FCC ID: PKW-WUSB11 Report No.: RF90011014-11Issued: April 18, 2001 ANNEX 2 PHOTOGRAPHS OF EUT FCC ID: PKW-WUSB11 Report No.: RF90011014-12Issued: April 18, 2001

FCC ID: PKW-WUSB11 Report No.: RF90011014-13Issued: April 18, 2001 FCC ID: PKW-WUSB11 Report No.: RF90011014-14Issued: April 18, 2001

FCC ID: PKW-WUSB11 Report No.: RF90011014-1 1 Issued: April 18, 2001 FCC TEST REPORT REPORT NO.: RF90011014-1 MODEL NO.: WUSB11 RECEIVED: January 10, 2001 TESTED: January 30, 2001 APPLICANT: The Linksys Group, Inc. ADDRESS: 17401 Armstrong Ave. Irvine, CA 92614, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 13-1, Lane 19, Wen Shan 3 rd St., Kweishan, Taoyuan Hsien, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Accredited Laboratory FCC ID: PKW-WUSB11 Report No.: RF90011014-1 2 Issued: April 18, 2001 Table of Contents 1CERTIFICATION ..................................................................................................... 4 2SUMMARY OF TEST RESULTS............................................................................ 5 3GENERAL INFORMATION ................................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................ 6 3.2DESCRIPTION OF TEST MODES .............................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ........................................................ 7 3.5CONFIGURATION OF SYSTEM UNDER TEST ......................................... 7 4TEST PROCEDURES AND TEST RESULTS ........................................................ 8 4.1CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..................................................... 8 4.1.2TEST INSTRUMENTS ..........................................................................................................8 4.1.3TEST PROCEDURES...........................................................................................................9 4.1.4TEST SETUP ...................................................................................................................... 10 4.1.5TEST RESULTS.................................................................................................................. 11 4.2RADIATED EMISSION MEASUREMENT.................................................. 17 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT........................................................ 17 4.2.2TEST INSTRUMENTS ........................................................................................................ 18 4.2.3TEST PROCEDURES......................................................................................................... 19 4.2.4TEST SETUP ...................................................................................................................... 20 4.2.5TEST RESULTS.................................................................................................................. 21 4.36dB BANDWIDTH MEASUREMENT ......................................................... 25 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ............................................................... 25 4.3.2TEST INSTRUMENTS ........................................................................................................ 25 4.3.3TEST PROCEDURE ........................................................................................................... 26 4.3.4TEST SETUP ...................................................................................................................... 26 4.3.5EUT OPERATING CONDITION.......................................................................................... 26 4.3.6TEST RESULTS.................................................................................................................. 27 4.4MAXIMUM PEAK OUTPUT POWER......................................................... 31 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.................................. 31 4.4.2INSTRUMENTS .................................................................................................................. 31 4.4.3TEST PROCEDURES......................................................................................................... 32 4.4.4TEST SETUP ...................................................................................................................... 32 4.4.5EUT OPERATING CONDITION.......................................................................................... 32 4.4.6TEST RESULTS.................................................................................................................. 33 4.5POWER SPECTRAL DENSITY MEASUREMENT .................................... 34 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT .......................................... 34 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 3 Issued: April 18, 2001 4.5.2TEST INSTRUMENTS ........................................................................................................ 34 4.5.3TEST PROCEDURE ........................................................................................................... 35 4.5.4TEST SETUP ...................................................................................................................... 35 4.5.5EUT OPERATING CONDITION.......................................................................................... 35 4.5.6TEST RESULTS.................................................................................................................. 36 4.6BAND EDGES MEASUREMENT .............................................................. 40 4.6.1LIMITS OF BAND EDGES MEASUREMENT..................................................................... 40 4.6.2TEST I…

Text truncated - open the document above for the full version.

FCC ID: PKW-WUSB11 Report No.: RF90011014-1 34 Issued: April 18, 2001 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Limit of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Aug. 04, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: PKW-WUSB11 Report No.: RF90011014-1 35 Issued: April 18, 2001 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP For the actual test configuration, please refer to the related Item – Photographs of the Test Configuration. 4.5.5 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Attenuator FCC ID: PKW-WUSB11 Report No.: RF90011014-1 36 Issued: April 18, 2001 4.5.6 TEST RESULTS EUTInstant Wireless USB Network AdapterModelWUSB11 Environmental Conditions 20°C, 60%RHTe s t e d B ySteven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 KHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAI L 12412-12.348PASS 62437-11.428PASS 112462-11.378PASS FCC ID: PKW-WUSB11 Report No.: RF90011014-1 37 Issued: April 18, 2001 CH1 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 38 Issued: April 18, 2001 CH6 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 39 Issued: April 18, 2001 CH11 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 40 Issued: April 18, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz RB). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Aug. 04, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: PKW-WUSB11 Report No.: RF90011014-1 41 Issued: April 18, 2001 4.6.4 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. 4.6.5 TEST RESULTS The spectrum plots are attached below. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). FCC ID: PKW-WUSB11 Report No.: RF90011014-1 42 Issued: April 18, 2001 4.6.6 NOTE ON BAND EDGE EMISSION The band edge emission plot on page 44. shows 43.3dB delta between carrier maximum power and local maximum emission in restrict band (2.484GHz). The emission of carrier strength list in table of page 24 is 94.4dBμV/m, so the maximum field strength in restrict band is 94.4-43.3=51.1 dBμV/m which is under 54 dBμV/m limit. FCC ID: PKW-WUSB11 Report No.: RF90011014-1 43 Issued: April 18, 2001 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 44 Issued: April 18, 2001 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 45 Issued: April 18, 2001 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6 dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is Ceramic Patch Antenna. There is no antenna connector. And the maximum Gain of this antenna is only -2dBi. FCC ID: PKW-WUSB11 Report No.: RF90011014-1 46 Issued: April 18, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PKW-WUSB11 Report No.: RF90011014-1 47 Issued: April 18, 2001 RADIATED EMISSION TEST FCC ID: PKW-WUSB11 Report No.: RF90011014-1 48 Issued: April 18, 2001 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited by the following approval agencies according to ISO/IEC Guide 25 or EN 45001: USA FCC, NVLAP Germany TUV Rheinland Japan VCCI New Zealand RFS Norway NEMKO, DNV U.K. INCHCAPE R.O.C. BSMI Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Design Center: Tel: 886-2-26093195 Fax: 886-2-26093184 Email: [email protected] Web Site: www.adt.com.tw

FCC ID: PKW-WUSB11 Report No.: RF90011014-1 1 Issued: April 18, 2001 ANNEX 1 PROCESSING GAIN OF DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT 1. 1.1. 1. LIMITS OF PROCESSING GAIN OF A DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT The limit of processing gain is 10dB 1.1 TEST INSTRUMENTS & SUPPORT UNIT Description & ManufacturerModel No.Serial No. Anritsu Spectrum Analyzer, 9kHz to 30GHz MS2667CM10281 Anritsu Signal Generator, 10kHz to 20GHz 68247B984703 Hewlett Packard Power Meter,HP438A2743A04416 Hewlett Packard Power Sensor, -30 to 20dBm 8485A2942A08387 Hewlett Packard Step Attenuator, 10dB steps HP8496B3247A18505 Mini-Circuits Power SplitterZN2PD-9GNA DELL Laptop ComputerInspiron 5000eNA Campaq Laptop ComputerPPX99125 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 2 Issued: April 18, 2001 1.2 METHOD OF MEASUREMENT The processing gain may be measured using the CW jamming margin method. Section 4.7.4 shows the test configuration. The test consists of stepping a signal generator in 50 kHz increments across the passband of the system. At each point, the generator level required to produce the recommended Bit Error Rate (BER) is recorded. This level is jammer level. The output power of the transmitting unit is measured at the same point. The jammer to Signal (J/S) ratio is then calculated. Discard the worst 20% of the J/S data points. The lowest remaining J/S ratio is used when calculating the Process Gain. The reference PER is specified as 8%. The corresponding Es/No (signal to noise ratio per symbol) is 16.4 dB. The curve is attached as below. This value and the measured J/S ratio are used in the following equation to calculate the Process Gain (Gp) of the system. Where: (S/N) o : Signal to noise ratio for the chosen BER. Gp = (S/N) o +Mj+Lsys FCC ID: PKW-WUSB11 Report No.: RF90011014-1 3 Issued: April 18, 2001 Mj : Maximum jammer to Signal Ratio recorded at the detected BER. Lsys : System losses . For the purpose of this processing gain calculation, we assume Lsys at its minimum value of 2 dB. TEST SETUP 7 NOTEBOOK EUT ANRITSU SIGNAL GENERATOR EUT NOTEBOOK PWR SENSOR 8485A Power meter HP 438A Mini-Circuits 15542 ZNZPD-9G HP8496D STEP ATTN 110dB (10dB steps) Matched Cables RECEIVER Transmitter FCC ID: PKW-WUSB11 Report No.: RF90011014-1 4 Issued: April 18, 2001 1.3 TEST PROCEDURES Obtain the simplex link shown. Perform all independent instrumentation calibrations prior to this procedure. Set operating power levels using fixed and variable attenuators in system to meet the following objectives: Signal Power at receiver approximately –55dBm (above thermal sensitivity such that thermal noise does not cause bit errors. Signal Power at power meter between –20 and –30dBm for optimal linearity. Use spectrum analyzer to monitor test. Ensure that CW Jammer generator RF output is disabled and measure the power at the power meter port using the power meter. This is the relative signal power, Sr. Disable Transmitter, and set CW Jammer generator RF output frequency equal to the carrier frequency and enable generator output. Set reference CW Jammer power level at power meter port 8.4dB below Sr (minimum J/S, or 10dB processing gain reference level). Note the power level setting on the generator, this is the reference CW Jammer power setting, Jr. Disable CW Jammer, re-establish link. PER test should be operating essentially error -free. Enable CW Jammer at the reference power level and verify that the PER test indicates a PER of less than 8%. Alternatively, adjust the CW Jammer level to that which causes 8% PER and verify that the S/J is less than 8.4dB. Repeat step 7 for uniform steps in frequency increments of 50 kHz across the receiver passband with the CW Jammer. In this case the receiver passband is +/- 8.5 MHz. The numerical data associated with the following radio channel is tabulated and presented for Channel 1,6, and 11. Note:Since the jamming signal will be blocked by the IF filter if the jamming frequency is far form the center of the carrier frequency. So, only those frequencies around carrier frequency are shown here. FCC ID: PKW-WUSB11 Report No.: RF90011014-1 5 Issued: April 18, 2001 1.4 EUT OPERATING CONDITION The software provided by client to set the EUT to transmit at lowest, middle and highest channel. 1.5 TEST RESULTS EUT11Mbps Wireless LAN CardModelWL-216C Environmental Conditions24°C, 70%RHTe s t e d B ySteven Lu Although the theoretical processing gain is lower than 10 dB, but the CCK coding provides an extra coding gain of 2.2dB. 11Mbps CHANNEL 1 Processing Gain Gp = (S/N)。 。。 。+ Mj + Lsys Freq.Gp(S/N)Mj = J/SLsysJammerLVL (GHz)(dB)(dB)(dB)(dB)(dBm)(dBm) 2.409511.316.4-7.12-47.1-0.7 2.4095511.416.4 -72-47-0.6 2.409611.416.4-72-47-0.6 2.4096511.416.4-72-47-0.6 2.409711.316.4-7.12-47.1-0.7 2.4097511.316.4-7.12-47.1-0.7 2.409811.116.4-7.32-47.3-0.9 2.4098511.116.4-7.32-47.30.9 2.40991116.4-7.42-47.4-1 2.409951116.4-7.42-47.4-1 2.4110.916.4-7.52-47.5-1.1 2.410051116.4-7.42-47.4-1 2.41011116.4-7.42-47.4-1 2.4101511.116.4-7.32-47.3-0.9 2.410211.216.4-7.22-47.2-0.8 2.4102511.316.4-7.12-47.1-0.7 2.410311.316.4-7.12-47.1-0.7 2.4103511.416.4-72-47-0.6 2.410411.316.4-7.12-47.1-0.7 2.4104511.316.4-7.12-47.1-0.7 2.410511.316.4-7.12-47.1-0.7 2.4105511.216.4-7.22-47.2-0.8 2.410611.216.4-7.22-47.2-0.8 2.4106511.316.4-7.12-47.1-0.7 2.410711.316.4-7.12-47.1-0.7 2.4107511.316.4-7.12-47.1-0.7 2.410811.416.4-72-47-0.6 FCC ID: PKW-WUSB11 Report No.: RF90011014-1 6 Issued: April 18, 2001 11Mbps CHANNEL 1 Processing Gain Gp = (S/N)。 。。 。+ Mj + Lsys Freq.Gp(S/N)Mj = J/SLsysJammerLVL (GHz)(dB)(dB)(dB)(dB)(dBm)(dBm) 2.4108511.516.4-6.92-46.9-0.5 2.410911.616.4-6.82-46.8-0.4 2.4109511.616.4-6.82-46.8-0.4 2.41111.616.4-6.82-46.8-0.4 2.4110511.416.4-72-47-0.6 2.411111.516.4-6.92-46.9-0.5 2.4111511.616.4-6.82-46.8-0.4 2.411211.516.4-6.92-46.9-0.5 2.4112511.516.4-6.92-46.9-0.5 2.411311.516.4-6.92-46.9-0.5 2.4113511.416.4-72-47-0.6 2.411411.416.4-72-47-0.6 2.4114511.416.4-72-47-0.6 2.411511.416.4-72-47-0.6 2.4115511.…

Text truncated - open the document above for the full version.

FCC ID: PKW-WUSB11 Report No.: RF90011014-1 46 Issued: April 18, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PKW-WUSB11 Report No.: RF90011014-1 47 Issued: April 18, 2001 RADIATED EMISSION TEST
