PKW-WUSB11-V26Wireless LAN USB Adapter

Installation and Configuration of the USB Adapter for Windows This Wireless USB Network Adapter Setup Utility will guide you through the Install and Uninstall Procedure for Windows 98, Millennium, 2000 and XP. Insert the Setup Utility CD into your CD-ROM Drive. The Setup Utility should run automatically and the screen shown below should appear. If it does not, click the Start button and choose Ru n. In the box that appears, enter D:\setup.exe (where “D” is the letter of your CD-ROM drive). • The Install tab begins the software installation process, as shown on the next page. • The Uninstall tab shows you how to uninstall the adapter (please see the sec-tion titled Uninstall Procedures for more information). • The User Guide tab shows you a PDF file of the User Guide. • The Contact Us tab links you to the Linksys website. • The Exit tab allows you to the exit the Setup Utility. 1. To install your Wireless USB Network Adapter, click on the Install tab. 2. Once you see the following screen, click the Next button to continue. 3. After reading to the Warranty Policy, click the Yes button if you agree, or No to end the installation.

4. The InstallShield Wizard will automatically choose a folder where Setup will install files. Click the Next button. 5. The InstallShield Wizard will ask you to choose a wireless mode. Choose the mode that applies to your network. Ad-Hoc Mode is used for simple peer-to-peer networking or sharing of local resources between wireless Networked PCs, and Infrastructure Mode allows a wireless network to be integrated into an existing, wired network through an access point, permit-ting roaming between access points while maintaining a connection to all network resources. Then, click the Next button. 6. If you chose Infrastructure Mode, go on to Step 7 now. If you chose Ad-Hoc Mode , choose the correct operating channel that applies to your network. The channel you choose should be set as the same as the other points in your wireless network. The default channel is set to Channel 6. Click Nex t. 7. Enter in the name of your SSID for your Ad-Hoc or Infrastructure setting. The SSID must be identical for all points in the network. To join any avail-able SSID, type AN Y. The default setting is linksys (all lowercase). Click Nex t. 8. The Wizard will ask you to review your settings before starting to copy files. Select Back to review or change any settings, or select Next if you are satis-fied with your settings. 9. The InstallShield Wizard will begin copying the files. The bar in the middle of the screen below shows the percentage of files copied. 10. Once the Wireless USB Network Adapter Configuration Utility has been successfully installed, the Wizard will ask you to restart your computer. Select Yes, I want to restart my computer no w, and then click Finish to restart. You have now completed the installation of your Wireless USB Network Adapter Configuration Utility. Please go on to the next page for informa-tion on Connecting the Wireless USB Network Adapter.

Configuring the USB Network Adapter After installing the Network Adapter, Windows 98, Millennium, 2000 and XP will automatically identify the adapter. Next, you may need to configure The adapter’s utility software. 1. After installing the Network USB Adapter, the blue Linksys 802.11b Wireless LAN Configuration Utility icon will appear on your system tray. double-click of the icon of the green monitor in the diagram below, and the following screen will appear: This screen shows you the status of your current connection. 2. Select the Connection tab. In the Connection lists, you can double click one of the items in the list box to make an association to the wireless profile. The items with no profile name is the existing wireless network in the air. You may get a connection to them by double click on the list item. 3.Select the Profile Setting tab. The items list on the list box shows you the profile currently exist. Click on New button to add a new profile.

4. When you click on the New button, the new profile dialog box will show out to allow you to key in some profile data. You may key in a profile name, Network Name to associate to wireless network, Network Type for Infrastructure or Ad-hoc; If you click “ Ad-hoc”, you can click the task bar, then choose the Chanel. 5. When you click the Advance button, the Advance dialog box will display. Users can insert and select the data. WEP for 64bits or 128bits; In order to enable WEP encryption, hexadecimal values must be inserted in WEP Key item. The value must match the Key on all other devices on the wireless network or else this device will be unable to transmit or receive data. （ Profile 1 ） （ Profile 2 ） （ Profile 3 ） （ Advance 1 ）

5. The About tab shows you copyright and version information about the driver, the configuration utility, and the firmware. The version number of the driver may vary from this screen, depending on which version was shipped with your Adapter. You can always visit www.linksys.com for the latest version of the driver. （ Advance 2 ） （ Advance 3 ） Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. R&TTE Compliance Statement This equipment complies with all the requirements of the DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. Safety This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this manual and of the computer manufacturer must therefore be allowed at all times to ensure the safe use of the equipment. EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France (with Frequency channel restrictions), Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Iceland, Liechtenstein, Norway and Switzerland. EU Countries Not Intended for Use None. Potential Restrictive Use France: Only channels 10,11,12, and13

Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910208R02A. And this compliance is subject to the following two conditions: (1) This device may not cause harmful interference and, (2) This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: 1) Product name, model name and trade name. 2) Company name, and address of the one who is responsible for this declaration. 3) Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5

Page 6

FCC ID: PKW-WUSB11-V26 ADT No.910208R02A Operational Description The transmitter of the EUT is powered by host equipment from USB port. The antenna is Monopole antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PKW-WUSB11-V26 ADT No.: 910208R02A FCC TEST REPORT REPORT NO.: RF910208R02A MODEL NO.: WUSB11 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:THE LINKSYS GROUP, INC. ADDRESS: 17401 Armstrong Ave. Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WUSB11-V26 ADT No.: 910208R02A RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: PKW-WUSB11-V26 ADT No.: 910208R02A LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: PKW-WUSB11-V26 ADT No.: 910208R02A 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1 dBi or 0.65 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241224.431.57 6243719.591.40 11246213.121.15 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: PKW-WUSB11-V26 Report No.: RF910208R02A 1 Issued: March 4, 2002 FCC TEST REPORT REPORT NO.: RF910208R02A MODEL NO.: WUSB11 RECEIVED: Feb. 8, 2002 TESTED: Feb. 8 ~ Feb. 19, 2002 APPLICANT:THE LINKSYS GROUP, INC. ADDRESS:17401 Armstrong Ave. Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PKW-WUSB11-V26 Report No.: RF910208R02A 2 Issued: March 4, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS ................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 26 4.3.2TEST INSTRUMENTS ......................................................................................................... 26 4.3.3TEST PROCEDURE ............................................................................................................27 4.3.4TEST SETUP ....................................................................................................................... 27 4.3.5EUT OPERATING CONDITIONS......................................................................................... 27 4.3.6TEST RESULTS ................................................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 32 4.4.2INSTRUMENTS.................................................................................................................... 32 4.4.3TEST PROCEDURES .......................................................................................................... 33 4.4.4TEST SETUP ....................................................................................................................... 33 4.4.5EUT OPERATING CONDITIONS......................................................................................... 33 4.4.6TEST RESULTS ................................................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 35 4.5.2TEST INSTRUMENTS ......................................................................................................... 35 4.5.3TEST PROCEDURE ............................................................................................................36 4.5.4TEST SETUP ....................................................................................................................... 36 4.5.5EUT OPERATING CONDITION ........................................................................................... 36 4.5.6TEST RESULTS ................................................................................................................... 37 4.6BAND EDGES MEASUREMENT ............................................................... 41 FCC ID: PKW-WUS…

Text truncated - open the document above for the full version.

FCC ID: PKW-WUSB11-V26 Report No.: RF910208R02A 46 Issued: March 4, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PKW-WUSB11-V26 Report No.: RF910208R02A 47 Issued: March 4, 2002 RADIATED EMISSION TEST
