PKW-WAP55AGDual-Band Wireless A+G Access Point

Instant Wireless ® Series Dual-Band Wireless A + G Access Point Use this guide to install: WAP55AG User Guide COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. Copyright © 2003 Linksys, All RightsReserved. Instant Wireless, Linksys, and the Linksys logo are registered trademarks ofLinksys Group, Inc. Microsoft, Windows, and the Windows logo are registered trade-marks of Microsoft Corporation. All other trademarks and brand names are the proper-ty of their respective proprietors. LIMITED WARRANTY Linksys guarantees that every Instant Wireless Dual-Band Wireless A + G Access Pointwill be free from physical defects in material and workmanship for one year from the dateof purchase, when used within the limits set forth in the Specifications section of this UserGuide. If the product proves defective during this warranty period, go to the Linksys website atwww.linksys.com for complete Return Merchandise Authorization (RMA) assistance. You can also call Linksys Technical Support in order to obtain a RMA Number. BE SURE TOHAVE YOUR PROOF OF PURCHASE AND A BARCODE FROM THE PRODUCT’S PACK-AGING ON HAND WHEN CALLING. RETURN REQUESTS CANNOT BE PROCESSEDWITHOUT PROOF OF PURCHASE. When returning a product, mark the RMA Numberclearly on the outside of the package and include a copy of your original proof of pur-chase. All customers located outside of the United States of America and Canada shallbe held responsible for shipping and handling charges.IN NO EVENT SHALL LINKSYS'S LIABILITY EXCEED THE PRICE PAID FOR THE PROD-UCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAM-AGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFT-WARE, OR ITS DOCUMENTATION. LINKSYS OFFERS NO REFUNDS FOR ITS PROD-UCTS. Linksys makes no warranty or representation, expressed, implied, or statutory,with respect to its products or the contents or use of this documentation and all accom-panying software, and specifically disclaims its quality, performance, merchantability, orfitness for any particular purpose. Linksys reserves the right to revise or update its prod-ucts, software, or documentation without obligation to notify any individual or entity.Please direct all inquiries to:Linksys P.O. Box 18558, Irvine, CA 92623. SAFETY AND REGULATORY NOTICESFCC STATEMENTThe Instant Wireless Dual-Band Wireless A + G Access Point has been tested and com-plies with the specifications for a Class B digital device, pursuant to Part 15 of the FCCRules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates, uses, and can radiate radio fre-quency energy and, if not installed and used according to the instructions, may causeharmful interference to radio communications. However, there is no guarantee that inter-ference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which is found by turning the equipment offand on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment or devices • Connect the equipment to an outlet other than the receiver's • Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any change or modification to the product not expressly approved byLinksys could void the user's authority to operate the device.FCC Caution: Operation within the 5150 to 5250GHz band is restricted to indoor use only.FCC RF Radiation Exposure StatementTo comply with the FCC and ANSI C95.1 RF exposure limits, the antenna(s) for thisdevice must comply with the following:• Access points with 2.4 GHz or 5 GHz integrated antenna must operate with a sepa-ration distance of at least 20 cm from all persons using the cable provided and mustnot be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operations for satisfying RF exposure compli-ance.Note: Dual antennas used for diversity operation are not considered co-located.Canadian Department of Communications Industry Canada (IC) NoticeThis Class B digital apparatus complies with Canadian ICES-003 and RSS-210.Cet appareil numérique de la classe B est conforme à la norme NMB-003 et CNR-210du Canada."To prevent radio interference to the licensed service, this device is intended to be oper-ated indoors and away from windows to provide maximum shielding. Equipment (or itstransmit antenna) that is installed outdoors is subject to licensing."" Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'unelicence, il doit être utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournirun écran de blindage maximal. Si le matériel (ou son antenne d'émission) est installé àl'extérieur, il doit faire l'objet d'une licence. "EC DECLARATION OF CONFORMITY (EUROPE)Linksys Group declares that the Instant Wireless ® Series products included in the Instant Wireless ® Series conform to the specifications listed below, following the provisions of the European R&TTE directive 1999/5/EC, EMC directive 89/336/EEC, and Low Voltagedirective 73/23/EEC: For 11Mbps, 2.4 GHz access points with 100 mW radios, the following standards wereapplied: • ETS 300-826, 301 489-1 General EMC requirements for Radio equipment. • EN 609 50 Safety • ETS 300-328-2 Technical requirements for Radio equipment. For 54 Mbps, 5 GHz access points with 40 mW radios, the following standards wereapplied: • ETS 301 489-1, 301 489-17 General EMC requirements for Radio equipment. • EN 609 50 Safety • ETS 301-893 Technical requirements for Radio equipment. Caution…

Text truncated - open the document above for the full version.

Instant Wireless ® Series 14 Chapter 6: Configuring the Dual-Band Wireless A + G Access PointThe Access Point’s settings can be configured through your web browser withthe Web-Based Utility. This chapter explains how to configure the Access Pointin this manner.Type the Access Point’s IP Addressinto your web browser’s addressfield. (The default IP address is192.168.1.246.) (Should you need tolearn what IP Address the AccessPoint presently uses, run the SetupWizard. It will scan the Access Pointand give you its IP Address.) Pressthe Enter key and the following screen, shown in Figure 6-1, willappear. Leave the User Name fieldblank. The first time you open theWeb-Based Utility, use the default password admin . You can set a new pass- word from the Password tab.The first screen that appears, shown in Figure 6-2, displays the Setup tab. This allows you to change the Access Point’s general settings. These settings aredescribed here. Click the Apply button to apply your changes or Cancel to can- cel your changes. If you require online help, click the Help button. Firmware . This will display the Access Point’s current firmware version. Firmware can be upgraded from the Help tab.Access Point Name. You may assign any name to the Access Point, which is how the Access Point is identified on your network. Unique, memorable namesare helpful, especially if you are employing multiple access points on the samenetwork. Verify this is the name you wish to use and click the Apply button to set it. Figure 6-1 The Setup Tab Note: The Access Point is designed to function properly after using the Setup Wizard. This chapter is provided solely for thosewho wish to perform more advanced configuration or monitoring. Dual-Band Wireless A + G Access PointMAC Address. The MAC Address of the LAN interface - connected through the LAN Port - is displayed here.Configuration Type. This selection tells the Access Point how IP Addresses are determined on your network. If you are using a DHCP server on your net-work to automatically generate different IP Addresses to each device, selectAutomatic Configuration - DHCP . Select Static IP Address if each device uses its own IP Address. The Access Point’s default IP Address, Subnet Mask,and Default Gateway will appear in the appropriate fields.Fields for configuring your wireless connections, both 802.11a and 802.11g-draft are located under this information. You must configure any wireless stan-dard you are using on your network.MAC Address. The first line of data provided about both wireless standards is the MAC Address of the wireless interface. 15 Figure 6-2 Dual-Band Wireless A + G Access Point 17 Instant Wireless ® Series 16 From the pull-down menu, select the type of WEP encryption you wish to use.If you are using 802.11a wireless technology, you will need to enter the keymanually. If you are using 802.11g-draft wireless technology and wish to use a WEPPassphrase, it can be a maximum of 16 alphanumeric characters. Thispassphrase may not work with non-Linksys products due to possible incom-patibility with other vendors’ passphrase generators. The WEP Key can be gen-erated using your Passphrase or you can enter it manually. Type that here. Figure 6-3 SSID. The SSID is the unique name shared among all points in a wireless net- work. The SSID must be identical for all points in the wireless network. It iscase sensitive and must not exceed 32 alphanumeric characters, which may beany keyboard character. Make sure this setting is the same for all points in yourwireless network.Channel. Select the appropriate channel from the list provided to correspond with your network settings. This should be between 1 and 11 (in NorthAmerica) for 2.4GHz/802.11b devices and 36 and 64 (in North America) for5GHz/802.11a devices. All points in your wireless network must use the samechannel in order to function correctly.WEP . The WEP Encryption method is Disabled by default. To enable WEP, click the WEP Key Setting button. Mode. This option works only for 802.11b and 802.11g-draft devices in your wireless network. Select Mixed and both Wireless-G and Wireless-B comput- ers will be allowed on the network, but the speed will be reduced. Select G- Only for maximum speed, but no Wireless-B users will be allowed on the net- work.Click the Apply button to apply your changes or Cancel to cancel your changes. If you require online help, click the Help button. Setting WEP Encryption through the Web-based Browser Utility is done byclicking the WEP Key Setting button on the Setup Screen for any type of wire- less device used on your network.This will open the WEP key setting screen. This screen is shown in Figure 6-3for 802.11a wireless products and Figure 6-4 for 802.11g-draft wireless prod-ucts. Select the WEP encryption for the type(s) of wireless technology you areusing. From this screen, you can select the type of WEP encryption to use aswell as set the WEP Key for that encryption. WEP Encryption Figure 6-4 Important: Always remember that each point in your wireless net- work MUST use the same WEP Encryption method and encryptionkey or your wireless network will not function properly. Dual-Band Wireless A + G Access PointThe Status tab, shown in Figure 6-6, displays currentinformation on the AccessPoint, its settings and perform-ance.The information displayed inthese fields reflects the set-tings that you saved on theSetup tab. For any informationabout what these settingsmean, turn back to the appro-priate heading in the sectionfor the Setup tab.The Statistics tab, shown in Figure 6-7, displaysinformation on how wellthe Access Point is trans-mitting data. It shows theamount of data packetsdropped with those trans-mitted. Remember, somepacket loss is common innetworking.To update the statistics,click the Refresh button. Click the Help button for more information aboutthis screen 19 The Status Tab Figure 6-6 Instant Wireless ® Series 18 The WEP key must consist of the letters “A” through “F” and the number…

Text truncated - open the document above for the full version.

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: Dual-Band Wireless A+G Access Point MODEL NO.: WAP55AG TRADE NAME: Linksys IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: RF910808R02B THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION： ManufacturerUSA Local Representative Company name: The Linksys Group, Inc. To Be Determined. Address: 17401 Armstrong Ave., Irvine, CA 92614 Contact Person: Frank Hung Title: Product Management Te l / F a x : (949) 784-1820 (949) 261-1168

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6

Page 7 Page 8 Page 9

Page 10 Page 11 Page 12

FCC ID: PKW-WAP55AG ADT No.910808R02B Technical Description The transmitter of the EUT is powered by power adapter and connected with notebook through RJ45 port. The antenna is Dipole antenna. There is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a Dual-Band Wireless A+G Access Point which operates in both the 5GHz and 2.4GHz bands and can be operated simultaneously. The total MPE of these combination is shorter than 20cm and the maximum data rate could be 72Mbps. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

FCC ID: PKW-WAP55AG Report No.: RF910808R02B 1 Issued: Mar. 13, 2003 FCC TEST REPORT REPORT NO.: RF910808R02B MODEL NO.: WAP55AG RECEIVED: Feb. 27, 2003 TESTED: Mar. 2 ~ Mar. 12, 2003 APPLICANT:The Linksys Group, Inc. ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 136 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 2 Issued: Mar. 13, 2003 Table of Contents 1.CERTIFICATION .................................................................................................................... 5 2.SUMMARY OF TEST RESULTS............................................................................................ 6 3.GENERAL INFORMATION .................................................................................................... 8 3.1GENERAL DESCRIPTION OF EUT ...................................................................................... 8 3.2DESCRIPTION OF TEST MODES ........................................................................................ 9 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ..................................................... 10 3.4DESCRIPTION OF SUPPORT UNITS................................................................................. 11 4.TEST TYPES AND RESULTS (For Part 802.11b and 802.11g) .......................................... 12 4.1CONDUCTED EMISSION MEASUREMENT....................................................................... 12 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 12 4.1.2TEST INSTRUMENTS ......................................................................................................... 12 4.1.3TEST PROCEDURES .......................................................................................................... 13 4.1.4DEVIATION FROM TEST STANDARD ................................................................................ 13 4.1.5TEST SETUP ....................................................................................................................... 14 4.1.6EUT OPERATING CONDITIONS......................................................................................... 14 4.1.7TEST RESULTS ................................................................................................................... 15 4.2RADIATED EMISSION MEASUREMENT ............................................................................ 21 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 21 4.2.2TEST INSTRUMENTS ......................................................................................................... 22 4.2.3TEST PROCEDURES .......................................................................................................... 23 4.2.4DEVIATION FROM TEST STANDARD ................................................................................ 23 4.2.5TEST SETUP ....................................................................................................................... 24 4.2.6EUT OPERATING CONDITIONS......................................................................................... 24 4.2.7TEST RESULTS ................................................................................................................... 25 4.2.8TEST RESULTS (A) ............................................................................................................. 27 4.2.9TEST RESULTS (B) ............................................................................................................. 30 4.36dB BANDWIDTH MEASUREMENT ................................................................................... 33 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 33 4.3.2TEST INSTRUMENTS ......................................................................................................... 33 4.3.3TEST PROCEDURE ............................................................................................................34 4.3.4DEVIATION FROM TEST STANDARD ................................................................................ 34 4.3.5TEST SETUP ....................................................................................................................... 34 4.3.6EUT OPERATING CONDITIONS......................................................................................... 34 4.3.7TEST RESULTS (A) ............................................................................................................. 35 4.3.8TEST RESULTS (B) ............................................................................................................. 39 4.4MAXIMUM PEAK OUTPUT POWER ................................................................................... 43 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 43 4.4.2INSTRUMENTS.................................................................................................................... 43 4.4.3TEST PROCEDURES .......................................................................................................... 44 4.4.4DEVIATION FROM TEST STANDARD ................................................................................ 44 4.4.5TEST SETUP ....................................................................................................................... 44 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 3 Is…

Text truncated - open the document above for the full version.

FCC ID: PKW-WAP55AG Report No.: RF910808R02B 81 Issued: Mar. 13, 2003 5.3 PEAK TRANSMIT POWER MEASUREMENT 5.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHzThe lesser of 50mW (17dBm) or 4dBm + 10logB 5.25 – 5.35 GHzThe lesser of 250mW (24dBm) or 11dBm + 10logB 5.725 – 5.825 GHzThe lesser of 1W (30dBm) or 17dBm + 10logB Note: Where B is the 26dB emission bandwidth in MHz. 5.3.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: PKW-WAP55AG Report No.: RF910808R02B 82 Issued: Mar. 13, 2003 5.3.3 TEST PROCEDURE 1. The transmitter output was connected to the spectrum analyzer. 2. Set span to encompass the entire emission bandwidth of the signal. 3. Set RBW to 1MHz, VBW to 100kHz. 4. Using the spectrum analyzer’s channel power measurement function to measure the output power. 5.3.4 DEVIATION FROM TEST STANDARD No deviation 5.3.5 TEST SETUP 5.3.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at specific channel frequencies individually. EUT SPECTRUM FCC ID: PKW-WAP55AG Report No.: RF910808R02B 83 Issued: Mar. 13, 2003 5.3.7 TEST RESULTS EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 23deg. C, 64%RH, 1005hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) 26dBc Occupied Bandwidth (MHz) PASS/FAIL 1518013.2717.0033.60PASS 4524012.9017.0032.00PASS 5526014.9924.0036.48PASS 8532013.3924.0033.28PASS NOTE: The 26dBc Occupied Bandwidth plot, please refer to the following pages. FCC ID: PKW-WAP55AG Report No.: RF910808R02B 84 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 85 Issued: Mar. 13, 2003 CHANNEL 4 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 86 Issued: Mar. 13, 2003 CHANNEL 5 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 87 Issued: Mar. 13, 2003 CHANNEL 8 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 88 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 89 Issued: Mar. 13, 2003 CHANNEL 4 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 90 Issued: Mar. 13, 2003 CHANNEL 5 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 91 Issued: Mar. 13, 2003 CHANNEL 8 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 92 Issued: Mar. 13, 2003 EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 24deg. C, 65%RH, 1005hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) 26dBc Occupied Bandwidth (MHz) PASS/FAIL 1521013.3117.0048.84PASS 2525013.0417.0048.84PASS 3529012.7524.0047.40PASS NOTE: The 26dBc Occupied Bandwidth plot, please refer to the following pages. FCC ID: PKW-WAP55AG Report No.: RF910808R02B 93 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 94 Issued: Mar. 13, 2003 CHANNEL 2 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 95 Issued: Mar. 13, 2003 CHANNEL 3 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 96 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 97 Issued: Mar. 13, 2003 CHANNEL 2 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 98 Issued: Mar. 13, 2003 CHANNEL 3 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 99 Issued: Mar. 13, 2003 5.4 PEAK POWER EXCURSION MEASUREMENT 5.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHz13dB 5.25 – 5.35 GHz13dB 5.725 – 5.825 GHz13dB 5.4.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: PKW-WAP55AG Report No.: RF910808R02B 100 Issued: Mar. 13, 2003 5.4.3 TEST PROCEDURE 1. The transmitter output was connected to the spectrum analyzer. 2. Set the spectrum bandwidth span to view the entire spectrum. 3. Using peak detector and Max-hold function for Trace 1 (RB=1MHz, VB=3MHz) and 2 (RB=1MHz, VB=100KHz). 4. The largest difference between Trace 1 and Trace 2 in any 1MHz band on any frequency was recorded. 5.4.4 DEVIATION FROM TEST STANDARD No deviation 5.4.5 TEST SETUP 5.4.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at specific channel frequencies individually. EUT SPECTRUM FCC ID: PKW-WAP55AG Report No.: RF910808R02B 101 Issued: Mar. 13, 2003 5.4.7 TEST RESULTS EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 23deg. C, 64%RH, 1005hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER EXCURSION (dB) PEAK to AV E R AG E EXCURSION LIMIT (dB) PASS/FAIL 151808.5613PASS 452408.0513PASS 552608.8113PASS 853209.2213PASS FCC ID: PKW-WAP55AG Report No.: RF910808R02B 102 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 103 Issued: Mar. 13, 2003 CHANNEL 4 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 104 Issued: Mar. 13, 2003 CHANNEL 5 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 105 Issued: Mar. 13, 2003 CHANNEL 8 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 106 Issued: Mar. 13, 2003 EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 24deg. C, 65%RH, 1005hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER EXCURSION (dB) PEAK to AV E R AG E EXCURSION LIMIT (dB) PASS/FAIL 1521010.9713PASS 2525011.6013PASS 3529011.7613PASS FCC ID: PKW-WAP55AG Report No.: RF910808R02B 107 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 108 Issued: Mar. 13, 2003 CHANNEL 2 FCC ID: PKW-WAP55AG Report No.: RF9108…

Text truncated - open the document above for the full version.

FCC ID: PKW-WAP55AG Report No.: RF910808R02B 111 Issued: Mar. 13, 2003 5.5.3 TEST PROCEDURES 1. The transmitter output was connected to the spectrum analyzer. 2. Set RBW=1MHz, VBW=3MHz. The PPSD is the highest level found across the emission in any 1MHz band. 5.5.4 DEVIATION FROM TEST STANDARD No deviation 5.5.5 TEST SETUP 5.5.6 EUT OPERATING CONDITIONS Same as 5.3.6 EUT SPECTRUM ANALYZER FCC ID: PKW-WAP55AG Report No.: RF910808R02B 112 Issued: Mar. 13, 2003 5.5.7 TEST RESULTS EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 23deg. C, 64%RH, 1005hPa TESTED BY Steven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 1 MHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 15180-3.794PASS 45240-4.594PASS 55260-1.8011PASS 85320-2.7811PASS FCC ID: PKW-WAP55AG Report No.: RF910808R02B 113 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 114 Issued: Mar. 13, 2003 CHANNEL 4 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 115 Issued: Mar. 13, 2003 CHANNEL 5 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 116 Issued: Mar. 13, 2003 CHANNEL 8 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 117 Issued: Mar. 13, 2003 EUT Dual-Band Wireless A+G Access Point MODEL WAP55AG MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 24deg. C, 65%RH, 1005hPa TESTED BY Steven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 1 MHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 15210-3.854PASS 25250-5.464PASS 35290-6.6511PASS FCC ID: PKW-WAP55AG Report No.: RF910808R02B 118 Issued: Mar. 13, 2003 CHANNEL 1 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 119 Issued: Mar. 13, 2003 CHANNEL 2 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 120 Issued: Mar. 13, 2003 CHANNEL 3 FCC ID: PKW-WAP55AG Report No.: RF910808R02B 121 Issued: Mar. 13, 2003 5.6 FREQUENCY STABILITY 5.6.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT The frequency tolerance of the carrier signal shall be maintained within +/- 0.02% of the operating frequency over a temperature variation of –30 degrees to 50 degrees C at normal supply voltage, and for a variation in the primary supply voltage from 85% to 115% of the rated supply voltage at a temperature of 20 degrees C. 5.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ANRITSU SPECTRUM ANALYZERMS2667CM10281Mar. 14, 2003 WIT STANDARD TEMPERATURE AND HUMIDITY CHAMBER TH-4S-CW901030Jun. 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 5.6.3 TEST PROCEDURE 1. The EUT was placed inside the environmental test chamber and powered by nominal DC voltage. 2. Turn the EUT on and couple its output to a spectrum analyzer. 3. Turn the EUT off and set the chamber to the highest temperature specified. 4. Allow sufficient time (approximately 30 min) for the temperature of the chamber to stabilize, turn the EUT on and measure the operating frequency after 2, 5, and 10 minutes. 5. Repeat step 2 and 3 with the temperature chamber set to the lowest temperature. 6. The test chamber was allowed to stabilize at +20 degree C for a minimum of 30 minutes. The supply voltage was then ad…

Text truncated - open the document above for the full version.
