PDYTP1432Electronic Ballast

U SER ’ S M ANUAL This light device has been tested and found to comply with the limits for consumer RF Lighting device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1. Use only on 120 volt 60 hertz. 2. Never disassemble or modify any changes could void the user’s authority to operate this device. 3. Type I outdoor use. 4. Class P thermally protected. 5. Disconnect line voltage before installing or replacing. Ballast case must be grounded. 6. This product could produce interference when used near a TV, radio, wireless remote control or maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHZ. If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamp or the appliance into a different outlet.

F IGURE 1 E LECTRONIC B ALLAST (M/N: TP120-1/32 IS) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 2 E LECTRONIC B ALLAST (M/N: TP120-1/32 IS) G ENERAL A PPEARANCE (B ACK V IEW ) F IGURE 3 E LECTRONIC B ALLAST (M/N: TP120-2/32 IS) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 4 E LECTRONIC B ALLAST (M/N: TP120-2/32 IS) G ENERAL A PPEARANCE (B ACK V IEW ) F IGURE 5 E LECTRONIC B ALLAST (M/N: TP120-3/32 IS) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 6 E LECTRONIC B ALLAST (M/N: TP120-3/32 IS) G ENERAL A PPEARANCE (B ACK V IEW ) F IGURE 7 E LECTRONIC B ALLAST (M/N: TP120-4/32 IS) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 8 E LECTRONIC B ALLAST (M/N: TP120-4/32 IS) G ENERAL A PPEARANCE (B ACK V IEW )

Label Drawing

Label Location Information Refer to the below red arrow: (for example)

F IGURE 1 E LECTRONIC B ALLAST (M/N: TP120-1/32 IS) C OVER R EMOVED F IGURE 2 E LECTRONIC B ALLAST (M/N: TP120-1/32 IS) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 E LECTRONIC B ALLAST (M/N: TP120-1/32 IS) M AIN B OARD (S OLDERED S IDE ) F IGURE 4 E LECTRONIC B ALLAST (M/N: TP120-2/32 IS) C OVER R EMOVED F IGURE 5 E LECTRONIC B ALLAST (M/N: TP120-2/32 IS) M AIN B OARD (C OMPONENT S IDE ) F IGURE 6 E LECTRONIC B ALLAST (M/N: TP120-2/32 IS) M AIN B OARD (S OLDERED S IDE ) F IGURE 7 E LECTRONIC B ALLAST (M/N: TP120-3/32 IS) C OVER R EMOVED F IGURE 8 E LECTRONIC B ALLAST (M/N: TP120-3/32 IS) M AIN B OARD (C OMPONENT S IDE ) F IGURE 9 E LECTRONIC B ALLAST (M/N: TP120-3/32 IS) M AIN B OARD (S OLDERED S IDE ) F IGURE 10 E LECTRONIC B ALLAST (M/N: TP120-4/32 IS) C OVER R EMOVED F IGURE 11 E LECTRONIC B ALLAST (M/N: TP120-4/32 IS) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E LECTRONIC B ALLAST (M/N: TP120-4/32 IS) M AIN B OARD (S OLDERED S IDE )

Schematics M/N: TP120-1/32 IS M/N: TP120-2/32 IS M/N: TP120-3/32 IS M/N: TP120-4/32 IS

Tospo Electronic Co., Ltd. FCC ID: PDYTP1432 Page 1 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01080 Application for FCC Certificate On Behalf of Tospo Electronic Co., Ltd. Electronic Ballast Model No.: TP120-1/32 IS TP120-2/32 IS TP120-3/32 IS TP120-4/32 IS FCC ID: PDYTP1432 Prepared For : Tospo Electronic Co., Ltd. No.2 West Xing-Sheng Road, Hengdian Industrial Area Dong Yang City, Zhejiang, P.R. China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +8621-64955500 Fax: +8621-64955491 Report No. : ACI-F01080 Date of Test : Aug 10-27, 2001 Date of Report : Nov 12, 2001 Tospo Electronic Co., Ltd. FCC ID: PDYTP1432 Page 2 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01080 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 8 3 FIELD STRENGTH TEST ........................................................................................................... 12 3.1 Test Equipment......................................................................................................................... 12 3.2 Block Diagram of Test Setup ................................................................................................... 12 3.3 Test Configuration.................................................................................................................... 12 3.4 Operating Condition of EUT .................................................................................................... 12 3.5 Test Procedure .......................................................................................................................... 13 3.6 Test Result ................................................................................................................................ 13 Tospo Electronic Co., Ltd. FCC ID: PDYTP1432 Page 3 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01080 TEST REPORT FOR FCC CERTIFICATE Applicant : Tospo Electronic Co., Ltd. Manufacturer : Tospo Electronic Co., Ltd. EUT Description : Electronic Ballast (A) Model No.: TP120-1/32 IS TP120-2/32 IS TP120-3/32 IS TP120-4/32 IS (B) Serial No.: AC2015703-10 AC2015703-9 AC2015703-11 AC2015703-12 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Aug 10 ~ 27, 2001 Prepared by : Test Engineer : STELLA TANG (Assistant) ADA ZOU (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Tospo Electronic Co., Ltd. FCC ID: PDYTP1432 Page 4 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01080 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Electronic Ballast Type of EUT : ; Production … Pre-product … Pro-type Model Number : TP120-1/32 IS TP120-2/32 IS TP120-3/32 IS TP120-4/32 IS Applicant : Tospo Electronic Co., Ltd. No.2 West Xing-Sheng Road, Hengdian Industrial Area Dong Yang City, Zhejiang, P.R. China Manufacturer : Tospo Electronic Co., Ltd. No.2 West Xing-Sheng Road, Hengdian Industrial Area Dong Yang City, Zhejiang, P.R. China M/N Input Power (VA) Output Power (W) TP120-1/32 IS 33.40 32.70 TP120-2/32 IS 58.70 58.00 TP120-3/32 IS 90.20 88.90 TP120-4/32 IS 106.10 104.70 Tospo Electronic Co., Ltd. FCC ID: PDYTP1432 Page 5 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01080 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Federal Communications Commission FCC Engineering Laboratory 7…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test FRONT VIEW (M/N: TP120-1/32 IS) Side View (M/N: TP120-1/32 IS) FRONT VIEW (M/N: TP120-2/32 IS) SIDE VIEW (M/N: TP120-2/32 IS) FRONT VIEW (M/N: TP120-3/32 IS) SIDE VIEW (M/N: TP120-3/32 IS) FRONT VIEW (M/N: TP120-4/32 IS) SIDE VIEW (M/N: TP120-4/32 IS) 2. Field strength Test (M/N: TP120-1/32 IS) (M/N: TP120-2/32 IS) (M/N: TP120-3/32 IS) (M/N: TP120-4/32 IS)
