Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
WN4636R Page 1/8 2014/8/26 PRODUCT SPECIFICATION WLAN Module WN4636R User Manual Change History Revision Date Author Change List Version 1.0 2014 / 07 / 10 Kaysa Lee Preliminary * This document contains confidential proprietary information and is property of LTC. The contents of this document should not be disclosed to unauthorized persons without the written consent of LTC. WN4636R Page 2/8 2014/8/26 1 PRODUCT OVERVIEW 1.1 DESCRIPTION WN4636R is a WLAN module which using MTK Chipset MT7603U 1.2 FEATURES Operate at 2.4GHz band 150Mbps PHY Rate Support 2T2R Modes 20MHz Bandwidth Support USB 2.0 support for date rates up to 12Mbps full speed and 480Mbps high speed IEEE standards support: IEEE 802.11b/g and 802.11n 802.11i- WEP 64/128, AES, TKIP RoHS compliance Low Halogen compliance 1.3 GENERAL SPECIFICATIONS Main Chipset MT7603U Standard IEEE 802.11b/g/n Bus Interface USB 2.0 Form Factor 53.8mm x 20mm x 5mm Weight 4.2g Data Rate 802.11b: CCK, DQPSK, DBPSK 802.11g: 64QAM, 16 QAM, QPSK, BPSK 802.11n: BPSK, QPSK, 16QAM, 64QAM Frequency Range 2.400 ~ 2.4835 GHz Transmit Output Power 11b: 15 +/- 1.5dBm 11g: 15 +/- 1.5dBm 11n: 15 +/- 1.5dBm Receive Sensitivity 11b @ 11Mbps -85dBm (PER<8%) 11g @ 54Mbps -69dBm (PER<10%) 11n @ MCS7 -67dBm (PER<10%) Temperature & Humidity Normal Test Condition: 25 +/- 2deg.C , 65 +/- 2% RH Operating: -10 to 45 deg.C (2x2 mode), -10 to 60 deg.C (1x2 mode) Storage: -40 to 85 deg.C Operating Voltage 3.3V ±10% I/O supply voltage Antenna Type Printed Antenna PWB WN4636R Page 3/8 2014/8/26 REGULATORY STATEMENTS FCC Certification The United States Federal Communication Commission (FCC) and the Canadian Department of Communications have established certain rules governing the use of electronic equipment. Part15, Class B This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WN4636R Page 4/8 2014/8/26 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. For product available in the USA market, only channel 1~11 can be operated. Selection of other channels is not possible. IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment authorizations (e.g. Verification , Doc) of the host device to be addressed by the integrator/manufacturer. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. Antenna General Information No. Ant. Cat. Ant. Type Model name Gain (dBi) 1 Integral PIFA WN4636R 0.16 2 Integral PIFA WN4636R 0.82 Note: The EUT Supported CCD Funection USERS MANUAL OF THE END PRODUCT: In the user manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to WN4636R Page 5/8 2014/8/26 operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the user manual: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: PPQ-WN4636R ". This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est auto…
Text truncated - open the document above for the full version.
Date: August 5, 2014 Subject: Ad Hoc Mode Function Declaration FCC ID: PPQ-WN4636R IC: 4491A-WN4636R To Whom it may concern, We, LITE-ON Technology Corp., declare that the device (FCC ID: PPQ-WN4636R /IC: 4491A-WN4636R ) 1. is acting as slave and operating on 2.4GHz band. 2. Ad Hoc function is available. 3. is not able to operate in non-US/IC frequencies, country code selection will be disable for this device. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Applicant : LITE-ON Technology Corp. Address : 4F, 90, Chien 1 Road, Chung Ho, Taipei Hsien, 235 Taiwan Signature : _________________________________ Name and Job Title. : TC Wu / Deputy Director(R & D Division) E-mail [email protected] Te l . 86-769-7312821
Confidentiality Request Letter Date: 2014/8/5 Federal Communications Commission Authorization and Evaluation Division FCC ID:PPQ-WN4636R Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : LITE-ON Technology Corp. Applicant’s company address : 4F, 90, Chien 1 Road, Chung Ho, Taipei Hsien, 235 Taiwan Signature : _________________________________ Job Title and Dept. : TC Wu / Deputy Director(R & D Division) E-mail : [email protected] Tel. : 86-769-7312821
Module Approval Request Letter Subject: Module Approval request letter Date: 8/5/2014 FCC ID: PPQ-WN4636R Dear Reviewer, We, LITE-ON Technology Corp., would request WLAN Module approved under module approval authorization. The requirements regulated in 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip (MT7603UN). 3. The requirement of power supply regulation: The part number of the power regulator is (MT7603UN). 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Applicant’s company name : LITE-ON Technology Corp. Applicant’s company address : 4F, 90, Chien 1 Road, Chung Ho, Taipei Hsien, 235 Taiwan Signature : _________________________________ Job Title and Dept. : TC Wu / Deputy Director(R & D Division) E-mail : [email protected] Tel. : 86-769-7312821
Date: 2014/8/5 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: PPQ-WN4636R Product name: WLAN Module To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model WN4636R to the FCC Rules and Regulations. Sporton International Inc. Address : No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Name : Wayne Hsu Job Title : Vice Manager e-mail : [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : LITE-ON Technology Corp. Address : 4F, 90, Chien 1 Road, Chung Ho, Taipei Hsien, 235 Taiwan Signature : _________________________________ Name and Job Title. : TC Wu / Deputy Director(R & D Division) E-mail : [email protected] Tel. : 86-769-7312821
FCC Test Report Report No. : EP471034 SPORTON International Inc. PAGE NUMBER : B1 OF B4 TEL : 886-3-327-3456 ISSUED DATE : Aug. 20, 2014 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT
4. Appearance, Marking 4.1 Appearance Top Bottom 4.2 Label Items Content Description Model Name WN4636R Taiwan NCC xxxxxxxxxxxx NCC Marking required Applicant Name Lite-On Technology Corp. Lite-On Country Origin MADE IN CHINA Made In China Sony P/N 1-458-842-11 BD address XXXXXXXXXXXX Address and QR code Serial Number YYMMDDLLSSSSHH Number and QR code
FCC Test Report Report No. : EP471034 SPORTON International Inc. PAGE NUMBER : B1 OF B4 TEL : 886-3-327-3456 ISSUED DATE : Aug. 20, 2014 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC Test Report Report No. : EP471034 SPORTON International Inc. PAGE NUMBER : B2 OF B4 TEL : 886-3-327-3456 ISSUED DATE : Aug. 20, 2014 FAX : 886-3-327-0973 FCC Test Report Report No. : EP471034 SPORTON International Inc. PAGE NUMBER : B4 OF B4 TEL : 886-3-327-3456 ISSUED DATE : Aug. 20, 2014 FAX : 886-3-327-0973
RF Exposure Report Report No. : FA471034 SPORTON INTERNATIONAL INC. Page No. : 1 of 4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Maximum Permissible Exposure 1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1,842 / f 4.89 / f (900 / f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1,500 F/300 6 1,500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1,500 F/1500 30 1,500-100,000 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 RF Exposure Report Report No. : FA471034 SPORTON INTERNATIONAL INC. Page No. : 2 of 4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1,500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1,500-15,000 137 0.364 50 6 15,000-150,000 137 0.364 50 616000/ƒ 1.2 150,000-300,000 0.354 ƒ 0.5 9.4 x 10 -4 ƒ 0.5 3.33 x 10 -4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1,500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1,500-15,000 61.4 0.163 10 6 15,000-150,000 61.4 0.163 10 616000/ƒ 1.2 150,000-300,000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 RF Exposure Report Report No. : FA471034 SPORTON INTERNATIONAL INC. Page No. : 3 of 4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1,842 / f 4.89 / f (900 / f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1,500 F/300 6 1,500-100,000 5.0 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 30 3-30 1,842 / f 4.89 / f (180/f 2 )* 30 30-300 27.5 0.073 1.0 30 300-1,500 F/1500 30 1,500-100,000 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see NCC LP0002 Section 5.20.2 1.1.1 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30 RF Exposure Report Report No. : FA471034 SPORTON INTERNATIONAL INC. Page No. : 4 of 4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.2 Result of Maximum Permissible Exposure RF General Information Frequency Range (MHz) IEEE Std. 802.11 Protocol Ch. Frequency (MHz) Channel Number Number of Transmit Chains (N TX ) RF Output Power (dBm) 2400-2483.5 b 2412-2462 1-11 [11] 2 20.01 2400-2483.5 g 2412-2462 1-11 [11] 2 24.93 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 2 24.89 Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Condition RF Output Power (dBm) Modulation Mode Chain- Port 1 Chain- Port 2 Chain- Port 3 Chain- Port 4 Sum Chain DG (dBi) EIRP Power PD (S) (mW/cm²) 11b 16.80 17.19 - - 20.01 0.50 20.51 0.02238 11g 21.71 22.11 - - 24.93 0.50 25.43 0.06944 HT-20 21.60 22.14 - - 24.89 0.50 25.39 0.06886 Maximum Permissible Exposure Limit (mW/cm²) 1
FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : 2 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Support Equipment ................................................................................................................................. 7 1.3 Testing Applied Standards ..................................................................................................................... 7 1.4 Testing Location Information .................................................................................................................. 7 1.5 Measurement Uncertainty ...................................................................................................................... 8 2 TEST CONFIGURATION OF EUT ........................................................................................................ 9 2.1 The Worst Case Modulation Configuration ............................................................................................ 9 2.2 The Worst Case Power Setting Parameter ............................................................................................ 9 2.3 The Worst Case Measurement Configuration ...................................................................................... 10 2.4 Test Setup Diagram ............................................................................................................................. 11 3 TRANSMITTER TEST RESULT .......................................................................................................... 13 3.1 AC Power-line Conducted Emissions .................................................................................................. 13 3.2 6dB Bandwidth ..................................................................................................................................... 16 3.3 RF Output Power .................................................................................................................................. 18 3.4 Power Spectral Density ........................................................................................................................ 23 3.5 Transmitter Bandedge Emissions ........................................................................................................ 25 3.6 Transmitter Unwanted Emissions......................................................................................................... 28 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 51 APPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : 3 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]: 0.1548450MHz 51.48 (Margin 14.26dB)-QP 30.86 (Margin 24.88dB)-AV FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth Unit [MHz] 20M: 7.96 ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm]: 29.86 Power [dBm]:30 Complied 3.4 15.247(d) Power Spectral Density PSD [dBm/100kHz]: -4.03 PSD [dBm/3kHz]:8 Complied 3.5 15.247(c) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 2399.50MHz: 26.02dB Restricted Bands [dBuV/m at 3m]: 2389.74MHz 71.38 (Margin 2.62dB) - PK 53.85 (Margin 0.15dB) - AV Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied 3.6 15.247(c) Transmitter Radiated Unwanted Emissions [dBuV/m at 3m]: 4924.00MHz 53.85 (Margin 0.15dB) – AV 57.50 (Margin 16.50dB) - PK Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : 4 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR471034 Rev. 01 Initial issue of report Aug. 20, 2014 2500-2690 FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : 5 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) RF Output Power (dBm) 2400-2483.5 b 2412-2462 1-11 [11] 2 22.94 2400-2483.5 g 2412-2462 1-11 [11] 2 29.81 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 2 29.86 Note 1: RF output power specifies that Maximum Peak Conducted Output Power. Note 2: 802.11b uses a combination of DSSS-DBPSK, DQPSK, CCK modulation. Note 3: 802.11g/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM modulation. 1.1.2 Antenna Information Antenna Category Integral antenna (antenna permanently attached) Temporary RF connector provided No temporary RF connector provided Transmit chains bypass antenna and soldered temporary RF connector provided for connected measurement. In case of conducted measurements the transmitter shall be connected to the measuring equipment via a suitable attenuator and correct for all losses in the RF path. Antenna General Information No. Ant. Cat. Ant. Type Model name Gain (dBi) 1 Integral PIFA WN4636R 0.16 2 Integral PIFA WN4636R 0.82 Note: The EUT supported CDD function. FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : 6 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.3 Type of EUT Identify EUT EUT Seria…
Text truncated - open the document above for the full version.
FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A1 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Appendix A. Test Photos FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A2 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A3 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 SIDE VIEW FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A4 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A5 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A6 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions above 1GHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR471034 SPORTON INTERNATIONAL INC. Page No. : A7 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 EUT take a close-up
