PKW-WRT55AGDual-Band Wireless A+G Broadband Router

Instant Wireless ® Series Dual-Band WirelessA+G Broadband RouterUse this guide to install:WRT55AG User Guide FCC Caution: Any change or modification to the product not expressly approved byLinksys could void the user's authority to operate the device.FCC Caution: Operation within the 5150 to 5250GHz band is restricted to indoor use only.FCC RF Radiation Exposure StatementTo comply with the FCC and ANSI C95.1 RF exposure limits, the antenna(s) for thisdevice must comply with the following:• Access points with 2.4 GHz or 5 GHz integrated antenna must operate with a sepa-ration distance of at least 20 cm from all persons using the cable provided and mustnot be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operations for satisfying RF exposure compli-ance.Note: Dual antennas used for diversity operation are not considered co-located.Canadian Department of Communications Industry Canada (IC) NoticeThis Class B digital apparatus complies with Canadian ICES-003 and RSS-210.Cet appareil numérique de la classe B est conforme à la norme NMB-003 et CNR-210du Canada."To prevent radio interference to the licensed service, this device is intended to be oper-ated indoors and away from windows to provide maximum shielding. Equipment (or itstransmit antenna) that is installed outdoors is subject to licensing."" Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'unelicence, il doit être utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournirun écran de blindage maximal. Si le matériel (ou son antenne d'émission) est installé àl'extérieur, il doit faire l'objet d'une licence. "EC DECLARATION OF CONFORMITY (EUROPE)Linksys Group declares that the Instant Wireless ® Series products included in the Instant Wireless ® Series conform to the specifications listed below, following the provisions of the European R&TTE directive 1999/5/EC, EMC directive 89/336/EEC, and Low Voltagedirective 73/23/EEC: For 11Mpbs, 2.4 GHz access points with 100 mW radios, the following standards wereapplied: • ETS 300-826, 301 489-1 General EMC requirements for Radio equipment. • EN 609 50 Safety • ETS 300-328-2 Technical requirements for Radio equipment. For 54 Mpbs, 5 GHz access points with 40 mW radios, the following standards wereapplied: • ETS 301 489-1, 301 489-17 General EMC requirements for Radio equipment. • EN 609 50 Safety • ETS 301-893 Technical requirements for Radio equipment. Caution: The frequencies used by 802.11a wireless LAN devices are not yet harmonizedwithin the European community, 802.11a products are designed for use only in specificcountries, and are not allowed to be operated in countries other than those of designat-ed use. Contact local Authority for procedure to follow.Caution: This equipment is intended to be used in all EU and EFTA countries. Outdooruse may be restricted to certain frequencies and/or may require a license for operation.Contact local Authority for procedure to follow. COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. Copyright © 2003 Linksys, All RightsReserved. Instant Wireless, Linksys, and the Linksys logo are registered trademarks ofLinksys Group, Inc. Microsoft, Windows, and the Windows logo are registered trade-marks of Microsoft Corporation. All other trademarks and brand names are the proper-ty of their respective proprietors. LIMITED WARRANTY Linksys guarantees that every Instant Wireless Dual-Band Wireless A+G BroadbandRouter will be free from physical defects in material and workmanship for one year fromthe date of purchase, when used within the limits set forth in the Specifications sectionof this User Guide. If the product proves defective during this warranty period, callLinksys Technical Support in order to obtain a Return Authorization number. BE SURE TOHAVE YOUR PROOF OF PURCHASE ON HAND WHEN CALLING. When returning aproduct, mark the Return Authorization number clearly on the outside of the package andinclude a copy of your original proof of purchase. RETURN REQUESTS CANNOT BEPROCESSED WITHOUT PROOF OF PURCHASE. All customers located outside of theUnited States of America and Canada shall be held responsible for shipping and han-dling charges.IN NO EVENT SHALL LINKSYS'S LIABILITY EXCEED THE PRICE PAID FOR THE PROD-UCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAM-AGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFT-WARE, OR ITS DOCUMENTATION. LINKSYS OFFERS NO REFUNDS FOR ITS PROD-UCTS. Linksys makes no warranty or representation, expressed, implied, or statutory,with respect to its products or the contents or use of this documentation and all accom-panying software, and specifically disclaims its quality, performance, merchantability, orfitness for any particular purpose. Linksys reserves the right to revise or update its prod-ucts, software, or documentation without obligation to notify any individual or entity.Please direct all inquiries to:Linksys P.O. Box 18558, Irvine, CA 92623. SAFETY AND REGULATORY NOTICESFCC STATEMENTThe Instant Wireless Dual-Band Wireless A+G Broadband Router has been tested andfound to comply with the specifications for a Class B digital device, pursuant to Part 15of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates, uses, and can radiate radio fre-quency energy and, if not installed and used according to the instructions, may causeharmful interference to radio communications. However, there is no guarantee that inter-ference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or televisio…

Text truncated - open the document above for the full version.

Dual-Band Wireless A+G Broadband Router 5GHz, 802.11a (WEP)The 5GHz, 802.11a (WEP) screen, shown in Figure 7-9, allows you to config- ure your 5GHz,802.11a WEPsettings. WEPencryptionshould alwaysbe enabled toincrease thesecurity of yourwireless net-work.Default Transmit Key Select which WEP key (1-4) will be used when the Router sends data. Make sure the receiver is using the same key.WEP Encryption Keys 1-4 offer 64-bit, 128-bit, or 152-bit encryption; select the type of encryption you want from the drop-down box. To disable WEPEncryption, select Disable . Passphrase (Complete this field when using 64-bit or 128-bit encryption.) Instead of manually entering WEP keys, you can enter a Passphrase. ThisPassphrase is used to generate one or more WEP keys. It is case-sensitive andshould not be longer than 16 alphanumeric characters. This Passphrase functionis compatible with Linksys wireless products only. [If you want to communi-cate with non-Linksys wireless products, enter the WEP key(s) manually on thenon-Linksys wireless products.] After you enter the Passphrase, click theGenerate button to create WEP keys. Keys 1-4 WEP keys enable you to create an encryption scheme for wireless LAN transmissions. Manually enter a set of values. (Do not leave a key fieldblank, and do not enter all zeroes. These are not valid key values.) Keys 1-4offer 64-bit, 128-bit, or 152-bit encryption.If you are using 64-bit WEP encryption, then the key must be exactly 10 hexa-decimal characters in length. If you are using 128-bit WEP encryption, then thekey must be exactly 26 hexadecimal characters in length. If you are using 152-bit WEP encryption, then the key must be exactly 32 hexadecimal characters inlength. Valid hexadecimal characters are “0”-“9” and “A”-“F”. 41 Figure 7-9 Instant Wireless ® Series 5GHz, 802.11aThe 5GHz, 802.11a portion of the Setup screen, shown in Figure 7-8, allows you to configure your 5GHz, 802.11a wireless network settings.Mode If you do not have any 802.11a devices in your network, you can dis- able this broadcasting by selecting Disable . Channel Select the appropriate channel from the list provided to correspond with your network settings, between 36 and 64. All devices in your wirelessnetwork must use the same channel in order to function correctly. If you wantthe Router to automatically scan for a clear channel, then click the checkbox.SSID The SSID is the network name shared among all points in a wireless network. The SSID must be identical for all points in the wireless network. Itis case-sensitive and must not exceed 32 characters (use any of the characterson the keyboard). Make sure this setting is the same for all points in your wire-less network. For added security, you should change the default SSID ( linksys ) to a unique name.WEP (Encryption) An acronym for Wired Equivalent Privacy, WEP is an encryption method used to protect your wireless data communications. WEPuses 64-bit, 128-bit, or 152-bit keys to provide access control to your networkand encryption security for every data transmission. To decode a data trans-mission, each device in a network must use an identical key. Higher encryptionlevels offer higher levels of security, but due to the complexity of the encryp-tion, they may decrease network performance. To enable WEP, click the radiobutton beside Enable . Click the Edit WEP Settings button to configure the WEP keys for your 5GHz, 802.11a wireless network (see Figure 7-9).Check all the values, and click the Apply button to save your 5GHz, 802.11a settings. To cancel any changes you’ve entered on this page, click the Cancel button. To get more information about the features, click the Help button. 40 Figure 7-8 Dual-Band Wireless A+G Broadband Router 43 42 WEP (Encryption) An acronym for Wired Equivalent Privacy, WEP is an encryption method used to protect your wireless data communications. WEPuses a combination of 64-bit or 128-bit keys to provide access control to yournetwork and encryption security for every data transmission. To decode a datatransmission, each device in a network must use an identical 64-bit or 128-bitkey. Higher encryption levels offer higher levels of security, but due to thecomplexity of the encryption, they may decrease network performance. Toenable WEP, click the radio button beside Enable . Click the Edit WEP Settings button to configure the WEP keys for your 2.4GHz, Wireless-G net- work (see Figure 7-11).Check all the values, and click the Apply button to save your 2.4GHz, Wireless- G settings. To cancel any changes you’ve entered on this page, click the Cancel button. To get more information about the features, click the Help button. 2.4GHz, 54g/Wireless-G (WEP)The 2.4GHz, 802.11b (WEP) screen, shown in Figure 7-11, allows you to con- figure your 2.4GHz, Wireless-G WEP settings. WEP encryption is recom-mended toincrease thesecurity ofyour wirelessnetwork.Default Transmit Key Select which WEP key (1-4) will be used when the Router sends data. Make sure the receiver is using the same key.WEP Encryption Keys 1-4 offer 64-bit or 128-bit encryption; select the type of encryption you want from the drop-down box. To disable WEP Encryption,select Disable . Figure 7-11 Instant Wireless ® Series Check all the values, and click the Apply button to save your 5GHz, 802.11a WEP settings. To cancel any changes you’ve entered on this page, click theCancel button. To get more information about the features, click the Help but- ton.2.4GHz, 54g/Wireless-G The 2.4GHz, 802.11g-draft portion of the Setup screen, shown in Figure 7-10 allows you to configure your 2.4GHz, Wireless-G wireless network settings.Mode If you have Wireless-G and 802.11b devices in your network, then keep the default setting, Mixed . If you have only Wireless-G devices, select G-Only . If you do not have any Wireless-G and 802.11b devices in your network, selectDisable . Channel Select the appropriate channel from the list provided to correspond with your network settings, between 3…

Text truncated - open the document above for the full version.

InternetConfiguration Type The type of Internet connection is displayed here. Status For PPPoE or PPTP, the status of the Internet connection is displayed here. If there is no connection, you can click the Connect button to re-estab- lish it. If there is a connection, you can click the Disconnect button to end it. IP Address, Subnet Mask, and Default Gateway The Router’s IP Address, Subnet Mask, and Default Gateway Address, as seen by external users on theInternet, are displayed here.DNS The DNS (Domain Name System) IP Addresses currently used by the Router are shown here. Multiple DNS IP settings are common. In most cases,the first available DNS entry is used.To refresh the Status screen, click the Refresh button. To get more information about the features, click the Help button. The Help screen, shown in Figure 7-19, offers links to all of the Router’s tech- nical support resources and the application that upgrades the Router’sfirmware. For additional information about each screen of the web-based util-ity, click the appropriate link on the lefthand side of the Help screen. 55 Instant Wireless ® Series 54 Dual-Band Wireless A+G Broadband Router Firmware Version The version number of the firmware currently installed is displayed here.Current Time The current time, as set from the Setup tab, is displayed here. Host Name The Host Name is the name of the Router. This entry is necessary for some ISPs.Domain Name The Domain Name is the name of the Router's domain. This entry is necessary for some ISPs.LANIP Address and Subnet Mask The current IP Address and Subnet Mask of the Router, as seen by users on your local area network (LAN), are displayedhere. DHCP Server The status of the Router's DHCP server function is displayed here.Wireless 5GHz, 802.11aMode The Mode setting, as set from the Setup tab, is displayed here. SSID The SSID of the 5GHz, 802.11a network is displayed here. Channel The channel for the 5GHz, 802.11a wireless network is displayed here.Encryption Function The status of the WEP encryption is displayed here. Wireless 2.4GHz, Wireless-GMode The Mode setting, as set from the Setup tab, is displayed here. SSID The SSID of the 2.4GHz, 802.11b network is displayed here. Channel The channel for the 2.4GHz, 802.11b wireless network is displayed here.Encryption Function The status of the WEP encryption is displayed here. Help Figure 7-19 Dual-Band Wireless A+G Broadband Router Wireless MAC FiltersWireless access can be filtered by using the MAC addresses of the wirelessdevices transmitting within your network’s radius. Select Enable from the drop-down menu and choose if you wish to Prevent wireless access by MAC addressor Permit by MAC Address. Then, click the Edit MAC Filter List button toaccess a secondary screen, where you can enter the MAC Addresses of thedevices you wish to filter.5GHz, 802.11aAuthentication Type The default is set to Auto , which allows either Open System or Shared Key authentication to be used. For Open System authentica-tion, the sender and the recipient do NOT use a WEP key for authentication.For Shared Key authentication, the sender and recipient use a WEP key forauthentication. If you want to use only Shared Key authentication, then selectShared Key . 57 Figure 7-20 Linksys Website Clicking this link will take you to Linksys’s website, www.linksys.com , provided you are connected to the Internet. Online User Guide in PDF Format and Adobe Website Clicking the Online User Guide in PDF format link opens the Router’s User Guide. The User Guide is in Adobe Acrobat Portable Document File (.pdf) format, so you needthe Adobe Acrobat Reader to view it. If you do not have the Acrobat Reader,click the Adobe website link to download it. The following instructions are for advanced users or users whose setup needsrequire special configuration. When you click the Advanced tab, you will be able to set up these features. There are six additional tabs available. Advanced Wireless - Allows you to customize data transmission and 802.1x settings for your wireless network(s).Internet Filter - Enables you to set up filters that block specific internal users from Internet access.Port Forwarding - Lets you set up public services on your network, such as an ftp server, mail server, or web server.Routing - Enables you to configure the routing mode of the Router. DDNS - Allows you to enable the Dynamic Domain Name System (DDNS) feature, so a fixed domain name can be assigned to a dynamic Internet IPaddress.If you need to access the basic configuration tabs, click the Setup tab. The Advanced Wireless screen, shown in Figure 7-20, allows you to customize data transmission settings. In most cases, the advanced wireless settings on thisscreen should remain at their default values. 56 Instant Wireless ® Series Advanced Tabs Advanced Wireless Dual-Band Wireless A+G Broadband Router 59 Transmission Rate The rate of data transmission should be set depending on the speed of your wireless network. You can select from a range of transmissionspeeds ( 6 , 9 , 12 , 18 , 24 , 36 , 48 , or 54 Mbps), or you can select Auto to have the Router automatically use the fastest possible data rate and enable the Auto-Fallback feature. Auto-Fallback will negotiate the best possible connectionspeed between the Router and a wireless client. The default value is Auto . Transmit Power Control The greater the transmit power used, the larger the area a wireless network covers. To minimize the likelihood of eavesdropping byunauthorized wireless users, do not use more transmit power than necessary tocover the range needed for your wireless network. Try using the Router at dif-ferent levels of transmit power, and determine how much transmit power isneeded to reach the wireless client, such as a PC, or access point that is farthestfrom the Router. Then select the appropriate level of transmit power ( Full , Half , Quarter , Eighth , or Min ) from the drop-down menu. The default value is Full . Beacon Interval The defa…

Text truncated - open the document above for the full version.

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: Dual-Band Wireless A+G Broadband Router MODEL NO.: WRT55AG TRADE NAME: Linksys IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: RF911005R01A THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION： ManufacturerUSA Local Representative Company name: The Linksys Group, Inc. To Be Determined. Address: 17401 Armstrong Ave., Irvine, CA 92614 Contact Person: Frank Hung Title: Product Management Te l / F a x : (949) 784-1820 (949) 261-1168

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6

Page 7 Page 8 Page 9

Page 10 Page 11 Page 12

FCC ID: PKW-WRT55AG ADT No.911005R01A Technical Description The transmitter of the EUT is powered by power adapter and connected with PC through RJ45 port. The antenna is Dipole antenna. There is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a Dual-Band Wireless A+G Broadband Router which operates in both the 5GHz and 2.4GHz bands and can be operated simultaneously. The total MPE of these combination is shorter than 20cm and the maximum data rate could be 72Mbps. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states : The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No: 911005R01A 1 FCC TEST REPORT REPORT NO.: RF911005R01A MODEL NO.: WRT55AG ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:The Linksys Group, Inc. ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 Report No: 911005R01A 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz Report No: 911005R01A 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. Report No: 911005R01A 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 2dBi or 1.58(numeric) for 2.4GHz band and 1dBi or 1.26(numeric) for 5GHz band. 6.2 Output Power Into Antenna & RF Exposure Distance : For Part 802.11b (OFDM technique): CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 12412114.823.81 62437114.823.81 112462112.203.76 For Part 802.11a: Normal Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1518025.001.58 4524020.091.42 5526033.271.83 8532021.131.46 Turbo Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1521017.861.34 2525015.141.23 3529012.471.77 The minimum allowable distance (1.83+3.81=5.64) is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20cm separation distance with the antenna.

FCC ID: PKW-WRT55AG Report No.: RF911005R01A 1 Issued: Mar. 13, 2003 FCC TEST REPORT REPORT NO.: RF911005R01A MODEL NO.: WRT55AG RECEIVED: Feb. 20, 2003 TESTED: Feb. 21 ~ Mar. 13, 2003 APPLICANT:The Linksys Group, Inc. ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 137 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WRT55AG Report No.: RF911005R01A 2 Issued: Mar. 13, 2003 Table of Contents 1CERTIFICATION........................................................................................... 5 2SUMMARY OF TEST RESULTS .................................................................. 6 3GENERAL INFORMATION ........................................................................... 8 3.1GENERAL DESCRIPTION OF EUT ...................................................................................... 8 3.2DESCRIPTION OF TEST MODES ........................................................................................ 9 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ..................................................... 10 3.4DESCRIPTION OF SUPPORT UNITS................................................................................. 11 4TEST TYPES AND RESULTS (For Part 802.11b and 802.11g).................. 12 4.1CONDUCTED EMISSION MEASUREMENT....................................................................... 12 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 12 4.1.2TEST INSTRUMENTS ......................................................................................................... 12 4.1.3TEST PROCEDURES .......................................................................................................... 13 4.1.4DEVIATION FROM TEST STANDARD ................................................................................ 13 4.1.5TEST SETUP ....................................................................................................................... 14 4.1.6EUT OPERATING CONDITIONS......................................................................................... 14 4.1.7TEST RESULTS ................................................................................................................... 15 4.2RADIATED EMISSION MEASUREMENT ............................................................................ 21 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 21 4.2.2TEST INSTRUMENTS ......................................................................................................... 22 4.2.3TEST PROCEDURES .......................................................................................................... 23 4.2.4DEVIATION FROM TEST STANDARD ................................................................................ 23 4.2.5TEST SETUP ....................................................................................................................... 24 4.2.6EUT OPERATING CONDITIONS......................................................................................... 24 4.2.7TEST RESULTS ................................................................................................................... 25 4.2.8TEST RESULTS (A) ............................................................................................................. 27 4.2.9TEST RESULTS (B) ............................................................................................................. 30 4.36dB BANDWIDTH MEASUREMENT ................................................................................... 33 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 33 4.3.2TEST INSTRUMENTS ......................................................................................................... 33 4.3.3TEST PROCEDURE ............................................................................................................34 4.3.4DEVIATION FROM TEST STANDARD ................................................................................ 34 4.3.5TEST SETUP ....................................................................................................................... 34 4.3.6EUT OPERATING CONDITIONS......................................................................................... 34 4.3.7TEST RESULTS (A) ............................................................................................................. 35 4.3.8TEST RESULTS (B) ............................................................................................................. 39 4.4MAXIMUM PEAK OUTPUT POWER .......................…
