PPQ-BMK201Bluetooth Speaker

APPROVEDCHECKEDDESIGNED MODEL No. PART NAME PART No. BMK-201 User Manual 515300108247 李采婕 blue 2013.10.08 材質模造 (): 100p 紙 上光方式 (): no 顏色black (): 尺寸 (): 60x60mm 公差 ():+-0.5mm 60mm 60mm (封面)(封底-空白) (內頁1) (內頁2)(內頁3) (折法) BMK-201 User Manual Schematic diagram LED USB Lanyard MIC VOL + MFB VOL - Charging starts when the unit and the computer are connected. Charging is completed in about 3.5 hours at most and the indicator goes off automatically. The indicator is lit during charging. 4 Make the Bluetooth connection from the Bluetooth device. 1 Place the Bluetooth device within 1 meter of this unit. 2 Long press MFB button up to 6 seconds to turn on this unit and enters pairing mode. (you can hear 2 beep prompts) The indicator flashes fast in pairing mode for 2 minutes. 3 Perform the pairing procedure on the Bluetooth device to detect this unit.When the list of detected devices appears on the display of the Bluetooth device, select “BMK-201 V0.x” If passkey input is required on the display of a Bluetooth device, input “0000.” Charge the unit Pairing and connecting with the Bluetooth device Operate your mobile phone to make a call. - To terminate a call, press the MFB button on the unit. Press the MFB button on the unit when an incoming call arrives. - Operate in the same way when an incoming call arrives while you are listening to the music. Making a call/Receiving a call Profile: HSP, HFP 1 Press MFB button for 3 seconds to turn on the unit.(you can hear the long prompt and the indicator is lit solidly for 5 seconds) 2 Make the Bluetooth connection from the Bluetooth device. Connecting with the paired device Start playback on the Bluetooth device. Listening and Calling Operate the unit after making Bluetooth connection Press MFB button for 3 seconds to turn off the unit.(you can hear 3 beep prompts and the indicator is lit) Turn off the unit Listening to music Profile: A2DP This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digi tal device, pursuant to part 15 of the FCC rules. These limits are designed to provide r easonable protection against harmful interference in a residential installation. This equ ipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio co mmunications. However, there is no guarantee that interference will not occur in a par ticular installation. If this equipment does cause harmful interference to radio or televi sion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measu res: ­Reorient or relocate the receiving antenna. ­ Increase the separation between the equipment and receiver. ­ Connect the equipment into an outlet on a circuit different from that to which the recei ver is connected. ­Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party r esponsible for compliance could void your authority to operate the equipm ent. FCC RF Radiation Exposure Statement: 1. This Transmitter must not be colocated or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Lite-On Technology Corp. 4F, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C. Date：November 20, 2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: PPQ-BMK201 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Lite-On Technology Corp. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Your Sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Lite-On Technology Corp. Lite-On Technology Corp. 4F, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C. Date: Nov. 26 ,2013 Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: PPQ-BMK201, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749

Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 1 Total Page: 8 Rev.00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 2 Rev.00 Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 3 Rev.00 Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 4 Rev.00

Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 5 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 6 Rev.00 Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 7 Rev.00 RF Module PCB print Antenna Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 12, 2013 A1 - 8 Rev.00 Battery

Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 26, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT Bluetooth Speaker Model Number BMK-201 Frequency band (Operating) Bluetooth: 2.402GHz ~ 2.480GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification Monopole Antenna Gain :2.29 dBi (Numeric gain:1.69) Max. output power Bluetooth Mode: 7.00 dBm(5.012 mW) Evaluation applied MPE Evaluation* SAR Evaluation N/A Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 26, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d GP E   30 & 377 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   22 0796.0 100/377 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T131008W07 Date of Issue: November 26, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: GPS000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Bluetooth mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm2) 024025.0121.69200.00171

Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 82 Rev.00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth Speaker Model: BMK-201 Trade Name: LITE-ON Issued to LITE-ON TECHNOLOGY CORP 4F, 90, Chien 1 Road, Chung Ho,New Taipei City 23585, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: November 12, 2013 Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 November 12, 2013 Initial Issue ALL Eunice Shen Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 3 Rev.00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .................................................................................................4 2. EUT DESCRIPTION ........................................................................................................................5 3. TEST METHODOLOGY .................................................................................................................6 3.1 EUT CONFIGURATION .....................................................................................................................6 3.2 EUT EXERCISE .................................................................................................................................6 3.3 GENERAL TEST PROCEDURES ..........................................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................7 3.5 DESCRIPTION OF TEST MODES ........................................................................................................8 4. INSTRUMENT CALIBRATION .....................................................................................................9 4.1 MEASURING INSTRUMENT CALIBRATION ...................................................................................9 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................9 4.3 MEASUREMENT UNCERTAINTY .......................................................................................... 10 5. FACILITIES AND ACCREDITATIONS ..................................................................................... 11 5.1 FACILITIES .................................................................................................................................... 11 5.2 EQUIPMENT ................................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS .................................................................................. 12 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................... 13 6.1 SETUP CONFIGURATION OF EUT .................................................................................................... 13 6.2 SUPPORT EQUIPMENT ............................................................................................................ 13 7. FCC PART 15.247 REQUIREMENTS .......................................................................................... 14 7.1 20 DB BANDWIDTH .................................................................................................................. 14 7.2 PEAK POWER ................................................................................................................................. 21 7.3 BAND EDGES MEASUREMENT ............................................................................................. 22 7.4 FREQUENCY SEPARATION .................................................................................................... 40 7.5 NUMBER OF HOPPING FREQUENCY .................................................................................... 45 7.6 TIME OF OCCUPANCY (DWELL TIME) ................................................................................ 50 7.7 SPURIO US EMISSIONS ............................................................................................................. 59 7.8 POWERLINE CONDUCTED EMISSIONS ............................................................................................ 77 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................ 80 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 4 Rev.00 1. TEST RESULT CERTIFICATION Applicant: LITE-ON TECHNOLOGY CORP 4F, 90, Chien 1 Road, Chung Ho,New Taipei City 23585, Taiwan, R.O.C. Equipment Under Test: Bluetooth Speaker Tr a d e N a m e : LITE-ON Model: BMK-201 Date of Test: October 11 ~ 23, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements set forth in the above standards. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Miller Lee Angel Cheng Section Manager Section Manager Compliance Certificati…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 80 Rev.00 APPENDIX I PHOTOGRAPHS OF TEST SETUP CONDUCTED EMISSION SETUP PHOTO Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 81 Rev.00 RADIATED EMISSION SETUP PHOTOS Compliance Certification Services Inc. FCC ID: PPQ-BMK201 Report No.: T131008W07-RP1 Page 82 Rev.00 POWERLINE CONDUCTED EMISSIONS SETUP PHOTOS
