOVED F IGURE 2 C OMPACT F LUORESCENT L AMP (M/N: TP120-15SL(F)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 3 COMPACT FLUORESCENT LAMP (M/N: TP120-15SL) MAIN BOARD (SOLDERED SIDE) F IGURE 4 C OMPACT F LUORESCENT L AMP (M/N: TP120-20SL(F)) C OVER R EMOVED F IGURE 5 C OMPACT F LUORESCENT L AMP (M/N: TP120-20SL(F)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 6 COMPACT FLUORESCENT LAMP (M/N: TP120-20SL(F)) MAIN BOARD (SOLDERED SIDE) F IGURE 7 C OMPACT F LUORESCENT L AMP (M/N: TP120-23SL(F)) C OVER R EMOVED IGURE 8 C OMPACT F LUORESCENT L AMP (M/N: TP120-23SL(F)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 9 COMPACT FLUORESCENT LAMP (M/N: TP120-23SL(F)) MAIN BOARD (SOLDERED SIDE) F IGURE 10 C OMPACT F LUORESCENT L AMP (M/N: TP120-25SL(F)) C OVER R EMOVED F IGURE 11 C OMPACT F LUORESCENT L AMP (M/N: TP120-25SL(F)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 12 COMPACT FLUORESCENT LAMP (M/N: TP120-25SL(F)) MAIN BOARD (SOLDERED SIDE) F IGURE 13 C OMPACT F LUORESCENT L AMP (M/N: TP120-15S(D)) C OVER R EMOVED F F IGURE 14 C OMPACT F LUORESCENT L AMP (M/N: TP120-15S(D)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 15 COMPACT FLUORESCENT LAMP (M/N: TP120-15S(D)) MAIN BOARD (SOLDERED SIDE) F IGURE 16 C OMPACT F LUORESCENT L AMP (M/N: TP120-20S(D)) C OVER R EMOVED F IGURE 17 C OMPACT F LUORESCENT L AMP (M/N: TP120-20S(D)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 18 COMPACT FLUORESCENT LAMP (M/N: TP120-20S(D)) MAIN BOARD (SOLDERED SIDE) F IGURE 19 C OMPACT F LUORESCENT L AMP (M/N: TP120-23S(D)) C OVER R EMOVED F IGURE 20 C OMPACT F LUORESCENT L AMP (M/N: TP120-23S(D)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 21 COMPACT FLUORESCENT LAMP (M/N: TP120-23S(D)) MAIN BOARD (SOLDERED SIDE) F IGURE 22 C OMPACT F LUORESCENT L AMP (M/N: TP120-13SL) C OVER R EMOVED F IGURE 23 C OMPACT F LUORESCENT L AMP (M/N: TP120-13S(D)) M AIN B OARD (C OMPONENT S IDE ) FIGURE 24 COMPACT FLUORESCENT LAMP (M/N: TP120-13SL) MAIN BOARD (SOLDERED SIDE)

Schematics M/N: TP120-15SL, 20SL, 23SL, 25SL M/N: TP120-13SL M/N: TP120-15S, 20S, 23S (B)/(D)

Tospo Electronics Co., Ltd. FCC ID:PDYTP1325 Page 1 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01070 Application for FCC Certificate On Behalf of Tospo Electronics Co., Ltd. Compact Fluorescent Lamp Model No: TP120-15SL(B) TP120-20SL(B) TP120-23SL(B) TP120-25SL(B) TP120-15SL(F) TP120-20SL(F) TP120-23SL(F) TP120-25SL(F) TP120-15S(B) TP120-20S(B) TP120-23S(B) TP120-15S(D) TP120-20S(D) TP120-23S(D) TP120-13SL FCC ID : PDYTP1325 Prepared For : Tospo Electronics Co., Ltd. No.2 West Xing-Sheng Road, Hengdian Industrial Area, Dong Yang City, Zhejiang, P.R, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F01070 Date of Test : Sept 04-11, 2001 Date of Report : Sept 21, 2001 Tospo Electronics Co., Ltd. FCC ID:PDYTP1325 Page 2 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01070 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test ........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration ...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures........................................................................................................................... 7 2.7 Test Results................................................................................................................................. 8 3 FIELD STRENGTH TEST ........................................................................................................... 16 3.1 Test Equipment......................................................................................................................... 16 3.2 Block Diagram of Test Setup ................................................................................................... 16 3.3 Test Configuration .................................................................................................................... 16 3.4 Operating Condition of EUT .................................................................................................... 16 3.5 Test Procedure .......................................................................................................................... 17 3.6 Test Result ................................................................................................................................ 17 Tospo Electronics Co., Ltd. FCC ID:PDYTP1325 Page 3 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01070 TEST REPORT FOR FCC CERTIFICATE Applicant : Tospo Electronics Co., Ltd. Manufacturer : Tospo Electronics Co., Ltd. EUT Description : Compact Fluorescent Lamp (A) Model No.: TP120-15SL(B) TP120-20SL(B) TP120-23SL(B) TP120-25SL(B) TP120-15SL(F) TP120-20SL(F) TP120-23SL(F) TP120-25SL(F) TP120-15S (B) TP120-20S (B) TP120-23S (B) TP120-15S (D) TP120-20S (D) TP120-23S (D) TP120-13SL (B) Serial No.: E082708 E082710 E08279 E082711 E082708 E082710 E08279 E082705 E082712 E082904 E082901 E082712 E082904 E082901 E082707 (C) Power Supply: 120V/60Hz Note: The model TP120-(15, 20, 23, 25)SL(B) and the model TP120-(15, 20, 23, 25)SL(F) just have different appearances, so the model TP120-(15, 20, 23, 25)SL(F) are only tested in this test. The model TP120-(15, 20, 23)S(B) and the model TP120-(15, 20, 23)S(D) just have different appearances, so the model TP120-(15, 20, 23)S(D) are only tested in this test. Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Sept 04 -11, 2001 Prepared by : Test Engineer : JEENY LUO Assistant ADA ZOU Engineer Reviewer : Approved Signatory : BYRON KWO Supervisor ALEX CHUI Assistant Manager Tospo Electronics Co., Ltd. FCC ID:PDYTP1325 Page 4 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01070 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Compact Fluorescent Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Numbe…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test M/N: TP120-SL(F) Series M/N: TP120-S(D) Series 2. Field strength Test
