PPQ-O90Access Point/Sensor

O-90 AirTight Access Point / Sensor Quick Start Guide Package Contents You should have received the following components in your O-90 package. Mounting Accessories O-90 x 1 x 2 x 4x 4 x 1 x 4 Wall Mount: AirTight logo facing away from the wall Pole Mount: AirTight logo facing away from the wall Mounting the O-90 Getting the O-90 Online Step 1: Power up Plug one end of the Ethernet cable into the PoE switch or injector and plug the other end into the LAN1 (PoE) on the O-90. Make sure the PoE source you are using is turned ON. Step 2: Connect to the network As you are using PoE, the O-90 should already be connected to your network. Step 3: Check the LED status Wait for a few minutes till the Power (PWR) LED and LAN1 (PoE) LED turn solid GREEN, which indicates that the O-90 is online and operational. Troubleshooting After the O-90 is powered ON and connected to Ethernet, if the status of Power (PWR) LED is not Solid Green, it indicates that the AP is not able to function normally. The following guidelines may help you to quickly diagnose and fix the problem. LED Status What does it mean? Power (PWR)2.4G/ 5G LAN2LAN1 (PoE) OffOffOffOff Not powered on or it is in the process of starting up Solid OrangeAnyOn/ OffSolid GreenNo active Ethernet link 1 Solid OrangeAnyOn/ OffFast Blink Green Did not receive a valid IP address via DHCP 2 Solid OrangeAnyOn/ Off Slow Blink Green Unable to connect to the AirTight Cloud Services or AirTight Server 3 1. Make sure that the Ethernet cable is correctly plugged into the LAN1 (POE) port on the O-90 and the other end of the cable is plugged into an Ethernet jack or a port on a switch that is turned ON. 2. If the O-90 did not receive a valid IP address from the DHCP server, make sure that a DHCP server is ON and available on the VLAN/subnet to which the AP is connected. If the AP still fails to get a valid IP address, you can reboot it once to see if that resolves the problem. 3. If you are using AirTight Cloud Services, make sure that Internet connectivity is available from the VLAN/subnet to which the AP is connected. Check if the required ports for AP and Server communication – UDP 3851 and default HTTP (TCP port 80) – are open on the Firewall. If you are using a Proxy, Web accelerator or URL content filtering, make sure the settings allow communication between the AP and AirTight Cloud Services. After following these guidelines, if you are still unable to resolve the problem, contact the local AirTight Sales Engineer or 24/7 AirTight Technical Support. Tel: +1 (650) 641 0027 Email: [email protected] AirTight Networks, Inc. 339 N. Bernardo Avenue #200, Mountain View, CA 94043 T +1.877.424.7844 T 650.961.1111 F 650.961.1169 www.airtightnetworks.com [email protected] AirTight O-90 Quick Setup Guide [Doc ID: ATN-QS-0315-001-00-EN] © 2014 AirTight Networks, Inc. All rights reserved. AirTight Networks and the AirTight Networks logo are trademarks, and AirTight is a registered trademark of AirTight Networks, Inc. All other trademarks mentioned herein are properties of their respective owners. Specifications are subject to change without notice. Comprehensive Cloud-Managed Wi-Fi O-90-E AirTight Access Point / Sensor Quick Start Guide Package Contents You should have received the following components in your O-90-E package. Mounting Accessories O-90-E x 1 x 2 x 4x 4 x 1 x 4 Wall Mount: AirTight logo facing away from the wall Pole Mount: AirTight logo facing away from the wall Mounting the O-90-E Getting the O-90-E Online Step 1: Power up Plug one end of the Ethernet cable into the PoE switch or injector and plug the other end into the LAN1 (PoE) on the O-90-E. Make sure the PoE source you are using is turned ON. Step 2: Connect to the network As you are using PoE, the O-90-E should already be connected to your network. Step 3: Check the LED status Wait for a few minutes till the Power (PWR) LED and LAN1 (PoE) LED turn solid GREEN, which indicates that the O-90-E is online and operational. Troubleshooting After the O-90-E is powered ON and connected to Ethernet, if the status of Power (PWR) LED is not Solid Green, it indicates that the AP is not able to function normally. The following guidelines may help you to quickly diagnose and fix the problem. LED Status What does it mean? Power (PWR)2.4G/ 5G LAN2LAN1 (PoE) OffOffOffOff Not powered on or it is in the process of starting up Solid OrangeAnyOn/ OffSolid GreenNo active Ethernet link 1 Solid OrangeAnyOn/ OffFast Blink Green Did not receive a valid IP address via DHCP 2 Solid OrangeAnyOn/ Off Slow Blink Green Unable to connect to the AirTight Cloud Services or AirTight Server 3 1. Make sure that the Ethernet cable is correctly plugged into the LAN1 (POE) port on the O-90-E and the other end of the cable is plugged into an Ethernet jack or a port on a switch that is turned ON. 2. If the O-90-E did not receive a valid IP address from the DHCP server, make sure that a DHCP server is ON and available on the VLAN/subnet to which the AP is connected. If the AP still fails to get a valid IP address, you can reboot it once to see if that resolves the problem. 3. If you are using AirTight Cloud Services, make sure that Internet connectivity is available from the VLAN/subnet to which the AP is connected. Check if the required ports for AP and Server communication – UDP 3851 and default HTTP (TCP port 80) – are open on the Firewall. If you are using a Proxy, Web accelerator or URL content filtering, make sure the settings allow communication between the AP and AirTight Cloud Services. After following these guidelines, if you are still unable to resolve the problem, contact the local AirTight Sales Engineer or 24/7 AirTight Technical Support. Tel: +1 (650) 641 0027 Email: [email protected] AirTight Networks, Inc. 339 N. Bernardo Avenue #200, Mountain View, CA 94043 T +1.877.424.7844 T 650.961.1111 F 650.961.1169 www.airtightnetworks.com [email protected] AirTight O-90 Quick Setup Guide [Doc …

Text truncated - open the document above for the full version.

LITE-ON Technology Corp. Date (25/May/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: PPQ-O90 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, LITE-ON Technology Corp. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics: (O-90) Schem Block Diagrams: (O-90) BlkDia Theory of Operation: (O-90) OPDes Software Security Description: (O-90) Software Security Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: TC Wu (signed by FCC listed Grantee contact) Telephone Number: 86-2222-6181 Email: [email protected]

Report No.: 1520469R-RFUSP01V00 Page : 1 of 7 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (External) (2) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 2 of 7 (3) EUT Photo (External) (4) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 3 of 7 (5) EUT Photo (External) (6) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 4 of 7 (7) EUT Photo (External) (8) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 5 of 7 (9) EUT Photo (External) (18) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 6 of 7 (19) EUT Photo (Internal) (20) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 7 of 7 (21) EUT Photo (Internal) (22) EUT Photo (Internal)

LITE-ON Technology Corp.. FCC ID.: PPQ-O90 4F, 90, Chien 1 Road, Chung Ho,New Taipei City 23585, Taiwan, R.O.C. Tel : 86-2222-6181 FCC ID Label External Antenna Internal Antenna

LITE-ON Technology Corp.. FCC ID.: PPQ-O90 Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Tel : 86-2222-6181 The FCC ID Label will be placed on the equipment as shown in the photograph below. M/N: O-90 LITE-ON Technology Corp.. FCC ID.: PPQ-O90 Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Tel : 86-2222-6181 M/N: O-90-E

Report No.: 1520469R-RFUSP01V00 Page : 1 of 12 Attachment 2 : EUT Detailed Photographs (10) EUT Photo (External) (11) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 2 of 12 (12) EUT Photo (External) (13) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 3 of 12 (14) EUT Photo (External) (15) EUT Photo (External) Report No.: 1520469R-RFUSP01V00 Page : 4 of 12 (16) EUT Photo (External) (17) EUT Photo (External) WLAN Module Report No.: 1520469R-RFUSP01V00 Page : 5 of 12 (23) EUT Photo (Internal) (24) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 6 of 12 (25) EUT Photo (Internal) (26) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 7 of 12 (27) EUT Photo (Internal) (28) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 8 of 12 (29) EUT Photo (Internal) (30) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 9 of 12 (31) EUT Photo (Internal) (32) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 10 of 12 (33) EUT Photo (Internal) (34) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 11 of 12 (35) EUT Photo (Internal) (36) EUT Photo (Internal) Report No.: 1520469R-RFUSP01V00 Page : 12 of 12 (37) EUT Photo (Internal)

Report No. 1520469R-RFUSP05V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name Access Point/Sensor Model No. O-90, O-90-E FCC ID PPQ-O90 Applicant Lite-On Technology Corp. Address Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Date of Receipt Feb. 25, 2015 Date of Declaration May 21, 2015 Report No. 1520469R-RFUSP05V00 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No. 1520469R-RFUSP05V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 1520469R-RFUSP05V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Access Point/Sensor Test Item : RF Exposure Evaluation Test Site : No.3 OATS Operation Frequency 2412-2462MHz 5745-5825MHz, 5755-5795MHz 5180-5240MHz, 5190-5230MHz 5210MHz, 5775MHz Maximum Conducted output power 24.76dBm Antenna gain 10.9dBi Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 299.2265 0.732370 Power density is lower than the limit (1 mW/cm2).

Report No.: 1520469R-RFUSP01V00 Page : 1 of 274 FCC Test Report Product Name Access Point/Sensor Model No O-90, O-90-E FCC ID. PPQ-O90 Applicant Lite-On Technology Corp. Address Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Date of Receipt Feb. 25, 2015 Issue Date May 21, 2015 Report No. 1520469R-RFUSP01V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1520469R-RFUSP01V00 Page : 2 of 274 Test Report Issue Date: May 21, 2015 Report No.: 1520469R-RFUSP01V00 Product Name Access Point/Sensor Applicant Lite-On Technology Corp. Address Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Manufacturer Lite-On Network Communication (Dongguan) Limited Model No. O-90, O-90-E FCC ID. PPQ-O90 EUT Rated Voltage Power By PoE (DC 48V) EUT Test Voltage Power By PoE (DC 48V) Trade Name LITE-ON Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2014 ANSI C63.10: 2009, KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By : ( Senior Adm. Specialist / Joanne Lin ) Tested By : ( Engineer / Jerry Tsai ) Approved By : ( Director / Vincent Lin ) Report No.: 1520469R-RFUSP01V00 Page : 3 of 274 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................13 3.1. Test Equipment............................................................................................................................13 3.2. Test Setup ....................................................................................................................................13 3.3. Limits ..........................................................................................................................................13 3.4. Test Procedure .............................................................................................................................13 3.5. Uncertainty ..................................................................................................................................13 3.6. Test Result of Peak Power Output...............................................................................................14 4. Radiated Emission .....................................................................................................................30 4.1. Test Equipment............................................................................................................................30 4.2. Test Setup ....................................................................................................................................31 4.3. Limits ..........................................................................................................................................32 4.4. Test Procedure .............................................................................................................................33 4.5. Uncertainty ..................................................................................................................................33 4.6. Test Result of Radiated Emission................................................................................................34 5. RF antenna conducted test........................................................................................................66 5.1. Test Equipment............................................................................................................................66 5.2. Test Setup ...............................…

Text truncated - open the document above for the full version.

Report No.: 1520469R-RFUSP01V00 Page : 195 of 274 Figure Channel 09: (Chain A) Figure Channel 03: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 196 of 274 Figure Channel 06: (Chain B) Figure Channel 09: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 197 of 274 Figure Channel 03: (Chain C) Figure Channel 06: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 198 of 274 Figure Channel 09: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 199 of 274 Product : Access Point/Sensor Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit (802.11b 1Mbps) (Internal Antenna) Channel No. Chain Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 01 A 2412 10200 >500 Pass 06 A 2437 10200 >500 Pass 11 A 2462 10200 >500 Pass 01 B 2412 10200 >500 Pass 06 B 2437 10200 >500 Pass 11 B 2462 10200 >500 Pass 01 C 2412 10200 >500 Pass 06 C 2437 10200 >500 Pass 11 C 2462 10200 >500 Pass Report No.: 1520469R-RFUSP01V00 Page : 200 of 274 Figure Channel 01: (Chain A) Figure Channel 06: (Chain A) Report No.: 1520469R-RFUSP01V00 Page : 201 of 274 Figure Channel 11: (Chain A) Figure Channel 01: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 202 of 274 Figure Channel 06: (Chain B) Figure Channel 11: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 203 of 274 Figure Channel 01: (Chain C) Figure Channel 06: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 204 of 274 Figure Channel 11: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 205 of 274 Product : Access Point/Sensor Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 2: Transmit (802.11g 6Mbps) (Internal Antenna) Channel No. Chain Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 01 A 2412 16500 >500 Pass 06 A 2437 16500 >500 Pass 11 A 2462 16550 >500 Pass 01 B 2412 16500 >500 Pass 06 B 2437 16550 >500 Pass 11 B 2462 16500 >500 Pass 01 C 2412 16500 >500 Pass 06 C 2437 16500 >500 Pass 11 C 2462 16500 >500 Pass Report No.: 1520469R-RFUSP01V00 Page : 206 of 274 Figure Channel 01: (Chain A) Figure Channel 06: (Chain A) Report No.: 1520469R-RFUSP01V00 Page : 207 of 274 Figure Channel 11: (Chain A) Figure Channel 01: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 208 of 274 Figure Channel 06: (Chain B) Figure Channel 11: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 209 of 274 Figure Channel 01: (Chain C) Figure Channel 06: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 210 of 274 Figure Channel 11: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 211 of 274 Product : Access Point/Sensor Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 3: Transmit (802.11n 21.7Mbps 20M-BW) (Internal Antenna) Channel No. Chain Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 01 A 2412 17700 >500 Pass 06 A 2437 17700 >500 Pass 11 A 2462 17700 >500 Pass 01 B 2412 17700 >500 Pass 06 B 2437 17700 >500 Pass 11 B 2462 17700 >500 Pass 01 C 2412 17700 >500 Pass 06 C 2437 17700 >500 Pass 11 C 2462 17700 >500 Pass Report No.: 1520469R-RFUSP01V00 Page : 212 of 274 Figure Channel 01: (Chain A) Figure Channel 06: (Chain A) Report No.: 1520469R-RFUSP01V00 Page : 213 of 274 Figure Channel 11: (Chain A) Figure Channel 01: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 214 of 274 Figure Channel 06: (Chain B) Figure Channel 11: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 215 of 274 Figure Channel 01: (Chain C) Figure Channel 06: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 216 of 274 Figure Channel 11: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 217 of 274 Product : Access Point/Sensor Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 4: Transmit (802.11n 45Mbps 40M-BW) (Internal Antenna) Channel No. Chain Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 03 A 2422 36600 >500 Pass 06 A 2437 36600 >500 Pass 09 A 2452 36600 >500 Pass 03 B 2422 36500 >500 Pass 06 B 2437 36300 >500 Pass 09 B 2452 36500 >500 Pass 03 C 2422 36500 >500 Pass 06 C 2437 36600 >500 Pass 09 C 2452 36500 >500 Pass Report No.: 1520469R-RFUSP01V00 Page : 218 of 274 Figure Channel 03: (Chain A) Figure Channel 06: (Chain A) Report No.: 1520469R-RFUSP01V00 Page : 219 of 274 Figure Channel 09: (Chain A) Figure Channel 03: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 220 of 274 Figure Channel 06: (Chain B) Figure Channel 09: (Chain B) Report No.: 1520469R-RFUSP01V00 Page : 221 of 274 Figure Channel 03: (Chain C) Figure Channel 06: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 222 of 274 Figure Channel 09: (Chain C) Report No.: 1520469R-RFUSP01V00 Page : 223 of 274 8. Power Density 8.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun., 2014 Spectrum Analyzer Agilent E4407B / US39440758 Jun., 2014 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2015 Note: 1. All equipments are calibrated with traceable calibrations. Each calibration is traceable to the national or international standards. 2. The test instruments marked with “X” are used to measure the final test results. 8.2. Test Setup 8.3. Limits The transmitted power density averaged over any 1 second interval shall not be greater +8dBm in any 3kHz bandwidth. 8.4. Test Procedure The EUT was setup according to ANSI C63.10, 2009; tested according to DTS test procedure of KDB 558074 for compliance to FCC 47CFR 15.247 requirements. The maximum power spectral density using KDB 558074 section 10.2 PKPSD (peak PSD) method. 8.5. Uncertainty ± 1.27 dB SMA EUT Spectrum Analyzer RF Cable Report No.: 1520469R-RFUSP01V00 Page : 224 of 274 8.6. Test Result of Power Density Product : Access Point/Sensor Test Item : Power Density Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit (802.11b 1Mbps) (External Antenna) Channel No. Frequency (MHz) Chain (dBm) PPSD (dBm) Total PPSD (dBm) Limit (dBm) Result 01 2412 A -1.840 2.931 < 8dBm Pass 01 2412 B -2.070 2.701 < 8dBm Pass 01 2412 C -1.290 3.481 < 8dBm Pass 06 2437 A -0.423 4.348 < …

Text truncated - open the document above for the full version.

Report No.: 1520469R-RFUSP01V00 Page : 1 of 6 Attachment 1: EUT Test Setup Photographs Front View of Radiated Test - External Back View of Radiated Test - External Report No.: 1520469R-RFUSP01V00 Page : 2 of 6 Front View of Radiated Test (Horn) - External Back View of Radiated Test (Horn) - External Report No.: 1520469R-RFUSP01V00 Page : 3 of 6 Front View of Radiated Test (Horn) - External Back View of Radiated Test (Horn) - External Report No.: 1520469R-RFUSP01V00 Page : 4 of 6 Front View of Radiated Test - Internal Back View of Radiated Test – Internal Report No.: 1520469R-RFUSP01V00 Page : 5 of 6 Front View of Radiated Test (Horn) - Internal Back View of Radiated Test (Horn) - Internal Report No.: 1520469R-RFUSP01V00 Page : 6 of 6 Front View of Radiated Test (Horn) - Internal Back View of Radiated Test (Horn) - Internal
