PLRAR125500AR1255 Integrated Headend Transceiver

March 1, 2002 ARCi Internet Broadband Fixed Wireless Internet Delivery System Physical Planning and Installation Manual AR1255 Integrated Headend Transceiver AR3155 Integrated Subscriber Transceiver © 2001-2002 by Advanced Radio Cells Inc. Other product and company names mentioned herein may be the trademarks of their respective owners. This publication may include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of this publication. ARCi may make improvements and/or changes in the product(s) described in this publication at any time. March 2002 March 1, 2002 Advanced Radio Cells Inc. LIMITED WARRANTY. ARCi warrants to Buyer at the time of delivery that the equipment will be free from defects in material and workmanship under normal use and service. ARCi's sole obligation under these warranties is limited to replacing or repairing, at its option, at its factory, any equipment which is returned to ARCi, transportation, duties, and taxes prepaid, within twelve (12) months after delivery. In the case of products not of ARCi's own manufacture, the only warranty available is that provided by the original equipment manufacturer. ARCi shall return the equipment to Buyer freight prepaid. THIS WARRANTY IS EXPRESSED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF ARCi, AND IT NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR ARCIANY OTHER LIABILITIES IN CONNECTION WITH THE SALE OF PRODUCTS. IN NO EVENT WILL ARCi BE LIABLE FOR CONSEQUENTIAL DAMAGES EVEN IF ARCi HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. This Warranty does not apply to any of such products which shall have been repaired or altered, except by ARCi, or which shall have been subjected to misuse, negligence, or accident or operation outside the environmental specifications. Repairs or replacements of Equipment made during the warranty period or thereafter will be warranted, as provided above, for the remainder of the original warranty period or for ninety days from the date of return, as applicable, whichever is longer. RETURN OF EQUIPEMENT UNDER WARRANTY: If an item of Equipment malfunctions or fails in normal intended usage and maintenance within the applicable Warranty Period: (a) the Customer shall promptly notify ARCi of the problem and the serial number of the defective item; (b) ARCi shall, at its sole option, either resolve the problem over the telephone or provide the Customer with a Returned Materials Authorization number (RMA #) and the address of the location to which the Customer may ship the defective item; (c) if the problem is not resolved over the telephone, the Customer shall attach a label to each returned item describing the fault and the Customer's return address. The Customer shall, at its cost, properly pack the item to be returned, prepay the insurance and shipping charges, and ship the item to the specified location; (d) if the ARCi product shall prove to be defective in material or workmanship upon examination by ARCi, ARCi shall either repair or replace the returned item at its sole option. The replacement item may be new or refurbished; if refurbished, it shall be equivalent in operation to new Equipment. If a returned item is replaced by ARCi, the Customer agrees that the returned item shall become the property of ARCi. (e) ARCi shall ship the repaired item or replacement to the Customer's return address by carrier and method of delivery chosen by ARCi at its cost. If Customer has requested some other form of conveyance, such as express shipping, then the Customer shall pay the cost of return shipment. March 1, 2002 Advanced Radio Cells Inc. Broadband Fixed Wireless Internet Delivery System Physical Planning and Installation Manual Entire Contents Copyright 2001-2002 Advanced Radio Cells Inc. 910 Campisi Way, Suite 1F Campbell, CA 95008 USA Phone: 408-558-2760 888-863-8225 FAX: 408-371-7584 www.arcells.com March 1, 2002 Page A1 A. Table of Contents March 1, 2002 Page A2 ARCi Internet Broadband Fixed Wireless Internet Delivery System Physical Planning and Installation Manual Table of Contents A. Table of Contents B. Introduction C. System Description D. Antenna and Frequency Planning E. Hub Installation Detail F. Subscriber Installation Detail G. Link Budget Paramaters H. Reader Feedback March 1, 2002 Page B1 B. Introduction Ctt March 1, 2002 Page B2 Introduction The ARCi Internet system, deployed in conjunction with the Vyyo Broadband Wireless Access System, provides a complete end-to-end solution for ISPs and other fixed wireless operators seeking to expand their markets by offering wireless delivery of the Internet to their customers at performance levels that normally exceed DSL. Figure 1 Typically the ARCi Hub Antenna is mounted on a building roof or tower structure with an unobstructed (as possible) view of the geographic area to be served by the ARCI Internet system. Each ARCi Hub Antenna “illuminates” a horizontal arc of about sixty degrees and a distance of about five miles. Therefore, an omni directional system would Hub Antenna Hub Cable Modem ARCi Subscriber Antenna WWW Wireless Modem Wireless Hub The ARCi Internet Solution ARCi Gateway Network Manager March 1, 2002 Page B3 require six ARCi Hub Antennas arranged pointing outward spaced every 60 degrees. A system only looking up a narrow canyon from one end might require only one ARCi Hub Antenna. Cables are run from the antenna(s) into the building to the hub equipment room. The ARCi Subscriber Antenna is mounted outdoors at the subscriber location with line of sight to the hub antenna. A single cable is run to the modem and computer inside the subscriber location. The electronic equipment associated with the ARCi Hub Antenna and the ARCi Subscriber Antenna i…

Text truncated - open the document above for the full version.

From: Mike Kuo Sent: Tuesday, March 05, 2002 4:17 PM To: Michael Heckrotte; Steve Cheng Cc: Denise Teng; Christine Vu; Chuck Cowden Subject: FW: ADVANCED RADIO CELLS, INC, FCC ID:PLRAR125500, An02T1843 -----Original Message----- From: CERTADM Sent: Tuesday, March 05, 2002 4:16 PM To: '[email protected]' Subject: ADVANCED RADIO CELLS, INC, FCC ID:PLRAR125500, An02T1843 Notice_content ------------- Question #1: What is the actual frequnecy range for this device ? Question # 2: The peak and average limits used for 15.205 restricted band emission are not correct ( page 48-50 ). Please provide revised test report. Question #3: The user manual does not contain RF exposure informatin. Suggest wording can be "IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, antenna installation and device operting configuration described in this user manual must be satisfied. The antenna(s) used for this device must be fixed-mounted on outdoor permanent structures with a separation of at least 1.5 meters from all persons during normal operation.". Please provide revised user manual. Question #4: Please address 15.407( c ) requirements. Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

PROPOSED FCC ID LABEL AND LOCATION ADVANCED RADIO CELLS, INC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PLRAR125500 FCC ID LABEL

MPE CALCULATION for ARCi CPE TX ANTENNA WITH OUTPUT POWER: 13.1 dBm GAIN 11 dBi Formula used in the MPE Calculations: E^2/3770 = S, mW/cm2 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 --------- (A) Since S (mW/cm2) = 1.00 from 1.1310 Table 1 P (dBm) = 13.1 EUT output power G (dBi) = 11.0 EUT antenna gain Substitute these parameters into the A above, we have MPE safe distance d (cm) = 4.5 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less MPE CALCULATION for ARCi HUB TX ANTENNA OUTPUT POWER: 16 dBm GAIN 13 dBi Formular used in the MPE Calculations: E^2/3770 = S, mW/cm2 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 --------- (A) Since S (mW/cm2) = 1.00 from 1.1310 Table 1 P (dBm) = 16.0 EUT output power G (dBi) = 13.0 EUT antenna gain Substitute these parameters into the A above, we have MPE safe distance d (cm) = 8.0 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less

FCC CFR47 PART 15 CERTIFICATION TEST REPORT FOR HUB OUTDOOR TRANSCEIVERS MODEL: AR1255 FCC ID: PLRAR 125500 REPORT NUMBER: 01U1019-1 ISSUE DATE: FEBRUARY 25, 2002 Prepared for ADVANCED RADIO CELLS,INC. 910 CAMPISI WAY STE. 1F CAMPBELL, CA 95008 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 2 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION..............................................................................................3 2. EUT DESCRIPTION.....................................................................................................................4 3. TEST METHODOLOGY..............................................................................................................4 4. TEST FACILITY...........................................................................................................................4 5. ACCREDITATION AND LISTING.............................................................................................4 5.1. LABORATORY ACCREDITATIONS AND LISTINGS........................................................................5 6. MEASURING INSTRUMENT CALIBRATION.........................................................................6 6.1. MEASUREMENT UNCERTAINTY.................................................................................................6 7. SUPPORT EQUIPMENT / TEST DIAGRAM.............................................................................7 8. APPLICABLE RULES AND BRIEF TEST RESULT.................................................................9 9. TEST SETUP, PROCEDURE AND RESULT............................................................................16 9.1. EMISSION BANDWIDTH....................................................................................................16 9.2. PEAK POWER......................................................................................................................20 9.3. PEAK POWER SPECTRAL DENSITY.................................................................................24 9.4. PEAK EXCURSION..............................................................................................................28 9.5. UNDESIRABLE EMISSION - BAND EDGE........................................................................32 9.6. FREQUENCY STABILITY...................................................................................................39 9.7. UNDESIRABLE EMISSION.................................................................................................41 9.8. POWER LINE CONDUCTED EMISSION............................................................................51 9.9. RADIATED EMISSION........................................................................................................53 9.10. SETUP PHOTOS....................................................................................................................57 ATTACHMENTS • EUT PHOTOGRAPHS • PROPOSED FCC ID LABEL • MPE CALCULATION • REQUEST FOR CONFIDENTIALITY • AGENT AUTHORIZATION • ANTENNA SPECIFICATION • USER'S MANUAL • PRODUCT SPECIFICATION • THEORY OF OPERATION • BLOCK DIAGRAM & SCHEMATIC DIAGRAM REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 3 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: ADVANCED RADIO CELLS, INC. 910 CAMPISI WAY STE. 1F CAMPBELL, CA 95008 USA CONTACT PERSON: LEON LOUIE / DIRECTOR OF OPERATIONS TELPHONE NO: 408-558-2764 EUT DESCRIPTION: HUB OUTDOOR TRANSCEIVERS MODEM NAME: AR1255 DATE TESTED: DECEMBER 28, 2001 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE 5.8 GHz TRANSCEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 15.E Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 15, Subpart E. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: STEVE CHENG HUE LY VANG EMC ENGINEERING MANAGER ASSOCIATE EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 4 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certificatio…

Text truncated - open the document above for the full version.

REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 57 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.10. SETUP PHOTOS Radiated Emission photos REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 58 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Conducted Emission Photos REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 59 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. FCC testing to antenna port REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 60 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. FCC testing above 1GIGHz REPORT NO: 01U1019-1 DATE: FEBRUARY 25, 2002 EUT: HUB OUTDOOR TRANSCEIVERS FCC ID: PLRAR 125500 Page 61 of 72 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Frequency Stability
