PKW-WMP54GV2Wireless-G PCI Adapter

Instant Wireless ® Series User Guide Wireless-G PCI Adapter Use this Guide to install:WMP54G COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. Copyright © 2003 Linksys, All RightsReserved. Instant Wireless, Linksys, and the Linksys logo are registered trademarks ofLinksys Group, Inc. Microsoft, Windows, and the Windows logo are registered trade-marks of Microsoft Corporation. All other trademarks and brand names are the proper-ty of their respective proprietors. LIMITED WARRANTY Linksys guarantees that every Instant Wireless ® Wireless-G PCI Adapter will be free from physical defects in material and workmanship for three years from the date of purchase,when used within the limits set forth in the Specifications section of this User Guide. TT hh ii ss WW aa rr rr aa nn tt yy ii ss vv aa ll ii dd aa nn dd mm aa yy bb ee pp rr oo cc ee ss ss ee dd oo nn ll yy ii nn tt hh ee cc oo uu nn tt rr yy oo ff pp uu rr cc hh aa ss ee .. If the product proves defective during this warranty period, go to the Linksys website at www.linksys.com for complete RMA (Return Merchandise Authorization) assistance. You can also call Linksys Technical Support in order to obtain a RMA Number. BE SURE TOHAVE YOUR PROOF OF PURCHASE AND A BARCODE FROM THE PRODUCT’S PACK-AGING ON HAND WHEN CALLING. RETURN REQUESTS CANNOT BE PROCESSEDWITHOUT PROOF OF PURCHASE. When returning a product, mark the RMA Numberclearly on the outside of the package and include a copy of your original proof of pur-chase. All customers located outside of the United States of America and Canada shallbe held responsible for shipping and handling charges.IN NO EVENT SHALL LINKSYS'S LIABILITY EXCEED THE PRICE PAID FOR THE PROD-UCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAM-AGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFT-WARE, OR ITS DOCUMENTATION. LINKSYS OFFERS NO REFUNDS FOR ITS PROD-UCTS. Linksys makes no warranty or representation, expressed, implied, or statutory,with respect to its products or the contents or use of this documentation and all accom-panying software, and specifically disclaims its quality, performance, merchantability, orfitness for any particular purpose. Linksys reserves the right to revise or update its prod-ucts, software, or documentation without obligation to notify any individual or entity.Please direct all inquiries to:Linksys P.O. Box 18558, Irvine, CA 92623. SAFETY AND REGULATORY NOTICESFCC STATEMENTThe Instant Wireless ® Wireless-G PCI Adapter has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates, uses, and can radiate radio fre-quency energy and, if not installed and used according to the instructions, may causeharmful interference to radio communications. However, there is no guarantee that inter-ference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which is found by turning the equipment offand on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment or devices • Connect the equipment to an outlet other than the receiver's • Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any change or modification to the product not expressly approved byLinksys could void the user's authority to operate the device.FCC RF Radiation Exposure StatementTo comply with the FCC and ANSI C95.1 RF exposure limits, the antenna(s) for thisdevice must comply with the following:• Access points with 2.4 GHz or 5 GHz integrated antenna must operate with a sepa-ration distance of at least 20 cm from all persons using the cable provided and mustnot be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operations for satisfying RF exposure compli-ance.Note: Dual antennas used for diversity operation are not considered co-located.Canadian Department of Communications Industry Canada (IC) NoticeThis Class B digital apparatus complies with Canadian ICES-003 and RSS-210.Cet appareil numérique de la classe B est conforme à la norme NMB-003 et CNR-210du Canada."To prevent radio interference to the licensed service, this device is intended to be oper-ated indoors and away from windows to provide maximum shielding. Equipment (or itstransmit antenna) that is installed outdoors is subject to licensing."" Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'unelicence, il doit être utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournirun écran de blindage maximal. Si le matériel (ou son antenne d'émission) est installé àl'extérieur, il doit faire l'objet d'une licence. "EC DECLARATION OF CONFORMITY (EUROPE)Linksys Group declares that the Instant Wireless ® Series products included in the Instant Wireless ® Series conform to the specifications listed below, following the provisions of the European R&TTE directive 1999/5/EC, EMC directive 89/336/EEC, and Low Voltagedirective 73/23/EEC: For 2.4 GHz devices with 100 mW radios, the following standards were applied: • ETS 300-826, 301 489-1 General EMC requirements for Radio equipment. • EN 609 50 Safety • ETS 300-328-2 Technical requirements for Radio equipment. Caution: This equipment is intended to be used in all EU and EFTA countries. Outdooruse may be restricted to certain frequencies and/or may require a license for operation.Contact local Authority f…

Text truncated - open the document above for the full version.

Wireless-G Notebook Adapter 19 Instant Wireless ® Series 18 The Profiles screen (Figure 7-6) lets you save different configuration profiles for different network setups. You can also import or export profiles. The defaultprofile holds the initial configuration saved when you ran the Setup Wizard.Profile - Name of the connection profile. SSID - The wireless network’s unique name, as set in the connection profile. Profile InformationNetwork Type - The mode of the wireless network currently in use. Transfer Rate - The data transfer rate of the current connection. (In Auto mode, the Adapter dynamically shifts to the fastest data transfer rate possibleat any given time.)Channel - The channel to which the wireless network devices are set. WEP - The status of the WEP encryption security feature. Connect - To connect to a wireless network using a specific profile, select the profile , and click the Connect button. Edit - Select a profile, and click the Edit button to change an existing profile. New - Click the New button to create a new profile. See the next section, “Creating a New Profile,” for detailed instructions. Figure 7-6 Profiles Site InformationWireless Mode - The mode of the wireless network currently in use. Channel - The channel to which the wireless network devices are set. WEP - The status of the WEP encryption security feature. MAC - The MAC address of the wireless network’s access point. Surveyed at - The time at which the wireless network was scanned. Refresh - Click the Refresh button to perform a new search for wireless devices. Connect - To connect to one of the networks on the list, select the wireless net- work , and click the Connect button. If the wireless network has WEP encryp- tion enabled, you will see the screen shown in Figure 7-5.In the WEP drop-down box, select the type of WEP encryption used by the wireless network: 64-bit , or 128-bit WEP. If the wireless network uses a passphrase, enter the passphrase in thePassphrase field. If the wireless network uses a WEP key, enter the WEP key in the Key 1 field. Click the OK button to complete the network connection and return to the Site Survey screen, or click the Cancel button to cancel the network connection and return to the Site Survey screen. On the Site Survey screen, click the X (Close) button in the upper right corner to exit the WLAN Monitor. Figure 7-5 Wireless-G Notebook Adapter1. On the Profiles screen, shown in Figure 7-6, click the New button to create a new profile. 2. When the Create connection profile screen appears (Figure 7-9), enter a name for the newprofile. Click OK to save the profile name or click Cancel to return to the previousscreen. 3. The Choose a network type screen (Figure 7-10) shows a choice of two wireless modes. Click the Infrastructure Mode radio button if you want your wireless computers to communicate with computers on your wirednetwork via a wireless access point. Click the Ad-Hoc Mode radio button if you want multiple wireless computers to communicate directly with eachother. Click the Next button to continue or the Back button to return to the previous screen.Infrastructure Mode - This mode allows wireless and wired networks to communicate through an access point.Ad-Hoc Mode - This mode allows wireless-equipped computers to com- municate directly with each other. No access point is used. 21 Instant Wireless ® Series 20 Figure 7-10 Figure 7-9 Creating a New Profile Import - Click the Import but- ton to import aprofile that hasbeen saved inanother location.From the screenthat appears(shown in Figure7-7), select theappropriate file,and click theOpen button. Export - To save the profile(s) in a different location, click theExport button. On the screen that appears (Figure 7-8), directWindows to the appropriate fold-er and click the OK button. Delete - Click the Delete button to delete a profile. Click the X (Close) button in the upper right corner to exit the WLAN Monitor. Figure 7-7 Figure 7-8 Note: If you have more than one profile, all profiles will be auto- matically selected and exported to the same folder. Wireless-G Notebook Adapter 23 Instant Wireless ® Series 4. The Wireless Settings screen (Figure 7-11) will appear. If you chose Infrastructure Mode, go to Step 5 now. If you chose Ad-Hoc Mode, select the correct operating channel for your network from the Channel drop- down menu. Then, select the Network Mode from the drop-down menu. Click the Next button, and go to Step 5 . Click the Back button to change any settings.Channel - The channel you choose should match the channel set on the other devices in your wireless network. If you are unsure about which chan-nel to use, select the default channel (Channel 6).Network Mode - Select Mixed Mode , and both Wireless-G and Wireless- B computers will be allowed on the network, but the speed will be reduced.Select G-Only Mode for maximum speed, but no Wireless-B users will be allowed on the network. 5. The Network Setting screen (Figure 7-12) will appear. If your network has a DHCP server, click the radio button next to Obtain an IP address automatically (DHCP) . Click the Next button to continue, or click the Back button to return to the previous screen. 22 If your network does not have a DHCP server, click the radio button next toSpecify the IP address . Enter an IP Address , Subnet Mask , Default Gateway , and DNS appropriate for your network. Enter each address in this format: xxx.xxx.xxx.xxx (the x’s represent the numbers that make up each address). You must specify the IP Address and Subnet Mask on this screen.If you are unsure about the Default Gateway and DNS addresses, then leavethese fields alone. IP Address - This IP Address must be unique to your network. Subnet Mask - The Adapter’s Subnet Mask must be the same as your wired network’s Subnet Mask.Default Gateway - Enter the IP address of your network’s Gateway here. DNS - Enter the DNS addresses of your Ethernet (wired) network here. Click the Next button to continue o…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 May 29, 2003 RE: FCC ID: PKW -WMP54GV2 Attention: Ellis Wu I have a few comments on this Application. 1. FYI – no action needed. Please note that conducted emissions IAW CFR47 part 15 is both QP and Average and both margins should be in the report. Generally if the QP reading or the peak reading is below the average limit the device is considered compliant. But these readings need to be compared to both the QP and average limits. This is especially true when the average reading has not been taken and the QP of peak is used to show compliance to the average limit but these readings are close to the average limit. For example, if no average reading was taken and the QP reading was 11dB under the QP limit, the actual margin is only 1dB from the average limit. 2. The typical gain of a dipole antenna is 2.14dBi. Your report states the gain of the dipole is 5dBi. Please verify that this is a dipole and that this is the actual gain. Please explain why the gain is so much higher than would be expected from a normal 1/4 dipole antenna. If this is not a dipole but some other kind of antenna, please explain. Using full wave dipole Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

WMP54GV2_Label-1 (952x559x16M jpeg) WMP54GV2_Label-2 (970x776x16M jpeg)

Page 3 Page 4 Page 5

FCC ID: PKW-WMP54GV2 ADT No.920502R01 Operational Description This device is a Wireless-G PCI Adapter which operates in the 2.4Ghz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment via a PCI interface. The antenna is Dipole antenna with Reversed SMA connector. The other instruction, please have a look at the users manual.

FCC ID: PKW-WMP54GV2 ADT No.: 920502R01 FCC TEST REPORT REPORT NO.: RF920502R01 MODEL NO.: WMP54G ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:The Linksys Group, INC. ADDRESS:17401 Armstrong Ave. Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WMP54GV2 ADT No.: 920502R01 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20cm away from the body of the user. Warning statement for keeping 20cm separation distance and the prohibition of operating next to a person has been printed on the user’s manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: PKW-WMP54GV2 ADT No.: 920502R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at the distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: PKW-WMP54GV2 ADT No.: 920502R01 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 5dBi or 3.162 (numeric). 6.2 Output Power Into Antenna & RF Exposure at distance 20cm: For 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241222.590.0141.0 6243731.120.0201.0 11246222.230.0141.0 For 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241228.310.0181.0 6243730.830.0191.0 11246226.670.0171.0 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: PKW-WMP54GV2 Report No.: RF920502R01 1 Issued: May 19, 2003 FCC TEST REPORT REPORT NO.: RF920502R01 MODEL NO.: WMP54G RECEIVED: Apr. 21, 2003 TESTED: Apr. 22, 2003 ~ May 5, 2003 APPLICANT:The Linksys Group, Inc. ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 61 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WMP54GV2 Report No.: RF920502R01 2 Issued: May 19, 2003 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS.................................................................11 4.1.7TEST RESULTS.......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2TEST INSTRUMENTS ................................................................................ 19 4.2.3TEST PROCEDURES................................................................................. 20 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 20 4.2.5TEST SETUP .............................................................................................. 21 4.2.6EUT OPERATING CONDITIONS................................................................ 21 4.2.7TEST RESULTS.......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 29 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 29 4.3.2TEST INSTRUMENTS ................................................................................ 29 4.3.3TEST PROCEDURE ................................................................................... 30 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 30 4.3.5TEST SETUP .............................................................................................. 30 4.3.6EUT OPERATING CONDITIONS................................................................ 30 4.3.7TEST RESULTS.......................................................................................... 31 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 39 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 39 4.4.2TEST INSTRUMENTS ................................................................................ 39 FCC ID: PKW-WMP54GV2 Report No.: RF920502R01 3 Issued: May 19, 2003 4.4.3TEST PROCEDURES................................................................................. 40 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 40 4.4.5TEST SETUP .............................................................................................. 40 4.4.6EUT OPERATING CONDITIONS................................................................ 40 4.4.7TEST RESULTS.......................................................................................... 41 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 42 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 42 4.5.2TEST INSTRUMENTS ................................................................................ 42 4.5.3TEST PROCEDURE ................................................................................... 43 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 43 4.5.5TEST SETUP .............................................................................................. 43 4.5.6EUT OPERATING CONDITIONS................................................................ 43 4.5.7TEST RESULTS.......................................................................................... 44 4.6BAND EDGES MEASUREMENT ................................................................ 52 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 52 4.6.2TEST INSTRUMENTS ................................................................................ 52 4.6.3TEST PROCEDURE ..........................…

Text truncated - open the document above for the full version.

FCC ID: PKW-WMP54GV2 Report No.: RF920502R01 59 Issued: May 19, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PKW-WMP54GV2 Report No.: RF920502R01 60 Issued: May 19, 2003 RADIATED EMISSION TEST
